Technogym BIOCIRCUIT User manual

BIOCIRCUIT - BIOCIRCUIT
FREE
Pre-Installation Requirements
Rev: 6.0
Date: 17-09-2021
Document Code: PIR-00063-EN

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 3 -PIR-00063-EN- Uncontrolled copy if printed
Table of Contents
1. GENERAL WARNINGS ........................................................................................7
2. NETWORK DESIGN – CONFIGURATION AND INSTALLATION........................9
2.1 INTRODUCTION ...........................................................................................................9
2.2 NETWORK DESIGN AND INSTALLATION ...................................................................9
2.3 CONFIGURATION AND INSTALLATION ......................................................................9
3. DISPLAY............................................................................................................. 11
3.1 BIOSTRENGTH LINE................................................................................................ 11
3.1.1 UNITY MINI............................................................................................................ 11
3.1.2 10” DISPLAY .......................................................................................................... 11
3.2 CARDIO MACHINES (NOT AVAILABLE FOR BIOCIRCUIT FREE) AND UNITY
SELF (NOT NECESSARY FOR BIOCIRCUIT FREE*) ...........................................12
3.2.1 DISPLAY UNITY ....................................................................................................12
4. TECHNICAL INFO AND REQUIREMENTS ....................................................13
4.1 TECHNICAL DATA AND POWER REQUIREMENTS..................................................13
4.2 RECOMMENDATION: RCD SWITCH TYPE F............................................................15
4.3 ELECTRICAL CONNECTION......................................................................................15
4.4 POSITION OF THE PRODUCT SOCKET ...................................................................16
5. BIOCIRCUIT - BIOCIRCUIT FREE NETWORK REQUIREMENTS..............21
5.1 BIOCIRCUIT NETWORK CONFIGURATION: FORBIDDEN MIXED CONFIGURA-
TIONS .........................................................................................................................21
5.2 BIOCIRCUIT NETWORK ARCHITECTURE ............................................................21
5.2.1 CORRECT WIRED NETWORK ARCHITECTURE (STRONGLY RECOMMEND-
ED)..........................................................................................................................21
5.2.2 CORRECT WIRELESS NETWORK ARCHITECTURE ......................................22
5.2.3 CORRECT COMPLEX NETWORK ARCHITECTURE (MANDATORY) ............22
5.2.4 FORBIDDEN NETWORK ARCHITECTURE THAT CAUSES LOCAL NETWORK
LATENCY (EXAMPLE 1).......................................................................................23
5.2.5 FORBIDDEN NETWORK ARCHITECTURE THAT CAUSES LOCAL NETWORK
LATENCY (EXAMPLE 2).......................................................................................24
5.3 ROUTER WITH 4G FAILOVER IN CASE OF UNSTABLE INTERNET CONNEC-
TION............................................................................................................................24
5.4 BIOCIRCUIT - BIOCIRCUIT FREE: NETWORK REQUIREMENTS......................25
5.4.1 ETHERNET CABLED NETWORK (RECOMMENDED)......................................25
5.4.2 WI-FI NETWORK...................................................................................................25
5.4.3 FIREWALL / ROUTER RULES FOR MYWELLNESS CLOUD...........................26

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 4 - PIR-00063-EN- Uncontrolled copy if printed
5.4.4 PROXY ...................................................................................................................27
5.4.5 NETWORK BANDWIDTH REQUIREMENTS......................................................27
5.5 SPECIFIC REQUIREMENTS FOR UNITY SELF OF BIOCIRCUIT.......................28
6. ACKNOWLEDGEMENT AND ACCEPTANCE ...................................................29
7. LIST OF CHANGES FOR MANUAL VERSION..............................................31
7.1 REVISION 1.0.............................................................................................................31
7.2 REVISION 2.0.............................................................................................................31
7.3 REVISION 3.0.............................................................................................................31
7.4 REVISION 4.0.............................................................................................................31
7.5 REVISION 5.0.............................................................................................................32
7.6 REVISION 6.0.............................................................................................................32

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 5 -PIR-00063-EN- Uncontrolled copy if printed
This document contains proprietary information that is covered by copyright. All rights re-
served. No part of this document may be circulated, copied, reproduced or translated into
another language without the prior written consent of Technogym.
Additional information may be included in the After Sales technical documents, available
in the Technogym ServicePortal.
Theinformationcontainedinthisdocumentmaybechangedwithoutpriornotification.For
updates, please refer to the Technogym Service Portal.
Technogym® is a trademark owned by Technogym S.p.A.
Document uncontrolled when printed.

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 6 - PIR-00063-EN- Uncontrolled copy if printed
Blank page

1. GENERAL WARNINGS


          


 

CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may re-
sult in minor or moderate injury. It may also be used to alert against unsafe practices.

 

Detail regarding the operation in progress.
BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 7 -PIR-00063-EN- Uncontrolled copy if printed

Blank page
BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 8 - PIR-00063-EN- Uncontrolled copy if printed

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 9 -PIR-00063-EN- Uncontrolled copy if printed
2. NETWORK DESIGN – CONFIGURATION AND
INSTALLATION
2.1 INTRODUCTION
▪

▪󰀩-
wellness Cloud services depend on the technical characteristics of the hardware that is in-
stalled.
▪

2.2 NETWORK DESIGN AND INSTALLATION

-
-
ments.
-
tion not correct.
2.3 CONFIGURATION AND INSTALLATION
            

-


provided and operational.

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 10 - PIR-00063-EN- Uncontrolled copy if printed
Blank page

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 11 -PIR-00063-EN- Uncontrolled copy if printed
3. DISPLAY
3.1 BIOSTRENGTH LINE
3.1.1 UNITY MINI

Fig. 1
3.1.2 10” DISPLAY

Fig. 2

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 12 - PIR-00063-EN- Uncontrolled copy if printed
3.2 CARDIO MACHINES (NOT AVAILABLE FOR
BIOCIRCUIT FREE) AND UNITY SELF (NOT
NECESSARY FOR BIOCIRCUIT FREE*)
*:AUnitySelfisNOTmandatoryforaBiocircuitFreeformat,butitisstronglyrecommendedto
have at least 1 per location to let end users manage their prescribed workouts.
3.2.1 DISPLAY UNITY

Fig. 3 - Run machine
Fig. 4 - Unity Self (Not necessary for Biocircuit Free)

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 13 -PIR-00063-EN- Uncontrolled copy if printed
4. TECHNICAL INFO AND REQUIREMENTS
4.1 TECHNICAL DATA AND POWER REQUIREMENTS
POWER SUPPLY
BIOSTRENGTH LINE
BIKE ARTIS
NEW SYNCHRO ARTIS
UNITY SELF

RUN ARTIS 

Tab. 1
MAXIMUM ABSORPTION VALUES

 
BIOSTRENGTH LINE

12A* 6A
LEG PRESS 20A* 10A
BIKE ARTIS 2.8A 1.6A
NEW SYNCHRO 2.5 A 1.5 A
Tab. 2
MAXIMUM ABSORPTION VALUES


   

   
RUN ARTIS - 10A 20A 16A
Tab. 3
(*): The values are theoretical.

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 14 - PIR-00063-EN- Uncontrolled copy if printed
USEFUL GUIDELINES FOR CIRCUIT BREAKERS
BIOSTRENGTH LINE

     


each 2 equipment of Biostrength Line
LEG PRESS      


each LEG PRESS
Tab. 4
BIOSTRENGTH LINE - TECHNICAL CHARACTERISTICS
Motor peak power 2kW
6kW in Leg Press
Noise Level Less than 70 dB
Protection rating IP 20
Tab. 5
BIKE ARTIS - TECHNICAL CHARACTERISTICS
Mains power input 
Braking Power (70 rpm) 40÷500 W ±10%
Protection rating IP 20
Tab. 6
SYNCHRO ARTIS - TECHNICAL CHARACTERISTICS
Mains power input 
Braking Power (90 spm) 30÷310 W ±10%
Time 0÷999min ±1%
Distance 0÷99.99km ±5% (0÷99.99mls ±5%)
Protection rating IP 20
Tab. 7

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 15 -PIR-00063-EN- Uncontrolled copy if printed
RUN ARTIS - TECHNICAL CHARACTERISTICS




Peak motor power 5800W (7.8Hp) 5800W (7.8Hp)
     -
mum power input
-0.8-25Km/h (0.5-15.5
mph) 1600VA
     -
mum power input
-0.8-25Km/h (0.5-15.5
mph) 2000VA
-

0.8-25Km/h (0.5-15.5 mph)
2200VA
0.8-25Km/h (0.5-15.5
mph) 2200VA
Gradient 0-15% 0-15%
Noise Level Less than 70 dB Less than 70 dB
Protection rating IP 20 IP 20
Tab. 8 - Run Artis - Technical Characteristics
4.2 

strength machine.
4.3 ELECTRICAL CONNECTION
-
            
󰀩


-

-
cordance with all local codes and ordinances.









BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 16 - PIR-00063-EN- Uncontrolled copy if printed
4.4 POSITION OF THE PRODUCT SOCKET


Fig. 5 - Example picture


Fig. 6

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 17 -PIR-00063-EN- Uncontrolled copy if printed
Fig. 7
Fig. 8 - Bike

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 18 - PIR-00063-EN- Uncontrolled copy if printed
Fig. 9 - Synchro
Fig. 10

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 19 -PIR-00063-EN- Uncontrolled copy if printed
Fig. 11 - Unity Self

BIOCIRCUIT - BIOCIRCUIT FREE Pre-Installation Requirements
Rev. 6.0
- 20 - PIR-00063-EN- Uncontrolled copy if printed
Blank Page
