TESTO Smart Probes 510i Installation manual
1 Safety
6
All Smart Probes only work in combination with a mobile
terminal and the testo Smart Probes App
1Safety
1.1. Safety with testo 510i
WARNING
Magnetic field
May be harmful to those with pacemakers.
>Keep a minimum distance of 10 cm between pacemaker and
instrument.
1.2. Safety with testo 549i
WARNING
Risk of injury caused by pressurized, hot, cold or toxic refrigerants/media!
>Only to be used by qualified staff.
>Wear protective goggles and safety gloves.
>Before applying pressure to the measuring instrument: always fix the
instrument tightly onto the pressure connection.
>Comply with the permissible measuring range (0 to 60 bar). Pay
particular attention to this in systems with R744 refrigerant, since
these are frequently operated with higher pressures!
1.3. Safety with testo 805i
CAUTION
Laser radiation! Class 2 laser
>Do not look into the laser beam!
1.4. testo 405i
Do not touch the sensor, keep the sensor clean. Close
protective cap after use!
1.5. testo 605i
Not for condensing atmospheres. For continuous application in
high humidity (> 80 %RH at ≤30 °C for > 12 h, > 60 %RH at >
30 °C for > 12 h), contact us
The sensor must not be exposed to volatile chemicals such as
solvents (e.g. ketene, ethanol, isopropyl alcohol, toluene) or
organic compounds, especially in high concentrations and
corresponding gases, over a prolonged period of time.
2 Overview
7
2Overview
1
Measuring unit
3
Key
2
LED
4
Battery compartment (at the
back)
3Switching on/off
3.1. Switching on
Testo 549i
1. Pull the film out of the battery compartment.
2. Press the key.
- The Smart Probes switch on.
3.2. Switching off
1. Press and hold the key.
- The Smart Probes switch off.
4 Bluetooth® module
8
4Bluetooth®module
Establishing Bluetooth®connection
You need a Tablet or Smartphone with the Testo Smart Probes
App already installed on it to be able to establish a Bluetooth
connection.
You can get the App for iOS instruments in the App Store or for
Android instruments in the Play Store.
Compatibility:
• requires iOS 8.3 or later / Android 4.3 or later
• requires Bluetooth 4.0
Bluetooth®approval
The use of the wireless module is subject to the regulations and
stipulations of the respective country of use, and the module may
only be used in countries for which a country certification has
been granted. The user and every owner has the obligation to
adhere to these regulations and prerequisites for use, and
acknowledges that the re-sale, export, import etc. in particular in
countries without wireless permits, is his responsibility.
5LED status
LED status Meaning
Flashing red Low battery status
Flashing yellow
• Smart Probe is switched on.
• Smart Probe searching, but not yet connected.
Flashing green
• Smart Probe is switched on.
• Bluetooth is connected.
6Transmitting reading
✓The Smart Probes are switched on and connected to their mobile
terminal via Bluetooth.
1. The Smart Probes' readings are automatically shown in the standard
display.
2. Press the key.
- The reading that is currently present is held.
3. Press the key again.
- The instrument again displays the current readings.
These commissioning instructions describe the basic operating
steps.
To find outhow to handle the product safely and for detailed
information, please refer to the instruction manual
0 Approval and Certification
31
Approval and Certification
Product
testo 115i, testo 405i, testo 410i, testo 510i, testo 549i,
testo 605i, testo 805i, testo 905i
Mat.-No.
0560 1115, 0560 1405, 0560 1410, 0560 1510, 0560 1549,
0560 1605, 0560 1805, 0560 1905
Country
Comments
Australia
E 1561
Brazil
“Este equipamento opera em caráter secundário, isto é, não
tem direito a proteção contra interferência prejudicial, mesmo
de estações do mesmo tipo, e não pode causar interferência a
sistemas operando em caráter primário. ”
Canada
Product IC ID:
testo 115i IC ID: 12231A-1115
testo 405i IC ID: 12231A-1405
testo 410i IC ID: 12231A-1410
testo 510i IC ID: 12231A-1510
testo 549i IC ID: 12231A-1549
testo 605i IC ID: 12231A-1605
testo 805i IC ID: 12231A-1805
testo 905i IC ID: 12231A-1905
0 Approval and Certification
32
see IC Warnings
China
CMII ID:
testo 115i CMIIT ID: 2015DP6557
testo 405i CMIIT ID: 2015DP6558
testo 410i CMIIT ID: 2015DP6612
testo 510i CMIIT ID: 2015DP6559
testo 549i CMIIT ID: 2015DP6560
testo 605i CMIIT ID: 2015DP6561
testo 805i CMIIT ID: 2015DP6562
testo 905i CMIIT ID: 2015DP6563
Europa
+ EFTA
The EU Declaration of Conformity can be found
on the testo homepage www.testo.com under the
product specific downloads.
EU countries:
Belgium (BE), Bulgaria (BG), Denmark (DK), Germany (DE),
Estonia (EE), Finland (FI), France (FR), Greece (GR), Ireland
(IE), Italy (IT), Latvia (LV), Lithuania (LT), Luxembourg (LU),
Malta (MT), Netherlands (NL), Austria (AT), Poland (PL),
Portugal (PT), Romania (RO), Sweden (SE), Slovakia (SK),
Slovenia (SI), Spain (ES), Czech Republic (CZ), Hungary
(HU), United Kingdom (GB), Republic of Cyprus (CY).
EFTA countries:
Iceland, Liechtenstein, Norway, Switzerland
Hong-
kong Authorized
Japan
testo 115i
testo 405i
testo 549i
testo 605i
0 Approval and Certification
33
testo 410i
testo 510i
testo 905i
see Japan Information
Korea
testo 115i Certification No. MSIP-CRM-Toi-115i
testo 405i Certification No. MSIP-CRM-Toi-405i
testo 410i Certification No. MSIP-CRM-Toi-410i
testo 510i Certification No. MSIP-CRM-Toi-510i
testo 549i Certification No. MSIP-CRM-Toi-549i
testo 605i Certification No. MSIP-CRM-Toi-605i
testo 805i Certification No. MSIP-CRM-Toi-805i
testo 905i Certification No. MSIP-CRM-Toi-905i
see KCC Warning
Taiwan
testo 115i NCC: CCAB16LP177FT0
testo 405i NCC: CCAB16LP177AT3
testo 410i NCC: CCAB16LP1770T1
testo 510i NCC: CCAB16LP177DT9
testo 549i NCC: CCAB16LP177ET1
testo 605i NCC: CCAB16LP177BT5
testo 805i NCC: CCAB16LP177CT7
testo 905i NCC: CCAB16LP177GT2
0 Approval and Certification
34
Turkey
Authorized
USA
Product FCC ID:
testo 115i FCC ID: 2ACVD-1115
testo 405i FCC ID: 2ACVD-1405
testo 410i FCC ID: 2ACVD-1410
testo 510i FCC ID: 2ACVD-1510
testo 549i FCC ID: 2ACVD-1549
testo 605i FCC ID: 2ACVD-1605
testo 805i FCC ID: 2ACVD-1805
testo 905i FCC ID: 2ACVD-1905
see FCC Warnings
Russia
Authorized
Philip-
pines
Authorized
South
Africa
testo 115i TA-2016/1207
testo 405i TA-2016/1201
testo 410i TA-2016/1200
testo 510i TA-2016/1199
testo 549i TA-2016/1198
testo 605i TA-2016/1204
testo 805i TA-2016/1206
testo 905i TA-2016/1205
Blue-
tooth®
SIG List
Bluetooth®
Range 15 m (free field)
(varies with the used mobile
device)
Bluetooth® type
L Series BLE Module (08
Mai 2013) based on TI
0 Approval and Certification
35
CC254X chip
Qualified Design ID
B016552
Bluetooth® radio class
Class 3
Bluetooth® company ID
LSD Science & Technology
Co., Ltd
RF Band
2402-2480MHz
Output power
O dBm
IC Warnings
This instrument complies with Part 15C of the FCC Rules and Industry
Canada RSS-210 (revision 8). Commissioning is subject to the following
two conditions:
(1) This instrument must not cause any harmful interference and
(2) this instrument must be able to cope with interference, even if
this has undesirable effects on operation.
Cet appareil satisfait à la partie 15C des directives FCC et au standard
Industrie Canada RSS-210 (révision 8). Sa mise en service est soumise
aux deux conditions suivantes :
(1) cet appareil ne doit causer aucune interférence dangereuse et
(2) cet appareil doit supporter toute interférence, y compris des
interférences qui provoquerait des opérations indésirables.
FCC Warnings
Information from the FCC (Federal Communications Commission)
For your own safety
Shielded cables should be used for a composite interface. This is to ensure
continued protection against radio frequency interference.
FCC warning statement
This equipment has been tested and found to comply with the limits for a
Class C digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
0 Approval and Certification
36
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
Shielded interface cable must be used in order to comply with the emission
limits.
Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
KCC Warning
해당 무선 설비는 운용 중전파혼신 가능성이 있음
Japan Information
当該機器には電波法に基づく、技術基準適合証明等を受けた特定無線設備
を装着している。
