Fine pressure probe
www. .com [e-mail]1.800.561.8187

General notes
Please read this documentation through carefully and familiarize yourself with the oper-
ation of the product before putting it to use. Keep this document to hand so that you
can refer to it when necessary.
Identification
Icon Significance Comments
Important. Please pay particular attention.
Text Text appears on the instrument display -
Key Press the key.
Function key with the function “OK”. Press function key..
xyz Short form for operating steps.
2
OK
www. .com [e-mail]1.800.561.8187

Contents
General notes ................................................................................................ 2
Contents ........................................................................................................ 3
A. Safety instructions ................................................................................ 4
B. Intended purpose .................................................................................. 5
C Product description .............................................................................. 6
C.1 Overview ....................................................................................... 6
C.2 Use hanger bracket ....................................................................... 7
D. Measurements....................................................................................... 8
D.1. Measurement with flue gas analyzers 0632 3301 - 3305 ............... 8
D.1.1 E-Draught................................................................................... 8
D.1.2 E-Delta-P ................................................................................... 9
D.2. Measurement with flue gas analyzers 0632 3306 - 3307 ............. 10
D.2.1 E-Draught................................................................................. 10
D.2.2 E-Delta-P Single measurement................................................. 10
D.2.3 E-Delta-P Program ................................................................... 11
E. Technical data ..................................................................................... 12
F. Accessories/spare parts ..................................................................... 13
3
www. .com [e-mail]1.800.561.8187

A. Safety instructions
Avoid electrical hazards:
Never use the measuring instrument and fine pressure probe to measure on or near
live parts!
Protect the fine pressure probe:
Never store the measuring instrument/measuring cells together with solvents
(e.g. acetone). Do not use any desiccants.
Product safety/preserving warranty claims:
Operate the fine pressure probe only within the parameters specified in the technical
data.
Handle the fine pressure probe properly and according to its intended purpose only.
Never apply force!
Temperatures given on probes/sensors relate only to the measuring range of the
sensors. Do not expose handles and feed lines to any temperatures in excess of
70 °C unless they are expressly permitted for higher temperatures.
Open the measuring instrument only when this is expressly described in the
instruction manual for maintenance purposes.
Carry out only the maintenance and repair work that is described in the Operating
Instructions. Follow the prescribed steps exactly. For safety reasons, use only original
spare parts from Testo.
Any additional work must only be carried out by authorized personnel. Testo will
otherwise refuse to accept responsibility for the proper functioning of the measuring
instrument after repair and for the validity of certifications.
Ensure correct disposal:
Dispose of defective rechargeable batteries and spent batteries at the provided
collection points.
Send the measuring instrument directly to us at the end of its useful life. We will
ensure that it is disposed of in an environmentally friendly manner.
4
www. .com [e-mail]1.800.561.8187

B. Intended purpose
This chapter describes the areas of application for which the fine pressure probe is
intended.
The fine pressure probe can be used for the following measurements in conjunction with
the testo 330 (0632 3301 - 3305 from firmware version 1.40 and 0632 3306 - 3307
from firmware 1.09):
- Measurement of the flue draught for atmospheric gas burners
- Checking the vacuum in a closed room with simultaneous operation of fireplace and
exhaust air equipment
- Measurement of vacuums in equipment rooms for fireplaces
- Parallel Delta-P measurement
The testo Easyheat software (as of software version 2.40) is required for the evaluation
of measurement data.
Under www.testo.com/download-center you can download the current instrument soft-
ware (Firmware) for the testo 330 (registration required).
5
www. .com [e-mail]1.800.561.8187

C Product description
This chapter provides an overview of the individual components of the product.
C.1 Overview
1 Surface probe connection
2Measuring instrument connecting cable
3Capillary hose/pressure tube
connection
4Hanger bracket
- for hanging on pipes of at least 15 mm
up to max. 40 mm diameter
- for hanging on (plate) edges up to
a thickness of 4 mm
Do not move the brackets sideways
towards the outside. To open, move
the brackets forwards and backwards.
5Magnetic holder (on rear)
WARNING! Magnetic field!
May be harmful to those with pacemakers.
>Keep a minimum distance of 15 cm between pacemaker and instrument..
ATTENTION! Magnetic field!
Damage to other devices
>Keep a safe distance away from products which could be damaged by the
effects of magnetism (e.g. monitors, computers or credit cards).
6
www. .com [e-mail]1.800.561.8187

C.2 Use hanger bracket
Detach hanger bracket from the rear side of thehousing and
fold upwards
To pry open the connecting joint at the opening, carefully
and repeatedly move the hanger brackets in opposite direc-
tions.
To open, move the brackets forwards and backwards.
Do not move the hanger brackets sideways towards the
outside.
7
www. .com [e-mail]1.800.561.8187

D. Measurements
A leak test cannot be performed with the fine pressure probe.
D.1. Measurement with flue gas analy-
zers 0632 3301 - 3305
D.1.1 E-Draught
Connect Pitot tube at input +.
A simultaneous E-Draught and flue gas measurement can be performed if:
- the parameter is included in the display sequence.
- no measurement was performed beforehand in the E-Delta-P menu.
Calling up the function:
- Measurements - OK - Finepress. probe - OK .
Performing the measurement:
1 E-Draught - OK
- Measurement begins.
2 Stop measuring: Stop .
- The reading is recorded.
Option:
To print the reading: Print .
3 Copy the reading to the Draught menu: OK .
- The
Measurements menu is opened.
D.1.2 E-Delta-P
The menu is only available if the fine pressure probe is connected to the instrument.
A simultaneous E-Delta P and flue gas measurement can be performed if:
- the parameter is included in the display sequence.
- no measurement was performed beforehand in the E-Delta-P menu.
8
www. .com [e-mail]1.800.561.8187

Calling up the function:
- Measurements - OK - Finepress. probe - OK - E-Delta-P - OK
D.1.2.1 Individual measurement:
Performing the measurement:
1 single - OK
2 Start measuring: Start
3 Stop measuring: Stop
- The reading determined from E-Delta-P is recorded and copied into the Flue gas
menu, where it is displayed (if selected in the Display sequence menu).
D.1.2.2 Logger
Performing the measurement:
1 Logger - OK
2 Enter the measurement period: Measurement period - Change - enter value
(max. 1440 min)
3 Enter rate:
Rate - Change - enter value (default value 1 sec)
The measuring rate must not be greater than the measurement period
4 Start measuring: Start
- The residual time and the current reading are shown.
Options:
Print readings: Print .
A printout of all readings is only possible in the “Memory/location” menu
(
Memory/location -
OK - Data - Print all)
Display readings graphically: Graph .
From the graphic display back to the reading display: Values
5 Stop measuring: Stop .
- The determined reading from E-Delta-P is displayed.
The logger program is always saved, even if it has not run through completely.
9
www. .com [e-mail]1.800.561.8187

D.2. Measurement with flue gas analy-
zers 0632 3306 - 3307
D.2.1 E-Draught
Connect Pitot tube at input +.
A simultaneous E-Draught and flue gas measurement can be performed if the para-
meter is included in the display sequence.
Calling up the function:
- Measurements - OK - Finepress. probe -
OK - E-Draught - OK
Carry out measurement:
1 Start measuring:
2 Stop measuring:
Options:
Options -Clipboard: Data are saved in the clipboard.
Options -Save: The measurement values are saved in a report
Options -Show Graphic: The measurement values are saved in a line diagram
3 Exit function:
D.2.2 E-Delta-P Single measurement
A simultaneous E-Delta-P Single measurement and flue gas measurement can be
performed if the parameter is included in the display sequence.
Calling up the function:
- Measurements - OK - Finepress. probe -
OK - E-Delta-P Single meas. - OK
Carry out measurement:
1 Start measuring:
2 Stop measuring:
10
www. .com [e-mail]1.800.561.8187

Options::
Options -
Clipboard: Data are saved in the clipboard.
Options -
Save: The measurement values are saved in a report
Options -
Show Graphic: The measurement values are saved in a line diagram
Options -Perform measurement program: The selected measurement program can be
started
3 Exit function:
D.2.3 E-Delta-P Program
Calling up the function:
- Measurements - OK - Finepress. probe -
OK - E-Delta-P Program - OK
Carry out measurement
1 Start measuring:
- Measurement is automatically ended after the end of the measurement duration
Options -
Show Graphic: The measurement values are displayed in a line diagram
Optionen -
Change Program: The measurement duration and measurement rate can
be changed in the selected measurement program
2 Exit function:
11
www. .com [e-mail]1.800.561.8187

E. Technical data
Characteristic Values
Parameter Differential pressure via internal sensor
Temperature via external thermocouple Typ K (accessory)
Calculated variables Flow Display range: 0.15 to 3 m/s
Resolution: 0.1 m/s
Differential pressure Measuring range -9999.9 Pa to 9999.9 Pa
measurement Resolution 0.01 Pa (-149.99 Pa to 149.99 Pa)
0.1 Pa (rest of measuring range)
Accuracy ±0.3 Pa (0 to 9.99 Pa)
±3% of reading (10.00 to 9999.9 Pa)
additionally ±1 digit
Measuring rate max. 1/s
Zero point drift none (cyclical zeroing)
Temperature measurement Measuring range Depends on probe, max. -40 °C to +1200 °C
Resolution 0.1 °C
Accuracy ±0.5 °C (-40 to 100 °C)
± 0.5% of reading (rest of measuring range)
additionally ±1 digit, additionally accuracy of probe
Measuring rate max. 1/s
Temperature measurement Measuring range -200 to 300 °C
with surface probe 0604 0994 Resolution 0.1 °C
(accessory)
Operating temperature 5 to 45 °C
Storage/transport temperature -20 to 50 °C
Humidity 10 to 90% RH non-dewing
Protection class IP 40
Warranty 2 years
12
www. .com [e-mail]1.800.561.8187

F. Accessories/spare parts
Designation Article no.
Fine pressure probe 0638 0330
Flue draught set 0554 3150
Capillary hose set 0554 1215
Update CD (firmware update for testo 330) 0554 3351
testo 330-1 LL 0632 3304
testo 330-2 LL 0632 3305
Basic retrofit kit 0563 3344
Professional retrofit kit 0563 3345
