TOORX TRX 40 S EVO User manual

Ed : 03/17 Rev : 00
INSTRUCTION

CONTENT
CONTENT --------------------------------------------------------------------------------------------------------------------------------1
IMPORTANT SAFETY PRECAUTIONS -------------------------------------------------------------------------------------2
TECHINICAL PARAMETERS---------------------------------------------------------------------------------------------------3
PRODUCT OVERVIE -----------------------------------------------------------------------------------------------------------3
ASSEMBLY INSTRUCTIONS ----------------------------------------------------------------------------------------------------4
FOLDING & UNFOLDING INSTRUCTIONS -------------------------------------------------------------------------------7
GROUNDING METHODS -----------------------------------------------------------------------------------------------------------8
OPERATION GUIDE -------------------------------------------------------------------------------------------------------------------9
GETTING STARTED GUIDE -----------------------------------------------------------------------------------------------------14
ARM-UP EXERCISES ------------------------------------------------------------------------------------------------------------15
SAFETY EXERCISES ---------------------------------------------------------------------------------------------------------------16
MAINTENANCE INSTRUCTIONS ---------------------------------------------------------------------------------------------17
BELT ADJUSTMENT ----------------------------------------------------------------------------------------------------------------18
EXPLODED DRA ING -------------------------------------------------------------------------------------------------------------19
PARTS LIST ------------------------------------------------------------------------------------------------------------------------------20
ERROR CODE AND SIGNIFICANCE----------------------------------------------------------------------------- 21
1

removed. Note the po er cord of motorized treadmill made by special equipment, and if it is broken,
please contact distributor quickly.
15. The treadmill is for home use only.
16. The treadmill maximum user eight is 100kgs
17. Please do not over-use the treadmill so can avoid any injury and do not use incorrect ay for your
safety.
18. When the treadmill is not being used, please keep the safety pull pin in the safety place to avoid the
other use.
Input supply voltage：220V Working temperature: 0-40 ℃
Speed range: 0.8-16KM/H Incline range:12 level Motor incline
Max. user eight: 100kg Distance display range: 0.00-99.9km
Calories display range: 000-999 Time display range: 00 ：00-99 ：59 (min :
sec)
Heart rate range: 50-200 (time / min) Running surface: 420*1300mm
Product size: 1700*710*1380MM
Folding size: 900*710*1510MM
Technical Parameters
Product Overview
Upright
Handrail
Motor cover
End cap
Running belt
Side rail
Side cover
Base frame
Safety key
Main frame val silicone pad
console
3

HEN YOU OPEN THE CARTON, YOU ILL FIND THE BELO SPARE PARTS:
STEP 1: Take out and prepare the belo parts
1 Main frame 1 set D17 Inner star asher M8
8 PCs
D13 Round hex bolt
M8*15 4 PCs
C13 Safety key 1 set
D3 Allen rench 5MM,
1 PC
B18 Silicon oil 1 PC D1Scre driver 1PC D16Round hex bolt
M8*45 4 PCs
B11L Left side cover
1 PC
B11R Right side cover
1 PC
D48 Cross self-tapping
bolt ith asher
ST4.2*19 4 PCs
B12 Rubber cover
2 PCs
Note: Don’t tighten bolts at once.
STEP 2: According to the follo ing steps to lift up the uprights.
Assembly instruction
4

STEP 3: Secure bottom frame ith bolt M8*45（D16）, M8*15 (D13) and inner star asher (D17).
Then assemble the console bracket ith bolt M8*15 (D13) and inner star asher (D17).
Step 4: Tighten the rubber cover (B12) to the left/right side covers (B11L/R) ith cross
self-tapping bolt ith asher ST4.2*19 (D48).
D16
D13
D17
D13
D13 D16
D48
B11L
B11R
B12
5

Step 5: Place on the safety key (C13).
Step 6: To check if the running belt runs correctly, placing treadmill in folding position and
tightening all the bolts. Then set speed under 3km/h and see if running belt runs ithout
problem.
6

Lift up the machine and force to pull up until
you heard "click" that made by safety
casing stuck the pneumatic cylinder.
Folding Instruction
Unfolding instruction
Kick the safety sleeve lightly and pull
do n the machine at the same time
as the arro direction. Then the
machine ill fall do n smoothly.
7

This product must be grounded. If it should malfunction or breakdo n, grounding provides
path of least resistance for electric current to reduce the risk of electric shock. This
product is equipped ith a cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance ith all local codes and ordinances.
DANGER – Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check ith a qualified electrician or serviceman if you are in doubt as to
hether the product is properly grounded. Do not modify the plug provided ith the
product – if it ill not fit the outlet, Please find a proper outlet installed by a qualified
electrician.
. This product is for use on a nominal 240V circuit and has a grounding plug. Make that the
product is connected to an outlet having the same configuration as the plug. No adapter
should be used ith this product.
Grounding Methods
8

1.1. INDO DISPLAY
1.1. Console
1.2. START
Normal start after 5 seconds countdo n
1.3 PROGRAM
3 countdo n functions, 12 sets of programs, 1 body fat program
1.4. SAFETY LOCK FUNCTION
The indo sho s"---" hen take a ay the safety lock and the treadmill ill stop quickly ith "didi"
alarm noise. And put the safety lock on, the computer ill display for 2 seconds and the date count
do n to “0”
1.5.BUTTON FUNCTION
1.1.1. START/STOP
“START”--When the treadmill is not running, press this button to start, speed is “0.8”
“STOP”--When the treadmill is running, press this button to stop, then set program default and then
return to manual mode after stopped.
1.5.2 “PROGRAM” BUTTON
Operation Guide
9

When the treadmill is not running, press this button can choose from program circle mode to manual mode
(P1-P12). The lo est speed for manual mode is “0.8km/h”, and the highest speed is “16km/h”; the lo est
incline is “0”, and the highest is “12”.
1.5.3 “MODE” BUTTON
When the treadmill is not running, press this button to choose countdo n
modes:”H-1”,”H-2”,”H-3”.
H-1” is the time countdo n mode, and “H-2” is the distance countdo n
mode, “H-3” is the calories countdo n mode.
Press the “SPEED+/-” or “INCLINE+/-“button to adjust
the data. After that, press the “START” button to start this treadmill
1.5.4 “SPEED +/- “BUTTON
SPEED +/– --Adjust speed hen treadmill start, the increment is 0.1km/time in kilometer. Press the
button more than 2 seconds, and it ill be up or do n automatically.
1.5.5 “INCLINE+/-” BUTTON
INCLINE +/ – --Adjust incline hen treadmill start; the increment is 1 level/time. Press the button
more than 2 seconds, and it ill be up or do n automatically
1.5.6 SPEED QUICK BUTTON
Press the speed quick button 3km/h, 6km/h, 9m/h, 12km/h to adjust the speed directly hen the treadmill
is running
1.5.7 INCLINE QUICK BUTTON
Press the incline quick button 3,6,9,12 to adjust the incline directly hen the treadmill is running
1.6. DISPLAY FUNCTION
1.6.1 TIME
Display the running time or countdo n time
1.6.2 SPEED
Display running speed
1.6.3 INCLINE
Display the incline
1.6.4 PULSE
Display pulse data
10

1.6.5 DISTANCE
Display the running total distance or distance countdo n.
1.6.6 CALORIES
Display the calorie or calorie countdo n
1.6.7 SPEED DIAGRAM
Display the diagram of the running speed
1.6.8 ALL INDO DISPLAY DATA RAGNE
TIME：0:00 – 99.59(MIN)
DISTANCE: 0.00 – 99.9(KM)
CALORIES: 0.0 – 999 (C)
SPEED:0.8 -16.0 (km/h)
INCLUDE: 0-12%
PULSE: 50 – 200 (BPM)
1.7 PULSE FUNCTION
When the treadmill is running, hold the hand pulse about 5 seconds, it ill display pulse data. The
pulse data range is 50-200 times/ minute. It has heart-shaped graphics hen testing pulse. This
data is only for reference, can not be as medical data.
1.2. PROGRAM EXERCISE CHART
There are 10 sections in each program.
SET TIME / 16 = TOTAL TIME IN EAC OPERATION
1 2 3 4 5 6 7 8 9 10
P1 SPD 3 3 6 5 5 4 4 4 4 3
INC 03 3 3 4 4 4 1 1 0
P2 SPD 3 3 4 4 5 5 5 6 6 4
INC 2 2 2 3 3 3 3 4 4 2
P3 SPD 2 4 6 8 7 8 6 2 3 2
INC 3 5 4 4 3 4 4 3 4 2
P4 SPD 3 3 5 6 7 6 5 4 3 3
INC 0 3 3 2 2 5 5 3 3 2
P5 SPD 3 6 6 6 8 7 7 5 5 4
INC 3 5 3 4 2 3 4 2 3 2
TIME
MODE
11

P6 SPD 2 6 5 4 8 7 5 3 3 2
INC 3 4 5 6 3 5 5 6 4 3
P7 SPD 2 9 9 7 7 6 5 3 2 2
INC 0 3 3 3 4 4 4 1 1 0
P8 SPD 2 4 4 4 5 6 8 8 6 2
INC 1 1 4 4 4 5 5 4 3 2
P9 SPD 2 4 5 5 6 5 6 3 3 2
INC 3 5 3 4 2 3 4 2 3 2
P10 SPD 2 5 7 5 8 6 5 2 4 3
INC 1 5 6 8 12 9 10 9 5 3
P11 SPD 2 5 6 7 8 9 10 5 3 2
INC 35 6 8 6 5 8 7 5 2
P12 SPD 2 3 5 6 8 6 9 6 5 3
INC 5 7 5 8 6 5 9 10 6 2
1.9 3 COUNTDO N FUNCTION PARAMETER DATA
Countdo n time initial setting 10：00 minutes，setting range 5：00---99：00 minutes , each step 1：00.
Countdo n calorie initial setting 50therm, setting range 20---990 therm，each step 10.
Countdo n distance initial setting 1.0km，setting range 1.0---99.0 km，each step 0.1
Cycle s itch order is: manual, time, distance, calories.
1.10 BODY TESTER（FAT）
At the beginning state, press “ PROGRAM” continually to enter “FAT“ body fat test，indo display
“FAT”. Press “MODE” to enter (F1 SEX, F2 AGE, F3 HEIGHT, F4 WEIGHT). Press “SPEED+”,
“SPEED-” to set. After setting, the computer ill display F5 and grasp the hand pulse, the indo
ill display your body quality index.
The body quality index is to test the relation bet een height and eight not the body scale.
The body FAT suits for any male and female to adjust the eight according together ith other
body quality index. The ideal FAT should be bet een 20-25, if under 19, it means too thin. If
bet een 25 and 29, it means over eight, if over 30, it means obesity. (The data is just for
reference and can not be as medicinal data)
01 Sex 01 Male 02 Female
02 Age 10------99
12

03 Height 100----200
04 Weight 20-----150
05 FAT ≤19 Under eight
FAT = (20---25) Normal eight
FAT = (25---29) Over eight
FAT ≥30 Obesity
1.11 OTHERS
1.11.1 When the countdo n mode is finished and “END” appears on screen, arning sound occurs
. Then it ill be back to manual mode.
1.11.2 You can set statistics at circled mode. Ex: When time is set at 5:00 – 99:00 and it hits 99:00,
press “+” button, it ill start from 5:00 again.
1.11.3 Countdo n time, countdo n calorie and countdo n distance, you just can set one of them
at
one time, press last item to set running, the setting parameter is countdo n, others display normal
data.
1.11.4 Speed control: acceleration at 0.5km/s; deceleration at 0.5km/s.
13

ARNING ：Please make sure pull out the treadmill's po er plug before cleaning or
maintaining the product.
CLEANSING：General cleaning or the unit ill greatly prolong the treadmill's life.
Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on
either side of the alking belt and also the side rails. This reduces the build up of foreign
material underneath the alking belt. Make sure the shoes are clean. The top of the belt
may be cleaned ith a et soapy cloth. Be careful to keep liquid a ay from inside the
motorized treadmill frame or from underneath the belt.
ARNING ：Al ays unplug the treadmill from the electrical outlet before removing the
motor cover. At least once a year remove the motor cover and vacuum under the motor
cover.
This treadmill's alking belt and deck are equipped ith a pre-lubricated, lo maintenance
deck system. The belt/ deck friction may play a major role in the function and life of your
treadmill, thus requiring periodic lubrication. We recommend a periodic inspection of the
deck.
We recommend lubrication of the deck according to the follo ing timetable:
Light user (less than 3 hours/ eek) Every 60 days
Medium user (3-5 hours/ eek) Every 45 days
Heavy user (more than 5 hours/ eek) Every 30 days
We suggest you buy lubricating oil from local distributors or contact our company directly.
Pay attention, any other maintains please ask professionals for help.
Maintenance Instruction
17

Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the
running belt deviate condition.
If the belt has drifted to the right, unplug the
safety lock and po er s itch, and turn the
right adjusting bolt 1/4 turn clock ise, then
insert the po er s itch and safety lock, make
the treadmill running, observe the running belt
deviate condition. Repeat above steps until
the running belt be placed in the middle. See
picture A
Once the treadmill belt s erving to the left,
unplug the safety lock, turn off the po er, then
ith the left adjusting bolt clock ise rotation
1 / 4 laps, and turn on the safety lock and
po er to make treadmill running, checking the
deviation of the treadmill belt. Repeat the
above steps until the belt centered. See
picture B
The treadmill belt ill gradually relax after
above steps or after a period of time using,
unplug the safety lock, and turn off the po er,
ith the t o adjusting bolt clock ise rotation 1
/ 4 laps, and turn on the safety lock and po er
to make treadmill running, then standing on
the belt to confirm the tightness. Repeat the
above steps until the belt moderate tightness.
See picture C
Belt Adjustment
18

Parts list
Exploded Drawing
B1
B11L
A3L
D13
D13
D17
D17
D23
D16
B12 B10
D46
D57 D57
B8
B8
D11
D21 D18
D47
19

A. elding parts
No. Description QTY No. Description QTY
A1 Main frame 1 A4 Console bracket 1
A2 Base frame 1 A5 Incline bracket 1
A3L Left upright 1 A6 Filter bracket 1
A3R Right upright 1 A11 Motor bracket 1
B.Plastic parts
No. Description QTY No. Description QTY
B1 Console set 1 B13 Motor upper cover 1
B1-1 Overlay 1 B14 Motor lo er cover 1
B1-2 Membrane keys 1 B15 Side rail 2
B1-3 Console 1 B16L Left end cap 1
B1-5 Tablet holder 1 B16R Right end cap 1
B2 Console cover 1 B17 Adjust heel 2
B3 Protecting foam 2 B18 Silicon oil 1
B4 Handrail plug 2 B19 Cable organizer 1
B6 Transporting heel plug 2 B20 Round plug 1
B7 Transporting heel 2 B21 Squared shape plug 4
B8 Flat foot pad 2 B27 Ne cushion 6
B9 U shaped foot pad 2 B31 Rubber pad 2
B10 Limited cushion 2 B32 Oval silicone pad 4
B11L Left side cover 1 B34 Rubber pad (for tablet holder) 1
B11R Right side cover 1 B51 Water bottle cup holder 2
B12 Rubber cover 2
C. Electric and drive parts
No. Description QTY No. Description QTY
C1 DC motor 1 C12 Incline motor 1
C2 Running belt 1 C13 Safety key 1
C3 Rear roller 1 C14 Single cord 1
C4 Front roller 1 C15 Po er cable 1
C5 Running deck 1 C16 Upper cable 1
C6 Cylinder 1 C17 Lo er cable 1
C7 Motor drive belt 1 C20 Magnetic ring 1
C8 Po er s itch 1 C21 Inductor 1
C9 Controller 1 C22 Filter 1
C10 Left handrail button 1 C27 Single cord 2
C11 Right handrail button 1
D. Hardware parts
No. Description QTY No. Description QTY
D1 Scre driver 13-15-17 1 D25 Spring asher M8 4
D3 Allen rench T5 1 D29 Hex round head bolt M6X45 1
D9 Round hex bolt M10X30 1 D30 Hex round head bolt M6x60 2
D10 Round hex bolt M10X45 4 D31 Hex round head bolt M8X20 4
Parts List
20

D11 Round hex bolt M10*50 3 D35 Hex round head bolt M8X80 1
D13 Round hex bolt M8X15 4 D36 Cross head bolt M6X25 2
D14 Round hex bolt M8X30 1 D43 Cross head bolt M4X20,
asher 2
D15 Round hex bolt M8X40 4 D45 Cross head bolt M5X15,
asher 7
D16 Round hex bolt M8X45 7 D46 Cross head bolt M5x20,
asher 2
D17 Inner star asher M8 8 D47 Cross self-tapping bolt
ST4.2X16, asher 17
D18 Nylon nut M10 8 D48 Cross self-tapping bolt
ST4.2X19, asher 4
D20 Nylon nut M8 8 D52 Cross self-tapping bolt
ST4.2X16 17
D21 Flat asher M10 8 D53 Cross self-tapping bolt
ST4.2x45 2
D23 Flat asher M8 13 D57 Cross self-tapping bolt
ST4.2X25 4
D24 Spring asher M5 1 D60 Cross head bolt M6X20 6
21

GARLANDO SPA
Via Regione Piemonte, 32 - Zona Industriale D1
15068 - Pozzolo Formigaro (AL) - Italy
www.toorx.it - [e-mail]
