Operator’s Manual
IMPORTANT: Read this manual carefully. It contains information about your
safety and the safety of others. Also become familiar with the controls and
their proper use before you operate the product.

FORM NO. 3321-713GB Rev A
ProLine
37” Recycler
for Mid-Size Traction Unit
Model No. 30139 – 895001 & Up

Printed in USA
Introduction
We want you to be completely satisfied with your
new product, so feel free to contact your local
Authorized Service Dealer for help with service,
genuine replacement parts, or other information you
may require.
Whenever you contact your Authorized Service
Dealer or the factory, always know the model and
serial numbers of your product. These numbers will
help the Service Dealer or Service Representative
provide exact information about your specific
product. You will find the model and serial number
plate located in a unique place on the product as
shown below .
1

1. Model and Serial Number Plate
For your convenience, write the product model and
serial numbers in the space below.
Model No:
Serial No.
The warning system in this manual identifies
potential hazards and has special safety messages that
help you and others avoid personal injury, even death.
DANGER, WARNING and CAUTION are signal
words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
DANGER signals an extreme hazard that will cause
serious injury or death if the recommended
precautions are not followed.
WARNING signals a hazard that may cause serious
injury or death if the recommended precautions are
not followed.
CAUTION signals a hazard that may cause minor or
moderate injury if the recommended precautions are
not followed.
Two other words are also used to highlight
information. “Important” calls attention to special
mechanical information and “Note” emphasizes
general information worthy of special attention.
The left and right side of the machine is determined
by sitting on the seat in the normal operator’s
position.

1
Contents
Page
Safety and Instruction Decals 2.
. . . . . . . . . . . . .
Installation 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loose Parts 3 . . . . . . . . . . . . . . . . . . . . . . . . .
Install Deflector Baffle 4 . . . . . . . . . . . . . . . .
Install Front Baffle 5 . . . . . . . . . . . . . . . . . . .
Install Belt Guard Hold-Down 5 . . . . . . . . . .
Installing the Castor Wheels 6 . . . . . . . . . . .
Installing the Carrier Frame
to the Traction Unit 7 . . . . . . . . . . . . . . . .
Installing the Cutting Deck 8 . . . . . . . . . . . .
Installing the Drive Belt 8 . . . . . . . . . . . . . . .
Operation 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side Discharge or Mulch Grass 10 . . . . . . . . .
Engaging the Mower Blades (PTO) 10 . . . . . .
Adjusting the Height-of-Cut 11 . . . . . . . . . . .
Tips for Mowing Grass 12 . . . . . . . . . . . . . . .
Page
Maintenance 13 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Interval Chart 13 . . . . . . . . . . . . . . . .
Cutting Blades 13 . . . . . . . . . . . . . . . . . . . . . .
Correcting Cutting Unit Mismatch 16 . . . . . .
Setting the Front-to-Rear Pitch 16 . . . . . . . . .
Setting the Side-to-Side Leveling 17 . . . . . . .
Greasing the Bearings and Bushings 18 . . . . .
Replacing the Deck Belt 18 . . . . . . . . . . . . . .
Replacing the Drive Belt 19 . . . . . . . . . . . . . .
Converting the Mower to
Side Dischar ge Mowing 20 . . . . . . . . . . . . .
Replacing the Castor Wheel Fork Bushings 22
Servicing the Castor Wheels and Bearings 23
Storage 24
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 25 . . . . . . . . . . . . . . . . . . . . . . . . .

Safety
2
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near
any area of potential danger. Replace any decal that is damaged or lost.
     
"$% # 
     
"$% # 
  !
"$% # 
   

"$% # 
  ! 
     
"$% # 
!  &

"$% # 
     
"$% # 
See T raction Unit Operator ’s Manual
for Glossary of Safety Symbols
  
"$% # 

3
Installation
Loose Parts
Note: Use the chart below to identify parts used for assembly.
DESCRIPTION QTY. USE
Deflector baffle
Bolt 5/16–18 x 3/4” (19mm)
Lock nut 5/16” thin
1
2
2
Install deflector baf fle
Front baffle
Bolt 5/16–18 x 3/4” (19mm)
Lock nut 5/16” thin
1
5
5
Install front deflector
Belt guard holdĆdown
Bolt 5/16–18 x 1-1/4” (32mm)
Nut 5/16”
Lock nut 5/16” thin
1
1
1
1
Install belt guard hold down
Decal package 1 Replace existing decals of like shape
Castor Wheel Assembly
Thrust W asher
Spacer
Retaining Ring
2
8
2
2
Install castor wheels to carrier frame
Right-hand Angle Bracket
Left-hand Angle Bracket
Flange Bolt, 1/2”-13 x 1” (25 mm)
Flange Locknut, 1/2”-13
1
1
6
6
Mount angle brackets to traction unit
Carrier Frame
Hex Head Bolt, 3/8”-16 x 1.75” (44 mm)
Hex Head Screw , 3/8”-16 x .88” (22 mm)
Locknut, 3/8”-16
Flat W asher, 3/8”
Shim
1
4
4
4
4
2
Install carrier frame to angle brackets
Adjusting Shaft
Jam Nut, 1/2”-13
Flat W asher, 1/2” (13 mm)
Spring
Bushing
2
4
2
2
2
Install adjusting shafts

Installation
4
DESCRIPTION USEQTY.
Discharge Deflector Assembly 1 Install for side-discharge cutting
Deck Drive Belt 1 Install on cutting unit and traction unit
Operator’ s Manual
Parts Catalog
1
1
Read before operating
Ordering parts
Install Deflector Baffle
1. Hold deflector baffle in position along front of
deflector, with large end toward the mower
(Fig. 1).
2. Line up inside edge with deflector edge and
space so it extends below as shown (Fig. 1).
3. Mark and drill (2) 9 mm holes in deflector
(Fig. 1).
4. Secure with 5/16–18 x 3/4 (9mm) bolts and thin
5/16 lock nuts (Fig. 1).
3
2041 2
1
4
16 mm
37 mm
Figure 1
1. Grass deflector
2. Deflector baf fle 3. Bolt
5/16–18 x 3/4” (9 mm)
4. Lock nut 5/16” thin

Installation
5
Install Front Baffle
1. Locate baffle inside front of mower with formed
notch to the right side. Bend baffle to conform to
mower front radius and even with lower edges of
outer cutting chambers. Clamp baffle at the
center.
2. Drill a 9 mm hole through the front of the
mower next to clamp at center. Secure baffle to
mower at center with 5/16–18 x 3/4” (19mm)
bolt, through from the inside, and a thin 5/16
lock nut (Fig. 2).
Note: Use the holes in the baffle only as a
guide for hole location. It is not
necessary to use there exact location.
Note: Look, before drilling holes, that there
will be clearance for installing bolts.
3. Working left and right from the center, drill (4)
9 mm holes in mower. Secure baffle with
5/16–18 x 3/4” (19mm) bolts, through from the
inside, and secure with thin 5/16 lock nuts
(Fig. 2).
1
3
5
4
2039
2
Figure 2
1. 37” mower
2. Front baf fle
3.
Drill 9 mm hole at center
4. Bolt 5/16–18 x 3/4”
(19mm)
5.
Lock nut 5/16’ thin
Install Belt Guard Hold-Down
1. Remove existing bolt securing kicker at center
rear of mower. Replace with longer 5/16–18 x
1-1/4 (32 mm) bolt from kit. Insert from inside
mower and secure with 5/16 nut (Fig. 3).
2. Position hold–down over bolt at the rear and to
the right of the step on belt guard (Fig. 3).
Secure hold-down with 5/16 thin lock nut
(Fig. 3).
2040
1
2
4
5
3
Figure 3
1. Belt cover
2. Bolt 5/16–18 x 1-1/4”
(32 mm)
3. Nut 5/16”
4. Hold–down bracket
5. Lock nut 5/16” thin

Installation
6
Installing the Castor Wheels
3. Place two (2) thrust washers onto the castor
wheel fork (Fig. 4).
4. Insert the castor wheel fork into the carrier frame
mounting tube (Fig. 4).
5. Install the spacer and two (2) thrust washers onto
the castor wheel fork, then secure with a
retaining ring (Fig. 4).

4
2
2
1
3
5
Figure 4
1. Retaining Ring
2. Thrust W ashers
3. Spacer
4.
Carrier Frame Mounting
Tube
5.
Castor Wheel Fork
6. Install the 1”–4” Height-of-cut decals over the
existing 2”–5” Height-of-cut decals.
7. Set the castor wheel tire pressure to 12–15 psi
(83–103 kPa).

Installation
7
Installing the Carrier Frame to
the T raction Unit
1. Fasten the angle brackets to the traction unit
frame with the six (6) 1/2”-13 x 1” (25 mm) hex
head flange bolts and flange locknuts. Position
the bottom locknuts on the outside of the angle
brackets. Torque the fasteners to 60–80 ft.-lbs
(81–109 NM) (Fig 5).
IMPORTANT: When installing the angle
brackets on traction units with hydrostatic
drive, use the 1/2”-13 x 1-1/4” hex head flange
bolts supplied with the traction unit.
2. Attach the carrier frame to the angle brackets
with the four (4) 3/8”-16 x 1-3/4” (44 mm) hex
head bolts and locknuts. Note that the locknuts
must be on the outside of the carrier frame.
Leave the locknuts loose to allow movement
between the carrier frame and angle brackets
(Fig 5).
3. Install the shims between the carrier frame and
angle brackets. Align the holes in the shims with
the top holes in the carrier frame and angle
brackets (Fig. 5).
4. Install the four (4) 3/8”-16 x 7/8” (22 mm) hex
head screws with flat washers through the carrier
frame and shims, and into the threaded holes in
the top of the angle brackets. Torque the hex
head screws to 27–33 ft.-lb (37–45 Nm)
(Fig. 5).
5. Torque the four (4) 3/8”-16 x 1-3/4” (44 mm)
hex head bolts and locknuts to 27–33 ft.-lb
(37–45 Nm) (Fig. 5).
9
1

1
4
2
3
6
7
8
5
10
Figure 5
1. 1/2”-13 Flange Locknut
2. T raction Unit Frame
3. Angle Bracket (typical)
4. 1/2”-13 x 1” (25 mm) Hex
Head Flange Bolt (gear
drive traction units only)
5. 3/8”-16 x 1-3/4” (44 mm)
Hex Head Bolt
6. Shim
7.
3/8”-16 x 7/8” (22 mm)
Hex Head Screw
8. 3/8” Flat W asher
9.
3/8”-16 Locknut
10. Carrier Frame

Installation
8
Installing the Cutting Deck
1. Position the cutting deck under the carrier frame.
2. Mount the cutting deck to the carrier frame with
four (4) clevis pins and hairpin cotters (Fig. 6).
Note: All four pins must be in the same hole
locations to prevent uneven cutting.
8
11
1
3
5
7
2
4
6
m-2683
9
10
Figure 6
1. 2” (51 mm) Cut Height
2. 2-1/2” (64 mm) Cut Height
3. 3” (76 mm) Cut Height
4. 3-1/2” (89 mm) Cut Height
5. 4” (102 mm) Cut Height
6. 4-1/2” (1 14 mm) Cut
Height
7.
5” (127 mm) Cut Height
8. Clevis Pin
9. Carrier Frame
10. Cutting Deck
11. Hairpin Cotter
Installing the Drive Belt
1. Remove the deck cover from the top of the
cutting deck.
2. Install the drive belt around the traction unit
drive pulley and the top pulley on the left
spindle. The belt must be to the left of the belt
guide (Fig. 7).
1
2
3
m-2684
4
Figure 7
1. Traction Unit Drive Pulley
2. Drive Belt
3. Belt Guide
4. T op Left Spindle Pulley
