FormNo.3397-442RevB
GeoLink®PrecisionSpraySystem
MultiPro®5800TurfSprayer
ModelNo.41623
QuickStartGuide
ContactToroNSNat1-844-GeoLink(1-844-436-5465)orNSNT[email protected]forcustomerservice.
Note:Whenyouturnonthedisplayforthersttime,itisinstandardmode.Ensurethemachineisstoppedwhilechanging
thedisplayandconguration.
UsingtheTouchScreen
Sprayerinformationisaddedtothescreenwhenyoutouchandenabletheindividualicons.
•Selectanyicononthescreentodisplaywhatisshownonthescreen.
•Pressonanicontochangeit,andfurtheroptionswilldisplay.
•Selecttheoptionsasrequiredandconrmthenewdisplay(Figure1).
g032674
Figure1
1
2
3
4
g031287
5
6
7
8
11
10
9
12
13
14
16 15
Figure2
Easy-modescreen
1.System-informationicon5.Inventory-managericon9.Job-menuicon13.Screen-viewicon
2.Guidanceicon6.Setupicon10.Field-menuicon14.Center-mapview
3.Job-informationicon7.Sprayerdashboard11.Job-assistanticon15.Boundary-selectionicon
4.Sprayer-controllericon8.Master-switchicon12.Zoom-functionicon16.Boom-displayicon
©2015—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3397-442*B

EnteringaProductandTank
Volume
1.Selectthesprayer-controllericon.
2.Expandthesprayer-controllerpanel.
3.Selecttheproducttitle,nishthewizardforrate,and
conrm(Figure3).
g031479
1 3
2
Figure3
1.Sprayer-controllericon3.Selecttheproductand
nishtheratewizard
2.Expandicon
CreatingaField
Note:Itisrecommendedtocreateoneeldpercoursewith
alleldboundariesforthatcourseunderthateld.
1.Selecttheeld-menuicon.
2.Selectthenew-eldicon.
3.Selecttheeldname,nametheeld,andconrm
(Figure4).
3 2 1
g031480
Figure4
1.Field-menuicon3.Fieldname
2.New-eldicon
CreatingNewFieldBoundaries
inStandardMode
Note:Ensurethatthedisplayisinstandardmodetocreate
boundaries.
Note:Ensuretheunitsarecorrectforyouruse.Refer
toSelectingtheCorrectUnitsofMeasureintheOperator’s
Manual.
CreatingaNewFieldBoundaryusing
Vehicle-PositionTracking
Theboundaryiscreatedattheoutsideofthefront,lefttire.
1.Drivetothearea.
2.Selecttheeld-menuicon.
3.Selecttherecord-eldboundaryicon.
2

g031481
2
1
3 4
Figure5
1.Field-menuicon3.Pauseeld-boundary
recordingicon
2.Record-eldboundary
icon
4.Completeeld-boundary
recordingicon
4.Whenyouareclosetothebeginning,selectthe
completeboundaryicon.
CreatingaNewFieldBoundarywhile
Spraying
Note:ThisprocedureisusedwithWAASorwithWAAS
plusRTKcorrections.
Theboundaryiscreatedattheoutsidenozzlethatisspraying.
RefertotheCreatingaFieldBoundaryfromSprayingvideo
inthefolderonthethumbdrive.
1.Drivetotheareathatistobemapped.
2.Selecttheauto-sectioncontrolicon.
3.Changedtheboundarylimittounlimited.
4.Selectthejob-menuicon.
5.Selectthenewjobicon.
6.Namethenewjob.
7.Turnonmasterswitchiconandsprayareatobe
mapped.
8.Whennishedsprayingborder,selectthecreate
boundaryfromcoverageicon.
9.Toonlyspraywithintheborder,selecttheauto-section
controliconandchangetheboundarylimittoeld
boundaries.
NamingandCategorizinga
FieldBoundary
1.Aftercreatingaboundary,holdyourngeronthe
boundaryline.
2.Whentheboundarylineishighlighted,removeyour
ngerfromthescreenandthepropertiesmenuwill
open.
3.Selectthedifferentpropertiesyouwanttochange,
inputtheinformation,andconrm.
g031482
1 2 3
Figure6
1.Selecttheboundarywith
yournger
3.Boundaryproperties
2.Boundary
UsingtheEasyModewitha
NewJob
1.Switchthedisplaytoeasymode.
2.Startthemachineandkeepthekeyintherunmode.
3.Openthesprayer-controllericon(Figure7).
4.Inthesprayer-controllerscreen,determineifthe
correctrate(gal/ac)isselected.
5.Iftherateisnotcorrect,changetheratewiththepreset
rates,incrementally,orselectthecurrentrateboxto
manuallyenteranapplicationrate.(Figure7).
3

g031494
1
2
34
Figure7
1.Currentrate3.Decreaseandincrease
icons
2.Preset-rateicons4.Sprayer-controllericon
6.Selectthejob-menuiconintheupperrightofthe
screen.
7.Enteranewnameforthejoborleavethedefaulttime
stamp(Figure8).
g031484
1
2
3
Figure8
1.Job-menuicon2.Enteranewnameoruse
thedefaulttimestamp
8.Openthejob-menuicon.
9.Selecttheworkregionyouaregoingtospray(i.e.
fairways,greens,tees,etc.)(Figure9).
g031485
1
3
2
Figure9
1.Job-menuicon3.Selectthejobregion
2.Congure-jobregionsicon
10.Selecttheexcludedregionsthatarenottobesprayed
(bunkers,trees,hazards,etc.)
Note:Refertothestandardmodevideosforspraying
aboundaryinsideanotherboundary.
11.Turnthesectionswitches(locatedbetweentheseats)
totheONposition(Figure10).
g031290
1 2 3
Figure10
1.Boomswitch,leftboom3.Boomswitch,rightboom
2.Boomswitch,centerboom
12.Tostartspraying,turnonthemaster-switchicon(the
master-switchturnsgreen)anddriveintothespray
area(Figure2).
Note:Themachinestartssprayingwhenthesprayer
crossesintothecorrectsprayarea.
Note:Thedisplayshowsareastobesprayedwith
lightgrayandnon-sprayareaswithadarkgray.Ifthe
displayshowsalllightgray,everyareacanbesprayed.
Note:Thedisplay,receiver,andsectioncontrollerwill
powerdownwhenthemachinekeyisturnedtothe
OFFposition.Apowerswitch(green)forthedisplayis
locatedontheback,leftsideoftheconsole.
