FormNo.3393-275RevA
EUComplianceKit
2015andAfterMultiPro®1750TurfSprayer
ModelNo.41155—SerialNo.315000001andUp
Operator'sManual
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1illustratesthelocationofthe
modelandserialnumbersontheproduct.
Figure1
ModelNo.
SerialNo.
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
TheEUComplianceKitisdesignedtomeetGermansafety
requirementsbyenablingoperatorstocleanoutresidual
chemicalsfromthesprayersystemandcleantheexternal
machinewhilebypassingthechemicaltank.Itisadedicated
kitforaturfsprayapplicationvehicleandisintendedto
beusedbyprofessional,hiredoperatorsincommercial
applications.
ThisproductcomplieswithallrelevantEuropeandirectives.
Fordetails,pleaseseetheDeclarationofIncorporation(DOI)
atthebackofthispublication.
Readthismanualcarefullytolearnhowtooperateand
maintainyourproductproperly.Theinformationinthis
manualcanhelpyouandothersavoidinjuryandproduct
damage.AlthoughTorodesignsandproducessafeproducts,
youareresponsibleforoperatingtheproductproperlyand
safely.
Safety
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2otherwordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Alsoreadthesafetyandoperationinstructionsinthevehicle
Operator’sManual.
©2014—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3393-275*A

ChemicalSafety
WARNING
Chemical substances used in the spray system may
be hazardous and to xic to y ou, bystander s, animals,
plants, soils or other pr oper ty .
•Carefullyreadandfollowthechemical
warninglabelsandMaterialSafetyData
Sheets(MSDS)forallchemicalsusedand
protectyourselfaccordingtothechemical
manufacturer'srecommendations.Forexample,
useappropriatePersonalProtectiveEquipment
(PPE)includingfaceandeyeprotection,gloves,
orotherequipmenttoguardagainstpersonal
contactwiththechemical.
•Keepinmindthattheremaybemorethanone
chemicalusedandinformationoneachshould
beassessed.
•
R efuse to operate or w or k on the spray er if this
inf or mation is not a v aila ble!
•Beforeworkingonaspraysystem,makesure
thesystemhasbeentriplerinsedandneutralized
accordingtotherecommendationsofthe
chemicalmanufacturer(s).
•Verifythereisanadequatesupplyofcleanwater
andsoapnearby,andimmediatelywashoffany
chemicalsthatcontactyou.
•Obtainpropertrainingbeforeusingorhandling
chemicals.
•Usethecorrectchemicalforthejob.
•Followthechemicalmanufacturer'sinstructionsforthe
safeapplicationofthechemical.
•Handlechemicalsinawellventilatedarea.
•Weargogglesandotherprotectiveequipmentas
instructedbythechemicalmanufacturer.Ensurethatas
littleskinaspossibleisexposedwhileusingchemicals.
•Havecleanwateravailableespeciallywhenllingthe
spraytank.
•Donoteat,drink,orsmokewhileworkingwithchemicals.
•Alwayswashyourhandsandotherexposedareasassoon
aspossibleafternishingthework.
•Properlydisposeofunusedchemicalsandchemical
containersasinstructedbythechemicalmanufacturer
andyourlocalcodes.
•Chemicalsandfumesinthetanksaredangerous;never
enterthetankorplaceyourheadoverorintheopening.
•Followalllocal,state,andfederalrequirementsforthe
sprayingofchemicals.
HandSprayerSafety
•Donotaimthehandsprayeratanypersonoranimal.
Fluidsunderhighpressurecanpenetrateskinandcause
severeinjury,possiblyresultinginamputationordeath.
Hotliquidsandchemicalscanalsocauseburnsorinjury.
Ifanypartofthebodycomesincontactwiththespray
stream,immediatelyconsultaphysicianfamiliarwith
injecteduidinjuries.
•Donotplaceyourhandoranyotherpartofyourbodyin
frontofthespraynozzle.
•Donotleavetheequipmentunderpressurewhenyou
arenotpresent.
•Donotusethehandsprayerifthehose,triggerlock,
nozzle,oranyotherpartisdamagedormissing.
•Donotusethehandsprayerifthereareanyleaksinany
hoses,ttings,orothercomponents.
•Donotspraynearpowerlines;thespraystreamcould
contactthepowerlinesandgiveyouapotentiallyfatal
electricalshock.
•Donotdrivewhilesprayingwithahandsprayer.
•Wearrubbergloves,safetygoggles,andafull-body
protectivesuitwhensprayingchemicalswiththehand
sprayer.
•Lightningcancausesevereinjuryordeath.Iflightning
isseenorthunderisheardinthearea,donotoperate
themachine;seekshelter.
2

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotential
danger.Replaceanydecalthatisdamagedorlost.
120-0673
1.Boomspray3.Handspray
2.RinseTank
120-0687
1.Valve,open2.Valve,closed
Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
Carriagebolt(5/16x1inch)2
Spray-gunbracket1
Clamp2
Flangedlocknut(5/16inch)2
Carriagebolt(3/8x1inch)1
Carriagebolt(3/8x1-1/4inch)2
Flangelocknut3
Rinsetank1
Fillercap1
Bulkheadtting1
Plasticangenut1
Retainer1
90-degreebarbedtting1
Rightrinse-tankbracket1
Hosemount1
Leftrinse-tankbracket1
2
Spacer(3/8x1/4inch)1
Installtherinsetank.
3

ProcedureDescriptionQty.Use
90°barbedtting(3/4inchNPTx3/4
inch)2
Plasticangenut2
Bulkheadtting2
Rinsenozzle2
Bushing2
Rinsevane2
3
Shoulderbolt2
Installtherinsenozzle.
Carriagebolt(3/8x1inch)2
FlangedLocknuts(3/8inch)2
Rinse-pumpmountingbracket1
Straight-barbedtting(1/2inchNPTx
1/2inch)2
Nipple(1/2inchNPT)1
Pressurelter1
Rinsepump1
Valvemount1
Bolt(1/4x1-3/4inch)4
Washer(1/4inch)4
Serrated-angenut4
4
Smallhairpin2
Installtherinsepump.
4-wayvalve1
Straight-barbedtting(1inchNPTx3/4
inch)1
90-degreebarbedtting(1inchNPTx
3/4inch)2
Straight-barbedtting(3/4inchNPTx
1/2inch)1
Reducertting(1inchNPTx3/4inch
NPT)1
Faceplatebracket1
Valve-mountassembly1
Bolt(6mm)4
Flatwasher(6mm)4
Locknut(6mm)4
Nut(3/8inch)2
5
Bolt(3/8inch)2
Assembleandmountthe4-wayvalve.
Fuse,40-amp1
6Dashswitch1
Installtherinse-pumpswitch,pump
connectors,andfuse.
Ballvalve1
Straight-barbedtting(1-1/4inchNPT
x3/4inch)2
Valve-mountbracket1
Hex-headbolt(5/16x5/8inch)2
Hex-headbolt(6x16mm)2
7
Locknut(6mm)2
Installtheballvalveandmounting
assembly.
4

ProcedureDescriptionQty.Use
Inlethose2.5x66cm(1x26inch)1
Hoseclamp2
90°hubtting2
LargeO-ring4
T-Fitting(upper)1
Retainer3
Reducerhub1
SmallO-ring1
Transferhose1.9x61cm(3/4x24
inch)1
8
Hubconnector1
InstalltheupperT-ttingassembly.
Hoseclamp1
9Retainer1
Installthehosebetweentheupper
T-ttingandtheballvalve.
Hose1.9x76cm(3/4x30inch)1
10Hoseclamp2
Installthehosebetweentheballvalve
andthe4-wayvalve.
Hose1.9x61cm(3/4x24inch)1
11Hoseclamp2
Installthehosebetweenthepressure
lterassemblyandthe4-wayvalve.
Hose1.9x48.3cm(3/4x19inch)2
Hose1.9x61cm(3/4x24inch)1
Teetting1
12Hoseclamp6
Installtherinsenozzlehoses.
Hose1.3x762cm(1/2x300inch)1
Spraygun1
Hoseclamp2
13Spraygunbarbedtting1
Connectthesprayhoseandgun.
Hose(45inches)1
Hoseclamp2
14Conduit1
Installtherinsetankhose.
Decal(120-0673)1
15Decal(120–0687)1Installthedecals.
5

1
PreparingtheMachine
NoPartsRequired
Procedure
1.Movethesprayerontoalevelsurface,settheparking
brake,stopthepump,stoptheengine,andremovethe
ignitionkey.
2.Drainthecontentsofthetanktoremoveanychemicals
inthelines.RefertotheOperator’sManualformore
information.
Note:Takecautionwhiledisconnectinganyhoses
duringtheinstallationofthiskit,andhaveacatch
bucketreadyforanychemicalsremaininginthehose.
CAUTION
Chemicalsarehazardousandcancausepersonal
injury.
•Readthedirectionsonthechemicallabels
beforehandlingthechemicals,andfollow
allmanufacturerrecommendationsand
precautions.
•Keepchemicalsawayfromyourskin.Should
contactoccur,washtheaffectedareathoroughly
withsoapandcleanwater.
•Weargogglesandanyotherprotective
equipmentrecommendedbythechemical
manufacturer.
2
InstallingtheRinseTank
Partsneededforthisprocedure:
2Carriagebolt(5/16x1inch)
1Spray-gunbracket
2Clamp
2Flangedlocknut(5/16inch)
1Carriagebolt(3/8x1inch)
2Carriagebolt(3/8x1-1/4inch)
3Flangelocknut
1Rinsetank
1Fillercap
1Bulkheadtting
1Plasticangenut
1Retainer
190-degreebarbedtting
1Rightrinse-tankbracket
1Hosemount
1Leftrinse-tankbracket
1Spacer(3/8x1/4inch)
RemovingtheFreshWaterTank
1.Iflledwithwater,emptythefreshwatertank.
2.Removethe4angedheadboltsthatsecurethefresh
watertanktothemountingbracket(Figure3).
6

Figure3
1.Freshwatertank3.Flangedheadbolts
2.Mountingbracket
3.Removethetankfromthemachine(Figure3).
Note:Retainthefreshwatertankandangedhead
boltsforinstallationinInstallingtheFreshWaterTank
(page10).
InstallingtheHardwarefortheRinse
TankStrapsandSprayGunBracket
1.Assemblethe2clampstothespray-gunbracket(Figure
4)with2carriagebolt(5/16x1inch)and2anged
locknuts(5/16inch).
Figure4
1.Carriagebolt(5/16x1
inch)
3.Clamp
2.Spray-gunbracket4.Flangedlocknut(5/16
inch)
2.Removeandretainthebolt(3/8x5inch),washers,and
angedlocknutthatsecurethefronttankstrapsatthe
topofthetank(Figure5).
Note:Retainthebolt(3/8x5inch),washers,and
angedlocknut;discardtheshortcarriageboltand
locknutholdingtheR-clampinplace.
Figure5
1.Locknut5.Washer
2.R-clamp6.Flangedlocknut
3.Carriagebolt(short)7.Right,fronttankstrap
4.Bolt(3/8x5inch)
3.Installacarriagebolt(3/8x1inch)intheupper-inboard
holesoftheleft,fronttankstrap(Figure6).
Note:Looselythreadaangedlocknuts(3/8inch)
ontothecarriagebolt.
Figure6
1.Flangedlocknuts(3/8
inch)
3.Carriagebolts(3/8x1-1/4
inch)
2.Carriagebolt(3/8x1inch)
7

4.Install1carriagebolt(3/8x1-1/4inch)inthe
upper-inboardholesoftheright,fronttankstrap
(Figure6).
Note:Looselythreadaangedlocknuts(3/8inch)
ontothecarriagebolt.
5.Install1carriagebolts(3/8x1-1/4inch)inthe
lower-outboardholesoftheright,fronttankstrap
(Figure6).
Note:Looselythreadaangedlocknuts(3/8inch)
ontothecarriagebolts.
6.Installthetankstraphardwarethatyouremovedin2
tosecurethestrapstothetank.
Note:Ensurethatthesquareportionofthecarriage
boltsareseatedinthesquareopeninginthetankstraps.
Note:Makesurethatthestrapsareushtothetank.
Donotovertightentankstraphardware.
7.Removetheangedlocknut(3/8inch)atthe
lower-outboardcarriageboltattheright,fronttank
strap,assemblethespraygunbrackettothecarriage
bolt,andsecurethebracketwiththeangedlocknut
(Figure7).
Figure7
1.Carriagebolts(3/8x1-1/4
inch)
3.Spray-gunbracket
2.Flangedlocknut(3/8inch)
InstallingtheTank
1.Installthebulkheadttingintotherinsetankas
follows:
A.Installtheangedsealontothebulkheadtting
(Figure8).
Figure8
1.Bulkheadtting3.Flangedseal
2.Retaining-forkhole
B.Attachawire,longerthanthetankistall,toone
oftheretaining-forkholesinthebulkheadtting
(Figure8andFigure9)
G014228
1
23
45
6
Figure9
1.Rinsetank4.Filleropening,rinsetank.
2.Fillercap5.Wire
3.Bulkheadtting6.Outlet(bottomofthetank)
C.Removethetankcap,insertthewirethroughthe
llerneck,andpassthewireoutthroughthe
outletatthebottomofthetank(Figure9).
D.Usethewiretoguidethebulkheadttingtothe
outlet(Figure10).
8

G014229
1
2
3
Figure10
1.Bulkheadtting(wire
attached)
3.Fillercap
2.Outlet(bottomofthetank)
E.Movethebulkheadttingintopositionmaking
surethattheangedgasketseatsagainstthe
interiorwalloftherinsetank(Figure10)
F.Securethebulkheadttingtotherinsetankwith
aplasticangenut
Note:Removethewirefromthebulkheadtting.
G014230
1
2
3
Figure11
1.Rinsetanksump3.Plasticangenut
2.Bulkheadtting
(positioned)
G.Installa90°barbedttingontothebulkhead
ttingandsecurethebarbedttingwitharetainer
(Figure12).
Note:Rotatethe90°barbedttingsothatit
facesrearward.
G014260
12
3
Figure12
1.Retainer3.90°barbedtting
2.Bulkheadtting
2.Releasethe2latchesthatsecuretheguardbehindthe
seattothechassisandremovetheguardfromthe
machine(Figure13).
Figure13
1.Guard2.Latch
3.Removethe2angedlocknutsatthecarriagebolts
attheupper-inboardholeoftheleft-andright,front
tankstraps.
4.Aligntherinsetanktothesprayertankasshownin
Figure14.
9

Figure14
1.Lefttankbracket(slotted
angeangleddownfrom
righttoleft)
3.Carriagebolt(3/8x1inch)
2.Flangedlocknut(3/8inch)
5.Alignthelefttankbracketontothecarriagebolt(3/8
x1inch)attheupper-inboardholesoftheleft,front
strap(Figure14).
Note:Ensurethatthetankbracketisalignedwiththe
pocketmoldedintothetoprearpartoftherinsetank.
Note:ReplacetheR-clampduringthistimetoo.
6.Securethetankbrackettothecarriageboltandstrap
(Figure14)withaangedlocknut(3/8inch).
7.Alignthehosemount,spacer(3/8x1/4inch),and
righttankbracketontothecarriagebolt(3/8x1
inch)attheupper-inboardholeoftheright-frontstrap.
(Figure15).
Note:Ensurethatthetankbracketisalignedwiththe
pocketmoldedintothetoprearpartoftherinsetank.
Figure15
1.Flangedlocknut(3/8inch)4.Righttankbracket(slotted
angeangleddownfrom
lefttoright)
2.Hosemount5.Carriagebolt(3/8x1-1/4
inch)
3.Spacer(3/8x1/4inch)
8.Securethehosemount,spacer,andtankbracketto
thecarriageboltandstrap(Figure15)withaanged
locknut(3/8inch).
Note:Oncetherinsetankhasbeeninitiallylledwithwater,
checktherinse-tankbracketfastenersandtightenedthenuts
asneededbecausetheweightoftheliquidinthetankcan
furtherseatthetankagainsttheframe.
InstallingtheFreshWaterTank
1.Aligntheholesinthefreshwatertankwiththeslotsin
themountingbracket;refertoFigure3inRemoving
theFreshWaterTank(page6).
2.Assemblethetanktothebracketwiththe4
anged-headboltsthatyouremovedinstep2of
RemovingtheFreshWaterTank(page6).
3.Torquetheboltsto1017to1355N-cm(90to120
in-lb).
10

3
InstallingtheRinseNozzles
Partsneededforthisprocedure:
290°barbedtting(3/4inchNPTx3/4inch)
2Plasticangenut
2Bulkheadtting
2Rinsenozzle
2Bushing
2Rinsevane
2Shoulderbolt
DrillingtheMainTank
1.Openthetanklidandremovethestrainerbasket.
2.Locatethe2drillmarksonthemaintank(Figure16).
1
G022212
Figure16
1.Drillmarks
3.Usea4cm(1-5/8inch)holesawtodrillaholeateach
drillmark.
Note:Placeareceptacleinsidethetankandbelowthe
areastobedrilledtocatchanydebriscreatedduring
thecutting.
Important:Debrisleftinsideatankcouldclog
anddamagethespraysystemduringoperation.
Note:Drillingcounterclockwisewillmakedrilling
easier.
InstallingtheNozzles
Note:ApplyPTFEtapetothethreadsofthetaper-threaded
ttingsusedinthesprayerandrinsesystems.
1.Assemblethe2rinsenozzlesasshowninFigure17.
G022281
1
2
3
4
5
Figure17
1.Bulkheadtting4.Rinsevane
2.Rinsenozzle5.Shoulderbolt
3.Bushing
2.Openthecoverofthesprayertank.
3.Assemblethenozzleassembliesupthroughthedrilled
holes(Figure18).
G022282
1
2
3
Figure18
1.Bulkheadtting3.Rinse-nozzleassembly
2.Plasticangenut
4.Attopofthetank,installtheplasticangenutsover
theexposedthreadsofthebulkheadttingsforthe
rinsenozzles(Figure18).
Note:Ensurethatthesealisseatedushbetweenthe
bulkheadttingandtheundersideofthetank.
11

5.Installa90°barbedtting(3/4inchNPTx3/4inch)
ontoeachofthethreadedopeningsoftherinse-nozzle
bulkheads(Figure19).
G022283
1
2
Figure19
1.90°barbedtting(3/4inch
NPTx3/4inch)
2.Rinse-nozzleassembly
6.Alignthe90°barbedttingstowardthemiddleofthe
rightsideofthemachine.
4
InstallingtheRinsePump
Partsneededforthisprocedure:
2Carriagebolt(3/8x1inch)
2FlangedLocknuts(3/8inch)
1Rinse-pumpmountingbracket
2Straight-barbedtting(1/2inchNPTx1/2inch)
1Nipple(1/2inchNPT)
1Pressurelter
1Rinsepump
1Valvemount
4Bolt(1/4x1-3/4inch)
4Washer(1/4inch)
4Serrated-angenut
2Smallhairpin
InstallingtheValveMount
1.Removethebolt(3/8x5inch),washers,anged
locknut,andhairpinthatsecuretheright,reartank
strapsatthetopofthetank.
Note:Retainthebolt(3/8x5inch),washers,anged
locknut,andhairpin.
2.Install1carriagebolt(3/8x1inch)inthe
upper-inboardholesoftheright,reartankstrap(Figure
20).
Note:Looselythreadaangedlocknuts(3/8inch)
ontothecarriagebolt.
1
2
3
1
g024697
4
Figure20
1.Nut3.Valvemount
2.Carriagebolt4.Hairpin
3.Install1carriagebolts(3/8x1inch)inthe
lower-outboardholesoftheright,reartankstrap
(Figure20).
4.Installthetankstraphardwarethatyouremovedin1
tosecurethestrapstothetank.
Note:Ensurethatthesquareportionofthecarriage
boltsareseatedinthesquareopeninginthetankstraps.
Note:Makesurethatthestrapsareushtothetank.
Donotovertightentankstraphardware.
5.Assemblethevalvemounttothe2carriagebolts(3/8
x1inch)using2angelocknuts(Figure20).
AssemblingthePressureFilterand
RinsePump
Note:ApplyPTFEtapetothethreadsofthetaper-threaded
ttingsusedinthesprayerandrinsesystems.
1.Assemblenipple(1/2inchNPTx1/2inch)into
theinletofthepressurelterassemblyandthe
straight-barbedtting(1/2inchNPTx1/2inch)into
theoutlet(Figure21).
Note:Thearrowatthetopofthepressurelter
pointstotheoutletsideofthelterhead.
12

1
2
3
g024704
Figure21
1.Straight-barbedtting(1/2
inchNPTx1/2inch)
3.Nipple(1/2inchNPTx1/2
inch)
2.Pressurelter
2.Assemblethepressure-lterassemblyontotherinse
pumpatthenipple(Figure22).
Note:Whenthenippleistight,ensurethatthelter
andpumparealignedvertically.
12
g025034
Figure22
1.Pressure-lterassembly2.Rinsepump
3.Securetherinsepumpandrinsepumpmounting
brackettothevalvemount(Figure23)withthe4
bolts(1/4x1-3/4inch),4washers(1/4inch),and4
serrated-angenuts(1/4inch).
12345
7
6g025042
8
Figure23
1.Serrated-angenut(1/4
inch)
5.Rinse-pumpcover
2.Rinse-pumpmounting
bracket
6.Hairpin
3.Rinsepump7.Washer(1/4inch)
4.Bolt(1/4x1-3/4inch)8.Straight-barbedtting(1/2
inchNPTx1/2inch)
4.Installastraight-barbedtting(1/2inchNPTx1/2
inch)intotheinletportoftherinsepump.
5.Securetherinse-pumpcovertotherinse-pump
mountingbracketwiththe2hairpins.
13

5
AssemblingandMountingthe
4-WayValve
Partsneededforthisprocedure:
14-wayvalve
1Straight-barbedtting(1inchNPTx3/4inch)
290-degreebarbedtting(1inchNPTx3/4inch)
1Straight-barbedtting(3/4inchNPTx1/2inch)
1Reducertting(1inchNPTx3/4inchNPT)
1Faceplatebracket
1Valve-mountassembly
4Bolt(6mm)
4Flatwasher(6mm)
4Locknut(6mm)
2Nut(3/8inch)
2Bolt(3/8inch)
Procedure
Note:ApplyPTFEtapetothethreadsofthetaper-threaded
ttingsusedinthesprayerandrinsesystems.
1.Assemblethe90°-barbedttings,straight-barbed
tting(1inchNPTx3/4inch),reducertting,and
straight-barbedtting(3/4inchNPTx1/2inch)into
the4-wayvalveasshowninFigure24.
Important:Alignthe90°barbedttingsasshown
inFigure24.
1
2
4
3
5
g024698
Figure24
1.90°barbedtting(1inch
NPTx3/4inch)
4.4-wayvalve
2.Straight-barbedtting(1
inchNPTx3/4inch)
5.Straight-barbedtting(3/4
inchNPTx1/2inch)
3.Reducertting(1inch
NPTx3/4inchNPT)
2.Insert4bolts(6x16mm)and4washers(6mm)into
theslotsofthe4-wayvalve(Figure25).
Figure25
1.4-wayvalve3.Washer(6mm)
2.Bolt(6x16mm)
3.Assemblethe4-wayvalveontothevalvemount(Figure
26)with4locknuts(6mm).
1
2
34
g024703
Figure26
1.Locknut(6mm)3.Washer
2.4-wayvalve4.Bolt
4.Installthefaceplatebracketontothevalve-mount
assembly(Figure27)with2angebolts(5/16x1inch)
and2angelocknuts(5/16inch).
14

1
2
3
g024700
Figure27
1.Flangelocknuts(5/16
inch)
3.Faceplatebracket
2.Flangebolts(5/16x1
inch)
6
InstallingtheRinse-Pump
Switch,PumpConnectors,
andFuse
Partsneededforthisprocedure:
1Fuse,40-amp
1Dashswitch
InstallingtheRinse-PumpSwitch
1.Tilttheoperator’sseatforwardandsecureitwiththe
proprod(Figure28).
Figure28
1.Proprod(operator’sseat)4.Carriagebolt
2.Flangedlocknut5.Positivebatterycable
3.Positivebatteryterminal
2.Removetheangedlocknut,carriagebolt,andpositive
batterycablefromthebattery(Figure28).
3.Locatetheplugwhereyouwillinstalltherinse-tank
switchattheleftsideoftheconsole(Figure29).
Note:Itistherstplugtotherightofthelockoutkey.
12
G022218
Figure29
1.Holeindash2.3-positionrockerswitch
(8-pin)
4.Removetheplugfromthesideoftheconsole(Figure
29).
5.Frombelowtheconsole,locatethe8-socketelectrical
connectorlabeled“RinseTank”inthemainharness.
15

6.Removetheplastictiethatsecurestherinsetank
connectortothewiringbundleandroutetheconnector
totheopeningthatyoumadeintheconsole.
7.Throughtheopeningintheconsole,connectthe8-pin
connectorofthe3-positionrockerswitchintothe
8-socketrinsetankconnector(Figure29).
8.Pushtheswitchintotheopeningintheconsoleuntil
theswitchsnapsintoposition.
ConnectingtheRinsePumpConnector
1.Alignthe2-socketelectricalconnectorofthewiring
harnessforthemachinewiththe2-pinelectrical
connectorfortherinsepump(Figure30).
Figure30
1.2-socketelectrical
connector(machinewiring
harness)
2.2-pinelectricalconnector
(rinse-pumpharness)
2.Pressthe2connectorstogetheruntilthelatchinthe
2-socketconnectorsnapssecurely(Figure30).
InstallingtheFuse
1.Atthefuseblock,removethe30ampfuse(Figure31).
Figure31
2.Atthesamesocketthatyouremovedthe30ampfuse,
inserta40ampfuse(Figure31).
3.Connectthepositivebatterycabletothebattery
(Figure28).
4.Lowertheoperator’sseat(Figure28).
7
InstallingtheBallValveand
MountingAssembly
Partsneededforthisprocedure:
1Ballvalve
2Straight-barbedtting(1-1/4inchNPTx3/4inch)
1Valve-mountbracket
2Hex-headbolt(5/16x5/8inch)
2Hex-headbolt(6x16mm)
2Locknut(6mm)
Procedure
Note:ApplyPTFEtapetothethreadsofthetaper-threaded
ttingsusedinthesprayerandrinsesystems.
1.Attheboom-mountingplatefortherightframe
channelofthemachine,measurerearward15.2cm(6
inches)andmarkalineacrosstherightboommount
thatsupportsthecenter-boomsection(Figure32).
16

Figure32
1.Right-boommount
(supportingthecenter
boomsection)
5.15.2cm(6inch)
2.Ball-valvebracket6.Mountingplate(rightframe
channel)
3.Drilland6.5mm(1/4inch)
drillbit
7.Rearofthemachine
4.Line
2.Centertheholesoftheballvalvebrackettotheline
thatyoumarkedinstep1.andcenterthebrackettothe
acrossrightboommount(Figure32).
Note:Usetheballvalvebracketforadrillingtemplate.
3.Marktheholesinthebracketontotherightboom
mountandcenterpunchthemarks.
4.Usingadrillanda6.5mm(1/4inch)drillbit,drill2
holesintotheframe(Figure32).
5.Assembletheballvalvetotheballvalvebracket(Figure
33)with2bolts(5/16x5/8inch).
1
2
3
4
3
g024826
Figure33
1.Bolt(5/16x5/8inch)3.Straight-barbedtting
(1-1/4inchNPTx3/4inch)
2.Ballvalvebracket4.Ballvalve
6.Installtheballvalveandvalvemountbrackettothe
machinewith2hex-headbolts(6x16mm)and2
angenuts(6mm)(Figure34).
1
2
g024828
Figure34
1.Hex-headbolt(6x16mm)2.Locknut(6mm)
17

8
InstallingtheUpperTee
Assembly
Partsneededforthisprocedure:
1Inlethose2.5x66cm(1x26inch)
2Hoseclamp
290°hubtting
4LargeO-ring
1T-Fitting(upper)
3Retainer
1Reducerhub
1SmallO-ring
1Transferhose1.9x61cm(3/4x24inch)
1Hubconnector
RemovingtheInletHose
1.Removetheangeclamp,gasket,angedelbow ,and
inlethosefromthepressurelterhead(AofFigure35).
Note:Retainthegasketandangeclampfor
installationlater.
Figure35
1.Inlethoseassembly5.Pressurelterhead
2.Flangedelbow(machine)6.Retainer
3.Flangeclamp7.LowerT-tting
4.Gasket8.Straight-hubtting(inlet
hose)
2.Removetheretainerthatsecuresthestraight-hub
ttingoftheinlethosetothelowerT-ttingofthe
sprayersystemandremovetheinlethosefromthe
machine(BofFigure35)
Note:RetaintheretainerforinstallationinInstalling
theUpperT-ttingandInletHose(page20).
3.Removetheangedelbowandhoseclampfromthe
inlethose(Figure35).
Note:Retaintheangedelbowandhoseclamp;
discardtheoldinlethoseandstraight-barbedtting.
18

AssemblingtheUpperT-tting,Inlet
HoseandBallValveHose
Note:Toinsertthebarbedttingintothehosemoreeasily,
applyalightcoatofanon-petroleum-basedlubricant,suchas
vegetableoiltothebarbedendofthetting.
1.Inserttheangedelbowthatyouremovedinstep3of
RemovingtheInletHose(page18)intotheinlethose
2.5x66cm(1x26inch)andsecurethettingwiththe
clampthatyouretained(Figure36)
Figure36
1.Flangedelbow(machine)5.O-ring
2.Hoseclamp6.UpperT-tting(kit)
3.Inlethose2.5x66cm(1
x26inch)
7.Retainer
4.90°hubtting
2.Insertthebarbedendofa90°hubttingintotheother
endoftheinlethoseandsecureitwithahoseclampas
showninFigure36.
Note:Alignthefaceoftheelbowwiththefaceof
the90°hubtting.
3.AssembleanO-ringintotheO-ringgrooveofthe90°
hubtting(Figure36)
4.Insertthehubofthe90°ttingintooneendofthe
upperT-tting(Figure36)andsecurethehubtting
theT-ttingwitharetainer.
5.InstallthelargeO-ringintotheO-ringgrooveofthe
reducerhubandthesmallO-ringintotheO-ring
grooveofthe90°hubtting(Figure37).
Figure37
1.O-ring(large)5.90°hubtting
2.Reducerhub6.Retainer
3.Transferhose1.9x61cm
(3/4x24inch)
7.O-ring(small)
4.Hoseclamp
6.Installthe90°hubttingintothereducerhuband
securethettingswitharetainer(Figure37).
7.Assembletransferhose1.9x61cm(3/4x24inch)
ontothebarbedendofa90°hubttingintoandsecure
thehoseandttingwithahoseclamp(Figure37).
19

InstallingtheUpperT-ttingandInlet
Hose
1.Installthe2largeO-ringsintotheO-ringgroovesat
eitherendofthehubconnector(Figure38)
Figure38
1.Retainer3.Hubconnector
2.LowerT-tting(machine)4.LargeO-rings
2.RoutetheinletandupperT-ttingthatyouassembled
inAssemblingtheUpperT-tting,InletHoseandBall
ValveHose(page19)asshowninFigure39.
Figure39
1.Inlethose3.Retainer
2.UpperT-tting
3.InstalltheupperT-ttingontothehubconnector
andsecurethettingandconnectorwiththeretainer
(Figure39)thatyouremovedinstep2ofRemoving
theInletHose(page18).
4.Aligntheangedelbowandathegasketthatyou
removedSecuretheangedelbowthehosewiththe
hoseclamp(Figure40)thatyouremovedin3of
RemovingtheInletHose(page18).
Figure40
1.Flangedclamp3.Flange(pressurelter
head)
2.Gasket4.Flange(90°tting—inlet
hose)
5.Securetheinlethosetothepressurelterheadwiththe
gasketandangedclamp(Figure40)thatyouremoved
in1ofRemovingtheInletHose(page18).
20
