Toro 04651 User manual

FormNo.3397-913RevC
8-Blade,11-Blade,and14-Blade
DPACuttingUnit
ForGreensmaster®3300or3400Series
TractionUnit
ModelNo.04651—SerialNo.316000001andUp
ModelNo.04653—SerialNo.316000001andUp
ModelNo.04655—SerialNo.316000001andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3397-913*C

ThisproductcomplieswithallrelevantEuropean
directives.Fordetails,pleaseseetheDeclarationof
Incorporation(DOI)atthebackofthispublication.
Introduction
Thiscuttingunitisdesignedforcuttingturfongreens
andsmallfairwaysofgolfcourses.Usingthisproduct
forpurposesotherthanitsintendedusecouldprove
dangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.Toro.comforproductsafetyandoperation
trainingmaterials,accessoryinformation,helpnding
adealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorT oroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberplate(if
equipped)toaccesswarranty,parts,andother
productinformation.
g292456
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................3
GeneralSafety...................................................3
CuttingUnitSafety..............................................3
BladeSafety.......................................................3
SafetyandInstructionalDecals..........................4
Setup........................................................................5
InstallingtheRoller.............................................5
AdjustingtheCuttingUnit...................................5
ProductOverview.....................................................6
Specications....................................................6
Attachments/Accessories...................................6
Operation..................................................................6
AdjustingtheCuttingUnit...................................6
Maintenance............................................................11
SupportingtheCuttingUnit................................11
ServicingtheBedbar.........................................11
BedknifeSpecications....................................13
BacklappingtheCuttingUnit.............................15
©2019—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

Safety
Thismachinehasbeendesignedinaccordancewith
ENISO5395:2013andANSIB71.1-2017.
GeneralSafety
Thisproductiscapableofamputatinghandsandfeet.
Alwaysfollowallsafetyinstructionstoavoidserious
personalinjury.
•Readandunderstandthecontentsofthis
Operator’sManualbeforestartingthemachine.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Donotputyourhandsorfeetnearmoving
componentsofthemachine.
•Donotoperatethemachinewithoutallguards
andothersafetyprotectivedevicesinplaceand
functioningproperlyonthemachine.
•Keepclearofanydischargeopening.
•Keepbystandersandchildrenoutoftheoperating
area.Neverallowchildrentooperatethemachine.
•Beforeyouleavetheoperator’sposition,dothe
following:
–Parkthemachineonalevelsurface.
–Lowerthecuttingunit(s).
–Disengagethedrives.
–Engagetheparkingbrake(ifequipped).
–Shutofftheengineandremovethekey.
–Waitforallmovementtostop.
Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol,which
meansCaution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
CuttingUnitSafety
•Thecuttingunitisonlyacompletemachinewhen
installedonatractionunit.Readthetraction
unitOperator’sManualcarefullyforcomplete
instructionsonthesafeuseofthemachine.
•Stopthemachine,removethekey(ifequipped),
andwaitforallmovementtostopbeforeinspecting
theattachmentafterstrikinganobjectorifthere
isanabnormalvibrationinthemachine.Makeall
necessaryrepairsbeforeresumingoperation.
•Keepallpartsingoodworkingconditionandall
hardwaretightened.Replaceallwornordamaged
decals.
•Useonlyaccessories,attachments,and
replacementpartsapprovedbyToro.
BladeSafety
Awornordamagedbladecanbreak,andapieceof
thebladecouldbethrowntowardyouorbystanders,
resultinginseriouspersonalinjuryordeath.
•Inspectthebladeperiodicallyforwearordamage.
•Usecarewhencheckingtheblades.Wrapthe
bladesorweargloves,andusecautionwhen
servicingtheblades.Onlyreplaceorsharpenthe
blades;neverstraightenorweldthem.
•Onmulti-bladedmachines,takecareasrotating1
bladecancauseotherbladestorotate.
3

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal137-9706
137-9706
1.Cuttinghazardofthehandorfoot—shutofftheengine,
removethekeyordisconnectthesparkplug,waitforall
movingpartstostop,andreadtheOperator’sManual
beforeperformingmaintenance.
4

Setup
MediaandAdditionalParts
DescriptionQty.Use
Operator'sManual1
PartsCatalog(notincluded)—refertothe
includedpostcardforinformationonobtaining
thePartsCatalog
–Reviewthematerialandsaveitinanappropriateplace.
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
InstallingtheRoller
Thecuttingunitisshippedwithoutafrontroller.
ObtainarollerfromyourauthorizedTorodistributor
andinstallitonthecuttingunit,asfollows:
1.Removetheplowboltandangelocknut
securingoneoftheheight-of-cutarmstothe
cuttingunitsideplate(Figure3).
g292580
Figure3
1.Height-of-cutarm4.Flangelocknut
2.Adjustingscrew5.Roller-mountingscrew
3.Plowbolt
2.Loosentheroller-mountingscrewsinthe
height-of-cutarms(Figure3).
3.Slidetherollershaftintotheheight-of-cutarm
ontheoppositeendofthecuttingunit(Figure3).
4.Slidetheheight-of-cutarmontotherollershaft
(Figure3).
5.Looselysecuretherollertothecuttingunitwith
theheight-of-cutarmandfastenerspreviously
removed(Figure3).
6.Centertherollerbetweentheheight-of-cutarms.
7.Tightentheroller-mountingscrews(Figure3).
8.Adjusttothedesiredheight-of-cutandtighten
theheight-of-cutarmmountingfasteners.
AdjustingtheCuttingUnit
1.Supportthecuttingunit;refertoSupportingthe
CuttingUnit(page11).
2.Adjustthebedknifetothereel.
3.Adjusttherearrollerheight.
4.Adjusttheheightofcut.
5.Adjustthecut-offbar.
RefertoAdjustingtheCuttingUnit(page5)
forcompleteinstructionsforperformingthese
adjustments.
5

ProductOverview
Specications
ModelNumberWeight
0465132kg(71lb)
0465334kg(74lb)
0465535kg(77lb)
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedToro
distributororgotowww.Toro.comforalistofall
approvedattachmentsandaccessories.
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
Operation
RefertoyourtractionunitOperator’sManualfor
detailedoperationinstructions.Beforeusingthe
cuttinguniteachday,adjustthebedknife;referto
AdjustingtheBedknife-to-ReelContact(page6).
Testthequalityofcutbycuttingatestswathbefore
usingthecuttingunittoensurethatthenishedcut
iscorrect.
AdjustingtheCuttingUnit
AdjustingtheBedknife-to-Reel
Contact
AdjustingtheBedknifeDaily
Priortomowingeachday,orasrequired,verifyproper
bedknife-to-reelcontact.Performthisprocedure
eventhoughthequalityofcutisacceptable.
1.Lowerthecuttingunitsontoahardsurface,shut
offtheengine,andremovetheignitionkey.
2.Slowlyrotatethereelinareversedirection,
listeningforreel-to-bedknifecontact.
•Ifnocontactisevident,adjustthebedknife
asfollows:
A.Turnthebedbaradjustingscrews
clockwise(Figure4),1clickatatime,
untilyoufeelandhearlightcontact.
Note:Thebedbaradjustingscrews
havedetentscorrespondingto0.018
mm(0.0007inch)bedknifemovement
foreachindexedposition.
g026076
Figure4
1.Bedbaradjustingscrew
2.Bedbar-adjusting-screwnut(2)
6

B.Insertalongstripofcuttingperformance
paperbetweenthereelandbedknife,
perpendiculartothebedknife(Figure5),
thenslowlyrotatethereelforward;it
shouldcutthepaper;ifnot,repeatsteps
AandBuntilitdoes.
•Ifexcessivecontact/reeldragisevident,
backlap,refacethefrontofthebedknife,or
grindthecuttingunittoachievethesharp
edgesneededforprecisioncutting(Referto
theToroManualforSharpeningReeland
RotaryMowers,FormNo.09168SL).
Important:Lightcontactispreferredatall
times.Ifyoudonotmaintainlightcontact,
thebedknife/reeledgeswillnotsufciently
self-sharpen,anddullcuttingedgeswill
resultafteraperiodofoperation.Ifyou
maintainexcessivecontact,bedknife/reel
wearwillbeaccelerated,unevenwearcan
result,andthequalityofcutmaydecline.
Note:Asthereelbladescontinuetorunagainst
thebedknife,aslightburrwillappearonthefront
cuttingedgesurfacealongthefulllengthofthe
bedknife.Occasionallyrunaleacrossthefront
edgetoremovethisburrtoimprovecutting.
Afterextendedrunning,aridgewilleventually
developatbothendsofthebedknife.Round
offthesenotchesorlethemushwiththe
cuttingedgeofthebedknifetoensuresmooth
operation.
AdjustingtheBedknifetotheReel
Usethisprocedureduringinitialcutting-unitsetupand
aftergrinding,backlapping,ordisassemblingthereel.
Thisisnotadailyadjustment.
1.Positionthecuttingunitonaat,levelwork
surface.
2.Tipthecuttingunittoexposethebedknifeand
reel.
Note:Ensurethatthenutsonthebackofthe
bedbaradjustingboltsarenotrestingonthe
worksurface(Figure12).
3.Rotatethereelsothat1ofthebladescrosses
thebedknifeedgebetweentherstandsecond
bedknifeboltheadslocatedontherightsideof
thecuttingunit.
4.Makeanidentifyingmarkonthebladewhereit
crossesthebedknifeedge.
Note:Thiswillmakelateradjustmentseasier.
5.Inserta0.05mm(0.002inch)shim(T oroPart
No.125-5611)betweenthebladeandthe
bedknifeedgeatthepointmarkedinstep4.
6.Turntherightbedbaradjustingbolt(Figure4)
untilyoufeellightpressureontheshimwhen
slidingitside-to-side.Removetheshim.
7.Fortheleftsideofthecuttingunit,slowlyrotate
thereelsothattheclosestbladecrossesthe
bedknifeedgebetweentherstandsecondbolt
heads.
8.Repeatsteps4through6fortheleftsideofthe
cuttingunitandleftbedbaradjustingbolt.
9.Repeatsteps5and6untilthereislightpressure
atthecontactpointsonboththeleftandright
sidesofthecuttingunit.
10.Toobtainlightcontactbetweenthereeland
bedknife,turneachbedbaradjustingbolt
clockwise3clicks.
Note:Eachclickonthebedbaradjustingbolt
movesthebedknife0.018mm(0.0007inches).
Donotovertightentheadjustingbolts.
Turningtheadjustingboltclockwisemoves
thebedknifeedgeclosertothereel.Turning
theadjustingboltcounterclockwisemovesthe
bedknifeedgeawayfromthereel.
11.Insertalongstripofcuttingperformancepaper
(ToroPartNo.125-5610)betweenthereeland
bedknife,perpendiculartothebedknife(Figure
5),thenslowlyrotatethereelforward;itshould
cutthepaper;ifnot,turneachbedbaradjusting
boltclockwise1clickandrepeatthisstepuntil
itcutsthepaper.
7

g014411
Figure5
Note:Ifexcessivecontact/reeldragisevident,
backlap,refacethefrontofthebedknife,orgrind
thecuttingunittoachievethesharpedgesneeded
forprecisioncutting(RefertotheToroManualfor
SharpeningReelandRotaryMowers,FormNo.
09168SL).
AdjustingtheRear-RollerHeight
Dependingonyourdesiredheight-of-cutrange,you
needtoadjusttherear-rollerbrackets(Figure6or
Figure7)totheloworhighposition:
•Positionthespacerabovethesideplate-mounting
ange(factorysetting)whentheheight-of-cut
settingsrangefrom1.5mmto6mm(1/16inchto
1/4inch)asshowninFigure6.
g014404
Figure6
1.Spacer3.Rollerbracket
2.Sideplate-mountingange
•Positionthespacerbelowthesideplate-mounting
angewhentheheight-of-cutsettingsrangefrom
3mmto25mm(1/8inchto1inch)asshownin
Figure7.
g014405
Figure7
1.Sideplate-mountingange3.Rollerbracket
2.Spacer
1.Raisetherearofthecuttingunitandplacea
blockunderthebedknife.
2.Removethe2nutssecuringeachrollerbracket
andspacertoeachsideplatemountingange.
3.Lowertherollerandboltsfromthesideplate
mountingangesandspacers.
4.Placethespacersontotheboltsaboveorbelow
therollerbrackets,asrequired(Figure6or
Figure7).
5.Securetherollerbracketandspacerstothe
undersideofthemountingangeswiththenuts
previouslyremoved.
Note:Thepositionoftherearrollertothereel
iscontrolledbythemachiningtolerancesofthe
assembledcomponentsandparallelingisnot
required.
AdjustingtheHeightofCut
Usethefollowingcharttodeterminewhichbedknifeis
bestsuitedforthedesiredheightofcut.
BedknifePartNo.Height-of-Cut
Edgemax
Micro-cut
(Standard)
115-18801.5to4.7mm(0.062to
0.188inch)
Edgemax
Tournament
(Optional)
115-18813.1to12.7mm(0.125to
0.500inch)
Micro-cut
(Optional)
93-42621.5to4.7mm(0.062to
0.188inch)
Tournament
(Optional)
93-42633.1to12.7mm(0.125to
0.500inch)
Extended
Micro-cut
(Optional)
108-43031.5to4.7mm(0.062to
0.188inch)
Extended
Tournament
(Optional)
108-43023.1to12.7mm(0.125to
0.500inch)
8

Low-cut
(Optional)
93-42644.7to25.4mm(0.188to
1.00inch)
High-cut
(Optional)
94-63927.9to25.4mm(0.312to
1.00inch)
Fairway
(Optional)
63-86109.5to25.4mm(0.375to
1.00inch)
Fairway
EdgeMax
(optional)
137-08799.5to25.4mm(0.375to
1.00inch)
Note:Forheightsofcutgreaterthan9.5mm(0.375
inch),installthehigh-height-of-cutkit.
AdjustingtheHeight-of-CutGauge
Beforeadjustingtheheightofcut,settheheight-of-cut
gaugeasfollows:
1.Loosenthenutonthegaugebarandsetthe
adjustingbolttothedesiredheightofcut(Figure
8).
Note:Thedistancebetweenthebottomofthe
boltheadandthefaceofbaristheheightofcut.
g000489
Figure8
1.Gaugebar3.Nut
2.Height-adjustingbolt
2.Tightenthenut.
AdjustingtheHeightofCut
1.Loosenthelocknutssecuringtheheight-of-cut
armstothecutting-unitsideplates(Figure9).
g278333
Figure9
1.Height-of-cutarm3.Adjustingbolt
2.Flangelocknut
2.Hooktheboltheadoftheheight-of-cutgauge
ontotherightsideofthecuttingedgeofthe
bedknifeandresttherearendofthebaronto
therearoftheroller(Figure10).
g014408
Figure10
1.Gaugebar
3.Rotatetheadjustingboltuntiltherollercontacts
thefrontofthegaugebar.
4.Repeatsteps2and3fortheleftside.
5.Adjustbothendsoftherolleruntiltheentire
rollerisparalleltothebedknife.
Important:Whensetproperly,therear
andfrontrollerswillcontactthegauge
barandtheboltwillbesnugagainstthe
bedknife.Thisensuresthattheheightofcut
isidenticalatbothendsofthebedknife.
6.Tightenthenutstosecuretheadjustment
enoughtoremoveplayfromthewasher.
9

7.Verifythattheheight-of-cutsettingiscorrect;
repeatthisprocedureifnecessary.
AdjustingtheCut-OffBar
Adjustthecut-offbartoensurethattheclippingsare
cleanlydischargedfromthereelarea,asfollows:
Note:Thebarisadjustabletocompensatefor
changesinturfconditions.Adjustthebarcloserto
thereelwhentheturfisextremelydry.Bycontrast,
adjustthebarfurtherawayfromthereelwhentheturf
conditionsarewet.Thebarshouldbeparalleltothe
reeltoensureoptimumperformance.Adjustitafter
thereelissharpenedonareelgrinder.
1.Loosentheboltssecuringthetopbar(Figure
11)tothecuttingunit.
g014643
Figure11
1.Cut-offbar
2.Inserta1.5mm(0.060inch)feelergauge
betweenthetopofthereelandthebarthen
tightenthebolts.
Important:Ensurethatthebarandreelare
equaldistanceapartacrossthecomplete
reel.
Note:Adjustthegapasneededforyourturf
conditions.
10

Maintenance
SupportingtheCuttingUnit
Wheneveryouneedtotipthecuttingunittoexpose
thebedknife/reel,propuptherearofthecutting
unittoensurethatthenutsonthebackendofthe
bedbar-adjustingboltsarenotrestingonthework
surface(Figure12).
g014596
Figure12
1.Prop(notprovided)2.Bedbar-adjusting-screw
nut(2)
ServicingtheBedbar
Onlyaproperlytrainedmechanicshouldservicethe
bedbarandbedknifetopreventdamagetothereel,
bedbar,orbedknife.Ideally,takethecuttingunitto
yourauthorizedT orodistributorforservice.Referto
theServiceManualforyourtractionunitforcomplete
instructions,specialtools,anddiagramsforservicing
thebedknife.Shouldyoueverneedtoremove
orassemblethebedbaryourself,instructionsare
providedbelow,asarethespecicationsforservicing
thebedknife.
Important:Alwaysfollowthebedknife
proceduresdetailedinyourServiceManualwhen
servicingthebedknife.Failuretoinstallandgrind
thebedknifecorrectlycanleadtodamagetothe
reel,bedbar,orbedknife.
RemovingtheBedbar
1.Turnthebedbaradjustingscrew,
counterclockwise,tobackthebedknife
awayfromthereel(Figure13).
g014641
Figure13
1.Bedbar-adjustingscrew3.Bedbar
2.Spring-tensionnut4.Washer
2.Backoutthespring-tensionnutuntilthewasher
isnolongertensionedagainstthebedbar
(Figure13).
3.Oneachsideofthemachine,loosenthelocknut
securingthebedbarbolt(Figure14).
11

g014409
Figure14
1.Bedbarbolt2.Locknut
4.Removeeachbedbarboltallowingthebedbar
tobepulleddownwardandremovedfromthe
cuttingunit(Figure14).
Accountforthe2nylonwashersand1steel
washeroneachendofthebedbar(Figure15).
g020056
Figure15
1.Bedbarbolt3.Nut
2.Steelwasher4.Nylonwasher
AssemblingtheBedbar
1.Installthebedbar,positioningthemountingears
betweenthewashersandthebedbar-adjusting
screw(Figure13).
2.Securethebedbartoeachsideplatewiththe
bedbarbolts(nutsonbolts)and3washers(6
total).
3.Positionanylonwasheroneachsideofthe
side-plateboss.Placeasteelwasheroutside
eachofthenylonwashers(Figure15).
4.Torquethebedbarboltsto27to36N∙m(240to
320inch-lb).
5.Tightenthelocknutsuntilyouremovetheend
playfromsteelwashers,butyouareableto
rotatethembyhand.Thewashersontheinside
mayhaveagap.
Important:Donotovertightenthelocknuts
ortheywilldeectthesideplates.
6.Tightenthespringtensionnutuntilthespringis
collapsed,thenbackitoff1/2turn(Figure16).
g016470
Figure16
1.Spring-tensionnut2.Spring
7.Adjustthebedknifetothereel;refertoAdjusting
theBedknife-to-ReelContact(page6).
12

BedknifeSpecications
InstallingtheBedknife
1.Removetherust,scale,andcorrosionfromthe
bedbarsurfaceandapplyathinlayerofoilto
thebedbarsurface.
2.Cleanthescrewthreads.
3.Applynever-seizecompoundtothescrewsand
installthebedknifetothebedbar.
g255045
Figure17
1.Bedbar3.Screw
2.Bedknife
4.Torquethe2outerscrewsto1N∙m(10in-lb).
5.Workingformthecenterofthebedknife,torque
thescrewsto23to28N∙m(200to250in-lb).
g255046
Figure18
1.Bednifescrewtool3.Torqueto23to28N∙m
(200to250in-lb).
2.Installandtorquethese
rstto1N∙m(10in-lb).
6.Grindthebedknife.
PreparingtheReelforGrinding
1.Ensurethatallcuttingunitcomponentsarein
goodconditionandcorrectanyissuesbefore
grinding.
2.Followthereelgrindermanufacturer’s
instructionstogrindthecuttingreeltothe
followingspecications.
ReelGrindingSpecications
NewReelDiameter128.5mm(5.06inches)
ReelDiameterServiceLimit114.3mm(4-1/2inches)
BladeReliefAngle30°±5°
BladeLandWidth1.0mm(0.04inches)
BladeLandWidthRange.8to1.2mm(0.03to0.05
inches)
ReelDiameterTaperService
Limit
0.25mm(1/100inch)
13

Relief-GrindingtheReel
Thenewreelhasalandwidthof.8to1.2mm(0.03to
0.05inches)anda30°reliefgrind.
Whenthelandwidthgetslargerthan3mm(0.120
inch)wide,dothefollowing:
1.Applya30°reliefgrindonallreelbladesuntil
thelandwidthis.76mm(0.030inch)wide
(Figure19.
g278332
Figure19
1.30°2..76mm(0.030inch)
2.Spingrindthereeltoachieve<0.025mm(0.001
inch)reelrun-out.
Note:Thiscausesthelandwidthtogrow
slightly.
3.Adjustthecuttingunit;refertoyourcuttingunit
Operator’sManual.
Note:T oextendthelongevityofthesharpnessofthe
edgeofthereelandthebedknife—aftergrindingthe
reeland/orthebedknife—checkthereeltobedknife
contactagainaftercuttingattheendofeachday,as
anyburrswillberemoved,whichmaycreateimproper
reeltobedknifeclearanceandthusacceleratewear.
BedknifeGrindingSpecications
g032182
Figure20
1.Reliefangle4.Frontface
2.Topface5.Frontangle
3.Removeburr
Standardbedknifereliefangle3°minimum
Extendedbedknifereliefangle7°minimum
FrontAngleRange13°to17°
14

CheckingtheTopGrindAngle
Theanglethatyouusetogrindyourbedknivesis
veryimportant.
Usetheangleindicator(T oroPartNo.131-6828)and
theangle-indicatormount(T oroPartNo.131-6829)to
checktheanglethatyourgrinderproducesandthen
correctforanygrinderinaccuracy.
1.Placetheangleindicatoronthebottomsideof
thebedknifeasshowninFigure21.
g034113
Figure21
1.Bedknife(vertical)2.Angleindicator
2.PresstheAltZerobuttonontheangleindicator.
3.Placetheangle-indicatormountontheedge
ofthebedknifesothattheedgeofthemagnet
mateswiththeedgeofthebedknife(Figure22).
Note:Thedigitaldisplayshouldbevisiblefrom
thesamesideduringthisstepasitwasinstep1.
g034114
Figure22
1.Angle-indicatormount3.Bedknife
2.Edgeofthemagnetmated
withtheedgeofthe
bedknife
4.Angleindicator
4.Placetheangleindicatoronthemountasshown
inFigure22.
Note:Thisistheanglethatyourgrinder
produces,andshouldbewithin2degreesofthe
recommendedtopgrindangle.
BacklappingtheCutting
Unit
DANGER
Contactwiththereelorothermovingparts
canresultinpersonalinjury.
Keepngers,hands,andclothingawayfrom
thereelsorothermovingparts.
•Stayawayfromthereelwhilebacklapping.
•Neveruseashort-handledpaintbrushfor
backlapping.Long-handledbrushesare
availablefromyourlocalauthorizedToro
distributor.
1.Positionthemachineonaclean,levelsurface,
lowerthecuttingunits,stoptheengine,engage
theparkingbrake,andremovetheignitionkey.
2.Removethereelmotorsfromthecuttingunits
anddisconnectandremovethecuttingunits
fromtheliftarms.
3.Connectthebacklappingmachinetothecutting
unitbyinsertingapieceof3/8inchsquarestock
intothesplinedcouplingintheendofthecutting
unit.
Note:Additionalinstructionsandprocedures
onBacklappingareavailableinyourtraction
unitOperator’sManualandtheToroSharpening
ReelandRotaryMowersManual,FormNumber
80-300PT.
Note:Forabettercuttingedge,runale
acrossthefrontfaceofthebedknifeandreel
whenthelappingoperationiscompleted.This
willremoveanyburrsorroughedgesthatmay
havebuiltuponthecuttingedge.
15

Notes:

Notes:

DeclarationofIncorporation
TheT oroCompany,8111LyndaleAve.South,Bloomington,MN,USAdeclaresthatthefollowingunit(s)
conform(s)tothedirectiveslisted,wheninstalledinaccordancewiththeaccompanyinginstructionsontocertain
ToromodelsasindicatedontherelevantDeclarationsofConformity.
ModelNo.SerialNo.ProductDescriptionInvoiceDescriptionGeneralDescriptionDirective
04651316000001andUp8-BladeDPAReelMower8BLADEDPA-TRIFLEX8-BladeDPAReelMower2006/42/EC,
2000/14/EC
04653316000001andUp11-BladeDPAReelMower11BLADEDPA-TRIFLEX11-BladeDPAReelMower2006/42/EC,
2000/14/EC
04655316000001andUp14-BladeDPAReelMower14BLADEDPA-TRIFLEX14-BladeDPAReelMower2006/42/EC,
2000/14/EC
RelevanttechnicaldocumentationhasbeencompiledasrequiredperPartBofAnnexVIIof2006/42/EC.
Wewillundertaketotransmit,inresponsetorequestsbynationalauthorities,relevantinformationonthispartly
completedmachinery.Themethodoftransmissionshallbeelectronictransmittal.
ThismachineryshallnotbeputintoserviceuntilincorporatedintoapprovedToromodelsasindicatedonthe
associatedDeclarationofConformityandinaccordancewithallinstructions,wherebyitcanbedeclaredin
conformitywithallrelevantDirectives.
Certied:AuthorizedRepresentative:
MarcelDutrieux
ManagerEuropeanProductIntegrity
ToroEuropeNV
Nijverheidsstraat5
2260Oevel
Belgium
JohnHeckel
Sr.EngineeringManager
8111LyndaleAve.South
Bloomington,MN55420,USA
May28,2019

EEA/UKPrivacyNotice
Toro’sUseofYourPersonalInformation
TheToroCompany(“Toro”)respectsyourprivacy.Whenyoupurchaseourproducts,wemaycollectcertainpersonalinformationaboutyou,eitherdirectly
fromyouorthroughyourlocalT orocompanyordealer.Torousesthisinformationtofullcontractualobligations-suchastoregisteryourwarranty,
processyourwarrantyclaimortocontactyouintheeventofaproductrecall-andforlegitimatebusinesspurposes-suchastogaugecustomer
satisfaction,improveourproductsorprovideyouwithproductinformationwhichmaybeofinterest.Toromayshareyourinformationwithoursubsidiaries,
afliates,dealersorotherbusinesspartnersinconnectiontheseactivities.Wemayalsodisclosepersonalinformationwhenrequiredbylaworin
connectionwiththesale,purchaseormergerofabusiness.Wewillneversellyourpersonalinformationtoanyothercompanyformarketingpurposes.
RetentionofyourPersonalInformation
Torowillkeepyourpersonalinformationaslongasitisrelevantfortheabovepurposesandinaccordancewithlegalrequirements.Formoreinformation
aboutapplicableretentionperiodspleasecontact[email protected].
Toro’sCommitmenttoSecurity
YourpersonalinformationmaybeprocessedintheUSoranothercountrywhichmayhavelessstrictdataprotectionlawsthanyourcountryofresidence.
Wheneverwetransferyourinformationoutsideofyourcountryofresidence,wewilltakelegallyrequiredstepstoensurethatappropriatesafeguardsare
inplacetoprotectyourinformationandtomakesureitistreatedsecurely.
AccessandCorrection
Youmayhavetherighttocorrectorreviewyourpersonaldata,orobjecttoorrestricttheprocessingofyourdata.Todoso,pleasecontactusbyemail
at[email protected].IfyouhaveconcernsaboutthewayinwhichT orohashandledyourinformation,weencourageyoutoraisethisdirectlywithus.
PleasenotethatEuropeanresidentshavetherighttocomplaintoyourDataProtectionAuthority.
374-0282RevC

TheToroWarranty
Two-Yearor1,500HoursLimitedWarranty
ConditionsandProductsCovered
TheToroCompanyanditsafliate,ToroWarrantyCompany,pursuant
toanagreementbetweenthem,jointlywarrantyourT oroCommercial
product(“Product”)tobefreefromdefectsinmaterialsorworkmanship
for2yearsor1,500operationalhours*,whicheveroccursrst.This
warrantyisapplicabletoallproductswiththeexceptionofAerators
(refertoseparatewarrantystatementsfortheseproducts).Wherea
warrantableconditionexists,wewillrepairtheProductatnocosttoyou
includingdiagnostics,labor,parts,andtransportation.Thiswarranty
beginsonthedatetheProductisdeliveredtotheoriginalretailpurchaser.
*Productequippedwithanhourmeter.
InstructionsforObtainingWarrantyService
YouareresponsiblefornotifyingtheCommercialProductsDistributoror
AuthorizedCommercialProductsDealerfromwhomyoupurchasedthe
Productassoonasyoubelieveawarrantableconditionexists.Ifyouneed
helplocatingaCommercialProductsDistributororAuthorizedDealer,or
ifyouhavequestionsregardingyourwarrantyrightsorresponsibilities,
youmaycontactusat:
ToroCommercialProductsServiceDepartment
ToroWarrantyCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
952–888–8801or800–952–2740
E-mail:[email protected]
OwnerResponsibilities
Astheproductowner,youareresponsibleforrequiredmaintenanceand
adjustmentsstatedinyourOperator'sManual.Repairsforproductissues
causedbyfailuretoperformrequiredmaintenanceandadjustmentsarenot
coveredunderthiswarranty.
ItemsandConditionsNotCovered
Notallproductfailuresormalfunctionsthatoccurduringthewarranty
periodaredefectsinmaterialsorworkmanship.Thiswarrantydoesnot
coverthefollowing:
•Productfailureswhichresultfromtheuseofnon-T ororeplacement
parts,orfrominstallationanduseofadd-on,ormodiednon-T oro
brandedaccessoriesandproducts.
•Productfailureswhichresultfromfailuretoperformrecommended
maintenanceand/oradjustments.
•ProductfailureswhichresultfromoperatingtheProductinanabusive,
negligent,orrecklessmanner.
•Partsconsumedthroughusethatarenotdefective.Examplesofparts
whichareconsumed,orusedup,duringnormalProductoperation
include,butarenotlimitedto,brakepadsandlinings,clutchlinings,
blades,reels,rollersandbearings(sealedorgreasable),bedknives,
sparkplugs,castorwheelsandbearings,tires,lters,belts,andcertain
sprayercomponentssuchasdiaphragms,nozzles,andcheckvalves.
•Failurescausedbyoutsideinuence,including,butnotlimitedto,
weather,storagepractices,contamination,useofunapprovedfuels,
coolants,lubricants,additives,fertilizers,water,orchemicals.
•Failureorperformanceissuesduetotheuseoffuels(e.g.gasoline,
diesel,orbiodiesel)thatdonotconformtotheirrespectiveindustry
standards.
•Normalnoise,vibration,wearandtear,anddeterioration.Normal
“wearandtear”includes,butisnotlimitedto,damagetoseatsdueto
wearorabrasion,wornpaintedsurfaces,scratcheddecalsorwindows.
Parts
Partsscheduledforreplacementasrequiredmaintenancearewarranted
fortheperiodoftimeuptothescheduledreplacementtimeforthatpart.
Partsreplacedunderthiswarrantyarecoveredforthedurationofthe
originalproductwarrantyandbecomethepropertyofT oro.Torowillmake
thenaldecisionwhethertorepairanyexistingpartorassemblyorreplace
it.Toromayuseremanufacturedpartsforwarrantyrepairs.
DeepCycleandLithium-IonBatteryWarranty
DeepcycleandLithium-Ionbatterieshaveaspeciedtotalnumber
ofkilowatt-hourstheycandeliverduringtheirlifetime.Operating,
recharging,andmaintenancetechniquescanextendorreducetotal
batterylife.Asthebatteriesinthisproductareconsumed,theamount
ofusefulworkbetweenchargingintervalswillslowlydecreaseuntilthe
batteryiscompletelywornout.Replacementofwornoutbatteries,
duetonormalconsumption,istheresponsibilityoftheproductowner.
Note:(Lithium-Ionbatteryonly):Pro-ratedafter2years.Refertothe
batterywarrantyforadditionalinformation.
LifetimeCrankshaftWarranty(ProStripe02657Model
Only)
TheProstripewhichisttedwithagenuineToroFrictionDiscand
Crank-SafeBladeBrakeClutch(integratedBladeBrakeClutch(BBC)+
FrictionDiscassembly)asoriginalequipmentandusedbytheoriginal
purchaserinaccordancewithrecommendedoperatingandmaintenance
procedures,arecoveredbyaLifetimeWarrantyagainstenginecrankshaft
bending.Machinesttedwithfrictionwashers,BladeBrakeClutch(BBC)
unitsandothersuchdevicesarenotcoveredbytheLifetimeCrankshaft
Warranty.
MaintenanceisatOwner’sExpense
Enginetune-up,lubrication,cleaningandpolishing,replacementoflters,
coolant,andcompletingrecommendedmaintenancearesomeofthe
normalservicesToroproductsrequirethatareattheowner’sexpense.
GeneralConditions
RepairbyanAuthorizedToroDistributororDealerisyoursoleremedy
underthiswarranty.
NeitherTheToroCompanynorToroWarrantyCompanyisliablefor
indirect,incidentalorconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythiswarranty,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletion
ofrepairsunderthiswarranty.ExceptfortheEmissionswarranty
referencedbelow,ifapplicable,thereisnootherexpresswarranty.All
impliedwarrantiesofmerchantabilityandtnessforusearelimitedto
thedurationofthisexpresswarranty.
Somestatesdonotallowexclusionsofincidentalorconsequential
damages,orlimitationsonhowlonganimpliedwarrantylasts,sotheabove
exclusionsandlimitationsmaynotapplytoyou.Thiswarrantygivesyou
speciclegalrights,andyoumayalsohaveotherrightswhichvaryfrom
statetostate.
NoteRegardingEmissionsWarranty
TheEmissionsControlSystemonyourProductmaybecoveredby
aseparatewarrantymeetingrequirementsestablishedbytheU.S.
EnvironmentalProtectionAgency(EPA)and/ortheCaliforniaAirResources
Board(CARB).Thehourlimitationssetforthabovedonotapplytothe
EmissionsControlSystemWarranty.RefertotheEngineEmissionControl
WarrantyStatementsuppliedwithyourproductorcontainedintheengine
manufacturer’sdocumentation.
CountriesOtherthantheUnitedStatesorCanada
CustomerswhohavepurchasedT oroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirToroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtaining
guaranteeinformation,contactyourAuthorizedT oroServiceCenter.
374-0253RevF
This manual suits for next models
2
Table of contents
Other Toro Tractor Accessories manuals

Toro
Toro Greensmaster TriFlex 3300 Series User manual

Toro
Toro 79181 User manual

Toro
Toro Direct Drive Power Box Rake User manual

Toro
Toro 136-8545 User manual

Toro
Toro 04720 User manual

Toro
Toro 119-9604 User manual

Toro
Toro 23172 User manual

Toro
Toro 30517 Instruction Manual

Toro
Toro 22414 User manual

Toro
Toro Field Pro 604 User manual
