PAGE 1 OF 3 0514 IH-2861
πH-2861
Sofpull®automatic
paper towel diSpenSer
1-800-295-5510
uline.com
IMPORTANT SAFETY INSTRUCTIONS
MOUNTING INSTRUCTIONS
NOTE: Recommended mounting height is 44"
from the floor to bottom of dispenser.
1. Press button on top of dispenser to open cover.
(See Figure 1)
PARTS
Figure 1
Dispenser x 1
NOTE: This dispenser runs on four D-cell alkaline
batteries, which are not included with product.
NOTE: Mounting hardware is not included with
this item. When mounting dispenser, ensure
that proper mounting hardware is used for
appropriate wall composition.
TOOLS NEEDED
Drill Drill Bit Phillips Screwdriver
ATTENTION: Read all instructions before using
the towel dispensing system.
TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL
SHOCK OR INJURY TO PERSONS:
1. Close supervision is necessary when this furnishing is
used by children or disabled persons.
2. Use this furnishing only for its intended use
as described in these instructions. Do not
use attachments not recommended by the
manufacturer.
3. Never operate this furnishing if it is not working
properly, if it has been dropped or damaged, or
dropped into water. Return the furnishing to a
service center for examination and repair.
4. Never operate the furnishing with the air openings
blocked. Keep the air openings free of lint, hair and
the like.
5. Never drop or insert any foreign object into any
opening.
6. Do not use outdoors.
7. Do not operate where aerosol (spray) products are
being used or where oxygen is being administered.
8. Do not mix old and new batteries.
9. Do not mix non-rechargeable and rechargeable
batteries.

PAGE 2 OF 3 0514 IH-2861
LOADING INSTRUCTIONS
LOADING THE BATTERIES
1. To load the batteries, locate the compartment inside
and towards the bottom of the dispenser.
(See Figure 4)
2. Remove the compartment cover by sliding the cover
left to unlock.
3. Place batteries into compartment according to the
battery diagrams on the inside of the compartment.
(See Figure 5)
4. Replace battery compartment cover and slide to
the right to lock.
NOTE: Three red lights will appear on the
dispenser sensor when batteries are properly
loaded.
2. Open dispenser cover completely and hold dispenser
to ideal mounting place on wall. (See Figure 2)
3. Using a pencil, mark the four holes on the wall where
screws will be inserted. (See Figure 2)
4. Set dispenser aside and drill into wall at four marked
locations with an appropriate drill bit. (See Figure 3)
5. Hold dispenser to wall so that the holes in the wall
and the dispenser match up. Insert four screws into
previously drilled holes.
MOUNTING INSTRUCTIONS CONTINUED
Mounting
Holes
Figure 4
Figure 5
Figure 2
Figure 3

PAGE 3 OF 3 0514 IH-2861
LOADING THE PAPER TOWELS
1. With dispenser cover open, place the roll of paper
towels on the roll holder supports located inside the
dispenser. The paper must feed from underneath
the roll. (See Figure 6)
2. Push the end of the paper in between the two feed
rollers. (See Figure 7)
3. Press the blue manual feed button located on the
front of the dispenser to feed paper through.
(See Figure 8)
4. Close dispenser cover.
π CHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
OPERATION
NOTE: This Sofpull®dispenser will only function
properly if the correct Sofpull®towel (S-17238) is
placed in the dispenser.
The dispenser runs on four D-cell alkaline batteries
(included) and has a low battery indicator light.
The dispenser also features adjustable settings for paper
length (S, M, L) and time delay, which is the amount of
time between dispenses. (See Figure 8)
The dispenser features two dispensing modes:
a. An on-demand mode, where a new towel is
presented when a hand is waved in front of the
sensor. (See Figure 8)
b. A hanging towel mode, where a new towel
is dispensed as soon as the current towel is
removed from the dispenser. (See Figure 8)
LOADING INSTRUCTIONS CONTINUED
Roll Holder
Supports
Figure 6
Figure 7
Figure 8 SHEET
LENGTHDELAY MODE
S M LS M L
HANGING TOWEL
ON DEMAND
MANUAL
FEED
Sensor
