U-Line H-1229 User manual

PAGE 1 OF 5 0314 IH-1229
πH-1229
JUMBO
STORAGE SHED
1-800-295-5510
uline.com
Phillips Screwdriver
Safety Glasses
or
PARTS
Floor Panel (A) x 1 Roof Panel (E) x 1
Lock Hasp x 1
Left Side Panel (B) x 1
Header (F) x 1 #14 x .75 Screw x 32
Right Side Panel (C) x 1
Left Door Panel (G) x 1
Back Panel (D) x 1
Right Door Panel (H) x 1 Door Handle x 2
TOOLS NEEDED
Electric Drill
with Phillips Bit
NOTE: Check that all parts are included in
packaging. Select a site with level ground and
good drainage. The doors and roof function
best when the shed is level.

PAGE 2 OF 5 0314 IH-1229
Step 1:
• Snap left side panel (B) into floor panel (A).
(See Figure 1)
• Position back panel (D) but DO NOT SNAP INTO BASE.
• Interlock back panel (D) into left side panel (B).
• Snap right side panel (C) into floor panel (A).
(See Figure 2)
• Interlock back panel (D) into left side panel (C).
• With back panel interlock with grooves on side
panels, slide down and snap into floor panel.
(See Figure 3)
Step 2:
• Insert header (F) into underside of roof panel (E).
(See Figure 4)
• Use 4 screws to secure header to roof panel.
DO NOT OVERTIGHTEN SCREWS. (See Figure 5)
ASSEMBLY INSTRUCTIONS
D
B
A
Figure 1
Figure 3
C
Figure 2
F
E
Figure 4
Figure 5

PAGE 3 OF 5 0314 IH-1229
Step 3:
• Position roof assembly on top of shed walls.
(See Figure 6)
• Position the bottom hinge pin of left door panel (G)
into left hole on floor panel. (See Figure 6)
• Lift roof slightly on left side and insert left door
panel (G) top hinge pin into hole on roof panel.
(See Figure 6)
• Repeat with right door panel (H). (See Figure 6)
Step 4:
• Secure roof assembly to side panels by inserting
4 screws into dimples on the interior header (See
Figure 7) and 10 screws into the dimples around the
interior roof perimeter. (See Figure 8)
ASSEMBLY INSTRUCTIONS CONTINUED
Figure 6
H
G
Figure 7
Figure 8

PAGE 4 OF 5 0314 IH-1229
Step 4 Continued:
• Secure side and back panels to the floor panel
using 6 screws in the dimples along the bottom
interior. (See Figure 9)
Step 5:
• Attach each door handle using 4 screws.
(See Figure 10)
• Snap lock hasp through the back of the left door.
(See Figure 10)
NOTE: Shed can be locked using Uline
padlocks. (Model Number H-1391, H-1392,
H-1632, H-2061, H-2491, or H-2492.)
CARE INSTRUCTIONS
Figure 9
Lock Hasp
Figure 10
ASSEMBLY INSTRUCTIONS CONTINUED
• Periodically inspect the shed to ensure proper
assembly is maintained and site remains level.
• Clean shed using a garden hose or wash with
a mild detergent and water.
• The shed can be anchored to the ground or a
platform by drilling holes in the floor at designated
locations and securing with the proper fasteners (not
included).
CAUTION! Do not clean with a stiff brush or
abrasive cleaner. Wear safety glasses and
follow the manufacturer’s instructions when
using power tools. Do not store hot yard
equipment, grills, or other hot materials in
the shed.

PAGE 5 OF 5 0314 IH-1229
WARNING! Do not exceed 50 lbs. on any one
given wall in the shed structure.
1. Attach 2 wall anchors no more than 6 inches from
the top of the peg board using provided screws.
(See Figure 1)
2. Ensure the anchors are the same distance apart as
the wall slots in the shed. (See Figure 2)
3. Attach 2 more wall anchors to the pegboard
vertically in line with and 22" below the top anchors
using provided screws. (See Figure 2)
4. Hang the peg board by sliding the wall anchors into
the wall slots on the shed. (See Figure 2)
OPTIONAL PEGBOARD INSTALLATION INSTRUCTIONS
Figure 1
1
2
Figure 2
1. Attach 2 wall anchors
to each shelf upright
22¹⁄" inches apart
using provided screws.
(See Figure 1)
2. Slide the wall anchors
on the shelf uprights
into wall slots on the
shed. (See Figure 2)
3. Insert shelf supports in the desired locations on
the shelf uprights and lay shelf into position.
(See Figure 3)
OPTIONAL ADJUSTABLE SHELF INSTALLATION INSTRUCTIONS
22½"
1
2
Shelf Supports
Figure 2
Figure 1
Figure 3
