LEA-M8S / LEA-M8T
u-blox M8 concurrent GNSS modules
Hardware Integration Manual
Abstract
This document describes the features and specifications of the
cost
effective and high-performance LEA-M8S and LEA-M8T modules,
which feature the u-blox M8 concurrent GNSS engine
with
reception of GPS, GLONASS, BeiDou and QZSS signals.
www.u
-blox.com
UBX
-13003140 - R07

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Page 2 of 31
Document Information
Title LEA-M8S / LEA-M8T
Subtitle u-blox M8 concurrent GNSS modules
Document type Hardware Integration Manual
Document number UBX-13003140
Revision and Date R07 02-Jun-2015
Document status Production Information
Document status explanation
Objective Specification Document contains target values. Revised and supplementary data will be published later.
Advance Information Document contains data based on early testing. Revised and supplementary data will be published later.
Early Production Information Document contains data from product verification. Revised and supplementary data may be published later.
Production Information Document contains the final product specification.
This document applies to the following products:
Product name Type number ROM/FLASH version PCN reference
LEA-M8S LEA-M8S-0-00 ROM 2.01 N/A
LEA-M8T LEA-M8T-0-01 ROM 2.01 / FLASH FW 2.30 TIMRAW 1.02 UBX-15012993
u-blox reserves all rights to this document and the information contained herein. Products, names, logos and designs described herein
may in whole or in part be subject to intellectual property rights. Reproduction, use, modification or disclosure to third parties of this
document or any part thereof without the express permission of u-blox is strictly prohibited.
The information contained herein is provided “as is” and u-blox assumes no liability for the use of the information. No warranty, either
express or implied, is given, including but not limited, with respect to the accuracy, correctness, reliability and fitness for a particular
purpose of the information. This document may be revised by u-blox at any time. For most recent documents, visit www.u-blox.com.
Copyright © 2015, u-blox AG.
u-blox®is a registered trademark of u-blox Holding AG in the EU and other countries. ARM®
is the registered trademark of ARM Limited in
the EU and other countries.

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Contents
Page 3 of 31
Contents
Contents..............................................................................................................................3
1Hardware description ..................................................................................................4
1.1 Overview .................................................................................................................................................................................4
1.2 Configuration ..........................................................................................................................................................................4
1.3 Connecting power ...................................................................................................................................................................4
1.3.1 VCC: Main Supply Voltage...................................................................................................................................................4
1.3.2 V_BCKP: Backup Supply Voltage ..........................................................................................................................................4
1.3.3 VDD_USB: USB interface power supply .................................................................................................................................5
1.3.4 VCC_RF: Output Voltage RF section......................................................................................................................................5
1.3.5 V_ANT: Antenna supply .......................................................................................................................................................5
1.4 Interfaces.................................................................................................................................................................................5
1.4.1 UART ..................................................................................................................................................................................5
1.4.2 USB.....................................................................................................................................................................................5
1.4.3 Display Data Channel (DDC).................................................................................................................................................6
1.4.4 SPI (LEA-M8T ONLY) ............................................................................................................................................................6
1.4.5 TX Ready signal ...................................................................................................................................................................6
1.5 I/O pins....................................................................................................................................................................................7
Electromagnetic interference on I/O lines ...........................................................................................................................................8
2Design ...........................................................................................................................9
2.1 Pin description .........................................................................................................................................................................9
2.2 Minimal design ......................................................................................................................................................................10
2.3 Footprint and paste mask .......................................................................................................................................................10
2.4 Antenna and Antenna supervision ..........................................................................................................................................11
2.4.1 Antenna design with passive antenna.................................................................................................................................11
2.4.2 Active antenna design........................................................................................................................................................12
3Migration to u-blox M8 modules ..............................................................................18
3.1 Migrating u-blox 6 designs to a u-blox M8 module..................................................................................................................18
3.2 Hardware migration LEA-6N -> LEA-M8S ................................................................................................................................18
3.3 Hardware migration LEA-6T -> LEA-M8T.................................................................................................................................19
3.4 Software migration ................................................................................................................................................................19
4Product handling........................................................................................................20
4.1 Packaging, shipping, storage and moisture preconditioning .....................................................................................................20
4.2 Soldering ...............................................................................................................................................................................20
4.3 EOS/ESD/EMI precautions .......................................................................................................................................................23
4.4 Applications with cellular modules ..........................................................................................................................................26
Appendix ..........................................................................................................................28
Recommended parts............................................................................................................................................................................28
A.1 Design-in recommendations in combination with cellular operation .........................................................................................29
Related documents...........................................................................................................30
Revision history................................................................................................................30
Contact..............................................................................................................................31

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Hardware description
Page 4 of 31
1Hardware description
1.1 Overview
LEA-M8S and LEA-M8T are standalone GNSS positioning modules featuring the high performance u-blox M8
positioning engine. They are easy to integrate and combine exceptional positioning performance with highly
flexible power, design, and connectivity options. SMT pads allow fully automated assembly with standard pick &
place and reflow-soldering equipment for cost-efficient, high-volume production enabling short time-to-market.
For specific product features, see the LEA-M8S Data Sheet [1] and the NEO/LEA-M8T Data Sheet [2].
To determine which u-blox product best meets your needs, see the product selector tables on the u-blox
website.
1.2 Configuration
The configuration settings can be modified using UBX protocol configuration messages, more information see
the u-blox M8 Receiver Description Including Protocol Specification [3]. The modified settings remain effective
until power-down or reset. If these settings have been stored in BBR (Battery Backed RAM), then the modified
configuration will be retained, as long as the backup battery supply is not interrupted.
The configuration can be saved permanently in flash of the LEA-M8T receiver.
1.3 Connecting power
The LEA-M8S and LEA-M8T positioning modules have up to three power supply pins: VCC, V_BCKP and
VDD_USB.
1.3.1 VCC: Main Supply Voltage
The VCC pin provides the main supply voltage. During operation, the current drawn by the module can vary by
some orders of magnitude, especially if enabling low-power operation modes. For this reason, it is important
that the supply circuitry is able to support the peak power for a short time (see the LEA-M8S Data Sheet [1] and
the NEO/LEA-M8T Data Sheet [2] for detail specification).
When switching from backup mode to normal operation or at start-up, the LEA-M8S and LEA-M8T
modules must charge the internal capacitors in the core domain. In certain situations, this can result in a
significant current draw. For low power applications using Power Save and backup modes, it is
important that the power supply or low ESR capacitors at the module input can deliver this
current/charge.
Use a proper GND concept. Do not use any resistors or coils in the power line.
1.3.2 V_BCKP: Backup Supply Voltage
If the module supply has a power failure, the V_BCKP pin supplies the real-time clock (RTC) and battery backed
RAM (BBR). Use of valid time and the GNSS orbit data at start-up will improve the GNSS performance, i.e.
enables hot and warm starts. If no backup battery is connected, the module performs a cold start at power-up.
Avoid high resistance on the V_BCKP line: During the switch from main supply to backup supply, a
short current adjustment peak can cause high voltage drop on the pin with possible malfunctions.
If no backup supply voltage is available, connect the V_BCKP pin to VCC.
As long as the LEA-M8S / LEA-M8T module is supplied via the VCC, the backup battery is disconnected
from the RTC and the BBR to avoid unnecessary battery drain (see Figure 1). In this case, VCC supplies
power to the RTC and BBR.

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Hardware description
Page 5 of 31
Figure 1: Backup battery and voltage (for exact pin orientation, see the LEA-M8S Data Sheet [1] and the NEO/LEA-M8T Data
Sheet [2])
1.3.3 VDD_USB: USB interface power supply
VDD_USB supplies the USB interface. If the USB interface is not used, the VDD_USB pin must be connected to
GND. For more information about correctly handling the VDD_USB pin, see section 1.4
1.3.4 VCC_RF: Output Voltage RF section
The VCC_RF pin can supply an active antenna or external LNA. For more information, see section 2.4.
1.3.5 V_ANT: Antenna supply
The V_ANT pin is available to provide antenna bias voltage to supply an optional external active antenna. For
more information, see section 2.4.
If not used, connect the V_ANT pin to GND.
1.4 Interfaces
1.4.1 UART
The LEA-M8S and LEA-M8T positioning modules include a Universal Asynchronous Receiver Transmitter (UART)
serial interface RxD/TxD, which supports configurable baud rates. The baud rates supported are specified in the
LEA-M8S Data Sheet [1] and the NEO/LEA-M8T Data Sheet [2]. The signal output and input levels are 0 V to
VCC. An interface based on RS232 standard levels (+/- 12 V) can be implemented using level shifters such as
Maxim MAX3232. Hardware handshake signals and synchronous operation are not supported.
1.4.2 USB
A USB version 2.0 FS (Full Speed, 12 Mb/s) compatible interface is available for communication as an alternative
to the UART. The USB_DP integrates a pull-up resistor to signal a full-speed device to the host. The VDD_USB
pin supplies the USB interface.
u-blox provides Microsoft® certified USB drivers for Windows Vista, and Windows 7 operating systems (also
Windows 8 compatible). These drivers are available at our website at www.u-blox.com
USB external components
The USB interface requires some external components to implement the physical characteristics required by the
USB 2.0 specification. These external components are shown in Figure 2 and listed in Table 1. To comply with
USB specifications, VBUS must be connected through an LDO (U1) to pin VDD_USB on the module.
The USB device is self-powered, the power supply (VCC) can be turned off and the digital block is not
powered. In this case, since VBUS is still available, the USB host would still receive the signal indicating that the
device is present and ready to communicate. This should be avoided by disabling the LDO (U1) using the enable
signal (EN) of the VCC-LDO or the output of a voltage supervisor. Depending on the characteristics of the LDO
(U1), it is recommended to add a pull-down resistor (R11) at its output to ensure VDD_USB is not floating if the
LDO (U1) is disabled or the USB cable is not connected, i.e. VBUS is not supplied.

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Hardware description
Page 6 of 31
USB bus powered is not supported.
Figure 2: USB Interface
Name Component Function Comments
U1 LDO Regulates VBUS (4.4 …5.25 V)
down to a voltage of 3.3 V.
Almost no current requirement (~1 mA)
C23,
C24
Capacitors Required according to the specification of LDO U1
D2 Protection
diodes
Protect circuit from overvoltage
/ ESD when connecting.
Use low capacitance ESD protection such as ST Microelectronics USBLC6-2.
R4, R5 Serial
termination
resistors
Establish a full-speed driver
impedance of 28…44 Ω
A value of 27 Ωis recommended.
R11 Resistor 100 kΩis recommended for USB self-powered setup. For bus-powered setup,
R11 can be ignored.
Table 1: Summary of USB external components
1.4.3 Display Data Channel (DDC)
An I2C compatible Display Data Channel (DDC) interface is available for serial communication with an external
host CPU. The interface only supports operation in slave mode (master mode is not supported). The DDC
protocol and electrical interface are fully compatible with the Fast-Mode of the I2C industry standard. DDC pins
SDA and SCL have internal pull-up resistors.
For more information about the DDC implementation, see the u-blox M8 Receiver Description Including Protocol
Specification [3]. For bandwidth information, see the LEA-M8S Data Sheet [1].For timing parameters, consult the
I2C-bus specification [8].
The u-blox M8 DDC interface supports serial communication with u-blox cellular modules. See the
specification of the applicable cellular module to confirm compatibility.
1.4.4 SPI (LEA-M8T ONLY)
An SPI interface is available for communication to a host CPU with LEA-M8T module.
SPI is not available in the default configuration, because its pins are shared with the UART and DDC
interfaces. The SPI interface can be enabled by connecting D_SEL to ground. For speed and clock
frequency, see the NEO/LEA-M8T Data Sheet [2]
1.4.5 TX Ready signal
The TX Ready signal indicates that the receiver has data to transmit. A listener can wait on the TX Ready signal
instead of polling the DDC or SPI interfaces. The UBX-CFG-PRT message lets you configure the polarity and the
number of bytes in the buffer before the TX Ready signal goes active. The TX Ready signal can be mapped to
UART TXD (PIO 06). The TX Ready function is disabled by default.
The TX-ready functionality can be enabled and configured by AT commands sent to the involved u-blox
cellular module supporting the feature. For more information, see the GPS Implementation and Aiding
Features in u-blox wireless modules [9].

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Hardware description
Page 7 of 31
1.5 I/O pins
RESET_N: Reset input
Driving RESET_N low activates a hardware reset of the system. Use this pin only to reset the module. Do not use
RESET_N to turn the module on and off, since the reset state increases power consumption. With LEA-M8S and
LEA-M8T modules RESET_N is an input only.
RESET_N should be used only in critical situations to recover the system. The Real-Time Clock (RTC) will
also be reset and thus immediately afterwards the receiver cannot perform a Hot Start.
EXTINT: External interrupt
EXTINT is an external interrupt pin with fixed input voltage thresholds with respect to VCC (see the LEA-M8S
Data Sheet [1] or the NEO/LEA-M8T Data Sheet [2] for more information). It can be used for wake-up functions
in Power Save Mode on all u-blox M8 modules and for aiding. Leave open if unused.
SAFEBOOT_N
If the SAFEBOOT_N pin is “low” at start up, the u-blox M8 module starts in Safe Boot Mode and doesn’t begin
GNSS operation. The Safe Boot Mode can be used to recover from situations where the Flash has become
corrupted.
D_SEL: Interface select (LEA-M8T ONLY)
The D_SEL pin selects the available interfaces. SPI cannot be used simultaneously with UART/DDC.
If open, UART and DDC are available. If pulled low, the SPI interface is available. See the NEO/LEA-M8T Data
Sheet [2].
Antenna Short circuit detection
The LEA-M8S and LEA-M8T modules include internal short circuit antenna detection. For more information, see
section 2.4.
Antenna open circuit detection
The LEA-M8S and LEA-M8T modules provide antenna open circuit detection (OCD) functionality over the
AADET_N pin.
AADET_N is an input pin used to report whether an external circuit has detected an external antenna or not.
Low means an antenna has been detected (antenna consumes current), while high means no external antenna
has been detected (no current drawn). This functionality is by default disabled. See section 2.4.2.
TIMEPULSE 1
A configurable time pulse signal is available with all u-blox M8 modules. By default, the time pulse signal is
configured to 1 pulse per second. For more information, see the u-blox M8 Receiver Description Including
Protocol Specification [3].
TIMEPULSE 2 (LEA-M8T only)
A configurable time pulse 2 signal is available on LEA-M8T module only. For more information see the u-blox M8
Receiver Description Including Protocol Specification [3].

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Hardware description
Page 8 of 31
Electromagnetic interference on I/O lines
Any I/O signal line with a length greater than approximately 3 mm can act as an antenna and may pick up
arbitrary RF signals transferring them as noise into the GNSS receiver. This specifically applies to unshielded lines,
in which the corresponding GND layer is remote or missing entirely, and lines close to the edges of the printed
circuit board.
If, for example, a cellular signal radiates into an unshielded high-impedance line, it is possible to generate noise
in the order of volts and not only distort receiver operation but also damage it permanently.
On the other hand, noise generated at the I/O pins will emit from unshielded I/O lines. Receiver performance
may be degraded when this noise is coupled into the GNSS antenna (see Figure 19).
To avoid interference by improperly shielded lines, it is recommended to use resistors (e.g. R>20 Ω), ferrite beads
(e.g. BLM15HD102SN1) or inductors (e.g. LQG15HS47NJ02) on the I/O lines in series. These components should
be chosen with care because they will affect also the signal rise times.
Figure 3 shows an example of EMI protection measures on the RX/TX line using a ferrite bead. More information
can be found in section 4.3.
Figure 3: EMI Precautions
TX
RX
GNSS
Receiver
FB
FB
BLM15HD102SN1
>10mm

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 9 of 31
2Design
2.1 Pin description
Function PIN No I/O Description Remarks
Power VCC 6 I Supply Voltage Provide clean and stable supply.
GND 7, 13, 14,
15, 17
- Ground Assure a good GND connection to all GND pins of the module
VCC_OUT 8 O Output Voltage
(VCC)
Leave open if not used.
V_BCKP 11 I Backup Supply
Voltage
It is recommended to connect a backup supply voltage to V_BCKP
in order to enable Warm and Hot Start features on the positioning
modules. Otherwise, connect to VCC.
VDD_USB 24 I USB Power
Supply
To use the USB interface connect this pin to 3.0 – 3.6V.
If no USB serial port used connect to GND.
Antenna RF_IN 16 I GNSS signal
input from
antenna
Use a controlled impedance transmission line of 50 Ωto connect to
RF_IN.
VCC_RF 18 O Output Voltage
RF section
Can be used to power external LNA or an external active antenna
(VCC_RF connected to V_ANT with 10
Ω
). The max power
consumption of the antenna must not exceed the datasheet
specification of the module.
Leave open if not used.
V_ANT 19 I Antenna Bias
voltage
Connect to GND (or leave open) if passive antenna is used. If an
active antenna is used, add a 10 Ωresistor in front of V_ANT input
to the Antenna Bias Voltage or VCC_RF
EXTINT1/
AADET_N
20 I Ext. Interrupt
/Active
Antenna Detect
Ext. Interrupt Pin. Int. pull-up resistor to VCC./ Input pin for optional
antenna supervisor circuitry. Leave open if not used.
UART TxD (LEA-M8S) 3
TxD / SPI MISO
(LEA-M8T)
O Serial Port Communication interface can be programmed as TX Ready for DDC
interface. Leave open if not used.
O
TxD
SPI MISO
Serial Port if D_SEL =1(or open)
SPI MISO if D_SEL = 0
RxD (LEA-M8S) 4
RxD /SPI MOSI
(LEA-M8T)
I Serial Port
Serial port input with internal pull-up resistor to VCC. Leave open if
not used. Do not use external pull up resistor.
I
RxD
SPI MOSI
Serial Port if D_SEL =1(or open)
SPI MOSI if D_SEL = 0
USB USB_DM 25 I/O USB I/O line USB2.0 bidirectional communication pin. Leave open if unused.
Implementations see section 1.4
USB_DP 26 I/O USB I/O line
System RESET_N 10 I Hardware Reset
(Active Low)
Leave open if not used. Do not drive high.
TIMEPULSE 1 28 O Timepulse 1 Configurable Timepulse signal (one pulse per second by default).
Leave open if not used.
SAFEBOOT_N / 12
TIMEPULSE 2
(LEA-M8T)
SAFEBOOT_N (LEA-M8S)
I/O Safeboot_N /
Timepulse 2
Configurable Timepulse signal. Must not be held LO during start-up.
I/O Safeboot_N Must not be held LO during start-up
EXTINT027 I Ext. Interrupt Ext. Interrupt Pin. Int. pull-up resistor to VCC. Leave open if unused.
SDA (LEA-M8S) 1
SDA /SPI CS_N
(LEA-M8T)
I/O
DDC Pins
DDC Data. Leave open if not used.
I/O SDA
SPI CS_N
DDC Data if D_SEL =1 (or open)
SPI Chip Select if D_SEL = 0
SCL (LEA-M8S) 2
SCL / SPI CLK
(LEA-M8T)
I DDC Pins DDC Clock. Leave open if not used.
I/O
SCL
SPI CLK
DDC Clock if D_SEL =1 (or open)
SPI Clock if D_SEL = 0
D_SEL (LEA-M8T) 5I Interface Select D_SEL = 0 -> SPI, D_SEL =1 (or open) -> DDC

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 10 of 31
Function PIN No I/O Description Remarks
Reserved
(LEA-M8S) - Reserved Leave open
Reserved 9, 21, 22,
23
- Reserved Leave open
Table 2: Pinout LEA-M8S / LEA-M8T
2.2 Minimal design
This is a minimal setup for a GNSS receiver with a LEA-M8S / LEA-M8T module:
•Passive antenna used
•No backup battery
•UART for communication
Figure 4: LEA-M8S / LEA-M8T passive antenna design
For active antenna design, see section 2.4
2.3 Footprint and paste mask
Figure 5 describes the footprint and provides recommendations for the paste mask for the LEA-M8S and
LEA-M8T modules. These are recommendations only and not specifications. Note that the copper and solder
masks have the same size and position.
To improve the wetting of the half vias, reduce the amount of solder paste under the module and increase the
volume outside of the module by defining the dimensions of the paste mask to form a T-shape (or equivalent)
extending beyond the copper mask. For the stencil thickness, see Figure 6.

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 11 of 31
17.0 mm [669 mil]
22.4 mm [881.9 mil]
1.0 mm
[39 mil]
0.8 mm
[31.5 mil]
2.45 mm
[96.5 mil]
1.1 mm
[43 mil]
3.0 mm
[118 mil]
2.15 mm
[84.5 mil]
0.8 mm
[31.5 mil]
Figure 5: LEA-M8S / LEA-M8T footprint
Figure 6: LEA-M8S / LEA-M8T paste mask
2.4 Antenna and Antenna supervision
2.4.1 Antenna design with passive antenna
A design using a passive antenna requires more attention to the layout of the RF section. Typically, a passive
antenna is located near electronic components; therefore, care should be taken to reduce electrical noise that
may interfere with the antenna performance. Passive antennas do not require a DC bias voltage and can be
directly connected to the RF input pin RF_IN. Sometimes they may also need a passive matching network to
match the impedance to 50 Ω.
Minimal setup with a good patch antenna
Figure 7 shows a minimal setup for a design with a good GNSS patch antenna.
Figure 7: Module design with passive antenna (for exact pin orientation see the LEA-M8S Data Sheet [1] and the NEO/LEA-M8T
Data Sheet [2])

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 12 of 31
Setup for best performance with passive antenna
Figure 8 shows a design using an external LNA to increase the sensitivity for best performance with passive
antenna.
Figure 8: Module design with passive antenna and an external LNA (for exact pin orientation see the LEA-M8S Data Sheet [1]
and the NEO/LEA-M8T Data Sheet [2].)
The VCC_RF output can be used to supply the LNA with a filtered supply voltage.
For recommended parts, see Appendix
A standard GNSS LNA has enough bandwidth to amplify GPS / GLONASS and BeiDou signals.
2.4.2 Active antenna design
Active antennas have an integrated low-noise amplifier. Active antennas require a power supply that will
contribute to the total GNSS system power consumption budget with additional 5 to 20 mA typically.
If the customers do not want to make use of the internal antenna supervisor and the supply voltage of the LEA-
M8S / LEA-M8T module matches the supply voltage of the antenna (e.g. 3.0 V), they can use the filtered supply
voltage VCC_RF output to supply the antenna (See Figure 9). This design is used for modules in combination
with active antenna.
In case of different supply voltage, use a filtered external supply, see Figure 10.
Active antenna design using VCC_RF pin to supply the active antenna
Figure 9: Active antenna design, external supply from VCC_RF (for exact pin orientation see the LEA-M8S Data Sheet [1])

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 13 of 31
Active antenna design powered from external supply
Figure 10 shows a design with direct externally powered active antenna.
This circuit has to be used if the active antenna has a different supply voltage than the VCC_RF (for example if a
5 V active antenna is used).
Figure 10: Active antenna design, direct external supply (for exact pin orientation see the LEA-M8S Data Sheet [1] and the
NEO/LEA-M8T Data Sheet [2])
For recommended parts, see Appendix.
In case VCC_RF voltage does not match with the antenna supply voltage, use a filtered external supply
as shown in Figure 10.
Antenna design with active antenna using antenna supervisor
An active antenna supervisor provides the means to check the antenna for open and short circuits and to shut
off the antenna supply if a short circuit is detected. The Antenna Supervisor is configured using serial port UBX
binary protocol message. Once enabled, the active antenna supervisor produces status messages, reporting in
NMEA and/or UBX binary protocol. These indicate the particular state of the antenna supervisor shown in the
state diagram (see Figure 11).

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 14 of 31
The current active antenna status can be determined by polling the UBX-MON-HW monitor command. If an
antenna is connected, the initial state after power-up is “Active Antenna OK.”
No
Super-
vision
Active
Antenna
OK
Open
Circuit
detected
Short
Circuit
detected
Powerup
Events AADET0_N
User controlled events
Disable Supervision
Enable Supervision
Short Circuit
detected
Disable
Supervision
Antenna
connected
Short Circuit
detected
open circuit
detected,given
OCD enabled
Periodic
reconnection
attempts
Figure 11: State diagram of active antenna supervisor
The module firmware supports an active antenna supervisor circuit, which is connected to the AADET_N pin. For
an example of an open circuit detection circuit, see Figure 14. High on AADET_N means that an external
antenna is not connected.
Status reporting
At startup, and on every change of the antenna supervisor configuration, the LEA-M8S and LEA-M8T modules
will output an NMEA ($GPTXT) or UBX (INF-NOTICE) message with the internal status of the antenna supervisor
(disabled, short detection only, enabled).
Abbreviation Description
AC Antenna Control (e.g. the antenna will be switched on/ off controlled by the GNSS receiver)
SD Short Circuit Detection Enabled
SR Short Circuit Recovery Enabled
OD Open Circuit Detection Enabled
PdoS Power Down on short
Table 3: Active Antenna Supervisor Message on startup (UBX binary protocol)
To activate the antenna supervisor use the UBX-CFG-ANT message. For further information, refer to the
u-blox M8 Receiver Description Including Protocol Specification [3].
Similar to the antenna supervisor configuration, the status of the antenna supervisor will be reported in an
NMEA ($GPTXT) or UBX (INF-NOTICE) message at start-up and on every change.

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 15 of 31
Message Description
ANTSTATUS=DONTKNOW Active antenna supervisor is not configured and deactivated.
ANTSTATUS=OK Active antenna connected and powered
ANTSTATUS=SHORT Antenna short
ANTSTATUS=OPEN Antenna not connected or antenna defective
Table 4: Active antenna supervisor message on startup (NMEA protocol)
Module design with active antenna, short circuit protection / detection
If a suitably dimensioned R_BIAS series resistor is placed in front of the V_ANT pin, a short circuit can be
detected in the antenna supply. The detection happens inside the u-blox M8 module, after which the antenna
supply voltage will be immediately shut down. Afterwards, periodic attempts to re-establish antenna power are
made by default.
An internal switch (under control of the receiver) can turn off the supply to the external antenna whenever it is
not needed. This feature helps to reduce power consumption in power save mode.
To configure the antenna supervisor use the UBX-CFG-ANT message. For further information, see the
u-blox M8 Receiver Description Including Protocol Specification [3].
Short circuits on the antenna input without limitation (R_BIAS) of the current can result in
permanent damage to the receiver! Therefore, it is mandatory to implement an R_BIAS in all
risk applications, such as situations where the antenna can be disconnected by the end-user or
that have long antenna cables.
In case VCC_RF voltage does not match with the antenna supply voltage, use a filtered external supply
as shown in Figure 13.
Supply from VCC_RF
Figure 12 shows an active antenna supplied from the LEA-M8S and LEA-M8T modules.
LEA-M8S and LEA-M8T modules includes a built in antenna bias supply for nominal 3V antennas enabled by
linking the filtered VCC_RF supply output pin to the V_ANT antenna supply input pin with a 10 Ohm resistor in
series. The module then controls the power supply to the antenna, applying power whenever the receiver is
active and removing power during power-save idle times and if a short-circuit is detected. Short-circuit is
detected if the voltage at the antenna supply falls close to zero and is indicated as an alarm in message MON-
HW
Figure 12: Module design with active antenna, internal supply from VCC_RF (for exact pin orientation see the LEA-M8S Data
Sheet [1] and the NEO/LEA-M8T Data Sheet [2].)
For recommended parts, see Appendix.

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 16 of 31
External supply
Figure 13 shows an externally powered active antenna design.
Since the external bias voltage is fed into the most sensitive part of the receiver (i.e. the RF input), this supply
should be free of noise. Usually, low frequency analog noise is less critical than digital noise of spurious
frequencies with harmonics up to the GPS/QZSS band of 1.575 GHz, GLONASS band of 1.602 GHz and BeiDou
band at 1.561 GHz. Therefore, it is not recommended to use digital supply nets to feed the V_ANT pin.
Figure 13: Module design with active antenna, external supply (for exact pin orientation see the LEA-M8S Data Sheet [1] and
the NEO/LEA-M8T Data Sheet [2])
Antenna supervision with open circuit detection (OCD)
Optionally the AADET_N pin may be reassigned to antenna supervision allowing an external circuit to indicate to
the module that the antenna is open-circuit. This condition is then reported by the module in message MON-
HW. Calculate the threshold current using Equation 1.
Figure 14: Schematic of open circuit detection (for exact pin orientation see the LEA-M8S Data Sheet [1] and the NEO/LEA-M8T
Data Sheet [2].)

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Design
Page 17 of 31
RFVcc
Rbias
RR
R
I_
32
2
•






+
=
Equation 1: Calculation of threshold current for open circuit detection
If the antenna supply voltage is not derived from VCC_RF, do not exceed the maximum voltage rating of
AADET_N.
For recommended parts, see Appendix

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Migration to u-blox M8 modules
Page 18 of 31
3Migration to u-blox M8 modules
3.1 Migrating u-blox 6 designs to a u-blox M8 module
u-blox is committed to ensuring that products in the same form factor are backwards compatible over several
technology generations. Utmost care has been taken to ensure there is no negative impact on function or
performance and to make u-blox M8 modules as fully compatible as possible with previous generations modules.
If using BeiDou, check the bandwidth of the external RF components and the antenna. For information about
power consumption, see the LEA-M8S Data Sheet [1] and the NEO/LEA-M8T Data Sheet [2]. It is highly advisable
that customers consider a design review with the u-blox support team to ensure the compatibility of key
functionalities.
3.2 Hardware migration LEA-6N -> LEA-M8S
Pin
LEA-6N LEA-M8S Remarks for Migration
Pin Name Typical Assignment Pin Name Typical Assignment
1 SDA DDC Data SDA DDC Data No difference
2 SCL DDC Clock SCL DDC Clock No difference
3 TxD Serial Port TxD Serial Port No difference
4 RxD Serial Port RxD Serial Port No difference
5 NC Not Connected Reserved Not Connected No difference
6 VCC Supply voltage VCC Supply voltage No difference
7 GND Ground (digital) GND Ground (digital) No difference
8 VCC_OUT Output voltage VCC_OUT Output voltage No difference
9 NC Not Connected Reserved Not Connected No difference
10 RESET_N External Reset RESET_N External Reset No difference
11 V_BCKP Backup voltage supply V_BCKP Backup voltage supply
If this was connected to GND
on u-blox 6 module, OK to
do the same on u-blox M8.
12 Safeboot_N Do not drive low Safeboot_N Do not drive low No difference
13 GND Ground GND Ground No difference
14 GND Ground GND Ground No difference
15 GND Ground GND Ground No difference
16 RF_IN GNSS signal input RF_IN GNSS signal input No difference
17 GND Ground GND Ground No difference
18 VCC_RF Output Voltage RF section VCC_RF Output Voltage RF section No difference
19 V_ANT Antenna Bias voltage V_ANT Antenna Bias voltage No difference
20 AADET_N Active Antenna Detect AADET_N Active Antenna Detect No difference
21 Reserved Not Connected Reserved Not Connected No difference
22 Reserved Not Connected Reserved Not Connected No difference
23 Reserved Not Connected Reserved Not Connected No difference
24 VDD_USB USB Supply VDD_USB USB Supply No difference
25 USB_DM USB Data USB_DM USB Data No difference
26 USB_DP USB Data USB_DP USB Data No difference
27 EXTINT0 External Interrupt Pin EXTINT0 External Interrupt Pin No difference
28 TIMEPULSE Timepulse (1PPS) TIMEPULSE Timepulse (1PPS) No difference
Table 5: Pin-out comparison LEA-6N vs. LEA-M8S

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Migration to u-blox M8 modules
Page 19 of 31
3.3 Hardware migration LEA-6T -> LEA-M8T
Pin
LEA-6T LEA-M8T Remarks for Migration
Pin Name Typical Assignment Pin Name Typical Assignment
1 SDA DDC Data SDA DDC Data No difference
2 SCL DDC Clock SCL DDC Clock No difference
3 TxD Serial Port TxD Serial Port No difference
4 RxD Serial Port RxD Serial Port No difference
5 NC Not Connected D_SEL D_SEL =1(or open) Do not drive low
6 VCC Supply voltage VCC Supply voltage No difference
7 GND Ground (digital) GND Ground (digital) No difference
8 VCC_OUT Output voltage VCC_OUT Output voltage No difference
9 TIMEPULSE2 2nd Timepulse Not Connected Reserved
Time Pulse 2 is now
available on pin 12
(Safeboot_N / Time Pulse 2)
10 RESET_N External Reset RESET_N External Reset No difference
11 V_BCKP Backup voltage supply V_BCKP Backup voltage supply
If this was connected to GND
on u-blox 6 module, OK to do
the same on u-blox M8.
12 Safeboot_N Safeboot_N Safeboot_N/
TIMEPULSE2 Safeboot_N /Timepulse 2 Must not be held LO during
start-up.
13 GND Ground GND Ground No difference
14 GND Ground GND Ground No difference
15 GND Ground GND Ground No difference
16 RF_IN GNSS signal input RF_IN GNSS signal input No difference
17 GND Ground GND Ground No difference
18 VCC_RF Output Voltage RF section VCC_RF Output Voltage RF
section No difference
19 V_ANT Antenna Bias voltage V_ANT Antenna Bias voltage No difference
20 AADET_N Active Antenna Detect EXTINT1/AADET_N External Interrupt Pin/
Active Antenna Detect
21 Reserved Not Connected Reserved Not Connected No difference
22 Reserved Not Connected Reserved Not Connected No difference
23 Reserved Not Connected Reserved Not Connected No difference
24 VDD_USB USB Supply VDD_USB USB Supply No difference
25 USB_DM USB Data USB_DM USB Data No difference
26 USB_DP USB Data USB_DP USB Data No difference
27 EXTINT0 External Interrupt Pin EXTINT0 External Interrupt Pin No difference
28 TIMEPULSE1 Timepulse (1PPS) TIMEPULSE1 Timepulse (1PPS) No difference
Table 6: Pin-out comparison LEA-6T vs. LEA-M8T
3.4 Software migration
For overall description of the module software operation, see the u-blox M8 Receiver Description
Including Protocol Specification [3].
All features requiring a flash on LEA-6N are not supported on LEA-M8S. (AssistNow offline / save config)

LEA-M8S / LEA-M8T - Hardware Integration Manual
UBX-13003140 - R07 Production Information Product handling
Page 20 of 31
4Product handling
4.1 Packaging, shipping, storage and moisture preconditioning
For information pertaining to reels and tapes, Moisture Sensitivity levels (MSL), shipment and storage
information, as well as drying for preconditioning see the LEA-M8S Data Sheet [1] and the NEO/LEA-M8T Data
Sheet [2].
Population of Modules
When populating the modules, make sure that the pick and place machine is aligned to the copper pins
of the module and not on the module edge.
4.2 Soldering
Soldering paste
Use of “No Clean” soldering paste is strongly recommended, as it does not require cleaning after the soldering
process has taken place. The paste listed in the example below meets these criteria.
Soldering Paste: OM338 SAC405 / Nr.143714 (Cookson Electronics)
Alloy specification: Sn 95.5/ Ag 4/ Cu 0.5 (95.5% Tin/ 4% Silver/ 0.5% Copper)
Melting Temperature: 217 °C
Stencil Thickness: See Figure 6.
The final choice of the soldering paste depends on the approved manufacturing procedures.
The paste-mask geometry for applying soldering paste should meet the recommendations.
The quality of the solder joints on the connectors (’half vias’) should meet the appropriate IPC
specification.
Reflow soldering
A convection type-soldering oven is highly recommended over the infrared type radiation oven.
Convection heated ovens allow precise control of the temperature, and all parts will heat up evenly, regardless
of material properties, thickness of components and surface color.
As a reference, see the “IPC-7530 Guidelines for temperature profiling for mass soldering (reflow and wave)
processes”, published in 2001.
Preheat phase
During the initial heating of component leads and balls, residual humidity will be dried out. Note that this
preheat phase will not replace prior baking procedures.
•Temperature rise rate: max. 3 °C/s. If the temperature rise is too rapid in the preheat phase it may cause
excessive slumping.
•Time: 60 – 120 s. If the preheat is insufficient, rather large solder balls tend to be generated. Conversely, if
performed excessively, fine balls and large balls will be generated in clusters.
•End Temperature: 150 – 200 °C. If the temperature is too low, non-melting tends to be caused in areas
containing large heat capacity.
Heating/ Reflow phase
The temperature rises above the liquidus temperature of 217°C. Avoid a sudden rise in temperature as the slump
of the paste could become worse.
•Limit time above 217 °C liquidus temperature: 40 – 60 s
•Peak reflow temperature: 245 °C
