UNIS POGO JUMP User manual

Operation Manual
IMPORTANT

Pogo Jump DLX GMP Manual
09/09/2022
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
www.unispartsandservice.com
When contacting Service, you will need the following information
and the name of your authorized distributor.

Pogo Jump DLX GMP Manual
09/09/2022
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 6
3. PART NAME............................................................................................................7
4. SET UP & INSTALLATION...................................................................................... 8
5. HOW TO PLAY......................................................................................................16
6. GAME OPTION..................................................................................................... 17
7. TROUBLESHOOTING............................................................................................19
8. MAINTENANCE & INSPECTION..........................................................................23
WIRING DIAGRAM

Pogo Jump DLX GMP Manual
09/09/2022
3
Thank you for purchasing Pogo Jump DLX GMP. We hope you enjoy the
product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Pogo Jump DLX GMP Manual
09/09/2022
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Pogo Jump DLX GMP Manual
09/09/2022
5
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz
Min. Power consumption: 320W
Max. Power consumption: 360W
Dimension: H107.70×W55.40×D87.23 in
H2735.5 ×W1407.2×D2215.6 mm
Weight：Approximately 429.90 lb/195kg
Model No: C-731
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game specifications are subject to change without notice.

Pogo Jump DLX GMP Manual
09/09/2022
6
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
Following accessories
NOTE: Part models are subject to change without notice.
No.
Code No.
Name/SPEC
Qty
1
2.33.01.010041
Power cord
3×16AWG 3M
1
2
2.19.01.000001
Fuse
Φ5×20mm T6A/250VAC
2
3
/
Manual
GMP
1
4
2.53.00171002
171A key
2
5
2.53.00172002
171B key
2

Pogo Jump DLX GMP Manual
09/09/2022
7
3. PART NAME
Key Components
Trampoline
Coin
mechanism
Marquee
Ticket
dispenser
Assy.
Monitor
Fence and
handle
Stair assembly

Pogo Jump DLX GMP Manual
09/09/2022
8
Leveler
About 0.2 in/5mm
Leveler
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
Place the unit on a dry level surface.
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground by 0.2 in/5mm. Repeat the same for all
levelers.
We do not recommend using power tools as they may cause damage.
NOTICE
Make sure the machine is level.
NOTICE
Leveler
Leveler

Pogo Jump DLX GMP Manual
09/09/2022
9
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 20 in
Service area
Your unit must be leveled to operate properly.
NOTICE
Play area

Pogo Jump DLX GMP Manual
09/09/2022
10
4.4 Machine Installation
Before processing with assembly assure you have the following tools.
Step 1 Open the Marquee case. Place Marquee case to the top of the Cabinet. Insert and
connect the connector. Utilize screws to secure.
Step 2 Install L&R LOGO marquee, Duck marquee, L&R POP plate and Background
decal.Connect the connectors.
No.
Name
1
Phillips screwdriver
2
Spanner(M10)
Marquee case
Cabinet

Pogo Jump DLX GMP Manual
09/09/2022
11
Step 3-1 Open back door. Loosen screws on the Monitor two sides as shown below.
Step 3-2 Utilize Spanner to lift up the Monitor assembly to a proper position(the screw
holes match well).
Turn clockwise to lift up.
Turn counterclockwise to lift down.
Screws
Monitor
assembly
Back door

Pogo Jump DLX GMP Manual
09/09/2022
12
Step 4 Install L&R light plastic. Connect the connectors.
Step 5 Locate Trampoline assembly. Remove 4 side Outer cover board.
L bottom
light plastic
L upper light
plastic
R upper
light plastic
R bottom
light plastic
Front outer
cover board
R outer
cover board
L outer
cover board
Back outer
cover board

Pogo Jump DLX GMP Manual
09/09/2022
13
Step 6 Install Fence to the Trampoline assembly. Utilize screws to secure.
Notice: the Front fence need to connect the connector.
Step 7 Install the 4 side Outer cover boards back.
Fence
Trampoline
Front Fence connector

Pogo Jump DLX GMP Manual
09/09/2022
14
Step 8 Install the Coin mechanism assembly to the Trampoline side as shown below.
Lead the Coin mech. connectors to the Monitor cabinet through the hole.Connect the
connectors.
Step 9 Locate Stair assembly. Remove upper board. Install Stair assembly to the
Trampoline. Utilize screws to secure. Install the upper board back.
Coin mech.
assembly
Trampoline
Upper board
Stair assembly

Pogo Jump DLX GMP Manual
09/09/2022
15
Step 10 Align the Trampoline assembly with the Monitor cabinet. Connect the connectors.
Utilize Connect plate and screws to secure.
Finish!
Connect tube
Monitor
cabinet
Connect plate

Pogo Jump DLX GMP Manual
09/09/2022
16
5. HOW TO PLAY
5.1 Insert card to play. 5.2 Select Character
5.3 Player can increase speed by using
accelerator and jumping platform.
5.4 Win more coins to increase game excitement.

Pogo Jump DLX GMP Manual
09/09/2022
17
6. GAME OPTION
6.1 Adjustment button instruction
6.2 Setting menu
6.2.1 Main menu
Options
Basic Setting
Customized Setting
Input Test
Output Test
Game Reset
Date/Time Setting
Language/语言
Bookkeeping
Daily Record
Back to game
6.2.3 Customized Setting
Options
Status
Linking Mode
OFF/ON
Linking Device
Router_Switch/
Network Cable
Machine ID
1-6
Maximum Stretch Limit
0-500
Fixed Ticket
0~99
Options
Status
Rank 1st Tickets
0~99
Rank 2nd Tickets
0~99
Rank 3rd Tickets
0~99
Mercy Tickets
0~99
Divided by 2
OFF/ON
Go Back & Save
Back
Reset
Test
6.2.2 Basic Setting
Options
Status
Free Play
OFF/ON
Tickets Out
OFF/ON
Demo Music
OFF/ON
Memory Save
OFF/ON
Volume
1-10
Game Time
45_60_90_120_150_180
Payment Mode
Insert Coins_Tap Card_Insert Coins Or
Tap Card
Coins Per Game
1-99
Out of Tickets
Store in memory/Call attendant
Go Back & Save
Back
Settings
Open the coin door and there is a
meter panel. Press Settings button to
enter the setting menu.

Pogo Jump DLX GMP Manual
09/09/2022
18
6.2.8 Bookkeeping
6.2.4Input Test 6.2.5 Output Test
6.2.6 Game Reset 6.2.7 Date/Time Setting
Options
Status
Coin Mechanism
OFF/ON
Handle Touch Test
OFF/ON
L Sensor Value
0-4096
R Sensor Value
0-4096
Back
Options
Status
Factory Restore
YES/NO
Reset Basic Setting
YES/NO
Reset Customized Setting
YES/NO
Clear All Records
YES/NO
Clear Owed Ticket
YES/NO
Clear Unused Coin
YES/NO
Back
Options
Ticket Drive
Surrounding Light(R)
Surrounding Light(G)
Surrounding Light(B)
Back
Options
Status
Year
2010-2100
Month
1-12
Day
1-31
Hour(24)
0-23
Minute
0-59
Second
0-59
Go Back & Save
Back
6.2.9 Daily Record
Player1 Coins Tickets Payout
1 0 0 0.00
Back
Date Weekday RunTime Coins Tickets Payout
2014-06-061 Fri 00:01 0 0 0.00
Prev. Page
Next Page
Clear
Back

Pogo Jump DLX GMP Manual
09/09/2022
19
7. TROUBLESHOOTING
7.1 Common Problem
Please confirm that all connectors fit tightly.
Symptom
Possible Cause
Recommended action
Game will not
start
Frame assembly connector is
loose.
Check connector.
Frame assembly fault
Contact with UNIS Service.
Power off
Circuit protector make power SW
in off state.
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact with UNIS
Service.
Card reader not
working
The connector is loose.
Check connector.
Card reader fault.
Check with card reader manufacturer.
No ticket
dispensing
Out of ticket.
Add ticket and press reset button
Ticket jamming.
Remove the jammed tickets and press
reset button.
The connector is loose.
Plug the connector tightly.
No sound
Low volume
Raise the volume.
Connector loose.
Check connector.
Speaker fault.
Check speaker.
Audio cable problem.
Reconnect the audio cable or change
it.
Display black
screen
Check connectors.
Plug in connector tightly
Display fault.
Utilize another source such as a PC to
verity if the display is operational.
Display blue
screen
VGA signal cable is loose.
Check VGA cable
