UNIS Star Crusaders 2 User manual

Operation Manual
IMPORTANT

Star Crusaders 2 Prototype Manual
07/09/2022
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
www.unispartsandservice.com
When contacting Service, you will need the following information
and the name of your authorized distributor.

Star Crusaders 2 Prototype Manual
07/09/2022
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 6
3. PART NAME............................................................................................................7
4. SET UP & INSTALLATION...................................................................................... 8
5. HOW TO PLAY......................................................................................................14
6. GAME OPTION..................................................................................................... 15
7. TROUBLESHOOTING............................................................................................19
8. MAINTENANCE & INSPECTION..........................................................................22
9. WIRING DIAGRAM.............................................................................................. 23

Star Crusaders 2 Prototype Manual
07/09/2022
3
Thank you for purchasing Star Crusaders 2. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Star Crusaders 2 Prototype Manual
07/09/2022
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Star Crusaders 2 Prototype Manual
07/09/2022
5
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz (It is subject to the nameplate on
the back of the machine.)
Min. Power consumption: 550W
Max. Power consumption: 650W
Dimension: H108.74×W66.29×D88.81 in
H2762× W1700 ×D2256 mm
Weight：Approximately 956.80 lb/434kg
Model No: C-739
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game specifications are subject to change without notice.
66.29 in
88.81 in
66.29 in

Star Crusaders 2 Prototype Manual
07/09/2022
6
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
Following accessories
NOTE: Part models are subject to change without notice.
No.
Code No.
Name/SPEC
Qty
1
2.53.00171002
171A key
2
2
2.53.00172002
171B key
2
3
201.04.020003
Cross recessed hexagon bolt set M6×20
12
4
201.01.108005
Hexagon flat head screw
M6×25
6
5
201.01.108022
Hexagon flat head screw
M4×8
6
6
201.04.023001
Cross recessed hexagon bolt set
M8×45
4
7
4.14.40000580
Manual
1
8
/
Power cord
10A/250V 1.8M
1
9
2.19.01.000013
Fuse
Φ5×20 T10A/250V
1

Star Crusaders 2 Prototype Manual
07/09/2022
7
3. PART NAME
Key Components
Seat platform
Gun
Marquee
Coin mechanism
Seat
Monitor
Control
panel

Star Crusaders 2 Prototype Manual
07/09/2022
8
Leveler
About 0.2 in/5mm
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
Place the unit on a dry level surface.
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground by 0.2 in/5mm. Repeat the same for all
levelers.
We do not recommend using power tools as they may cause damage.
NOTICE
Make sure the machine is level.
NOTICE
Leveler
Leveler
Leveler

Star Crusaders 2 Prototype Manual
07/09/2022
9
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 500 mm
Service area
Play area
Your unit must be leveled to operate properly.
NOTICE

Star Crusaders 2 Prototype Manual
07/09/2022
10
4.4 Machine Installation
Step 1 Remove all the screws as shown below. Remove Seat assembly.
Screws
Seat assembly

Star Crusaders 2 Prototype Manual
07/09/2022
11
Step 2 Install L&R side decal to the top of the cabinet. Utilize screws to secure.
Step 3 Place LOGO marquee to the top of the cabinet. Utilize screws to secure. Connect the
connector.
Name
L side decal
Qty
1
Name
Cross recessed
hexagon bolt set
Spec.
M6×20
Qty
4
LOGO Marquee
Name
Hexagon flat
head screw
Spec.
M4×8
Qty
10
Name
R side decal
Qty
1

Star Crusaders 2 Prototype Manual
07/09/2022
12
Step 4 Install POP board to the back of the LOGO marquee. Utilize screws to secure.
Step 5 Align the Control panel with the cabinet. Connect the connectors.
Name
POP board
Qty
1
Name
Cross recessed
hexagon bolt set
Spec.
M6×20
Qty
4
POP board
Cabinet
Control panel

Star Crusaders 2 Prototype Manual
07/09/2022
13
Step 6 Open the L&R front door. Utilize screws to secure.
Step 7 Align the Seat assembly with the cabinet. Connect the connectors. Utilize screws to
secure.
Finish!
Name
Cross recessed
hexagon bolt set
Spec.
M8×45
Qty
4
Name
Hexagon flat
head screw
Spec.
M6×25
Qty
6
Seat assembly
Control panel

Star Crusaders 2 Prototype Manual
07/09/2022
14
4.5 Card Reader Installation Safety Notice
Take precaution to assure that all wiring voltages are confirmed prior to installation
of card reader. All warranties are void if not properly installed resulting in logic board
damage.
Important: This game is pre-wired to AAMA standards. It is highly recommended to utilize
this wiring for Card reader installation.
5. HOW TO PLAY
5.1 Insert card to play. Press the button to play.
5.2 Pull the gun to shoot the target and get points.
5.3 Get high score and win more tickets.

Star Crusaders 2 Prototype Manual
07/09/2022
15
6. GAME OPTION
6.1 Adjustment button instruction
6.2 Setting menu
6.2.1 Main menu
Options
Game Setting
I/O Output Test
I/O Input Test
Bookkeeping
Daily Record
Game Reset
语言/Language
Time Setting
Exit And Save
Exit Without Save
Options
Status
Description
Difficulty
Easy/Normal/Hard
Game Volume
0-10
Demo Volume
0-10
Coins Per Game
0-10
Prize Mode
Ticket/None
Tickets out or not
Fixed Tickets
OFF/0-50
Scores Per Ticket
50-30000
Big Prize Required Coins
10-40
Big Prize Tickets
0-2000
Reset
Open the coin door and there is a
meter panel. Press Settings button to
enter the setting menu.
Settings
Test
6.2.2 Game Setting

Star Crusaders 2 Prototype Manual
07/09/2022
16
6.2.2.1 Gun Calibration
6.2.2.2 Shock Adjustment
Options
Status
Description
Game Time
0-600(s)
Continue Time (s)
0-60
Pay Mode
Coins/Insert Coins/Tap
Card/Card
1P Gun Calibration
Refer to 6.2.2.1
2P Gun Calibration
3P Gun Calibration
4P Gun Calibration
Shock Adjustment
Gun shock adjustment.
Refer to 6.2.2.2
Back
Options
Status
1P Small Shock
1-10
2P Small Shock
1-10
3P Small Shock
1-10
4P Small Shock
1-10
Back
Press TEST BUTTON To Exit
Potentiometer X Max:
Potentiometer Y Max:
Potentiometer X Min:
Potentiometer Y Min:
Use 1P gun point at the circle 1 then press START BUTTON to confirm
Potentiometer X:
Potentiometer Y:

Star Crusaders 2 Prototype Manual
07/09/2022
17
6.2.3 I/O Output Test
Options
Status
1P Out Tickets
ON/OFF
2P Out Tickets
ON/OFF
3P Out Tickets
ON/OFF
4P Out Tickets
ON/OFF
1P Gun Vibration
2P Gun Vibration
3P Gun Vibration
4P Gun Vibration
1P Gun&Chair Light
ON/OFF
2P Gun&Chair Light
ON/OFF
3P Gun&Chair Light
ON/OFF
4P Gun&Chair Light
ON/OFF
Border Light
ON/OFF
Control Panel Light
ON/OFF
Seat Light
ON/OFF
6.2.4 I/O Input Test
Options
Status
1P Insert Coin
ON/OFF
2P Insert Coin
ON/OFF
3P Insert Coin
ON/OFF
4P Insert Coin
ON/OFF
1P Potentiometer X
1P Potentiometer Y
2P Potentiometer X
2P Potentiometer Y
3P Potentiometer X
3P Potentiometer Y
4P Potentiometer X
4P Potentiometer Y
Options
Status
Out of Ticket Light 1
ON/OFF
Out of Ticket Light 2
ON/OFF
1P Ticket Counter
ON/OFF
2P Ticket Counter
ON/OFF
3P Ticket Counter
ON/OFF
4P Ticket Counter
ON/OFF
1P Coin Counter
ON/OFF
2P Coin Counter
ON/OFF
3P Coin Counter
ON/OFF
P1 Seat Vibration
ON/OFF
P2 Seat Vibration
ON/OFF
P3 Seat Vibration
ON/OFF
P4 Seat Vibration
ON/OFF
Back
Options
Status
1P Start Button
ON/OFF
2P Start Button
ON/OFF
3P Start Button
ON/OFF
4P Start Button
ON/OFF
Test Button
ON/OFF
Settings Button
ON/OFF
Reset Button
ON/OFF
1P DBV
ON/OFF
2P DBV
ON/OFF
3P DBV
ON/OFF
4P DBV
ON/OFF
Back

Star Crusaders 2 Prototype Manual
07/09/2022
18
6.2.5 Bookkeeping
6.2.6 Daily Record
6.2.7 Game Reset 6.2.8 Time Setting
Options
Factory Restore
Clear Record
Clear Owed Tickets
Clear Unused Coins
Back
Player Coins In Tickets Out
Back
Date Week Run Time Coins In Tickets Out
Prev Page
Next Page
Back
Year
Month
Day
Hour
Minute
Second
Back And Save
Back Without Save

Star Crusaders 2 Prototype Manual
07/09/2022
19
7. TROUBLESHOOTING
7.1 Common Problem
Please confirm that all connectors fit tightly.
Symptom
Possible Cause
Recommended action
Game will not
start
Frame assembly connector is
loose.
Check connector.
Frame assembly fault
Contact with UNIS Service.
Power off
Circuit protector make power SW
in off state.
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact with UNIS
Service.
No sound
Low volume
Raise the volume.
Connector loose.
Check connector.
Speaker fault.
Check speaker.
POT installation error.
Install POT correctly.
POT fault.
Change POT.
Audio cable problem.
Reconnect the audio cable or change
it.
PC crash.
Restart or system recovery.
Driver problem
Restart the audio driver.
Display black
screen
Check connectors.
Plug in connector tightly
Display fault.
Utilize another source such as a PC to
verity if the display is operational.
RAM is loose.
Remove and reinsert RAM.
Display blue
screen
PC power cord is loose
Check PC power cord whether is loose.
VGA signal cable is loose.
Check VGA cable
PC video card is loose.
Reseat video card.
“0X000000A” code appears.
Conflict between computer drive
and software.
Contact service
Note: After replacing component from PC (except for RAM), and replacing monitor, the
game should be recovered again with the recovery stick attached to the machine.
