UNIS FANTASTC PRIZE User manual

Operation Manual
IMPORTANT

Skill Fantastic Prize 2 GMP Manual
06/15/2023
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
www.unispartsandservice.com
When contacting Service, you will need the following information
and the name of your authorized distributor.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS........................................................................ 3
1. SPECIFICATIONS...................................................................................................... 5
2. CONTENTS OF THE ACCESSORY KIT.....................................................................6
3. PART NAME.............................................................................................................. 7
4. SET UP & INSTALLATION........................................................................................ 8
5. LOCATION OPERATION INSTRUCTIONS..............................................................10
6. HOW TO PLAY........................................................................................................ 11
7. GAME OPTION ........................................................................................................12
8. TROUBLESHOOTING ..............................................................................................15
9. MAINTENANCE & INSPECTION............................................................................17
10. OVERALL CONSTRUCTION.................................................................................18
WIRING DIAGRAM

Skill Fantastic Prize 2 GMP Manual
06/15/2023
3
Thank you for purchasing Fantastic Prize 2 GMP. We hope you enjoy the
product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
5
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz;
Min. Power consumption: 550W
Max. Power consumption: 700W
Dimension: W31.69×D34.37×H93.54 in
W805 ×D873 ×H2376 mm
Weight：Approximately 513.67 lb/ 233kg
Model No: A-495
Part No.: F164
NOTICE: After turning off the game, please wait at least 1 minute before
restarting again.
Note: Game specifications are subject to change without notice.
31.69 in
805 mm
34.37 in
873 mm
2376 mm
93.54 in

Skill Fantastic Prize 2 GMP Manual
06/15/2023
6
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
Following accessories
No.
Part No.
Part No.
Name/SPEC
Qty
1
F164-0503-00
2.53.00608837
1408a key
2
2
F164-0504-00
2.53.00608838
1408b key
1
3
F164-0505-00
2.53.00608839
1408c key
1
4
F164-0506-00
2.33.01.010020
Power cord
1
5
F164-0502-00
2.51.08.010023
String
1
6
F164-0510-00
4.14.40000645
Manual
1
7
F164-0507-00
2.19.01.000013
Fuse
Φ5×20 T10A/250V
1
8
F164-0508-00
2.19.01.000015
Fuse
φ5×20mm T6.3A/250V
1
9
F164-0509-00
2.19.01.000012
Fuse
Φ5×20mm T5A/250VAC
1
10
F164-0501-00
202.2.2306.001
Coin mech. Blanking plate
1
11
F164-0511-00
2.66.01.110457
Packing bag
1
12
F164-0512-00
2.66.01.110458
Blade set
1
NOTE: Part models are subject to change without notice.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
7
3. PART NAME
Key Components
Marquee Assembly
Coin mechanism
Scissor
Button
Display

Skill Fantastic Prize 2 GMP Manual
06/15/2023
8
Leveler
About 0.2 in/5mm
Leveler
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
Place the unit on a dry level surface.
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground by 0.2 in/5mm. Repeat the same for all
levelers.
We do not recommend using power tools as they may cause damage.
NOTICE
Make sure the machine is level.
NOTICE
Leveler
Leveler

Skill Fantastic Prize 2 GMP Manual
06/15/2023
9
4.3 Machine Installation
Step 1 Place the marquee on the top, connect the connectors for marquee, and tighten
screws;
Finish!
Marquee
Marquee

Skill Fantastic Prize 2 GMP Manual
06/15/2023
10
5. LOCATION OPERATION INSTRUCTIONS
5.1 First Power On Operation
Step 1. When first power on the machine, only need to confirm and adjust below
parameter ↓
No.
Parameter
Recommend
How to Set
1
Coin/Game
(How many
coins per play)
3-5 coins
Screen:ParaSet-Coin/Game
Warning: All the other parameters have been fully tested by factory technical personnel
before shipped. Do not adjust until you have read the manual & instructions in detail.
5.2 Prize Hanging Important Notice
Note: Please follow the process to hang the prize!
Step 1. Take out the String from accessory bag (see below picture).
Open front Prize door with door key,
there is a Keyboard near the Coin box.
Press “PROGRAM” button to enter the
setting menu.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
11
Step 2. Tie one end of String to the Hook and the other end of String to the Prize; The String
must be tied inside the middle lowest point of Hook, and must be fixed straight;
(One end of String to the hook↑） (The other end of String to the Prize↑）
Two Ways of Placing Prize: Prize can be hung or place onto the Platform
Prize Hung Weight Limit: 33.06 lb
Step 3. When pull the string to pass through the prize bar, please make sure the string
pass both Limit hole A and Limit hole B, requests 2-3 circles to go through Limit hole B;
6. HOW TO PLAY
1. Insert Coin(s) or Tap/Swipe Card to Start.
2. Press and hold the button to extend the scissors.
3. Release the button in a good timing to cut the string.
4. If String cut: Glass door will open, the prize drops and player wins the prize. If String not
cut: player should try again.
Note: Attendant should refill the prize after prize is collected by player.
Limit hole B
Limit hole A
Prize bar
Hook
Scissor
Prize
Prize Platform Bearing Weight Limit: 176.36 lb

Skill Fantastic Prize 2 GMP Manual
06/15/2023
12
7. GAME OPTION
7.1 Keyboard instruction
After entering the menu, use the keyboard to control mini screen cursor to up, down, left
and right to choose, press “Confirm” button to enter or save.
Options
Description
L
Move mini screen cursor to left
R
Move mini screen cursor to right
UP
Move mini screen cursor to up
DOWN
Move mini screen cursor to down
PROGRAM
Long press to enter setting menu/Return
FREEGAME
Service coin to activate plays
CONFIRM
To confirm every selection/Enter
7.2 Setting menu
7.2.1 Main menu: The first interface while entering the setting menu
No.
Options
Description
01
Accounts
Refer to 7.2.2
02
ParaSet
Refer to 7.2.3
03
Hardware
Refer to 7.2.4
04
VerInfo
Refer to 7.2.5
05
Exit
Open front Prize door with door key,
there is a Keyboard near the Coin box.
Press “PROGRAM” button to enter the
setting menu.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
13
7.2.2 Accounts: operation records are included as below
Options
Description
COINS
The total number of coins inserted.
GAMES
The total number of game plays.
PRIZES
The total number of prize out.
7.2.3 Para Set: Game settings up are included as below
No.
Options
Adjustable value
Default
Description
01
Coin/Game
1-20
2
The number of coins for each game.
02
Pats/Game
1-2
2
How many pats per game.
03
Level
Easy/Normal/Hard
Easy
The playing difficulty.
04
Blade
270-400
280
05
Volume
0-30
25
06
Run Max
0-4280
-
07
Cut Pos
2800-3000
-
For prize out usage: The distance
between the scissor and the rope. It is
to help prize out, the biggest the
number, more helpful for prize out.
08
Open Mode
Win/Lock
Win
Win:Glass door will open while the
player wins;
Lock: Need attendant to use Keys to
open the front door;
09
Free Mode
On/Off
Off
Free play
10
DBV Bonus
On/Off
On
If no DBV installed, On/Off: both invalid
If DBV installed and select Off: no extra
credits;
If DBV installed and select On: 4 bonus
credits will be given while inserting 5,
10 or 20 dollars;
11
Demo Music
On/Off
On
12
Np Alarm
On/Off
On
13
Language
English/Chinese
English
14
Clr Accounts
Continue/Exit
-
Clear account and the number of
games
15
Factory Reset
Continue/Exit
-
To reset the machine
16
Exit
Back to the front page

Skill Fantastic Prize 2 GMP Manual
06/15/2023
14
7.2.4 Hardware
7.2.5 Ver Info (Show Version number & Date)
Ver:
SKNJ - - - -
(Date)
_ _-_ _-_ _
No.
Options
Description
01
Test
Test the electrical components.
02
Cut Off
Test the crane to cut the string.
03
Open Door
Open the front glass door.
04
Demo Color
Change the led lighting colors.
05
Music Test
06
Exit

Skill Fantastic Prize 2 GMP Manual
06/15/2023
15
8. TROUBLESHOOTING
8.1 Common Problem
Please confirm that all connectors fit tightly.
Symptom
Possible Cause
Recommended action
Game will not
start
Frame assembly connector is
loose.
Check connector.
Frame assembly fault
Contact with UNIS Service.
Power off
Circuit protector make power SW
in off state.
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact with UNIS
Service.
No sound
Low volume
Raise the volume.
Connector loose.
Check connector.
Speaker fault.
Check speaker.
POT installation error.
Install POT correctly.
POT fault.
Change POT.
Audio cable problem.
Reconnect the audio cable or change
it.
The prize door
can’t open.
Door lock is faulty
Replace the door lock.
The door holder stuck with the
lock.
Remove the door holder.
The door stuck with the cabinet
frame.
Utilize key to open.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
16
If you see following error signs showing on the display, please try the recommended action.
Display
Possible Cause
Recommended action
E5 Pls Close
Door
The prize door is not been
closed.
Close the prize door
The prize door lock is faulty.
Replace the prize door lock.
E3 Motor Err
The crane do not touch the
Back limited sensor.
Restart the machine.
Connector became loose
during transport.
Check and reconnect the Back limited
sensor and Front&back motor
connector.
Back limited sensor is faulty.
Replace Back limited sensor.
Front and back motor is faulty.
Replace Front and back motor motor.
E4 Cut Err
The scissors are not cut or
continuously cutting during the
game.
Restart the machine.
Connector became loose
during transport.
Check and reconnect the sensor and
motor connector.
Scissors sensor screw loosen
Adjust the scissors sensor screw.
Scissors sensor is faulty.
Replace scissors sensor.
Scissors motor is faulty.
Test the scissors motor.(Refer to 8.4).
If the motor is faulty, replace scissors
motor.
E1 Coin Error
The coin mechanism signal is
faulty.
Turn the NO/NC switch to the NO
position.
The coin mechanism is faulty.
Replace coin mechanism.
E2 No Prize
Hanging
No prize on the cabinet.
Add prize.
The prize is too light
The prize weight should be over 0.5kg.
Hook sensor is faulty.
Replace Hook sensor.
8.2 System Update Operation
Step 1. Power off the game.
Step 2. Insert the TF card with new program into the TF card socket of the mainboard.
Step 3. Power on and the system will automatically start update.
Step 4. Wait for several seconds, remove TF card. Restart the machine.
Step 5. Factory Reset: Enter Program-ParaSet-Factory Reset.
Step 6. Program Update complete!
WARNING: The TF card should only be used to update system. Using it for other
purposes may cause unexpected results and damages.

Skill Fantastic Prize 2 GMP Manual
06/15/2023
17
9. MAINTENANCE & INSPECTION
9.1 Safety Check
Check the points listed before operating the machine. These checks are necessary for safe
machine operation:
1. Test game before operation each day.
2. Conduct monthly routine checks of game components to ensure good working
condition.
3. Check the machine regularly for dust and clean when necessary.
Note: Parts and components require preventative maintenance to maintain proper
operation.
9.2 Handling Precautions
When installing or inspecting the machine, be very careful and pay attention to ensure that
the player can enjoy the game safely.
Inappropriate handling running counter to the cautionary matters can cause personal injury
or damage to the machine.
We do not recommend using power tools as they may cause damage.
NOTICE

Skill Fantastic Prize 2 GMP Manual
06/15/2023
18
10. OVERALL CONSTRUCTION
10.1 General Assembly
No.
Part No.
Code No.
Name
Version
Qty
1
F164-0002-00
206.2.2306.002
Glass door PVC board
V1.1
4
2
F164-0004-00
206.2.2306.026
Glass door hole rubber pad
V1.1
8
3
F164-0009-00
206.2.2306.008
Front glass door light plastic
V1.1
1
4
F164-0010-00
206.2.2306.009
Front glass door light plastic
V1.1
1
5
F164-0011-00
206.2.2306.010
Front glass door light plastic
V1.1
1
6
F164-0012-00
206.2.2306.011
Front glass door light plastic
V1.1
1
7
F164-0013-00
206.2.2306.012
Front glass door light plastic
V1.1
1
8
F164-0014-00
206.2.2306.013
Front glass door light plastic
V1.1
1
9
F164-0015-00
206.2.2306.016
Display cover plastic
V1.1
1
10
F164-0016-00
206.2.2306.017
Display light plastic
V1.1
2
11
F164-0017-00
206.2.2306.018
Side light plastic 1
V1.1
4
12
F164-0018-00
206.2.2306.019
Side light plastic 2
V1.1
4
13
F164-0019-00
206.2.2306.020
Front glass
V1.1
1
14
F164-0020-00
206.2.2306.021
Side glass
V1.1
2
15
F164-0021-00
206.2.2306.033
Panel light plastic
V1.1
1
16
F164-0022-00
206.2.2306.022
Inner base glass
V1.1
1

Skill Fantastic Prize 2 GMP Manual
06/15/2023
19
10.2 Cabinet Frame
No.
Part No.
Code No.
Name
Version
Qty
17
F164-0023-00
206.2.2306.023
Side bottom light plastic
V1.1
2
18
F164-0024-00
206.2.2306.024
Front bottom light plastic
V1.1
1
19
F164-0025-00
2.60.00008000
Leveller
V1.1
4
20
F164-0026-00
2.60.00010000
Caster plate
V1.1
4
21
F164-0029-00
203.2.2306.001
Electrical mounting plate 1
V1.1
1
22
F164-0030-00
203.2.2306.002
Electrical mounting plate 2
V1.1
1
23
F164-0031-00
203.2.2306.003
Mirror back board
V1.1
1
24
F164-0032-00
203.2.2306.004
Spotlight mounting plate 1
V1.1
2
25
F164-0033-00
203.2.2306.005
Spotlight mounting plate 2
V1.1
2
26
F164-0034-00
206.2.2306.034
Marquee light mounting PVC
V1.1
1
27
F164-0035-00
206.2.2306.014
Marquee light plastic 1
V1.1
1
28
F164-0036-00
206.2.2306.015
Marquee light plastic 2
V1.1
1
29
F164-0037-00
LJ.G-02-08
Marquee bracket
V1.1
1
