UNIS PONG Arcade User manual

Arcade version
www.universal-space.com
Operation Manual
IMPORTANT

PONG Arcade Ver. Manual
08/13/2019
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
When contacting Service, you will need the following information
and the name of your authorized distributor.

PONG Arcade Ver. Manual
08/13/2019
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 6
3. PART NAME............................................................................................................7
4. SET UP & INSTALLATION.....................................................................................8
5. HOW TO PLAY......................................................................................................10
6. GAME OPTION..................................................................................................... 11
7. TROUBLESHOOTING............................................................................................17
8. MAINTENANCE & INSPECTION.......................................................................... 17
9. OVERALL CONSTRUCTION..................................................................................27
10. WIRING DIAGRAM............................................................................................ 44

PONG Arcade Ver. Manual
08/13/2019
3
Thank you for purchasing PONG. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

PONG Arcade Ver. Manual
08/13/2019
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

PONG Arcade Ver. Manual
08/13/2019
5
1. SPECIFICATIONS
Rated power supply: AC110V~50/60Hz; AC220V~50/60Hz;
Min. Power consumption: 200W
Max. Power consumption: 280W
Dimension: W 55.91×D 34.10×H 31.67 in
W 1420×D 866×H 804.3 mm
Weight: Approximately 353 lb
Part No: P148
Model: A-427
NOTICE : After turning off the game, please wait at least 1 minute before
restarting again.
Note: Game specifications are subject to change without notice.

PONG Arcade Ver. Manual
08/13/2019
6
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
1. Following accessories
No.
Part No.
Code
Name
Qty
1
P152-801-000
23301010020
Power cord
1
2
P152-436-000
21901000010
Fuse
1
3
P152-806-000
41440000247E
Manual
1
4
P152-180-000
20211707045A
Adjust plate A
1
5
P152-181-000
20211707046A
Adjust plate B
1
6
P152-803-000
25300171002
Key
2
7
P152-804-000
25300172002
Key
2
8
P152-334-000
20101020034
Cross recessed
pan head
screw set
2
9
P152-303-000
20113000003
Standard
spring washer
2
10
P152-805-000
25302000010
Key
2
11
P152-807-000
20211707H040
weight
1
12
P152-808-000
40607000013
Allen wrench
1
NOTE: Part models are subject to change without notice.

PONG Arcade Ver. Manual
08/13/2019
7
3. PART NAME
Key Components
Paddle
Display
Power switch
Ball
Coin
mechanism
Jog
Paddle
Display
Power switch
Ball
Paddle
Display
Power switch
Ball
Coin
mechanism
Jog
Paddle
Display
Power switch
Ball
Ticket dispenser

PONG Arcade Ver. Manual
08/13/2019
8
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
Place the unit on a dry level surface
Ventilation openings must not be obstructed by objects or by wall.
4.1 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Play area: 20 in
We do not recommend using power tools as they may cause damage.
NOTICE
Play area
Your unit must be leveled to operate properly.
NOTICE

PONG Arcade Ver. Manual
08/13/2019
9
4.2 Voltage Conversion
Locate the Power supply. Loosen the power supply cover screws and take it off.
Toggle the switches to 115V or 230V according to your need.
4.3 Card Reader Installation Safety Notice
Take precaution to assure that all wring voltages are confirmed prior to installation
of card reader. All warranties are void if not properly installed resulting in logic board
damage.

PONG Arcade Ver. Manual
08/13/2019
10
5. HOW TO PLAY
5.1 Press 1P Start button or 2P Start button, then choose Easy/Normal/Hard mode to start
the game. Move the jog to control the paddle, press the orange button to shoot. (Same
function as the two orange buttons)
Press the orange
button to start the
game and shoot
the ball!
Turn the jog to
control the paddle
moving left and
right in order to
catch the ball.
Easy
Normal
Hard
Orange button
Jog
1 P start
2 P start
Orange button
Orange button

PONG Arcade Ver. Manual
08/13/2019
11
6. GAME OPTION
Enter into the setting menu
Step 1 Locate the Player 1 side(the side near Power switch) and open the coin door.
Step 2 Press Settings button to move the Ball to the middle and press the Settings button
again, then you’ll see “CONF” on the display. (It doesn’t work during game over.)
Roll the jog or press 1P and 2P to select the setting, press the right orange button to enter
and set, press the left orange button to exit.
Note: It is the same steps when game playing.
Back
Next
Next/Prev
Prev
Enter/Set

PONG Arcade Ver. Manual
08/13/2019
12
6.1 Setting Menu
When SERVICE MODE is active, you
will see CONF in the scoreboard by
default. Spinning the JOG will switch
spelling between configuration (CONF)
and checks (CHEC)
BACK exits SERVICE MODE and SET
selects the active option.
Functions audio related
DATA CLEAR
Clear all data.
Default settings reset
(Press SET to “0” to set)
Clear all data.
(Press SET to “0” to set)

PONG Arcade Ver. Manual
08/13/2019
13
VALUES: CL
FU
Ny
Re
DEFULT: CL
VALUES: CL
FU
Ny
Re
DEFULT: CL
VALUES: #
RANGE:
0..99
DEFULT: 30
VALUES: #
RANGE:
0..99
DEFULT: 99
VALUES: #
RANGE:
0..99
DEFULT: 99
This option only applies to units
fitted with a coin mechanism.
Choose FREE PLAY or COIN
OPERATED.
This menu is navigated with
NEXT/PREV
JOG changes the parameter.
SET for select.
MERCY TICKET
TICKET FOR
WINNER
VALUES: #
RANGE: 0..99
DEFULT: 0
VALUES: #
RANGE: 0..99
DEFULT: 0
VALUES: #
RANGE: 1..20
DEFULT: 1
LOCK COIN
VALUE:#
RANGE:0-02
LC01: Lock coin mode. After one side inserts coins, the other
side can’t insert coins and press 2P button to join until one side
consumes all coins.
LC02: 1. (1)Insert coins is enabled during game time. (2)Coins
inserted by one side can be shared with the other side.
(3)Games can be started by either side.
2. When one side is playing 1P game, new player can insert
coins but can’t join the game until one side finishes that round.
LC00: 1. (1)Insert coins is enabled during
game time. (2)Coins inserted by one side
can’t be shared with the other side.
(3)Games can only be started by the side
that inserts coins.
2. When one side is playing 1P game and
the higher score is less than a half of the
points per game (Eg: Points per game:6,
Score:3-X, X ≤3; Points per game:5,
Score:2-X ，X≤2 ), new player can insert
coins and press 2P button to join.

PONG Arcade Ver. Manual
08/13/2019
14
VALUE: #
RANGE: 0..99
DEFAULT: 01
VALUES: #
RANGE: 3..39
DEFAULT: 05
VALUES: #
RANGE: 0..6
DEFAULT: 03
NORMAL GAME
SPEED
HARD GAME
SPEED
EASY GAME
SPEED
VALUES: #
RANGE: 0..6
DEFAULT: 0
VALUES: #
RANGE: 0..6
DEFAULT: 05
VALUES: #
RANGE: 0..04
DEFAULT: 02
Game Speed:
0-----0.3175m/s
1-----0.4978m/s
2-----0.6782m/s
3-----0.8585m/s
4-----1.0389m/s
5-----1.2192m/s
6-----1.5875m/s

PONG Arcade Ver. Manual
08/13/2019
15
AUTO
LEDS, Motors and
Inputs auto tests.
( Press SET and
BACK to exit.)
Motors tests.
( Press SET and
BACK to exit.)
Inputs tests.
( Press SET and
BACK to exit.)
VALUES: #
RANGE: 0..99
DEFAULT: 50
VALUES: #
RANGE: 0..90
DEFAULT: 03
(Note: 00=30s)

PONG Arcade Ver. Manual
08/13/2019
16
After powering on the machine, the display will show the Program Version(the left two
characters) and the Music File Version(the right two characters).
P1 EASY pressed
P1 NORMAL pressed
P1 HARD pressed
P2 EASY pressed
P2 NORMAL pressed
P2 HARD pressed
Music File
Version
Program
Version
(Press SET & BACK buttons)

PONG Arcade Ver. Manual
08/13/2019
17
7. TROUBLESHOOTING
7.1 Common Problem
Please confirm that all connectors fit tightly.
Symptom
Possible Cause
Recommended action
Game will not
start
Frame assembly connector is
loose.
Check connector.
Frame assembly is faulty.
Contact UNIS Service.
Power off
Circuit protector changes power
SW to “off”.
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact UNIS Service.
No sound
Low volume
Raise the volume.
Connector loose.
Check connector.
Speaker is faulty.
Check speaker.
Audio cable problem.
Reconnect the audio cable or change
it.
Driver problem
Restart the audio driver.
Ball shaking
The bottom of the Ball or the
playfield has dirt.
Utilize non-woven fabric with distilled
water to clean the bottom of the Ball.
Clean the playfield. (Refer to 8.3)
Error code
Possible Cause
Recommended action
Motors of Ball X axle
doesn’t work.
Check the connection of motors of Ball X
axle.
Check the motors of Ball X axle.
Sensor of Ball X axle
doesn’t work.
Check the sensor of Ball X axle.
Motor of Ball Y axle doesn’t
work.
Check the connection of motor of Ball Y
axle.
Check the motor of Ball Y axle.
Sensor of Ball Y axle
doesn’t work.
Check the sensor of Ball Y axle.
Motor of P1 Paddle doesn’t
work.
Check the connection of motor of P1
Paddle.
Check the motor of P1 Paddle.
Sensor of P1 Paddle
doesn’t work.
Check the sensor of P1 Paddle.
Motor of P2 Paddle doesn’t
work.
Check the connection of motor of P2
Paddle.
Check the motor of P2 Paddle.
Sensor of P2 Paddle
doesn’t work.
Check the sensor of P2 Paddle.
Out of ticket
Fill the ticket dispenser with tickets.
(Refer to next page for detailed locations.)

PONG Arcade Ver. Manual
08/13/2019
18
8. MAINTENANCE & INSPECTION
8.1 Safety Check
These checks are necessary for safe machine operation:
1. Test game before operation each day.
2. Conduct monthly routine checks of game components to ensure good working
condition
3. Check the machine regularly for dust and clean as necessary.
Note: Parts and components require preventative maintenance to maintain proper
operation.
8.2 Handling Precautions
When inspecting the machine, be very careful of the following points and pay attention
to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the
cautionary matters herein stated can cause personal injury or damage to the machine
We do not recommend using power tools as they may cause damage.
NOTICE
Motor of Ball Y axle
Motor of P2
Paddle
Motor of Ball
X axle
Motor of Ball
X axle
Motor of P1
Paddle
Sensor of Ball Y axle
Sensor of
Ball X axle
Sensor of P1
Paddle
Sensor of P2
Paddle

PONG Arcade Ver. Manual
08/13/2019
19
8.3 How To Clean The Playfield
Step 1 Power off the game. Insert the key to the lock and turn 90 °clockwise or
counterclockwise. Press the glass pressing plate slightly to make the lock pop up. (The
method is the same on both two locks.)
Open the glass.
Step 2 Utilize non-woven fabric with distilled water to clean the playfield.
8.4 How To Replace Wool Felt Pad On Paddle
Step 1 Remove the wool felt pad from the paddle.
Step 2 Adhere the new wool felt pad to the paddle.
8.5 How To Replace The Teflon Tape On The Ball
Step 1 Remove the Teflon tape on the ball.
Step 2 Adhere the new Teflon tape to the ball.
＋
=
＋
=
playfield
