Viega Multiplex Trio E User manual

for the operation of Multiplex Trio E by mobile end devices (APP)
Model Year built:
6146.224 from 06/2016
en_INT
Multiplex Trio E-WLAN module
Instructions for Use

Multiplex Trio E-WLAN module 2 from 15

Table of contents
1About these instructions for use 4
1.1 Target groups 4
1.2 Labelling of notes 4
1.3 About this translated version 5
2Product information 6
2.1 Safety advice 6
2.2 Intended use 6
2.3 Product description 7
2.3.1 Overview 7
2.3.2 Technical data 7
3Handling 8
3.1 Mounting instructions 8
3.2 Assembly 8
3.2.1 Installation situation Trio E or E2 8
3.2.2 Installation situation Trio E3 9
3.3 Commissioning 11
3.3.1 Establishing a connection with mobile end devices 11
3.4 Disposal 15
Table of contents
Multiplex Trio E-WLAN module 3 from 15

1 About these instructions for use
Trade mark rights exist for this document, further information can be
found at viega.com/legal .
1.1 Target groups
The information in this instruction manual is directed at the following
groups of people:
nHeating and sanitary professionals and trained personnel
nOperators
nConsumers
It is not permitted for individuals without the abovementioned training or
qualification to mount, install and, if required, service this product. This
restriction does not extend to possible operating instructions.
The installation of Viega products must take place in accordance with
the general rules of engineering and the Viega instructions for use.
1.2 Labelling of notes
Warning and advisory texts are set aside from the remainder of the text
and are labelled with the relevant pictographs.
DANGER!
This symbol warns against possible life-threatening injury.
WARNING!
This symbol warns against possible serious injury.
CAUTION!
This symbol warns against possible injury.
NOTICE!
This symbol warns against possible damage to property.
Notes give you additional helpful tips.
About these instructions for use
Multiplex Trio E-WLAN module 4 from 15

1.3 About this translated version
This instruction for use contains important information about the choice
of product or system, assembly and commissioning as well as intended
use and, if required, maintenance measures. The information about the
products, their properties and application technology are based on the
current standards in Europe (e. g. EN) and/or in Germany
(e. g. DIN/DVGW).
Some passages in the text may refer to technical codes in Europe/
Germany. These should serve as recommendations in the absence of
corresponding national regulations. The pertinent national laws, stand-
ards, regulations and guidelines, as well as other technical guidelines,
have priority over German/European guidelines in this manual: The
information is not binding for other countries and territories and should,
as mentioned, be considered as support.
About these instructions for use
Multiplex Trio E-WLAN module 5 from 15

2 Product information
2.1 Safety advice
DANGER!
Risk of electric shock
An electric shock can lead to burns and serious injury and
even death.
– Work on the electrics may only be carried out by trained
electricians.
– Switch off the mains voltage before opening the casing.
– Switch off the mains voltage before connecting the
power pack.
WARNING!
Risk of scalding from hot water
Excessively hot water can lead to severe scalding, espe-
cially in the case of children.
Take the following steps to avoid scalding:
– Do not allow children to play with the control elements
unsupervised.
– Disable the temperature safeguard in exceptional cases
only.
– Make sure that no one can come into contact with the
hot water before carrying out thermal disinfection.
WARNING!
Risk of injury due to control via remote access
Controlling the equipment via remote access is permissible
only if there are no persons standing in the direct operating
range.
2.2 Intended use
The WLAN module controls the Multiplex Trio E fittings by means of a
mobile end device (such as smartphone or tablet). The WLAN module is
easy to refit for already installed Multiplex Trio E fittings (art. no. 662295,
682972, 684655).
The installation is permissible for specialist companies only under com-
pliance with the applicable regulations.
Pay attention to the additional notes in the respective instructions for
use of the Multiplex Trio E.
Product information
Multiplex Trio E-WLAN module 6 from 15

2.3 Product description
2.3.1 Overview
2
1
3
Fig. 1: Overview
1 - WLAN module
2 - Connection socket
3 - Plug (display)
2.3.2 Technical data
Dimensions H x W x D 63 x 63 x 24 mm
Operating temperature min.–max. 0–60 °C
Rel. humidity min.-max. 5–95 %
Plug JST XHP6
Cable length 200 mm
Encryption WPA 2
Network WLAN (802.11 b/g/n)
IP Code IP 20
Protection class III
Power supply 6–15 V
Transmission frequency 2.4 Ghz
Material (casing) ABS
NOTICE!
Regularly update your browser and operating system.
Should you have any questions on compatibility, please
contact the Viega Service Center.
Product information
Multiplex Trio E-WLAN module 7 from 15

3 Handling
3.1 Mounting instructions
The WLAN module is mounted in different manners, depending on the
existing Multiplex Trio E-fitting:
nMultiplex Trio E and E2 ( ÄChapter 3.2.1 „Installation situation Trio E
or E2“ on page 8 )
nMultiplex Trio E3 ( ÄChapter 3.2.2 „Installation situation Trio E3“
on page 9 )
If the WLAN module is mounted together with the Multiplex Trio E fit-
ting, the assembly steps for the Multiplex Trio E fitting must be
observed as well.
Connect the existing connection cables in the following plugging order:
1 TLI A
2 TLI B
3 Motor
4 Display
5 BATTERY
6 15 V
7 ! 230-V connection
3.2 Assembly
3.2.1 Installation situation Trio E or E2
Use a Phillips-tip screwdriver to remove the two screws from the
casing, and lift off the cover.
Refitting an existing Multiplex Trio E fitting
Mounting the Multiplex Trio E fitting together with the WLAN module
Handling
Multiplex Trio E-WLAN module 8 from 15

Insert the WLAN module (cable outlet left-hand side) at an angle into
the gap between battery and power pack.
Plug the connection cable of the WLAN module into the slot with the
designation „Display“ .
Replace the casing cover and use the Phillips-tip screwdriver to
tighten the two screws.
3.2.2 Installation situation Trio E3
PW: 1 23456 789 0
ON Prototy pe
SN 12345 678 90
PW: 123 4567890
ON Prot otype
SN 1234 567890
Handling
Multiplex Trio E-WLAN module 9 from 15

Use a Phillips-tip screwdriver to remove the two screws from the
casing, and lift off the cover.
Remove the plug at the „Display“ slot.
Plug the removed display cable into the WLAN module.
Insert the WLAN module (cable outlet left-hand side) at an angle into
the gap between battery and power pack.
Handling
Multiplex Trio E-WLAN module 10 from 15

Plug the connection cable of the WLAN module into the „Display“
slot.
Lay the display cable in the cable conduit below the battery.
Replace the casing cover and use the Phillips-tip screwdriver to
tighten the two screws.
3.3 Commissioning
3.3.1 Establishing a connection with mobile end devices
There are two ways to connect the Multiplex Trio E fitting with its mobile
end devices.
nPeer-to-peer connection
nvia the router in the home network (Internet connection required)
We recommend to use a direct connection only during the initial installa-
tion. For daily use, the integration of the Multiplex Trio E fitting into the
home network is more comfortable. To use this variant, you will addi-
tionally need a free-of-charge user account with Viega.
PW: 1 234 567 890
ON Pr oto typ e
SN 12 345 678 90
PW: 1 2345 678 90
ON Pr otot ype
SN 12 3456 789 0
PW: 123 4567890
ON Prot otype
SN 1234 567890
Handling
Multiplex Trio E-WLAN module 11 from 15

WEP
WPA 2
Fig. 2: Peer-to-peer connection
Step 1: At your end device, select Settings > WLAN to indicate the
available WLAN networks.
Step 2: Select a network, e.g. "trio-e-1234567890".
Step 3: Enter the password and connect (see the ten-digit PW
number on the label of the WLAN module)
ðYou have established a direct connection between the end
device and the WLAN module.
Step 4: Open the Internet browser at the end device. Type 1.1.1.1 in
the address line and press Enter to confirm.
ðThe user interface of the Multiplex Trio E is indicated.
Requirements:
nA direct connection has been established between an end device
and the WLAN module.
nThe home network must have a good signal strength in the area of
the Multiplex Trio E fitting.
Establishing a peer-to-peer connection
Connecting the WLAN module with the home network
Handling
Multiplex Trio E-WLAN module 12 from 15

Fig. 3: Connecting the WLAN module with the home network
Step 1: Open the Internet browser in the end device. Type
192.168.1.1 in the address line and press Enter to confirm.
ðThe user interface of the Multiplex Trio E is indicated.
Step 2: In the menu, open the item „Network“ .
Step 3: Select the personal home network from the list of available
networks.
Step 4: Enter the personal WLAN password for the home network.
ðThe WLAN module connects to the home network (router).
Once the connection has been established, the window
remains inactive and can be closed.
Step 5: At your end device, select Settings > WLAN to indicate the
available WLAN networks and to connect to the home network.
As soon as the WLAN module connects to the router, the network
established by the WLAN module is not longer indicated.
When the router is disconnected from the mains, the net-
work established by the WLAN module will be indicated
once more after a waiting period of approx. 6 minutes.
Step 1: Open the Internet browser in the end device.
Step 2: Type https://trio-e.viega.de
in the address line and press Enter to confirm.
ðThe registration screen of the Multiplex Trio E is indicated.
Step 3: Click „Register“ in the registration window.
Step 4: Enter your personal data.
Creating a user account on the Internet
Handling
Multiplex Trio E-WLAN module 13 from 15

After you made the registration, you'll receive an email to
the indicated email account. Copy the Internet address from
the email into the address line of your browser and press
Enter to complete the registration. You have created your
user account, and it is now available to you.
In the user account, the WLAN module must be assigned to a certain
object (e.g. own house, rental apartment Station Road). If several
objects are managed in one user account, you can differentiate the
objects by way of this object name so that you can control the individual
devices separately.
Step 1: Open the Internet browser in the end device. Type https://
trio-e.viega.de in the address line and press Enter to confirm.
ðThe registration screen of the Multiplex Trio E is indicated.
Step 2: Enter your email and password and click „Login“ .
ðThe device overview is indicated.
When you do the initial installation, no device is connected yet.
Step 3: Click the blue Plus icon (= create a new object).
Step 4: Give the object a meaningful name and press „OK“ to con-
firm your entry.
ðThe new object is shown in the device overview.
Step 5: Click „Add new device“ in the top menu bar.
Step 6: Enter the serial number and password of the WLAN module
(see WLAN module label).
Step 7: Select the respective object via the Object selection menu.
Step 8: Press „Add“ to confirm your entry.
ðThe WLAN module establishes a connection with the object.
The device overview is indicated.
Requirements:
nYou already have a personal user account.
nThe WLAN module is connected to the home network (router).
Step 1: Open the Internet browser in the end device. Type https://
trio-e.viega.de in the address line and press Enter to confirm.
ðThe registration screen of the Multiplex Trio E is indicated.
Step 2: Enter your email and password and click „Login“ .
Adding the WLAN module to the user account
Opening the user interface
Handling
Multiplex Trio E-WLAN module 14 from 15

Step 3 (optional): Click the Link button to create a rapid access
(favorite).
Step 4: Press the „Start“ button to call up the user interface of the
Multiplex Trio E.
3.4 Disposal
Separate the product and packaging materials (e. g. paper, metal,
plastic or non-ferrous metals) and dispose of in accordance with valid
national legal requirements.
Handling
Multiplex Trio E-WLAN module 15 from 15
