Whalen WSF60RV26DO User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2020-05-27 Rev. 0001-C
Ridgeview 60in Fireplace Console
Model # WSF60RV26DO
# WSF60RV26WA
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenfurniture.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /
OR

2
IMPORTANT
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and
non-abrasive surface. You will need the parts identified on page 3 and 4 of this instruction manuals.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE
WIPED OFF WITH A DAMP CLOTH.
Insert dowel at least half way by tapping lightly with a rubber mallet (not included), IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam Bolt into the pre-drilled small holes on the panel. Connect both panels together; making
sure the Cam Bolt goes into the pre-drilled hole at the end of the panel with the Cam Lock.
2. Insert the Cam Lock into the pre-drilled large hole in the panel. Make sure the arrow on the Cam Lock is
pointed towards the Cam Bolt.
3. Once the Cam Bolt is connected inside the Cam Lock, take a Phillips screwdriver (not included) and
tighten the Cam Lock clockwise.
4. Plug the Cam Lock Cover into the cross slot of the Cam Locks to conceal the cam.
You are now ready to assemble the KD unit.
How to adjust the European adjustable hinges on doors
Shipping may cause doors to go out of alignment. If you find that the doors need to be adjusted
slightly, turn the appropriate screw, as illustrated.
1. TO ADJUST DOOR FORWARD OR BACKWARD.
2. TO ADJUST DOOR TO RIGHT OR TO LEFT.
3. TO ADJUST DOOR UP OR DOWN.
1
2
3
GLUE
XXFINAL
1 2 43
1234

3
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Top Panel (Qty. 1) B- Fixed Shelf (Qty. 1) C- Base (Qty. 1)
D- Side Panel with Molding (Qty. 2) E- Left Partition Panel (Qty. 1) F- Right Partition Panel (Qty. 1)
G- Upper Crossbar (Qty. 1) H- Middle Crossbar (Qty. 1) I- Middle Left Stile (Qty. 1)
J- Middle Right Stile (Qty. 1) K- Firebox Support (Qty. 1) L- Left Adjustable Shelf (Qty. 2)
M- Right Adjustable Shelf (Qty. 2) N- Door (Qty. 2) O- Left Back Panel (Qty. 1)
P- Middle Back Panel (Qty. 1) Q- Right Back Panel (Qty. 1) R- Glass Door Insert (Qty. 2)
Fireplace Insert (Qty. 1) Remote Control with Battery (Qty. 1) (1) Cam Lock (Qty. 22+1 extra)

4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
(2) Cam Bolt (3) M8 x 30 mm Wood Dowel (4) M3.5x12mmScrew
(Qty. 22+1 extra) (Qty. 24+1 extra) (Qty. 24+1 extra)
(5) M3.5x15mmWasherHeadScrew (6) M4x30mmScrew (7) M3.5x15mmPanHeadScrew
(Qty. 38+1 extra) Qty. 8+1 extra) (Qty. 8+1 extra)
(8) M4 x 50 mm Screw (9) Mending Plate (10) Stopper
(Qty. 4+1 extra) (Qty. 2) (Qty. 2)
(11) L-shaped Metal Bracket (12) Handle (13) 5/32’’ x 22 mm Bolt
(Qty. 2) (Qty. 2) (Qty. 4+1 extra)
(14) Shelf Support (15) Acrylic Stopper (16) Cam Cover
(Qty. 16+1 extra) (Qty. 1) (Qty. 18+1 extra)
Glue Touch-up Pen Tipping RestraintHardware Kit (Qty. 2)
(Qty. 1) (Qty. 1) (Included in plastic bag)
Tools required (not included): Phillips screwdriver, stud finder, pencil, tape measure, power drill and 1/8 in
drill bit.

5
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), Base (C),
Partition Panels (E and F) and Middle Crossbar (H) with a Phillips screwdriver.
NOTE: Screw-in cam bolts must be screwed down flush.
3. Insert fourteen Wood Dowels (3) into the inner holes on the Fixed Shelf (B) and Partition Panels (E and
F). Make sure that you use a small amount of glue with both ends of all dowels.
NOTE: It is very important to use a small amount of glue on both ends of dowels.
2
C
A
E
F
H
E
3
3
3
3
3
F
3
3
3
3
B
3
3
3
3
3

6
Assembly Instructions
4. Align and attach the Middle Crossbar (H) to the Fixed Shelf (B) by engaging three Cam Locks (1)
(Refer to page 2 on Cam Lock system operation supplement).
5. Align and attach the Middle Left Stile (I) to the Left Partition Panel (E) and fasten them into place with
four 30 mm Screws (6).
6. Repeat the same procedure to attach the Middle Right Stile (J) to the Right Partition Panel (F).
B
H1
1
1
EF
I
J
6
6

7
Assembly Instructions
7. Align and attach the Stoppers (10) to the Partition Panels (E and F) with four 12 mm Screws (4).
8. Attach the Fixed Shelf (B) beween the Partition Panels (E and F) by engaging four Cam Locks (1).
EF
10
4
1
E
F
B
E/F
B

8
Assembly Instructions
9. Using the wood dowels as a guide, firmly press the assembled Partition Panels (E and F) to the Base (C)
and fasten them in place with four 50 mm Screws (8). Fully tighten the screws with a Phillips
screwdriver.
10. Glue the Wood Dowels (3) into the inner holes of Side Panel with Moldings (D) and Upper Crossbar (G)
as shown.
NOTE: Do Not insert the wood dowels into the cam bolts holes.
8
8
8
8
E
F
C
D
DG
33
3
3
3
3
3
3
3
3

9
Assembly Instructions
11. Align the large holes on one Side Panel with Molding (D) with the inserted Wood Dowels (3) on the
Base (C). Firmly press them together and fasten it in place by engaging two Cam Locks (1).
12. Repeat the same procedure to attach the other Side Panel with Molding (D) at the other end.
13. Align and attach the Upper Crossbar (G) to the Top Panel (A) with three Cam Locks (1).
A
G
1
1
1
D
D
C

10
Assembly Instructions
14. Place the Top Panel (A) onto the inserted Wood Dowel (3) properly and fasten it in place by engaging
eight Cam Locks (1).
15. Ask for assistance to flip the unit around at its front edge as shown.
16. With the pilot holes as a guide, fasten the Middle Crossbar (H) to the Middle Left and Right Stiles (I
and J) by attaching two Mending Plates (9) at the joints, using two 12 mm Screws (4) per plate.
1
A
D
E
F
D
AD/E/F
HI
J
4
9
HI/J
