Table Top Racks
Assembly GUIDE
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
*All models follow the same assembly procedure varying only in the number of middle ladders your rack will require.
Package Contents tools for assembly
Page 1
or visit
wineracksamerica.com
Questions?
888.373.6057
WOOD SCREWS
LEFT
END LADDER
MIDDLE
LADDER
SOLID TOP (X1)
STANDARD CONNECTOR (X4)
SCREW COVERS
RIGHT
END LADDER
Cordless Drill
Wood Glue
Screwdriver
Required
Suggested
KITCHEN MODEL MIDDLE LADDERS
24 BOTTLE RACK [3x]
36 BOTTLE RACK [5x]
48 BOTTLE RACK [3x]
64 BOTTLE RACK [7x]
SCAN FOR
ASSEMBLY VIDEO

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
Table Top Racks
Page 2
1. Find an open, flat area in which to work. Carefully remove all components from the box and remove banding
with a utility knife. Check the parts list to verify package contents.
2.
Arrange the end ladders on the floor so that the angled bottle supports face the ground. Align the large gaps on each
end ladder. The end with the larger gap is the top of your rack. Attach a standard column connector to the top and
bottom of your rack using the screws provided. Make sure the connectors are flush with the top and bottom of your
rack. (figure 1)
Top of rack
1
BEGIN WITH BACK
OF RACK
3. Insert the middle ladders and finish securing the top & bottom connectors using the screws provided. Make sure
that the angled bottle supports are facing the ground. (figure 2)
2
FINISH SECURING BACK
CONNECTORS

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
Measurements are from
the bottom of the rack to
the top of the connector
IMPORTANT!
Table Top Racks
Page 3
25 11/16"
*NOTE: If you purchased a 48 Bottle Kitchen Rack, your unit will come with 1 extra standard connector. Attach
connector to the back of the rack with a cordless drill or screwdriver.
4. Flip rack over. Attach the remaining connectors to the top and bottom of the rack using the provided screws.
(figure 3)
Cover the screw holes on the front connectors using the provided adhesive screw covers.
3
FRONT OF RACK

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
Table Top Racks
Page 4
4
ATTACH SOLID
TOP
5. Stand the rack up and insert the solid top into place on top of the rack. The bottom side of the solid top will have
wooden cleats in place to ensure proper alignment of the top. (figure 4)
Secure the solid top by adding wood glue to the tops of each vertical riser. Hold until glue is dry.
That’s it! Fill this beautiful rack with your favorite wines and enjoy! Pair with other rack styles for an ultimate
cellar storage look.
