Wine Storage Cubes
Assembly GUIDE
Cordless Drill
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
*All models follow the same assembly procedure varying only in the number of parts your rack will require.
Package Contents tools for assembly
Page 1
or visit
wineracksamerica.com
Questions?
888.373.6057
WOOD SCREWS
TOP & BOTTOM PANEL (X2)
SIDE PANEL (X2)
MIDDLE "X" PANEL (X2)
Screwdriver
Rubber Mallet
Top/Bottom Panel
Side Panel
Middle "X" Panel
Top/Bottom Panel
Required
Suggested
20" 26 3/8"
19"
SCAN FOR
ASSEMBLY VIDEO

Wine Storage Cubes
Assembly GUIDE Page 2
or visit
wineracksamerica.com
Questions?
888.373.6057
1. Find an open, flat area in which to work. Carefully remove all components from the box and remove banding or
protective wrapping. Check the parts list to verify package contents.
2. Using the included hardware, screw both side frame panels into the notch on the bottom frame panel. Once
attached repeat the process for the top frame panel. (figure 1)
1
BUILD BOX
FRAME
Assembled Box Frame
* Minimize the risk of splitting the wood by drilling a 1/16" pilot hole before driving the wood screws.
For best results, drive the screw most of the way in with your drill, then finish tightening by hand.
3. Lay the assembled frame flat on the ground. Insert the first Middle "X" panel into the assembled frame with the
notch facing upward. (figure 2)
4. Insert the remaining "X" panel into the frame by matching up the notches and sliding down into place. (figure 3)
* DO NOT FORCE! Carefully work the "X" panels into place until they settle flush with the frame. If necessary,
use a rubber mallet to lightly tap it into place.
2
INSERT FIRST
"X" PIECE
3
INSERT SECOND
"X" PIECE
Fully Assembled Wine Cube
5. Stand your rack upright and that’s it! Repeat this assembly process for any remaining cubes. Stack cubes in any
configuration you like once they are assembled.
