Wine racks America Lattice Cube Cubicle User manual

Lattice Cube - Cubicle
Assembly GUIDE
Cordless Drill
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
Package Contents tools for assembly
Page 1
or visit
wineracksamerica.com
Questions?
888.373.6057
WOOD SCREWS
SIDE LADDERS (X2) TOP/BOTTOM CONNECTOR (X4)
Screwdriver
MIDDLE
LADDERS (X3)
Required
Suggested
SCAN FOR
ASSEMBLY VIDEO

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
Lattice Cube - Cubicle
Page 2
1. Find an open, flat area in which to work. Carefully remove all components from the box and remove banding
with a utility knife. Check the parts list to verify package contents.
2.
Secure 2 Top/Bottom Connectors to the bottom of the Left Side Ladder using the provided wood screws. (figure 1)
1
SECURE LEFT
SIDE LADDER
3. Attach the middle ladders to the bottom connectors using the screws provided. Make sure the angled bottle
supports are all facing the same direction. (figure 2)
2
SECURE MIDDLE
LADDERS
Top of rack

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
Lattice Cube - Cubicle
Page 3
3
SECURE RIGHT
SIDE LADDER
4. Secure the Right Side Ladder to the bottom connectors using the provided screws. (Figure 3)
4. Attach the top connectors to the ladders using the screws provided. (Figure 4)
4
ATTACH TOP
CONNECTORS
