Wine racks America Top Horizontal Display User manual

Top Horizontal Display
Assembly GUIDE
Cordless DrillFinish Nailer
Hammer Nail Setter
Wood Glue
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
Package Contents tools for assembly
Page 1
or visit
wineracksamerica.com
Questions?
888.373.6057
Required
Suggested
ScrewdriverAllen Wrench
*Follow the same assembly procedure for all Top Label Out Display models
Single Deep Double Deep
WOOD SCREWS FINISH NAILS
TOP PANEL (x1)
TRIM PIECE (x1)
WOOD PUTTY
DOUBLE DEEP SIDE PANEL (x2)
METAL RODS
RAIL SCREWS
SINGLE DEEP SIDE PANEL (x2)
DOUBLE DEEP (x32) SINGLE DEEP (x16)

Assembly GUIDEor visit
wineracksamerica.com
Questions?
888.373.6057
Top Horizontal Display
Page 2
1. Find an open, flat area in which to work. Carefully remove all components from the box and remove any packaging
materials. Check the parts list to verify package contents.
1
START WITH
4 CORNERS
2. Begin by attaching 4 metal rods into the pre-drilled holes on the four corners of each side piece. Using an allen wrench
or drill, carefully attach each metal screw to the 4 metal rods. Make sure that the metal screws are attached to the side
with the countersunk holes. Do not tighten until ALL metail rods have been attached. Make sure all of the holes
line up evenly. (figure 1)
3. Attach the remaining metal rods to the side panels using the provided metal screws. (figure 2)
Do not tighten screws until ALL rods have been attached. After they are attached, carefully tighten each metal
screw all the way. *Do not overtighten.
2
ATTACH REMAINING
METAL RODS
Bottom
Top

Assembly GUIDEor visit
wineracksamerica.com
Questions?
888.373.6057
Top Horizontal Display
Page 3
4. Attach the top panel to the side panels using the wood screws provided. The end with the larger gap is the top of
the rack. Keep the side panels and top panel held tightly together when securing. Be sure that the puck light cord
comes out towards the back of the rack. (figure 3)
5. Attach the front trim piece so that the top of the trim is flush with the top of the rack.
We recommend that you use a finish nailer to drive a nail through the trim piece into each side frame piece.
If you do not have a finish nailer, drive one of the provided finish nails into each side frame piece using a hammer
until it is flush with the surface trim piece and countersink using a nail setter. Use wood glue for added support.
Fill the nail holes using the wood putty provided. Push a small amount of putty into each hole and wipe excess putty
off the surface using a damp cloth. (figure 4)
3
ATTACH
TOP PANEL
TOP
4
ATTACH
TRIM PIECE
360 North 700 West Suite F • North Salt Lake, UT 84054
(toll free) 888-373-6057
(fax) 801-936-0534
Once again, thank you for your business. Remember, customer
service is available to answer any questions Monday-Friday
7:00 am - 5:00 pm MST. Please feel free to contact us for any
wine storage needs.
We would love to see your wine racks in use! Please feel free to
send any photos of your rack to [email protected]
WINERACKSAMERICA.COM
