ACME DOT User manual

- 1 -
CONTENTS
01/ Safety Instructions.................................................................................................. 2
02/ Technical Specifications ........................................................................................ 4
03/ Control Panel........................................................................................................... 5
04/ Fixture Installation.................................................................................................. 6
05/ Control By Universal DMX Controller................................................................ 8
5.1 DMX512 Connection..................................................................................... 8
5.2 Address Setting................................................................................................ 9
5.3 DMX512 Configuration................................................................................. 9
06/ Error Information .................................................................................................. 12
07/ Troubleshooting ....................................................................................................13
08/ Fixture Cleaning....................................................................................................13

- 2 -
01/ Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be
sure that they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liability for any resulting defects or problems.
Unpack and check carefully to ensure that there is no transportation damage before
using the unit.
This product is for indoor use only. Use only in a dry location.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Use safety chain when fixing the unit. Handle the unit by carrying its base instead of
head only.
The unit must be installed in a location with adequate ventilation, at least 50cm from
adjacent surfaces.
Be sure that no ventilation slots is blocked, otherwise the unit will be overheated.
Before operation, ensure that you are connecting this product to the proper voltage in
accordance with the specifications in this manual or on the product’s specification label.
It’s important to ground the yellow/green conductor to earth in order to avoid electric
shock.
Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃. Do
not operate this product at a lower or higher temperature.
DO NOT connect the device to any dimmer pack.
Keep flammable materials away from the fixture while operating to avoid fire hazard.
Make sure the power cord is not crimped or damaged; replace it immediately if damaged.
Unit’s surface temperature may reach up to 65 ℃. DO NOT touch the housing
bare-handed during its operation.
Avoid any flammable liquids, water or metal from entering the unit. Once it happens, cut
Please read the instruction carefully which includes important information
about the installation, usage and maintenance.

- 3 -
off the mains power immediately.
DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly.
DO NOT touch any wire during operation as there might be a hazard of electric shock.
Avoid entanglement of the power cord with other wires.
The minimum distance to objects/surface must be more than 0.5 meters.
In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly
damaged.
DO NOT open the housing as there are no user serviceable parts inside.
DO NOT attempt to operate this unit if it becomes damaged. DO NOT attempt any
repairs yourself. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center if needed.
Disconnect this product from its power source before servicing.
DO use the original packaging if the device is to be transported.
Avoid direct eye exposure to the light source while the product is on.
DO NOT operate this product if you see damage on the housing, shields, or cables. Have
the damaged parts replaced by an authorized technician at once.

- 4 -
02/ Technical Specifications
Power Voltage
180-240V~ 50/60Hz
Power Consumption
20W
Light Source
1x10W laser module
Color Temperature
6000K-8000K
Beam Angle
87°
Dimmer/Strobe
0-100% smooth dimming; outstanding strobe effect with variable
speed
Control
DMX Channel
5 Channels
Control Mode
DMX512
RDM
Primary/Secondary Mode
Firmware Upgrade
Firmware Upgrade via DMX link
Construction
Data In/Out
RJ45 in/out
Power In/Out
IEC in
Protection Rating
IP20
Features
Excellent starry sky effect
Advanced optical design system
Multiple built-in show modes
Dimensions
220x196x188mm
8.7"x7.7"x7.4"in
Weight
2kgs
4.4lbs

- 5 -
03/ Control Panel
1. DMX IN
For DMX512 link, use a network cable to link the unit and the DMX
controller
2. DMX OUT
For DMX512 link, use a network cable to link the next units
3. POWER
To connect to supply power

- 6 -
04/ Fixture Installation
DO install and operate by qualified operator. Fixture(s) should be installed in areas
outside walking paths, seating areas, or away from areas were unauthorized personnel
might reach the fixture by hand. NEVER stand directly below the fixture(s) when rigging,
removing or servicing.
Always ensure that the unit is firmly fixed to avoid vibration and slipping off during
operation. Ensure that the trussing or area of installation must be able to hold 10 times
the weight without any deformation. Always attach a safety cable that can hold at least
12 times the weight of the fixture whenever installing this fixture in a suspended
environment to ensure that the fixture will not fall if the clamp fails.
This fixture is fully operational in two different mounting positions: hanging, or fix on the
ceiling. Always use and install the supplied safety cable as a safety measure to prevent
accidental damage and/or injury in the event the clamp fails.
Hanging the fixture:

- 7 -
Fix the fixture on the ceiling:
1. Drill an expansion screw hole (for M12 expansion screw) in the ceiling.
2. Unscrew the washer and nut of the expansion screw, and insert the expansion screw tube
and screw into the drilled screw hole.
3. Align the hole on the bracket of the fixture with the screw, then put the washer and nut of
the expansion screw in turn and tighten it with a wrench.
4. After tightening the nut, check whether the fixture is installed firmly, then adjust the
fixture to the required angle through the bracket knob.

- 8 -
05/ Control By Universal DMX Controller
5.1 DMX512 Connection
1. To avoid erratic behavior, make sure that the output of the last DMX device in the chain
is terminated by a resistor (120-ohm 1/4W) which is connected between RJ45 PIN 1 (XLR
PIN 3) and RJ45 PIN 2 (XLR PIN 2) of a RJ45 connector (a male XLR connector).
2. Connect the unit together in a “daisy chain” by network cable from the output of the
unit to the input of the next unit. The cable can only be used in series and cannot be
connected in parallel. DMX512 is a very high-speed signal. Inadequate or damaged cables,
soldered joints or corroded connectors can easily distort the signal and shut down the
system.
3. The DMX output and input connectors are pass-through to maintain the DMX circuit,
when one of the units’ power is disconnected.
4. Each lighting unit needs to have a DMX address to receive the data by the controller.
The address number is between 1-512.
5. The end of the DMX512 system should be terminated to reduce signal errors.
6. This device transmits DMX512 signal through RJ45 port.
Positive signal: RJ45 (PIN 1) corresponds to XLR (PIN 3)
Negative signal: RJ45 (PIN 2) corresponds to XLR (PIN 2)
GND: RJ45 (PIN 7/PIN 8) corresponds to XLR (PIN 1)

- 9 -
5.2 Address Setting
If you use a universal DMX controller to control the units, you have to set DMX address
between 1 and 512 so that the units can receive DMX signal.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
5 channels
1
6
11
16
5.3 DMX512 Configuration
Please control the fixture by referring to the configurations below
5 Channels (Mode 1):
CHANNEL
VALUE
FUNCTION
1
000-255
DIMMER
0%100%
2
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
STROBE
Close
Open
Strobe from Slow to Fast
Open
Fast Open Slow Close from Slow to Fast
Open
Slow Open Fast Close from Slow to Fast
Open
Random Strobe from Fast to Slow
Open
3
000-007
008-125
126-129
130-247
248-255
REFLECTOR ROTATION
Standby
Clockwise Rotation, Fast to Slow
Stop
Counter-Clockwise Rotation, Slow to Fast
Stop
Attentions:
The unit will maintain the last condition until reset if you cut-off the DMX signal.
For the channel Function, keep the value for about 3 seconds, then the
corresponding function will take into effect.

- 10 -
4
000-007
008-015
016-255
SHUTTER
Stop
Open
Shutter from Slow to Fast
5
000-045
046-087
088-129
130-171
172-213
214-255
SHOW MODE
Null
Show 1
Show 2
Show 3
Show 4
Show 0 (Random Show 1-4 Effect)

- 11 -
RDM functions: Certain menus of the device and functions can be called up via the RDM
protocol.
The parameter IDs are implemented as follows for different commands:
Parameter ID
Command
‘Discovery’
Command
‘Set’
Command
‘Get’
DISC_UNIQUE_BRANCH
√
√
√
DISC_MUTE
√
√
√
DISC_UN_MUTE
√
√
√
DEVICE_INFO
√
SUPPORTED_PARAMETERS
√
SOFTWARE_VERSION_LABEL
√
DMX_START_ADDRESS
√
√
IDENTIFY_DEVICE
√
√
DEVICE_MODEL_DESCRIPTION
√
COMMS_STATUS
√
√
QUEUED_MESSAGE
√
√
STATUS_MESSAGES
√
STATUS_ID_DESCRIPTION
√
√
CLEAR_STATUS_ID
√
√
PRODUCT_DETAIL_ID_LIST
√
MANUFACTURER_LABEL
√
√
DEVICE_LABEL
√
FACTORY_DEFAULTS
√
√
BOOT_SOFTWARE_VERSION_ID
√
DMX_PERSONALITY
√
√
DMX_PERSONALITY_DESCRIPTION
√
√
SLOT_INFO
√
SLOT_DESCRIPTION
√
DEFAULT_SLOT_VALUE
√
SENSOR_DEFINITION
√
√
SENSOR_VALUE
√
√
DEVICE_HOURS
√
LAMP_HOURS
√

- 12 -
RESET_DEVICE
√
√
√
CURVE
√
√
SHOW_MODE
√
√
PRIMARY_SECONDARY
√
√
DMX_STATE
√
√
DIMMER_SPEED
√
√
MOTOR_OFFSET
√
√
√-Command implemented for the respective parameter ID
06/ Error Information
Led Temp. Error
LED Timeout Use
LED Too Hot Off
Base Fan 1 Error
Check whether the fan is not running.
Check whether the fan leads are installed in place or disconnected.
Check whether the fan is damaged.
Check whether there are obstacles in the fan operating range.
Check whether the fan circuit on the motherboard breaks down.
Check whether the component is damaged.
Check whether the fan is out of order.
When the fixture temperature reaches 75℃, it will automatically turn
off to protect the fixture.
Check whether the temperature detecting board is normal.
Check whether the components of the temperature detecting board
are damaged.
Check whether the lead on the temperature detecting board is
installed in place or disconnected.

- 13 -
07/ Troubleshooting
Following are a few common problems that may occur during operation. Here are some
suggestions for troubleshooting:
A. The unit does not work and no light
Check the connected power.
Measure the voltage.
Check the power indicator to see whether it can be lit up or not.
B. Not responding to the DMX controller
Check whether the DMX connectors and the DMX cables are connected correctly.
Check whether the DMX address is correctly set.
If the intermittent DMX signal problem occurs, check whether the XLR socket and the
signal cable are well connected.
Try it with another DMX controller.
Check whether the DMX cables run near or alongside to the high-voltage cables, which
may damage or interfere with the signal circuit.
08/ Fixture Cleaning
It is absolutely essential that the fixture is kept clean to ensure the maximum light-output
and allow the fixture to function reliably throughout its life. The fixture must be cleaned
regularly to avoid dust, dirt and smoke-fluid residues building up on or within the fixture. The
cleaning frequency depends on the application environment. Clean the fixture immediately if
the dust enters it to avoid damage to the optical lens due to excessive dust.
A soft lint-free cloth moistened with any good glass cleaning fluid is recommended,
under no circumstances should solvents be used.
Always dry the parts carefully.
Clean the external optical lens at least every 20 days and the internal optical lens every
30 days.

- 14 -
