ADLINK Technology cPCI-9116 User manual

cPCI-9116®/cPCI-9116R®
64 Ch, 16 bit, 250KS/s
Analog input Card
For 3U CompactPCI
User’s Guide
Recycled Paper

Copyright 2002 ADLINK Technology Inc.
All Rights Reserved.
Manual Rev. 1.02: JUL 23, 2002
Part No: 50-15002-100
The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.
Innoeventwillthemanufacturerbeliablefordirect,indirect,special,incidental,
or consequential damages arising out of the use or inability to use the product
or documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
NuDAQ, NuIPCare registered trademarks of ADLINK Technology Inc.
Other products names mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their respective
companies.

Getting service from ADLINK
•Customer Satisfaction is the most important priority for ADLINK Tech Inc.
If you need any help or service, please contact us.
ADLINK Technology Inc.
Web Site http://www.adlinktech.com
Sales & Service
[email protected]
NuDAQ + USBDAQ [email protected]
Automation [email protected]
NuIPC [email protected]
Technical
Support
NuPRO / EBC [email protected]
TEL [phone] FAX [phone]
Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan.
•Please email or FAX us of your detailed information for a prompt,
satisfactory and constant service.
Detailed Company Information
Company/Organization
Contact Person
E-mail Address
Address
Country
TEL FAX
Web Site
Questions
Product Model
Environment to Use
OS:
Computer Brand:
M/B: CPU:
Chipset: BIOS:
Video Card:
Network Interface Card:
Other:
Detail Description
Suggestions to ADLINK

Table of Contents•i
Table of Contents
Tables .....................................................................................iii
Figures .....................................................................................iv
How to Use This Guide .............................................................v
Chapter 1 Introduction..............................................................1
1.1 Features .............................................................................1
1.2 Applications ........................................................................2
1.3 Specifications......................................................................3
1.4 Software Support ................................................................5
1.4.1 Programming Library....................................................................5
1.4.2 PCIS-LVIEW: LabVIEW®Driver.................................................6
1.4.3 DAQBenchTM: ActiveX Controls..................................................6
Chapter 2 Installation................................................................7
2.1 What You Have...................................................................7
2.2 Unpacking ..........................................................................8
2.3 cPCI-9116 and cPCI-9116R Layout ......................................9
2.4 PCI Configuration.............................................................. 11
Chapter 3 Signal Connections...............................................12
3.1 Connectors and Pin Assignment ........................................ 12
3.2 Analog Input Signal Connection ......................................... 15
3.2.1 Types of signal sources .............................................................15
3.2.2 Input Configurations....................................................................15
3.3 Digital I/O Connection........................................................ 17
Chapter 4 Registers.................................................................18
4.1 I/O Port Address ............................................................... 18
4.2 Internal Timer/Counter Register ......................................... 20
4.3 General Purpose Timer/Counter Register ........................... 21
4.4 General Purpose Timer/Counter Control Register................ 22
4.5 A/D Data Registers............................................................ 23

ii •Table of Contents
4.6 Channel Gain Queue Register ........................................... 24
4.7 A/D & FIFO Control Register.............................................. 25
4.8 A/D & FIFO Status Register ............................................... 27
4.9 Digital I/O register ............................................................. 28
4.10 A/D Trigger Mode Register ................................................ 29
4.11 Interrupt Control Register................................................... 31
4.12 Interrupt Status Register.................................................... 33
Chapter 5 Operation Theory...................................................34
5.1 A/D Conversion................................................................. 34
5.1.1 A/D Conversion Procedure........................................................34
5.1.2 Software conversion with polling data transfer acquisition
mode (Software Polling).............................................................35
5.1.2.1 Specifying Channels, Gains, and input
configurations in the Channel Gain Queue..........36
5.1.3 Programmable scan acquisition mode....................................36
5.1.3.1 Scan Timing and Procedure...................................36
5.1.3.2 Specifying Channels, Gains, and input
configurations in the Channel Gain Queue..........38
5.1.3.3 Trigger Modes...........................................................39
5.1.4 A/D Data Transfer Modes..........................................................47
5.2 Digital Input and Output ..................................................... 48
5.3 General Purpose Timer/Counter Operation ......................... 49
Chapter 6 Software Utility & Calibration...............................51
6.1 Running 9116util.exe program ........................................... 51
6.2 Calibration........................................................................ 52
6.2.1 What do you need.......................................................................52
6.2.2 VR Assignment............................................................................53
6.2.3 A/D Adjustment............................................................................53
6.2.3.1 PGA offset Calibration.............................................54
6.2.3.2 Bipolar input Calibration..........................................54
6.2.3.3 Unipolar input Calibration........................................54
6.3 Functional Testing............................................................. 54
Warranty Policy........................................................................56

Tables •iii
Tables
Table 1. Legend of J1 Connector ......................................... 14
Table 2. I/O Port Address.................................................... 19
Table 3. Timer/Counter Register Address............................. 20
Table 4. General Purpose Timer/Counter Register................ 21
Table 5. General Purpose Timer/Counter Control Register .... 22
Table 6.GPTC0’s Mode selection........................................ 23
Table 7. A/D Data Registers ................................................ 23
Table 8. Channel Gain Queue Register................................ 24
Table 9. Gain Selection Bits ................................................ 24
Table 10. A/D & FIFO Control Register .................................. 25
Table 11. A/D & FIFO Status Register.................................... 27
Table 12. Digital I/O register (Read)....................................... 28
Table 13. Digital I/O register (Write) ....................................... 29
Table 14. A/D Trigger Mode Register..................................... 29
Table 15. Trigger Mode Selection Bits.................................... 30
Table 16. Interrupt Control Register ....................................... 31
Table 17. Interrupt Status Register ........................................ 33
Table 18. Functions of VRs ................................................... 53

iv •Figures
Figures
Figure 1: PCB Layout of the cPCI-9116...................................9
Figure 2: PCB Layout of cPCI-9116R and Rear I/O adaptor.... 10
Figure 3: J1 Pin Assignments ............................................... 13
Figure 4: Single-ended Mode and Floating sources................ 15
Figure 5: Ground-referenced source and differential input....... 16
Figure 6: Floating source and differential input ....................... 16
Figure 7: Ground-referenced source and User Common Mode
connections........................................................... 17
Figure 8: Digital I/O Connection ............................................ 17
Figure 9: Scan Timing .......................................................... 37
Figure 10: Pre-trigger (trigger occurs after M scans)................. 40
Figure 11: Pre-trigger (trigger with scan is in progress)............. 40
Figure 12: Pre-trigger with M_enable = 0................................. 41
Figure 13: Pre-trigger with M_enable = 1................................. 42
Figure 14: Middle trigger with M_enable = 1............................ 43
Figure 15: Middle trigger (trigger with scan is in progress)........ 44
Figure 16: Post trigger............................................................ 44
Figure 17: Delay trigger.......................................................... 45
Figure 18: Post trigger with re-trigger ...................................... 46
Figure 19: General-purpose Timer/Counter model ................... 49
Figure 20: Mode 0 Operation.................................................. 50
Figure 21: Mode 1 Operation.................................................. 50
Figure 22: CPCI-9116 Utility Main Screen ............................... 52
Figure 23: A/D Adjustment menu Screen................................. 53
Figure 24: cPCI-9116 Function Testing Screen........................ 55

How to Use This Guide•v
How to Use This Guide
This manual is designed to help you use the 9116 series. The manual
describes how to modify various settings on the card to meet your
requirements. It is divided into seven chapters:
Chapter1, “Introduction”, gives an overview of the product features,
applications, and specifications.
Chapter 2, “Installation”, describes how to install the 9116 series.
The layout of 9116 series is shown.
Chapter 3, “Signal Connection”, describes the connectors' pin
assignment and how to connect external signal and devices
to the9116 series card.
Chapter 4, “Registers”, describes the details of the registers and its
structure. This information is important for programmers who
want to control the hardware with low-level programming.
Chapter 5, “Operation theory”, describes the working theory of the
9116 series card. The A/D, DIO and timer/counter
functions are introduced. Also, some programming concepts
are specified.
Chapter 6, “Software Utility & Calibration”, describes how to run the
utility program included in the software CD and how to
calibrate the9116 series card for accurate measurements.

Introduction •1
1
Introduction
The 9116 series products are advanced data acquisition cards based on the
32-bit CompactPCI architecture. The 9116 series include:
•cPCI-9116 : 16-bit 250KHz DAS card for 3U CompactPCI
•cPCI-9116R : 16-bit 250KHz DAS card for 3U CompactPCI with Rear I/O
connector
The 9116 series DAS cards use state-of-the-art technology making it an ideal
for data logging and signal analysis applications in medical, process control,
etc.
1.1 Features
The 9116 series CompactPCI Advanced Data Acquisition Card provides the
following advanced features:
•32-bit PCI-Bus, plug and play
•Up to 64 single-ended inputs or 32 differential inputs, mixing of using SE
and DI analog signal sources
•16-bit analog input resolution
•On-board A/D 1K FIFO memory
•512 words analog input Channel Gain Queue spaces
•Sampling rate up to 250KS/s
•Bipolar or Unipolar input signals
•Programmable gain of x1, x2, x4, x8
•Jumper-less and software configurable

2•Introduction
•Five A/D trigger modes: software trigger, pre-trigger, post-trigger,
middle-trigger and delay-trigger
•SoftwarePolling,InterruptandBus-masteringDMAdatatransferavailable
•8 digital input and 8 digital output channels
•100-pin D-type SCSI-II connector for cPCI-9116
•100-pin D-type SCSI-II connector on a rear I/O transition board for
cPCI-9116R
•Compact size: standard compact PCI 3U size
1.2 Applications
•Automotive Testing
•Cable Testing
•Transient signal measurement
•ATE
•Laboratory Automation
•Biotech measurement

Introduction •3
1.3 Specifications
♦Analog Input (A/D)
•Converter: LT1606 (or equivalent) 250KHz
•Number of channels: (programmable)
P64 single-ended (SE)
P32 differential input (DI)
PMixing of SE and DI analog signal between channel allowed
•A/D Data FIFO Buffer Size: 1024 locations
•Channel Gain Queue Length: 512 words configurations
•Resolution: 16-bit
•Input Range: (Controlled by Channel Gain Queue)
PBipolar:±5V, ±2.5V, ±1.25V, ±0.625V
PUnipolar:0~10V, 0~5V, 0~2.5V, 0~1.25
•CMRR (DC to 60 Hz, typical)
Input Range CMRR
±5, 0~10V 87dB
±2.5,0~5V 90dB
±1.25,0~2.5V 92dB
±0.625,0~1.25V 93dB
•Overvoltage Protection: Continuous ±35V maximum
•Accuracy: 0.01% of FSR
•Input Impedance: 100 MΩ| 6pF
•Time-base source:
PInternal 24MHz
PExternal clock Input (fmax: 24MHz, fmin: 1MHz)
•Programmable scan interval and sampling rate (divided from
time-base source)

4•Introduction
•Trigger Mode:
PSoftware-trigger.
PPre-trigger.
PPost-trigger.
PMiddle-Trigger.
PDelay Trigger
•Data Transfer:
PPolling.
PEOC interrupt transfer.
PFIFO half-full Interrupt transfer.
PBus-mastering DMA.
•Data Throughput:250KHz (maximum)
♦Digital I/O (DIO)
•Channel: 8TTL compatible digital inputs and outputs
•Input Voltage:
PLow: VIL=0.8 V max. IIL=0.2mA max.
PHigh: VIH=2.0V max. IIH=0.02mA max
•Output Voltage:
PLow: VOL=0.5 V max. IOL=8mA max.
PHigh: VOH=2.7V min; IOH=400µA
♦General Purpose Timer/ Counter
•Number of channel:One 16-bit Up/Down Timer/Counter
•Clock Input:Internal 24MHz or External CLK input up to 20MHz
♦General Specifications
•Connector: 100-pin D-type SCSI-II connector
•Operating Temperature: 0°C ~ 60°C
•Storage Temperature: -20°C ~ 80°C
•Humidity: 5 ~ 95%, non-condensing
•Power Consumption:

Introduction •5
P+5V @ 560mA typical
P+3.3V@ 100mA typical
•±15V (pin35, pin85) Output Current (max): 5mA
•+5V(pin49, pin99) Output Current (max): 500mA
•Dimension:Standard Compact PCI 3U size
1.4 Software Support
ADLINK provides versatile software drivers and packages for users’ different
approach to building a system. We not only provide programming libraries
such as DLL for many Windows systems, but also provide drivers for other
software packages such as LabVIEW®.
All software options are included in the ADLINK CD. Non-free software drivers
are protected with licensing codes. Without the software code, you can install
and run the demo version for two hours for trial/demonstration purposes.
Please contact ADLINK dealers to purchase the formal license.
1.4.1 Programming Library
For customers who are writing their own programs, we provide function
libraries for many different operating systems, including:
•PCIS-DASK: Include device drivers and DLL for Windows 98, Windows
NT and Windows 2000. DLL is binary compatible across Windows 98,
Windows NT and Windows 2000. That means all applications developed
with PCIS-DASK are compatible across Windows 98, Windows NT and
Windows 2000. The developing environment can be VB, VC++, Delphi,
BC5, or any Windows programming language that allows calls to a DLL.
The user’s guide and function reference manual of PCIS-DASK are in the
CD. Please refer the PDF manual files under
\\Manual_PDF\Software\PCIS-DASK
•PCIS-DASK/X: Includes device drivers and shared library for Linux. The
developingenvironmentcanbeGnuC/C++oranyprogramminglanguage
that allows linking to a shared library. The user's guide and function
reference manual of PCIS-DASK/X are in the CD.
(\Manual_PDF\Software\PCIS-DASK-X.)
The above software drivers are shipped with the board. Please refer to the
“Software Installation Guide” for installation procedures.

6•Introduction
1.4.2 PCIS-LVIEW: LabVIEW®Driver
PCIS-LVIEW contains the VIs, which are used to interface with NI’s
LabVIEW® software package. The PCIS-LVIEW supports Windows
95/98/NT/2000. The LabVIEW® drivers is shipped free with the board. You
can install and use them without a license. For more information about
PCIS-LVIEW, please refer to the user’s guide in the CD.
(\\Manual_PDF\Software\PCIS-LVIEW)
1.4.3 DAQBenchTM: ActiveX Controls
We suggest customers who are familiar with ActiveX controls and VB/VC++
programming use the DAQBenchTM ActiveX Control component library for
developing applications. The DAQBenchTM is designed under Windows
NT/98. For more information about DAQBench, please refer to the user’s
guide in the CD. (\\Manual_PDF\Software\DAQBench\DAQBench
Manual.PDF).

Installation •7
2
Installation
Thischapterdescribeshowtoinstallthe9116seriescards.Thecontentsofthe
package and unpacking information that you should be aware of are described
first.
The 9116 series cards perform an automatic configuration of the IRQ, port
address, and BIOS address. You do not need to set these configurations, as
you would do in ISA form factor DAS cards. Automatic configuration allows
your system to operate more reliable and safe.
2.1 What You Have
In addition to thisUser's Guide, the package should also include the following
items:
•cPCI-9116 or cPCI-9116R with rear I/O adaptor Analog input Data
Acquisition Card
•ADLINK All-in-one Compact Disc
•Software Installation Guide
If any of these items are missing or damaged, contact the dealer from whom
you purchased the product. Save the shipping materials and carton in case
you want to ship or store theproduct in the future.

8•Installation
2.2 Unpacking
The card contains electro-static sensitive components that can be easily be
damaged by static electricity.
Therefore, the card should be handled on a grounded anti-static mat. The
operator should be wearing an anti-static wristband, grounded at the same
point as the anti-static mat.
Inspect the card module carton for obvious damages. Shipping and handling
may cause damage to your module. Be sure there are no shipping and
handling damages on the modules carton before continuing.
After opening the card module carton, extract the system module and place it
only on a grounded anti-static surface with component side up.
Again, inspect the module for damages. Press down on all the socketed IC's to
make sure that they are properly seated. Do this only with the module place on
a firm flat surface.
Note: DO NOT APPLY POWER TO THE CARD IF IT HAS BEEN
DAMAGED.
You are now ready to install your cPCI-9116/R.

Installation •9
2.3 cPCI-9116 and cPCI-9116R Layout
Figure 1: PCB Layout of the cPCI-9116

10 •Installation
Figure 2: PCB Layout of cPCI-9116R and Rear I/O adaptor
