AGCO Massey Ferguson 9702 User manual

© AGCO Corporation, 2013 All rights reserved.
Part Number 4283530M1 (English)
Printed in U.S.A.
September 2013
Massey Ferguson®
9702 / 9708 / 9722
Planter
SERVICE MANUAL
4283530M1
CONTENTS
GENERAL INFORMATION ....................................................................................................................................01
ROW UNIT..............................................................................................................................................................02
DRIVE SYSTEMS...................................................................................................................................................03
AIR SYSTEM..........................................................................................................................................................04
HYDRAULICS ........................................................................................................................................................05
ELECTRICAL .........................................................................................................................................................06
FRAME ...................................................................................................................................................................07
TROUBLESHOOTING............................................................................................................................................08
CONSOLES AND MONITORS...............................................................................................................................09

4283530M1 01-i
Contents
Massey Ferguson®
9702 / 9708 / 9722
Planter
SERVICE MANUAL
4283530M1
01 - General Information
Contents
GENERAL INFORMATION
General Information ....................................................................................................................................... 01-1
Serial Number Plate Location ........................................................................................................................ 01-2
Serial Number Definition ......................................................................................................................... 01-2
SAFETY
Safety Alert Symbol ....................................................................................................................................... 01-3
Signal Words ................................................................................................................................................. 01-3
Informational Messages ................................................................................................................................. 01-3
Safety Signs ................................................................................................................................................... 01-4
Introduction .................................................................................................................................................... 01-4
Prepare For Operation ................................................................................................................................... 01-4
Understanding Planter Safety ........................................................................................................................ 01-4
Genreral Operation And Service .................................................................................................................... 01-5
Operating ................................................................................................................................................. 01-5
Agricultural Chemicals ............................................................................................................................. 01-6
Transporting ............................................................................................................................................ 01-6
Servicing .................................................................................................................................................. 01-7
Lockup Devices ............................................................................................................................................. 01-7
Flat-Fold Markers .................................................................................................................................... 01-7
Standard Markers .................................................................................................................................... 01-8
Folding Wings .......................................................................................................................................... 01-8
SPECIFICATIONS
General .......................................................................................................................................................... 01-9
9702 ............................................................................................................................................................... 01-9
9708 ............................................................................................................................................................... 01-9
9722 ............................................................................................................................................................... 01-9
Row Units ...................................................................................................................................................... 01-9
Hydraulic System ......................................................................................................................................... 01-10
Air System ................................................................................................................................................... 01-10
Transmission ............................................................................................................................................... 01-10
Shear Pins ................................................................................................................................................... 01-10
Monitor ......................................................................................................................................................... 01-11
Electronic Seed Drive Controller .................................................................................................................. 01-11
Highway Lights ............................................................................................................................................ 01-11
Approx. Shipping Weights ........................................................................................................................... 01-11
FIELD OPERATIONS AND ADJUSTMENTS
Tractor Preparation ...................................................................................................................................... 01-13
General .................................................................................................................................................. 01-13
Recommended Tractor Horsepower ..................................................................................................... 01-13
Wheel Spacing ...................................................................................................................................... 01-13
Find manuals at https://best-manuals.com

01-ii 4283530M1
Contents
Electrical Requirements ........................................................................................................................ 01-13
Remote Hydraulic Valve Requirements ................................................................................................ 01-13
Tractor Drawbar .................................................................................................................................... 01-14
Three-Point Hitch .................................................................................................................................. 01-14
Three-Point Hitch Adjustment ............................................................................................................... 01-14
Quick Hitch ............................................................................................................................................ 01-14
Front Weights ........................................................................................................................................ 01-15
Rear Wheel Weights ............................................................................................................................. 01-15
Planter Preparation ...................................................................................................................................... 01-15
Lubrication ............................................................................................................................................. 01-15
Bolt Torque ............................................................................................................................................ 01-15
Tire Inflation ........................................................................................................................................... 01-15
Seed Discs ............................................................................................................................................ 01-15
Chains ................................................................................................................................................... 01-15
Weights ................................................................................................................................................. 01-15
Seed and Transmissions ....................................................................................................................... 01-15
Planter Monitor ...................................................................................................................................... 01-15
Planter Hydraulic Drive Controls ........................................................................................................... 01-16
Leveling The Planter ............................................................................................................................. 01-17
Connecting the Planter to the Tractor .......................................................................................................... 01-18
Connecting the Three-Point Hitch ......................................................................................................... 01-18
Lower Links - Standard Hitch ................................................................................................................ 01-18
Lower Links - Quick Hitch ...................................................................................................................... 01-18
Upper Link - Standard Hitch .................................................................................................................. 01-19
Upper Link - Quick Hitch ....................................................................................................................... 01-20
Disconnecting the Planter From the Tractor ................................................................................................ 01-21
Transporting The Planter ............................................................................................................................. 01-22
Preparation - All Models ........................................................................................................................ 01-22
Preparation - Folding Models ................................................................................................................ 01-22
Safety Precautions ................................................................................................................................ 01-22
Field Preparation ......................................................................................................................................... 01-23
General .................................................................................................................................................. 01-23
Before Entering the Field ....................................................................................................................... 01-23
In the Field ............................................................................................................................................. 01-23
Finishing the Field ................................................................................................................................. 01-24
Markers ........................................................................................................................................................ 01-25
Rigid Markers ........................................................................................................................................ 01-25
Flat-fold Markers ................................................................................................................................... 01-26
Circuit Operation - All Marker Types ..................................................................................................... 01-28
Marker Disc Blade ................................................................................................................................. 01-28
Arm Section And Linkage Adjustments ................................................................................................. 01-29
Air Pressure Settings ................................................................................................................................... 01-31
Seed Disc Identification Chart ............................................................................................................... 01-32
Larger Bean Disc ................................................................................................................................... 01-34
Snap Bean Disc ..................................................................................................................................... 01-35
Treated Seed ......................................................................................................................................... 01-35
Transmission Settings ................................................................................................................................. 01-36
Seed Rate Transmission ....................................................................................................................... 01-36
Seed Population .................................................................................................................................... 01-37
Seed Rate Chart - 30 Inch And 38 Inch Rows ...................................................................................... 01-45
Seed Rate Chart - 22 Inch Rows ........................................................................................................... 01-46
Seed Rate Chart - Peanuts ................................................................................................................... 01-47
Chemical Attachment ................................................................................................................................... 01-48
General .................................................................................................................................................. 01-48
Cleaning Hoppers and Meters ............................................................................................................... 01-48
Application Rate .................................................................................................................................... 01-49
Checking Application Rate .................................................................................................................... 01-49
Insecticide Rate Chart - Clay Granules ................................................................................................. 01-50
Insecticide Rate Chart - Sand Granules ................................................................................................ 01-51
Herbicide Rate Chart ............................................................................................................................. 01-52
Insecticide In-furrow Placement ............................................................................................................ 01-53
Spring Tooth Incorporator ..................................................................................................................... 01-53
Checking Population .................................................................................................................................... 01-54
Find manuals at https://best-manuals.com

4283530M1 01-iii
Contents
Leveling The Planter .................................................................................................................................... 01-55
Operating Notes .................................................................................................................................... 01-55
Test Button .................................................................................................................................................. 01-56
Test Switch Storage Tube ..................................................................................................................... 01-56
Bearing Replacement (Eccentric Self-Locking Collar) ................................................................................. 01-58
Torque Values For Standard Bolts .............................................................................................................. 01-59
Special Torque Values .......................................................................................................................... 01-59
Torque Values For Metric Bolts ................................................................................................................... 01-61
LUBRICATION
Service Chart ............................................................................................................................................... 01-63
Lubrication Points ........................................................................................................................................ 01-64
INSTALLATION INSTRUCTIONS
Installation Instructions ................................................................................................................................ 01-69
INDEX ............................................................................................................................................................. 01-71
Find manuals at https://best-manuals.com

01-iv 4283530M1
Contents
NOTES
Find manuals at https://best-manuals.com

4283530M1 01-1
General Information
General Information
GENERAL INFORMATION
9700 Series Mounted Planters are designed, built and
tested to make sure high quality, maximum strength and
long service life. The planters, available as 8 and 12-row
models, feature a positive air flow system and the 9000
Series meter for accurate seed spacing.
mWARNING: Pictures in this manual may
show protective shields and guards opened
or removed for illustration purposes. Be
sure all shields and guards are in place
during operation.
This manual was prepared from the latest product
information available at publication time. The Company
reserves the right to make changes at any time without
notice or obligation.
FIG. 1
WP_8700a
9702 12 Row, 30 inch row spacing,
Rigid Frame
9708 8 row, 30 inch row spacing, Rigid
Frame
9722 12 row, 30 inch row spacing,
Vertical Fold Frame
Find manuals at https://best-manuals.com

General Information
01-2 4283530M1
SERIAL NUMBER PLATE LOCATION
The serial number plate (1) is found on the left end of the
toolbar.
Serial Number Definition
Definition of the serial number for model year 2010 and
up.
(1)Beginning symbol
(2)World Manufacturer Code
(3)Brand Code
(4)Model Identifier (Model number)
(5)Check Letter (0 or used if model identifier is five digits)
(6)Model Year Code (A=2010, B=2011, C=2012, and on)
(7)Plant Code
(8)Family Code
(9)Unit Number for the Year
(10)Ending symbol
NOTE: For serial number breaks in this manual, only the
information from the model year code and following will
be given.
FIG. 2
1
31882
FIG. 3
**
AGC
2 3 4 5 76 981 10
Find manuals at https://best-manuals.com

4283530M1 01-3
Safety
SAFETY
SAFETY ALERT SYMBOL
FIG. 4: The safety alert symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!
Look for the safety alert symbol both in this manual and
on safety signs on this machine. The safety alert symbol
will direct your attention to information that involves your
safety and the safety of others.
SIGNAL WORDS
FIG. 5: The words DANGER, WARNING or CAUTION
are used with the safety alert symbol. Learn to recognize
these safety alerts and follow the recommended
precautions and safety practices.
mDANGER: Indicates an imminently
hazardous situation that, if not avoided, will
result in DEATH OR VERY SERIOUS
INJURY.
mWARNING: Indicates a potentially
hazardous situation that, if not avoided,
could result in DEATH OR SERIOUS
INJURY
mCAUTION: Indicates a potentially
hazardous situation that, if not avoided,
may result in MINOR INJURY.
INFORMATIONAL MESSAGES
The words IMPORTANT and NOTE are not related to
personal safety, but are used to give additional
information and tips for operating or servicing this
equipment.
IMPORTANT: Identifies special instructions or
procedures which, if not strictly observed, could
result in damage to or destruction of the
machine, process, or its surroundings.
NOTE: Identifies points of particular interest for more
efficient and convenient repair or operation.
FIG. 4
Saf
FIG. 5
Wc1957
Find manuals at https://best-manuals.com

01-4 4283530M1
Safety
SAFETY SIGNS
mWARNING: DO NOT remove or obscure
safety signs. Replace any safety signs that
are not readable or are missing.
Replacement signs are available from your
dealer in the event of loss or damage. The
actual location of the safety signs is
illustrated at the end of this section.
Keep signs clean by wiping off regularly. Use a cleaning
solution if necessary.
If a used machine has been purchased, make sure all
safety signs are in the correct location and can be read.
See Safety Sign Location of this section for illustrations.
Replace any safety signs that can not be read or are
missing. Clean the machine surface thoroughly with a
cleaning solution before replacing signs. Replacement
safety signs are available from your dealer.
INTRODUCTION
The Safety Section of this manual is intended to point out
some of the basic safety situations in which can be
encountered during normal operation of your planter. This
section also suggests possible ways of dealing with those
situations. The section is NOT a replacement for other
safety practices featured in other sections of this manual.
Additional precautions can be necessary, depending on
attachments used and conditions at the work site or in the
service area. AGCO has no direct control over planter
application, operation, inspection, lubrication or
maintenance. Therefore, it is your responsibility to use
good safety practices in those areas.
NOTE: This manual is published for North American
distribution, and availability of equipment shown
either as basic or accessory can vary according
to the territory in which the planter will be
operated. Full details of equipment available in
your area can be obtained from your planter
dealer. Use only AGCO approved attachments
and equipment.
PREPARE FOR OPERATION
Read this manual completely and make sure you
understand the controls. Know the positions and
operations of all controls before you operate this machine.
Check all controls in an area clear of people and
obstacles before starting your work.
All equipment has a limit. Make sure you understand the
speed, brakes, steering, stability, and load characteristics
of this machine and your tractor before you start.
Make sure your machine has the correct equipment
needed by the local regulations.
mWARNING: An operator should not use
alcohol or drugs which can affect their
alertness or coordination. An operator on
prescription or Over the counter drugs
needs medical advice on whether or not
they can properly operate machines.
UNDERSTANDING PLANTER SAFETY
It is YOUR responsibility to read and understand the
Safety Section before operating your planter. You must
follow the safety instructions that take you step-by-step
through the workday.
Remember that you are the key to safety. Good safety
practices not only protect you, but also those people
around you. Study the features in this manual and make
them a working part of your safety program. Keep in mind
that this Safety Section is written specifically for a planter.
Practice all other usual and customary safe working
precautions.
REMEMBER: SAFETY IS YOUR RESPONSIBILITY,
ONLY YOU CAN PREVENT SERIOUS INJURY OR
DEATH.
NOTE: This manual covers general safety practices for
this machine. The Operator Manual must always
be kept with the machine.
mWARNING: Pictures in this manual may
show protective shields and guards opened
or removed for illustration purposes. BE
SURE ALL SHIELDS AND GUARDS ARE IN
PLACE DURING OPERATION.
Find manuals at https://best-manuals.com

4283530M1 01-5
Safety
GENRERAL OPERATION AND SERVICE
Operating
• Read and understand all the operating and safety
precautions before operating machinery.
• In addition to equipment configuration and design,
hazard control and accident prevention depend on
awareness, concern, prudence and proper training of
personnel in the operation, maintenance, transport
and storage of equipment.
• Always raise implement, shut off tractor engine, set
the parking brake, shift to park position (or neutral)
remove the key and install cylinder lockup channels
before working around the machine.
• Avoid working under the planter. However, if it
becomes unavoidable to do so, make sure the planter
is securely blocked and the cylinder lockup channels
are in place.
• Do not attempt to lubricate or adjust the planter while
the machine is in operation.
• Machinery operation can be performed only by
persons who are responsible and delegated to do so.
• Only the operator must be permitted on the tractor
(unless tractor has a factory-installed instructor seat)
when the tractor and the planter are moving. Never
permit anyone to ride on the planter.
• Avoid wearing loose-fitting clothing and jewelry.
Always tie up long hair that can be caught in moving
parts.
• Wear personal protective equipment (PPE) such as,
but not limited to, protection for eyes, lungs, ears,
head, hands and feet when operating, servicing or
repairing equipment.
• Make sure bystanders are clear before operating
tractor or machine.
• Do not leave tractor or implement unattended with
the engine running.
• Never attempt to operate the planter unless seated in
the operator’s seat on the tractor.
• Tractor must be equipped with rollover protective
structure (ROPS), and a seat belt. Use seat belt
during operation.
• Make sure the tractor is in good operating condition,
and has adequate braking capabilities.
• Do not dismount from a moving tractor.
• Regulate ground speed to field conditions, and
maintain control at all times.
• When working around discs, be careful to not get cut
on sharp edges.
• Watch for overhead wires or other obstructions when
raising markers, and when moving the planter with
marker(s) raised.
• Disconnect and store planter where children do not
normally play. Stabilize the planter by using suitable
supports, and block the wheels.
• Always lower the planter when not in use and relieve
the pressure in hoses and cylinders.
• Do not allow children to ride on, play on, or operate
equipment. Always keep children away from
equipment operating, servicing, and storage areas.
• Do not stand between the tractor and the planter to
install hitch pin when the tractor engine is running.
Find manuals at https://best-manuals.com

01-6 4283530M1
Safety
Agricultural Chemicals
• Ag chemicals can be very hazardous. Improper use
of fertilizer, fungicides, herbicides, insecticides and
pesticides can injure people, plants, animals, soil and
other people's property.
• Always read and follow all manufacturers' instructions
before opening any chemical container.
• Even if you think you know them, read and follow
instructions each time you use a chemical.
• Use same precautions when adjusting, servicing,
cleaning or storing planter as used when installing
chemicals into the hoppers or tanks.
• Inform anyone who comes in contact with chemicals
of the potential hazards involved and the safety
precautions required.
• Stand upwind and away from smoke from a chemical
fire.
• Store or dispose of all unused chemicals only in a
manner as specified by the chemical manufacturer.
Transporting
• Do not transport planter in excess of 24 km/h (15
mph).
• Use good judgment when transporting the planter on
the highway. Maintain complete control of the
machine at all times.
• Use tractor of recommended size and weight to tow
the machine.
• Comply with state and local laws governing highway
safety and regulations when moving machinery.
• Always make the necessary safety precautions prior
to transporting machine on public roads.
• Make sure the SMV (Slow Moving Vehicle) sign is
clean and visible.
• Use flashing warning s except when prohibited by
law.
• Watch for overhead wires or other obstructions when
transporting the planter with markers raised.
• Connect the transport safety chain to the tractor
drawbar and use a retainer on the hitch pin.
• Install marker lockup pins before transporting or
parking planter.
• Install wheel cylinder lockup channels before
transporting or parking planter.
• Vertical Fold Models: Always install wing lockup pins
before transporting or parking planter.

4283530M1 01-7
Safety
Servicing
FIG. 6: Fluid Leak Detection
• Correct hydraulic leaks immediately. All fittings must
be tight and all lines and hoses in good condition.
Escaping hydraulic fluid, under extremely high
pressure, can penetrate the skin and cause blood
poisoning. Use a piece of wood or cardboard to
detect fluid leaks (Fig. 1). If injured by escaping fluid,
see a doctor immediately.
• After repairing or adjusting planter, remove all tools
and parts from machine before operating it.
• When working around discs, be careful to not get cut
on sharp edges.
• Lower planter to the ground before attempting to
remove a wheel for tire repair.
• Tire changing can be very hazardous and must be
done by trained personnel using proper tools and
equipment.
• Do not re-inflate the tire that was seriously
under-inflated or run flat. Have it checked by qualified
personnel.
LOCKUP DEVICES
Flat-Fold Markers
FIG. 7: The lockout valve in the closed position (1).
With markers fully raised, turn lockout valve to off position,
stopping fluid flow to the marker cylinder.
mWARNING: Always lock up markers in
raised position when working around,
storing or transporting planter.
FIG. 8: The lockout valve in the open position (1).
To allow marker operation, turn lockout valve to the open
position.
FIG. 6
D-5842a
FIG. 7
FC080002
1
FIG. 8
FC080001
1

Safety
01-8 4283530M1
Standard Markers
FIG. 9: With markers fully raised, insert lockup pin (1)
through the marker support and marker arm as shown.
Install a pin clip.
mWARNING: Always pin markers in raised
position when working around, storing or
transporting planter.
During marker operation, store a pin in the support to act
as an upper limit stop for the marker arm.
Folding Wings
FIG. 10: On vertical fold models, raise the wings and
install L-pins (1) and pin clips (2) in each lockup assembly
as shown.
mWARNING: Always engage lockups when
transporting planter.
mWARNING: Do not raise wings into wires or
other overhead objects.
When wings are lowered, store L-pins and clips in lockup
storage (3) as shown.
FIG. 9
G808015
1
FIG. 10
G807014
1
2
3

4283530M1 01-9
Specifications
SPECIFICATIONS
GENERAL
Frame (Toolbar) Size............................................................................................................... 17.5 x 17.5 cm (7 x 7 in)
Tires ...........................................................................................................................................................9.5 L-15, 6-ply
Tire Pressure (max.)............................................................................................................................ 242 kPa (35 psi)
Lift Assist Tire Pressure (max.)........................................................................................................... 276 kPa (40 psi)
9702
Frame Type............................................................................................................................................................... Rigid
Rows..............................................................................................................................................................................12
Row Spacing................................................................................................................................................76 cm (30 in)
Toolbar Width...........................................................................................................................................884 cm (348 in)
Transport Width........................................................................................................................................935 cm (368 in)
Wheels..........................................................................................................................................................................4**
9708
Frame Type............................................................................................................................................................... Rigid
Rows................................................................................................................................................................................8
Row Spacing................................................................................................................................................81 cm (32 in)
Toolbar Width...........................................................................................................................................579 cm (228 in)
Transport Width........................................................................................................................................630 cm (248 in)
Wheels..........................................................................................................................................................................2**
9722
Frame Type....................................................................................................................................................Vertical Fold
Rows..............................................................................................................................................................................12
Row Spacing................................................................................................................................................76 cm (30 in)
Toolbar Width........................................................................................................................................428 cm (168.5 in)
Wing Width.................................................................................................................................................251 cm (99 in)
Transport Width........................................................................................................................................650 cm (256 in)
Wheels..........................................................................................................................................................................4**
* Wheels extend forward but can extend rearward (without
lift assist) on these models. Drive wheels on all other
models extend forward.
** Two lift assist wheels recommended.
ROW UNITS
Seed Discs.....................................................................Corn, soybean, sunflower, sugar beet, cotton, sorghum, milo,
................................................................................................maize, navy bean, large edible bean, snap bean, peanut
Seed Disc-to-Metering Unit Clearance.....................................................................0.254 - 1.27 mm (0.010 - 0.050 in)
Metering Units.................................................................................................................................................... Individual

Specifications
01-10 4283530M1
Seed Hopper Capacity.............................................................................................................................70.5 l (2.0 bu.)
Optional Hopper.......................................................................................................................................105.8 l (3.0 bu.)
Chemical Capacity......................................................................................................................................... 32 kg (70lb)
Openers.........................................................................................................................................................Double Disc
Gauge Wheels..................................................................................................................................Walking Beam Type
Gauge Wheel Tire Size..................................................................................................... 11.4 x 40.6 cm (4.5 x 16 in)
Single Closing Wheel Tire Size............................................................................................. 10.3 x 30.1 cm (4 x 12 in)
Single Closing Wheel Down Pressure................................................................................... 4.5 - 50.0 kg (10 - 130 lb)
Dual Closing Wheel Tire Size ................................................................................................. 30.8 cm dia (12 inch dia)
Dual Closing Wheel Down Pressure...................................................................................... 6.8 - 90.9 kg (50 - 200 lb)
HYDRAULIC SYSTEM
Fluid Capacities
4 and 6 Row.............................................................................................................................................. 0.9 l (1 qt.)
8 and 12 Row........................................................................................................................................ 1.89 l (2 qts.)
Tractor Remote Valve Requirements
With hydraulic pump for blower................................................................................................................................1
With tractor hydraulics for blower.............................................................................................................................2
With folding wings....................................................................................................................................1 additional
AIR SYSTEM
PTO Pump
Speeds.............................................................................................................................................540 or 1000 rpm
Capacity.......................................................................................................12.5 Lpm (3.3 gpm) @ rated PTO rpm
Pressure.........................................................................................................4140 kPa (600 psi) @ rated PTO rpm
Relief Valve...............................................................................................15513 kPa (2250 psi) @ rated PTO rpm
Motor and Fan
Fluid Requirement...........................................................................................................................7.6 Lpm (2 gpm)
Max. Fan Speed..........................................................................................................................................2600 rpm
Max. Working Air Pressure................................................................................................102 mm (4 inch) of water
Fluid Filter............................................................................................................10 micron w/ 20-25 psi relief valve
TRANSMISSION
Type...................................................................................................................................... Chain with sliding sprockets
Sprocket Combinations .................................................................................................................................................32
SHEAR PINS
Flat Fold Markers
6 Row and 8 Row....................................................................................................... 3/8 x 2 1/4 inch bolt, Grade 5
12 Row......................................................................................................................5/16 x 2-3/4 inch bolt, Grade 5
Row Unit Drives..................................................................................................................... 3/16 x 2-1/2 inch cotter pin
Transmission.............................................................................................................................1/4 x 1 inch bolt, Grade 2

4283530M1 01-11
Specifications
MONITOR
SM100
Voltage ...........................................................................................................................................................12 VDC
Fuse...............................................................................................................................................3 amp, violet ATO
Monitoring Capability..................................................................................................................................Seed flow
SM300
Voltage ...........................................................................................................................................................12 VDC
Fuse..................................................................................................................................................................5 amp
Monitoring Capability...............................Row population, high/low population limits, areas (3), distance counter,
...............................................................................................seed spacing, seed count, acres hour, ground speed
SM400..............................................................................................................................................Standard Equipment
Voltage ...........................................................................................................................................................12 VDC
Fuse..........................................................................................................................................7.5 amp, brown ATO
Monitoring Capability...............................Row population, high/low population limits, areas (3), distance counter,
...............................................................................................seed spacing, seed count, acres/hour, ground speed
ELECTRONIC SEED DRIVE CONTROLLER
ISO Bus Electronic Controller
Voltage...........................................................................................................................12 VDC, w/ nonvolatile memory
Program Capability.........................................................................................................Seed Population, seed spacing
HIGHWAY LIGHTS
Type.................................................................................................................Two red tail / stop lights, two amber lights
Connector ..........................................................................................................................................Standard seven-pin
Bulb Size..........................................................................................................................................Red Lights use 1157
......................................................................................................................................................Amber Lights use 1156
APPROX. SHIPPING WEIGHTS
Model Weight
9702 - 12RN 3370 kg (7430 lb)
9708 - 8RN 2452 kg (5405 lb)
9722 - 12RN VF 3336 kg (7355 lb)

Specifications
01-12 4283530M1
NOTES

4283530M1 01-13
Field Operations and Adjustments
FIELD OPERATIONS AND ADJUSTMENTS
TRACTOR PREPARATION
General
Before operating the planter, refer to your tractor Operator
Manual for operating information about hydraulics, tire
inflation, connecting the planter, weights and wheel
adjustments.
Recommended Tractor Horsepower
Wheel Spacing
Set the tractor wheel spacing to at least twice the row
spacing distance. For example: If the row spacing is 76
cm (30 in), adjust the wheels to 152 cm (60 in). Set all
wheels equally from the tractor centerline.
When operating on hillsides or steep slopes, set the
wheels as wide as possible for maximum stability and
steering control. If the front axle is adjustable, set the
wheels at the same width as the rear wheels.
Do not position the tractor wheels directly ahead of the
planter row units that will cause soil compaction and
inaccurate seed placement.
Electrical Requirements
The tractor electrical system must provide 12 volt DC to
operate the seed monitor, highway lighting system and
optional hydraulic seed drive controller.
Find a suitable location to mount the seed monitor
console. Connect the leads to the tractor battery and
route the wire harness to the rear of the tractor.
The transport lighting system is connected to the tractor
with a standard 7-pin connector.
Remote Hydraulic Valve Requirements
Rigid Frame Model
• The planter is raised by the three-point hitch. The
marker is on a separate remote.
• Another valve is required if the blower motor is
operated from the tractor hydraulics.
Planter Model Minimum
PTO HP
Required
Planter
Weight (dry) Total Planter
Weight
Desired
Tractor
Weight (lbs)
9702 - 12RN 100 7430 11990 7995
9708 - 8RN 85 5405 8445 5630
9722 -12RN VF 100 7355 11915 7945

Field Operations and Adjustments
01-14 4283530M1
Vertical Fold Models
• One valve is required to raise and lower the markers,
and lift assist wheels if so equipped.
• A second valve is required to operate the folding
wings.
• A third valve is necessary if the blower motor is
operated from tractor hydraulics.
Tractor Drawbar
Length
FIG. 11: Adjust the tractor drawbar length so the pinhole
is 356 mm (14 in) from the end of the PTO shaft.
NOTE: The dimension must be 36 cm (14 in) for both
540 and 1000 rpm pumps.
IMPORTANT: Fasten the drawbar on the tractor
centerline.
Three-Point Hitch
4 and 6 Row: Cat. II
8 and 12 Row: Cat. II or III
Three-Point Hitch Adjustment
Before connecting the planter to the tractor:
• Adjust hitch sway blocks and stabilizing bars to
provide minimum lateral hitch sway. The planter must
not swing into tractor when planter is in the raised
position.
• Adjust length of lower lift links so center of hitch
latches are 15 cm (6 in) from the ground in the
fully-lowered position.
• Adjust the lower links to the float position to ensure
planter drive wheels are continuously contacting the
ground during operation.
• Adjust hitch draft control for average conditions.
See your tractor Operator Manual for more specific hitch
adjustment information.
Quick Hitch
Adjust the standard three-point hitch, then connect the
quick hitch.
NOTE: If the planter is equipped with lift assist wheels,
remove the quick hitch upper hook.
FIG. 11
E32216b

4283530M1 01-15
Field Operations and Adjustments
Front Weights
Add enough front weights to keep the tractor front wheels
on the ground at all times. Refer to the tractor Operator
Manual for Weight information about mounted and
semi-mounted implements.
Rear Wheel Weights
Add weights as required to maintain stability when
planting on hillsides and when transporting the planter.
PLANTER PREPARATION
Lubrication
Lubricate the planter as described in the Lubrication and
Maintenance Section. Also, check the fluid level in the
PTO pump. Add fluid if required.
Bolt Torque
Make sure all bolts, nuts, and screws are tight and all
cotter pins are spread. IMPORTANT: Tighten lift wheel bolts after first day of operation and periodically thereafter.
Tire Inflation
See the Specifications Section for the correct tire
pressure.
Seed Discs
Install the desired seed discs in all metering units.
Chains
Make sure all drive chains are installed with proper
tension, alignment, and lubrication.
Weights
Add optional weights as necessary, especially for no-till
operation. Weights can be installed on the frame or on the
lift assist wheel arms.
Seed and Transmissions
Determine the seed and chemical rates before going to
the field, if possible, and set the transmission or the seed
drive controller accordingly. Make a test run in a clear
area to verify initial settings.
NOTE: If the planter is equipped with chemical
attachment, rates will change when adjusting the
seed transmission.
Planter Monitor
Monitor and Hydraulic Drive Controls
(1) Monitor Console
(2) AGCO Console
(3) Implement Switch
Mount the seed monitor console in a suitable location
near the operator. Connect the input leads of monitor to
the battery terminals.
NOTE: The monitor does not have to be mounted on the
level to operate properly.
