AGCO Valtra BC 800 User manual

Operator's Manual
BC 800
Combine
BC7800
BC8800
Canoas
AGCO do Brasil - Av. Guilherme Schell, 10260 –
Canoas/ RS
VALTRA is a worldwide brand of AGCO
© AGCO 2017
Original Operator's Manual
April 2017
ACW1493520
English

Contents
BC800 TIERIII OM EN 4
1. Safety 6
1.1 General Information 8
1.2 Travel on Public Roads 16
1.3 Safety in Maintenance 17
1.4 Safety 25
1.5 Safety Decals 27
2. General Information 60
2.1 Introduction 62
2.2 Units of Measurement 63
2.3 Replacement Parts 64
2.4 Location of the Serial Number Identification Plate 65
2.5 Dealer Information 67
2.6 Main components of the machine 68
2.7 How a Combine Works 69
2.8 Headers 71
2.9 Disposal 72
2.10 Intended Use 73
3. Operation 74
3.1 Running in the New Combine 80
3.2 Running in the New Engine 81
3.3 Pre-Operation Inspection 82
3.4 Starting the Engine 83
3.5 Engine shutdown 86
3.6 Transport Switch 87
3.7 Hydrostatic Transmission 88
3.8 Two-speed rear wheel drive assistant 92
3.9 Towing the Combine 94
3.10 Transporting combines on public roads 95
3.11 Towing the header using the combine 101
3.12 Removing a stuck combine 102
3.13 Ladders 103
3.14 Guards and Latches 108
3.15 Access panels 112
3.16 Handrails 116
3.17 Steps 117
3.18 Header Lift Cylinder Latch 118
3.19 Operator's Cab 119
3.20 Seats 123
3.21 Steering Column and Foot Controls 126
3.22 Parking Brake 129
3.23 Combine Lamps 130
3.24 Windscreen wiper 137
3.25 Temperature Control 138
3.26 Electric Rear-View Mirrors 142
3.27 Automatic Guidance (autopilot) 143
3.28 Terminal 144
3.29 Combine Operations 161
3.30 Control Console 228
3.31 Tilt and Header Control Operation 236
3.32 Fuelling the combine 249
3.33 Header Tools 254
3.34 Headers 255
3.35 Feeder 258
3.36 Variable speed header engagement 259
3.37 Beater 263
Find manuals at https://best-manuals.com

3.38 Stone traps 264
3.39 Threshing Rotor 265
3.40 Concaves 267
3.41 Separator Grate 270
3.42 Upper Sieve Pre-cleaner 271
3.43 Separation Grill Pan 272
3.44 Cleaning sieve (vibration system) 273
3.45 Cleaning Fan 277
3.46 Clean Grain and Return Systems 279
3.47 Grain Tank 283
3.48 Unloading Material 287
3.49 Combine Harvesting Configuration Guidelines 297
3.50 Changing the speed of the beater cylinder 326
4. Adjustments 328
4.1 Drive Alignment 330
4.2 Drive Belts 333
4.3 Chains 356
4.4 Concave 360
4.5 Discharge Deflectors 362
4.6 Feeder Channel Drum Stop 363
4.7 Adjusting the Sensor 365
4.8 Adjusting the Ground Speed Cable 369
4.9 Transmission Shift Cable Adjustment 370
4.10 Axles 371
4.11 Brakes 379
4.12 Cab Lighting 380
5. Lubrication and Servicing 382
5.1 Combine Lubrication and Servicing 386
5.2 Lubrication and servicing charts 387
5.3 Lubrication points 394
5.4 Chains 406
5.5 Elevator Chains 407
5.6 Engine Oil 408
5.7 Fuel Filter 411
5.8 Selective Catalytic Reduction System 414
5.9 Engine Air Cleaner 416
5.10 Engine Coolant 419
5.11 Cooling systems assembly 422
5.12 Windscreen washer reservoir 424
5.13 Cleaning the Cab Window 425
5.14 Temperature Control System 426
5.15 Electrical system 428
5.16 Hydraulic System 445
5.17 Transmission 453
5.18 Final drive 454
5.19 Brakes 455
5.20 Drive transmission boxes 457
5.21 Concaves 461
5.22 Separation Grates 466
5.23 Rotor 468
5.24 Unloader tube drive fuse bolt 470
5.25 Straw chopper 473
5.26 Lifting points 476
5.27 Tyres and Wheels 477
5.28 Preparation for off-season storage 481
5.29 Preparation for use after storage 482
5.30 Components' Speed 483
6. Troubleshooting 488
6.1 Headers 490
Find manuals at https://best-manuals.com

6.2 Processing 494
6.3 Engine 500
6.4 Propulsion hydrostatic system 503
6.5 Hydraulic system 506
6.6 Terminal 507
6.7 Fieldstar® II 508
7. Specifications 512
7.1 Harvest system 514
7.2 Engine 519
7.3 Transmission and rear axle 520
7.4 Hydraulic 521
7.5 Electrical system 524
7.6 Weights and dimensions 525
7.7 Capacities 528
7.8 Wheels and Tyres 530
7.9 Headers 532
8. Accessories and Optional Items 534
8.1 Precision Agriculture 536
8.2 Threshing System - Separation 537
8.3 Threshing System - Cleaning 538
8.4 Grain Tank 540
Find manuals at https://best-manuals.com

Find manuals at https://best-manuals.com

1. Safety
1.1 General Information .....................................................17
1.1.1 Safety Alert Symbol ....................................................17
1.1.2 Safety Messages ......................................................17
1.1.3 Informative Messages ..................................................17
1.1.3.1 Safety Signs ...................................................17
1.1.4 A Word to the Operator .................................................18
1.1.4.1 Operator Manual ...............................................19
1.1.5 Prepare for Operation ...................................................19
1.1.6 Operation ...........................................................19
1.1.6.1 General Information ..............................................20
1.1.6.2 PPE (Personal Protection Equipment) .................................21
1.1.6.3 Seat Instructions ................................................22
1.1.6.4 Shield and Guards ...............................................22
1.1.6.5 Exhaust Warning ................................................23
1.1.6.6 Flying Debris ...................................................23
1.1.6.7 Handrails .....................................................24
1.2 Travel on Public Roads ...................................................25
1.3 Safety in Maintenance ...................................................26
1.3.1 General Information ....................................................26
1.3.2 Fire Prevention and First Aid ..............................................28
1.3.3 Checking for High Pressure Leaks ..........................................29
1.3.4 Engine Safety ........................................................29
1.3.5 Adding Fuel ..........................................................31
1.3.6 DEF safety ...........................................................31
1.3.7 Battery Safety ........................................................32
1.3.8 Tire Safety ...........................................................32
1.3.9 Accumulator Safety ....................................................33
1.4 Safety ..................................................................34
1.4.1 Warning Lights ........................................................34
1.4.2 Beacon Lamps ........................................................34
1.4.3 Backup Alarm ........................................................34
1.4.4 Parking Brake .........................................................35
1.4.5 Fire Extinguisher ......................................................35
1.4.6 Header Lift Cylinder Latch ...............................................35
1.5 Safety Decals ............................................................36
1.5.1 Location of decals .....................................................36
1.5.1.1 Safety decals ..................................................41
1.5.1.2 Optional equipment ..............................................58
Table of contents
BC 800 15
ACW1493520
Find manuals at https://best-manuals.com

Table of contents
16 BC 800
ACW1493520
Find manuals at https://best-manuals.com

1.1 General Information
1.1.1 Safety Alert Symbol
The safety alert symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!
Look for the safety alert symbol both in this
manual and on safety signs on this machine. The
safety alert symbol will direct your attention to
information that involves your safety and the
safety of others.
GUID-462DD9F8-63FB-40AD-B62C-FCE9049A24F3-high.jpg [High]
Fig. 1
1.1.2 Safety Messages
The words DANGER, WARNING or CAUTION are
used with the safety alert symbol. Learn to
recognize these safety alerts and follow the
recommended precautions and safety practices.
• DANGER: Indicates an imminently hazardous
situation that, if not avoided, will result in
DEATH OR VERY SERIOUS INJURY.
• WARNING: Indicates a potentially hazardous
situation that, if not avoided, could result in
DEATH OR SERIOUS INJURY.
• CAUTION: Indicates a potentially hazardous
situation that, if not avoided, may result in
MINOR INJURY. GUID-C7C344BB-D28C-4828-953E-DEEA4DC9BF3B-high.jpg [High]
Fig. 2
1.1.3 Informative Messages
The words IMPORTANT and NOTE are not related to personal safety, but are used to give additional
information and tips for operating or servicing this equipment.
•IMPORTANT: They identify specific instructions or procedures that must be strictly observed to avoid
damage to or destruction of the machine, the process or nearby objects.
•NOTE: They identify specific points that provide a more efficient and appropriate operation or repair.
1.1.3.1 Safety Signs
WARNING:
Do not remove or obscure Danger, Warning or Caution signs. Replace any Danger,
Warning or Caution signs that are not readable or are missing. Replacement signs are
available from your dealer in the event of loss or damage. The actual location of the safety
signs is illustrated at the end of this section.
Keep signs clean by wiping off regularly. Use a cleaning solution if necessary.
If parts have been replaced or a used machine has been purchased, make sure all safety signs are in the
correct location and can be read. See Safety Sign Location in this section for illustrations.
[V]
GUID-796C6EC2-5758-4951-9EAB-7FDEDE2043B9 [V1]
GUID-7907E89A-E1AD-4467-96CF-403E751DE44D [V1]
GUID-2ABF686B-4B2F-4951-A27A-57405E63F1FB [V2]
GUID-A03ECF75-D64C-480A-8140-A706B5AAAC87 [V1]
1. Safety
BC 800 17
ACW1493520
Find manuals at https://best-manuals.com

Replace any safety signs that can not be read or are missing. Clean the machine surface thoroughly with a
cleaning solution before replacing signs. Replacement safety signs are available from your dealer.
1.1.4 A Word to the Operator
It is YOUR responsibility to read and understand
the safety section in this manual and the manual
for all attachments before operating this machine.
Remember YOU are the key to safety. Good
safety practices not only protect you, but also the
people around you.
Study the features in this manual and make them a
working part of your safety program. Keep in mind
that this safety section is written only for this type
of machine. Practice all other usual and customary
safe working precautions, and above all
REMEMBER - SAFETY IS YOUR
RESPONSIBILITY. YOU CAN PREVENT SERIOUS
INJURY OR DEATH.
This safety section is intended to point out some
of the basic safety situations that may be
encountered during the normal operation and
maintenance of your machine. This section also
suggests possible ways of dealing with these
situations. This section is NOT a replacement for
other safety practices featured in other sections of
this manual.
Personal injury or death may result if these
precautions are not followed.
Learn how to operate the machine and how to use
the controls properly.
Do not let anyone operate the machine without
instruction and training.
For your personal safety and the personal safety of
others, follow all safety precautions and
instructions found in the manuals and on safety
signs affixed to the machine and all attachments.
Use only approved attachments and equipment.
Make sure your machine has the correct
equipment needed by the local regulations.
GUID-F12599F4-CAB7-46F1-B3D2-11E8CE25FD31-high.jpg [High]
Fig. 3
WARNING:
An operator should not use alcohol or drugs which can affect their alertness or
coordination. An operator on prescription or 'over the counter' drugs needs medical
advice on whether or not they can properly operate machines.
CAUTION:
If any attachments used on this equipment have a separate Operator Manual, see that
manual for other important safety information.
CAUTION:
See the engine Operation and Maintenance Manual for other important safety
information. See the combine Operator Manual for other important safety information.
GUID-FB1B067D-7F26-4FEC-9A6E-57B2BE81A029 [V1]
1. Safety
18 BC 800
ACW1493520
Find manuals at https://best-manuals.com

1.1.4.1 Operator Manual
This manual covers general safety practices for this machine. The Operator Manual must always be kept
with the machine.
Right-hand and left-hand, as used in this manual, are determined by facing the direction the machine will
travel when in use.
The photos, illustrations, and data used in this manual were current at the time of printing, but due to
possible in-line production changes, your machine can vary slightly in detail. The manufacturer reserves the
right to redesign and change the machine as necessary without notification.
WARNING:
In some of the illustrations and photos used in this manual, shields or guards may have
been removed for clarity. Never operate the machine with any shields or guards removed.
If the removal of shields or guards is necessary to make a repair, they MUST be replaced
before operation.
The Operator Manual is stored in the holder (1) on
the machine. After using the Operator Manual,
return the manual to the storage location.
GUID-937201FA-6DBF-4E6D-98D3-05287F6B5DEE-high.jpg [High]
Fig. 4
1.1.5 Prepare for Operation
Read and understand all operating instructions and precautions in this manual before operating or servicing
the machine.
Make sure you know and understand the positions and operations of all controls. Make certain all controls
are in neutral and the parking brake is applied before starting the machine.
All equipment has a limit. Make sure you understand the speed, brakes, steering, stability, and load
characteristics of this equipment before you start.
1.1.6 Operation
Safety instructions for operation.
GUID-0A4C1D46-9B09-437E-983C-DA420C25E73C [V1]
GUID-9C59B9E6-408B-43E9-B47B-B523F97453C6 [V1]
GUID-E9C2CAE7-D6D2-4DD1-BA64-E98229B0ED70 [V1]
1. Safety
BC 800 19
ACW1493520
Find manuals at https://best-manuals.com

1.1.6.1 General Information
When parking, park the machine on a solid level
surface and lower the header to the ground. Put all
controls in neutral and apply the parking brake.
Stop the engine and take the key with you.
WARNING:
A sudden loss of hydraulic pressure
can cause the header to drop without
warning. Do not leave the machine
unattended with the header raised.
Lower the header fully before leaving
the machine.
GUID-DBC8A524-7276-4692-8CF9-D4278EBFEE72-high.jpg [High]
Fig. 5
Make sure the machine is in the proper operating condition according to the Operator Manual.
Always operate the machine with the control console turned on.
Do not dismount from moving machinery.
Stay off slopes too steep for operation.
Be aware of the size of the machine and have enough space available to allow for operation.
Use extra care and reduce speed when operating
on hillsides or near ditches or embankments
especially with a full grain tank to avoid rollover.
Travel speed must be such that complete control
and machine stability is maintained at all times.
Shift to a lower gear before descending a steep
hill.
Regulate ground speed to field conditions, and
maintain control at all times.
Do not dismount from moving machinery.
GUID-23E43F88-0121-4C49-AA97-F70F61535A5D-high.jpg [High]
Fig. 6
Avoid contact with electrical power lines. Always
put the grain tank unloader tube in the transport
position and lower the radio aerial and the engine
deck hand rails before moving combine near
electrical wires. Contact with electrical power lines
can cause electrical shock, resulting in very serious
injury or death.
GUID-CB47BF68-BE16-42C8-B94E-9E67412E2F37-high.jpg [High]
Fig. 7
GUID-3216580D-2230-4529-884F-F51C4566FA56 [V1]
1. Safety
20 BC 800
ACW1493520

Never allow anyone on any part of the combine or
attachments except in the operator's seat and the
instructor seat when the engine is running.
Do not to get on or off the combine while the
combine is moving.
GUID-5030F6C4-1831-45B3-A58A-F8409CA3A2DE-high.jpg [High]
Fig. 8
Always shut off the engine, shift the transmission
to neutral, set parking brake and remove the start
key before leaving the operator cab or before
permitting anyone to inspect, clean, lubricate,
adjust or repair any part of the combine or
attachments unless specifically instructed
otherwise in this manual. Never leave combine
unattended while the engine is operating.
Always keep hands, feet, hair, and clothing away
from moving parts. Do not wear loose clothing,
jewelry, watches, or other items that could
entangle in moving parts. Tie up long hair that can
also entangle in moving parts. GUID-4FAECDFF-3914-4232-80E2-C85AD7E2A5B2-high.jpg [High]
Fig. 9
1.1.6.2 PPE (Personal Protection Equipment)
Wear all personal protective equipment (PPE) and
protective clothing issued to you or called for by
job conditions and country/local regulations. PPE
includes, but is not limited to, equipment to
protect eyes, lungs, ears, head, hands and feet
when operating, servicing or repairing equipment.
GUID-4FAECDFF-3914-4232-80E2-C85AD7E2A5B2-high.jpg [High]
Fig. 10
GUID-A2A94692-BDE1-428C-A877-3989DD3C9EB1 [V1]
1. Safety
BC 800 21
ACW1493520

1.1.6.3 Seat Instructions
Securely fasten the seat belt before operating the
machine. Always remain seated and have the seat
belt fastened while operating the machine.
Replace the seat belts when they become worn or
broken.
Never wear a seat belt loosely or with slack in the
belt system. Never wear the seat belt in a twisted
condition or pinched between the seat structural
members.
GUID-BCA43C6C-C308-4A51-8136-A2C6EF752D1E-high.jpg [High]
Fig. 11
When using the instructor seat (1), securely fasten
the seat belt (2). The instructor seat is to be used
only to train new operators or diagnose a problem.
The instructor seat is only intended for short
periods of use. Extra riders, especially children, are
not permitted on the machine.
When the instructor seat is used the machine
must be driven at a slower speed and on level
ground. Avoid quick starts, stops, and sharp turns.
Avoid driving on highways or public roads.
GUID-264FE9C7-44A8-4117-A6CD-05494CF8546B-high.jpg [High]
Fig. 12
1.1.6.4 Shield and Guards
All shields and guards must be in the correct
operating position and in good condition. Refer to
the Operation section for more information on the
shields.
GUID-ECBDD26A-5021-4BC1-A0D3-4D8CE0722CAF-high.jpg [High]
Fig. 13
GUID-86D79E2F-DE06-4A61-83A9-E37EB59D8705 [V1]
GUID-AB5FC489-7664-458A-A1E9-2A9DD56AABE5 [V1]
1. Safety
22 BC 800
ACW1493520

Do not operate the machine with the drive shaft
shields open or removed. Entanglement in rotating
drive shafts can cause serious injury or death. Stay
clear of rotating components.
Make sure rotating guards turn freely.
GUID-CF8C5C96-A386-4257-9BFF-19FCDE0B1195-high.jpg [High]
Fig. 14
1.1.6.5 Exhaust Warning
Never operate the engine in a closed building
unless the exhaust is vented outside.
GUID-B9375382-FE4D-429A-B959-BD578F5E8FCE-high.jpg [High]
Fig. 15
1.1.6.6 Flying Debris
Never stand near the machine during operation.
Debris can be thrown from the machine during
operation possibly resulting in injury.
GUID-60B8533A-5C7C-45CF-A009-7F0192CAD8BF-high.jpg [High]
Fig. 16
GUID-27D93D94-C913-4D3C-A954-5A2F85C4B17C [V1]
GUID-57041901-BB4D-4118-8C8C-21DFEB02C58F [V1]
1. Safety
BC 800 23
ACW1493520

1.1.6.7 Handrails
Face the ladder and use the handrails when
getting on or off the machine.
GUID-9463C433-AF78-4061-8EE9-11F493C348B8-high.jpg [High]
Fig. 17
GUID-161C3DA5-4E98-4DAA-BCC4-1D3CEE0CD91D [V1]
1. Safety
24 BC 800
ACW1493520

1.2 Travel on Public Roads
Make sure you understand the speed, brakes,
steering, stability, and load characteristics of this
machine before you travel on public roads.
Use good judgment when traveling on public
roads. Maintain complete control of the machine at
all times. Never coast down hills.
The maximum speed of farm equipment is
governed by local regulations. Adjust travel speed
to maintain control at all times. See Specifications
for the maximum speed for this machine.
Familiarize yourself with and obey all road
regulations that apply to your machine. Consult
your local law enforcement agency for local
regulations regarding movement of farm
equipment on public roads. Use headlights,
flashing warning lights, taillights and turn signals,
day and night, unless prohibited by local law.
GUID-4F988BC0-1D48-4F09-9A53-A4C28186BBD5-high.jpg [High]
Fig. 18
Make sure all the flashers are operating prior to driving on the road. Make sure reflectors are correctly
installed, in good condition, and wiped clean. If equipped, make sure the Slow Moving Vehicle (SMV)
emblem is clean, visible, and correctly mounted on the rear of the machine.
Always travel with the header as low as possible. Do not drive with header up and the header lift cylinder
stop in the locked position. Refer to the Operation section for more information on the header lift cylinder
stop.
Lock brake pedals together with the locking strap so that both front wheel brakes will be applied at the
same time.
Be aware of other traffic on the road. Keep well over to your own side of the road and pull over, whenever
possible, to let faster traffic pass.
Be aware of the overall width, length, height, and weight of the machine. Be careful when transporting the
machine on narrow roads and across narrow bridges.
Watch for overhead wires and other obstructions.
Avoid contact with electrical power lines. Contact
with electrical power lines can cause electrical
shock, resulting in very serious injury or death.
When transporting the combine on a trailer, make
sure to measure the clearance height of the
combine and the trailer.
GUID-BF1A2BBE-5E7A-4633-BD2D-4A444E7C6D3C-high.jpg [High]
Fig. 19
GUID-CF6FC302-D1FD-4D99-B382-E9DD7823344D [V1]
1. Safety
BC 800 25
ACW1493520

1.3 Safety in Maintenance
1.3.1 General Information
Before doing any unplugging, lubricating, servicing,
cleaning, or adjusting of the machine:
• Park the machine on a solid level surface.
• Make sure the transmission is in gear and apply
the parking brake.
• Turn off the control console, if equipped.
• Stop the engine and take the key with you.
• Look and Listen! Make sure all moving parts
have stopped. Do not attempt to service or
adjust the machine until all moving parts have
stopped.
• Put blocks in front of and behind the wheels of
the machine before working on or under the
machine.
GUID-FBC97331-BDF4-4BC2-AAED-739377BF281A-high.jpg [High]
Fig. 20
Do not pull crop or any other object from the machine while the machine engine is running. Moving parts
can pull you in faster than you can move away.
Check for loose, broken, missing, or damaged parts. Make sure the machine is in good repair. Make sure
all guards and shields are in position.
Check all nuts and bolts periodically for tightness, especially wheel mounting hardware.
After unplugging, lubricating, servicing, cleaning, or adjusting the machine make sure all tools and
equipment have been removed.
Make sure electrical connectors are clean and free of dirt or grease before connecting.
Never service, check or adjust drive chains or belts
while the engine is running.
GUID-F316B841-4091-49B1-B640-9FC307C1AD29-high.jpg [High]
Fig. 21
GUID-1A905109-F955-4B9D-B589-F53C37915BAB [V1]
GUID-E5C9B0E0-D3E4-4098-A935-DFE8F436FC55 [V1]
1. Safety
26 BC 800
ACW1493520

Do not operate the machine with the drive shafts
shields open or removed. Entanglement in rotating
drive shafts can cause serious injury or death.
Stay clear of rotating components.
Make sure rotating guards turn freely.
A loose yoke can slip off a shaft and result in injury
to persons or damage to the machine.
When installing a quick disconnect yoke, the
spring activated locking pins must slide freely and
be seated in the groove on the shaft. Pull on the
driveline to make sure the quick disconnect yoke
can not be pulled off the shaft. GUID-4BD97B26-E0D2-4EE4-9214-7AF5B5471C91-high.jpg [High]
Fig. 22
When working on the machine, make sure the
header and reel are lowered all the way.
When it is necessary for the header or the reel to
be in the raised position, raise the header or reel all
the way and engage the header lift cylinder stop.
Refer to the Operation section for more
information on the header lift cylinder stop. Refer
to the header Operator Manual for more
information about the reel lift stops.
WARNING:
A sudden loss of hydraulic pressure
could cause the header to lower
unexpectedly. Do not rely on the
hydraulic system to keep the header
raised. Always install the header lift
cylinder stop when working near the
header.
GUID-8EAE1279-ACC0-41DC-8EDA-B3C4404EC598-high.jpg [High]
Fig. 23
Remove spilled oil, antifreeze or fuel immediately
from the operator's ladder and platform and other
access areas.
Keep all access areas clean and free of
obstructions.
GUID-EE9E0C7D-4D0A-4A46-8771-F367E8D4BEF1-high.jpg [High]
Fig. 24
1. Safety
BC 800 27
ACW1493520

1.3.2 Fire Prevention and First Aid
Be prepared for emergencies.
Keep a first aid kit handy for treatment of minor
cuts and scratches.
Due to the nature of the crops this machine will
operate in, the risk of fire is of concern.
Always carry one or more fire extinguishers of the
correct type. Check fire extinguishers regularly as
instructed by the manufacturer. Make sure fire
extinguishers are properly charged and in
operating condition.
Use a water type fire extinguisher or other water
source for a fire in crop. GUID-423D4C47-E2CF-487A-BAAF-73E8EB3D4516-high.jpg [High]
Fig. 25
Know how to operate the fire extinguisher before operating the machine.
For fires involving anything other than crop, such as oil or electrical components, use a dry chemical fire
extinguisher with an ABC rating.
Mount fire extinguishers within easy reach of where fires can occur.
Frequently remove accumulated crop material from the machine and check for overheated components.
Check the machine daily for any noises that are not normal. Such noises could indicate a failed component
that can cause excess heat.
If any flame cutting, welding, or arc welding is to be done on the machine or attachments, make sure to
clear any crop material or debris from around the area. Make sure the area below the work area is clear of
any flammable material as falling molten metal or sparks can ignite the material.
If fire occurs stand upwind and away from smoke
from the fire.
GUID-886D2A98-DA55-43DF-939F-A25686B18603-high.jpg [High]
Fig. 26
GUID-58F4B03F-6549-4093-9A80-70B738E53DA1 [V1]
1. Safety
28 BC 800
ACW1493520

1.3.3 Checking for High Pressure Leaks
Fluid leaking from the hydraulic system or the fuel
injection system under high pressure can be very
hard to see. The fluid can go into the skin causing
serious injury.
Fluid injected into the skin must be surgically
removed within a few hours. If not removed
immediately, serious infection or reaction can
develop. Go immediately to a doctor who knows
about this type of injury.
GUID-92ACA1BC-9042-4AB2-9C8D-2A5D05872530-high.jpg [High]
Fig. 27
Use a piece of cardboard or wood to search for
possible leaks. Do not use your bare hand. Wear
leather gloves for hand protection and safety
goggles for eye protection.
Relieve all pressure before loosening any hydraulic
lines. Relieve the pressure by lowering raised
equipment, shutting off accumulator valve, if
equipped, and shutting off the engine. Tighten all
connections securely before applying pressure.
GUID-D1147E26-CC12-49EA-AD78-178B59131956-high.jpg [High]
Fig. 28
1.3.4 Engine Safety
CAUTION:
Engine safety See the engine instruction manual for other important information
regarding the safety of the engine.
Make sure all guards, shields and access doors are
in place and correctly closed before starting the
engine.
Start the engine from the operator's seat only.
Make sure that all controls are in neutral and that
the transmissions are disengaged.
Verify that all personnel are clear of the machine
before starting the engine.
Do not skip the neutral-start system. The neutral-
start system has been designed to prevent the
machine from starting with the gear engaged. Any
manual override of this system may cause death
or serious injury.
Never connect jumper cables across the starter
motor terminals because this can cause a short
circuit across the starter motor terminals.
GUID-314BC024-C982-4EDE-B61A-86F82A0D4408-high.jpg [High]
Fig. 29
GUID-FC1904D2-6F85-4B7A-B233-B5CAAE70D515 [V1]
GUID-E1EAD00D-EA3A-4858-AAEF-42E000B05D60 [V3]
1. Safety
BC 800 29
ACW1493520
