Allsteel All-Around Table User manual

All-Around Table
Installation Instructions
343-3690A
Index
General Guidelines ....................2
Non-Powered Small & Medium Base Assembly................... 2
Non-Powered & Glenbeigh Powered Large Base Assembly ......... 5
Small Powered Base Assembly...........7
Medium Powered Base Assembly.........8
Large Powered Base Assembly. . . . . . . . . . 10
View Worksurface ....................11
Electrical Installation ..................11
Allsteel Inc.
Muscatine, Iowa 52761-0071
www.allsteelofce.com

SCALE 0.250
Tools:
• 1/4" Nut Driver
• 3/4” Nut Driver
• 7/6” Nut Driver
• #2 Phillips Bit
• Drill
1/4-20 x 1.5” Hex
Head Screws
Small / Medium
Non-Powered
Base Assembly
Small-Powered
Base Assembly
Medium-Powered
Base Assembly
Large-Powered
Base Assembly
1. Ensure that the oor is clean and free of debris which may scratch the unit.
2. Attachment hardware is provided in hardware packs unless otherwise noted.
IMPORTANT: Do not over-torque screws
Step 1 - Attach Top Supports to Column using
6 – ¼-20 x 1.5” Hex Head Screws.
Getting Started:
1a. Attach Top Supports
Illustration 1. Small & Medium Non-Powered Base Assembly
All-Around Table Installation Packet
Failure to install product as instructed, use of hardware other than that which is provided, or failure to comply
with instructions can result in product failure, personal injury, or property damage.
WARNING
343-3690A
(10/17)
Pages 2 of 11

Bottom Shroud
Spacer
1/4-20 x 1.5” Hex
Head Screws Stiffeners
# 8 x 3/4” Phillips
Head Screw
# 8 x 1/2” Hex
Head Screws
Levelers
Counterweight
NOTE: On Small (23”) Bases, do not fully
tighten until the completion of Step 4.
IMPORTANT: Do not over-torque screws
IMPORTANT: On Small Bases, align the 4-hole
line in Counterweight with the Narrow,
Non-Powered Top Support (See Illustration 1e).
Step 2 - Line-up the Stiffener (secured with
the chamfered side down), Spacer,
Bottom Shroud, and Column
holes as shown to the right.
Secure with 6 – 1/4-20 x 1.5”
Hex Head Screws.
Step 3 - Attach Counterweight to Bottom
Shroud using 6 - #8 x 3/4”
Phillips Head Screws.
Step 4 - Secure Counterweight to Stiffeners
using 6 - #8 x 1/2” Hex Head Screws.
Step 5 - Install 8 Levelers.
Illustration 1. Small & Medium Non-Powered Base Assembly Continued
1c. Attach Counterweight
1b. Attach Bottom Shroud & Stiffeners
All-Around Table Installation Packet
343-3690A
(10/17)
Page 3 of 11

IMPORTANT: Lay Work Surface upside-down
on a carpeted or protected surface, if available,
so as to protect the Top
Line-up holes in Ring anges
with the holes in the Stiffeners
(Small Bases Only).
IMPORTANT: Do not over-torque screws
IMPORTANT: For Small
(23”) Bases only, ensure the
4- hole line in Counterweight
is aligned with the Narrow,
Non-Powered Top Support.
Step 6 -Drop-in Stiffener Ring and secure to
Stiffeners using 6 - #8 x ½” Hex
Head Screws.
Step 7 - Fully tighten the 6 – ¼-20 x ½” Hex
Head Screws that were installed in
Step 2.
Step 8 -Attach Work Surface to Top Supports
using 16 - #8 x .875” Wood Screws.
Illustration 1. Small & Medium Non-Powered Base Assembly Continued
1d. Drop-In Stiffener Ring
(Small, 23” Bases Only)
1e. Attach Base to Work Surface
All-Around Table Installation Packet
343-3690A
(10/17)
Page 4 of 11

# 8 x 3/4” Hex
Head Screws
Counterweight
Base
Stiffeners
Levelers
IMPORTANT: Line-up Stiffener, Leveler,
and Top Shroud holes when securing.
Step 1 - Secure Counterweight to Base using
6 - #8 x ¾” Phillips Head Screws.
Step 2 - Secure Counterweight to Stiffeners
using 4 - #8 x ¾” Phillips Head Screws.
Step 3 - Attach six Levelers to the Counterweight.
Illustration 2. Large Base Assembly
2a. Attach Counterweight to Base
2b. Attach Levelers to Counterweight
All-Around Table Installation Packet
343-3690A
(10/17)
Page 5 of 11

Step 4 - Attach Work Surface to Base using
6 - #8 x .875” Hex Head Wood Screws.
Illustration 2. Large Base Assembly Continued
2c. Attach Base to Work Surface
All-Around Table Installation Packet
343-3690A
(10/17)
Page 6 of 11

IMPORTANT: Lay Work Surface upside-down
on a carpeted or protected surface, if available,
so as to protect the Top
1/4 - 20 x 1.5”
Hex Head Screws
IMPORTANT: Do not over-torque screws
Step 1 - Attach Top Bracket to Column using
6 – 1/4 - 20 x 1.5” Hex Head Screws.
Step 2 - Complete Steps 2-4 (Page 3) from the
Non-Powered Base instructions to attach
the Base Assembly to the Column.
Step 3 - Attach Work Surface to Base using
8 - #8 x .875” Hex Head Wood Screws.
3a. Attach Top Bracket
Illustration 3. Small Powered Base Assembly
3b. Attach Top Bracket
All-Around Table Installation Packet
343-3690A
(10/17)
Page 7 of 11

Top Shroud
Base Assembly
Column
Top Support
1/4 - 20 x 1.5”
Hex Head Screws
IMPORTANT: Do not over-torque screws
IMPORTANT: Do not over-torque screws
Step 3 - Attach Top Support to Column using
6 – 1/4-20 x 1.5” Hex Head Screws.
Step 1 - Complete Steps 2-4 (Page 3) from the
Non-Powered Base instructions to attach
the Base Assembly to the Column.
Step 2 - Drop the Top Shroud through the Column,
and rest it on the Base, being cautious to
not scratch the Column.
Illustration 4. Medium Powered Base Assembly
4b. Attach Top Support to Column
4a. Attach Base to Column
All-Around Table Installation Packet
343-3690A
(10/17)
Page 8 of 11

#8 x .875”
Hex Head Screws
IMPORTANT: Be careful not to scratch
the Column when raising Top Shroud.
Step 4 - Attach Top Support to Work Surface using
6 - #8 x .875” Hex Head Wood Screws.
Step 5 - Lower Top Shroud and attach to Work
Surface using 4 - #8 x .875” Hex Head
Wood Screws.
4c. Attach Top Support to Work Surface
Illustration 4. Medium Powered Base Assembly Continued
4d. Attach Shroud to Work Surface
All-Around Table Installation Packet
343-3690A
(10/17)
Page 9 of 11

#8 x .875”
Hex Head
Wood Screws
Step 1 - Complete Steps 1-2 (Page 5) from the
Large Base Assembly instructions to
attach the Counterweight to the Base.
Step 2 - Attach the Base to the Work Surface using
6 - #8 x .875” Hex Head Wood Screws.
Illustration 5. Large Powered Base Assembly
5a. Attach Counterweight
5b. Attach Base to Work Surface
All-Around Table Installation Packet
343-3690A
(10/17)
Page 10 of 11

Step 1 - Use Locator Holes in worksurface to align
Stiffeners
Step 2 - Attach using 16 - #8 x .875” Hex Head
Wood Screws.
Step 1 - Run the cord down the center hole and
through the Column
Illustration 6. Veneer View Worksurface with Tite-Joint
6a. Attach 2 Stiffeners
Illustration 7. Electrical – Corded & Hardwired
7a. Electrical Installation
All-Around Table Installation Packet
343-3690A
