Harvest Rustic Table: Non-Powered
Installation Instructions
Standing Height Table
Seated Height Table
03/22/2019

Harvest Rustic Table: Non-Powered Installation Packet
Failure to install product as instructed, use of hardware other than that which is provided, or failure to comply
with instructions can result in product failure, personal injury, or property damage.
WARNING
3430399500Pages 2 of 10
x12
#10 X 5/8”
Phillips Head screw
Hardware - Total Quantities Shown
5/16” - 18” X 2-1/4”
Flathead Machine Screw
#10 X 1-3/4”
Phillips Head Screw
#12 x 1” Wood Screw
x4 x12 x60
1/4” - 20 X 1/2”
Panhead Machine Screw
x40
#10 x 7/8”
Hex Head Screw
x40
#8 x 1/2”
Waferhead Screw
x12
5/16 x 2”
Lag screw
5/16” x 2”
Panhead Screw
5/16” glide
x8
x16
x4
x8
1/4”-20 X 3/4”
Trusshead Screw - Black
Cross Dowel Nut
Single Hole
x4 x4
Cross Dowel Nut
Double Hole

Page 3 of 10 3430399500
Harvest Rustic Table: Non-Powered Installation Packet
Hardware Bags
Tools
Drill
No. 2 Phillips bit
No. 3 Phillips bit
Extra long No. 2 Phillips bit
No. 2 Magnetic tip hex drive drill
1/4” Driver bit
Flat head screwdriver
1/8” Drill bit
1/4-20 x 1/2” Pan Head Machine Screw - Bag #1
1/4-20 x 3/4” Truss Head Screw - Bag #2 (Standing Height Only)
#8 x 1/2” Wafer Head Screw - Bag #3
5/16 x 2” Pan Head Screw - Bag #4
#12 x 1” Wood Screw - Bag #5
#10 x 5/8” Phillips Pan Head Screw - Bag #6
#10 x 1-3/4” Phillips Head Screw - Bag #7
#10 x 7/8” Hex Head Screw

3430399500Page 4 of 10
Harvest Rustic Table: Non-Powered Installation Packet
Build staging
Build table with underside
facing up.
Protect this surface
and edges of the top
1. Protect worksurface by clearing the build area of any debris that can cause damage.
2. Place worksurafce upside down (as shown) on packing blankets or equivalent to protect
upward facing show surface during the installation process.
3. Open up hardware pack and lay out the numbered bags within.
Hardware:
x4 x4x12
Leg Assembly
1. Insert (1) Single-Hole Dowel Nut into leg. Rotate
nut so the threaded hole and slot are facing up.
2. Attach leg mount plate to leg with (3) #10 x 1-3/4”
wood screws. Add 1-3/8” pilot holes with 1/8” drill
bit if pilot holes are not present.
3. Install (1) 5/16”-18 x 2-1/4” machine screw through
plate and into the threaded dowel hole.
4. Repeat all steps for 3 remaining legs.
(3) #10 x 1-3/4”
Wood Screw
Single-Hole
Dowel Nut
5/16”-18 x 2-1/4”
Machine Screw
Leg Mount
Plate
Machine screw
clearance hole

Page 5 of 10 3430399500
Harvest Rustic Table: Non-Powered Installation Packet
Corner Brace
Leg Assembly continued...
x32
x16
Hardware:
1. Attach Corner Brace to Leg with (4) 5/16 x 2” Lag Screws.
Lag Screw
2. Align leg assembly with corner pilot hole shown, leaving a 1/4” reveal between leg and edge
of worksurface. Attach to worksurface using (8) #12 x 1” wood screws.
Note: For best alignment, do not fully seat wood screws until after installation of aprons.
3. Repeat steps for remaining legs.
Holes must be oriented as shown
**Standing Height only**
Alignment
Hole

3430399500Page 6 of 10
Harvest Rustic Table: Non-Powered Installation Packet
x32
Aprons
1. Align aprons with holes of corner braces, ensuring proper edge is resting on the worksurface.
Incorrect orientation of apron is shown below.
2. Loosely attach aprons to each corner brace using (4) 1/4-20 x 1/2” machine screws.
3. After all aprons are installed, fully tighten machine screws.
Hardware:
Correct Incorrect
Misaligned
Holes

Page 7 of 10 3430399500
Harvest Rustic Table: Non-Powered Installation Packet
Center Support Channels
1. Place center support channels across the length of the table with the at surface facing
upwards, as shown below.
2. Align support brackets with holes of support channel, and attach on each end with (3) #8 x 3/4”
wafer head screws. To prevent aprons from bowing, keep support brackets pressed outward.
3. Rotate support channel so support brackets face outward. Attach each support bracket to apron
with (2) 1/4-20 x 1/2” machine screws.
Hardware:
x12 x8
Support Bracket
Apron
Waferhead
Screws
Machine
Screws
Support Channel
x8
Anti-Bow Brackets
Center
Support Channel
Anti-Bow
Bracket
1. Mount anti-bow bracket into cavity of center support channels, and 6” away from each end.
2. Fasten each bracket to worksurface with (1) #12 x 1” wood screw. Repeat on both sides.
3. Mount remaining anti-bow brackets evenly across each support channel and attach to surface.
Hardware:
6”

3430399500Page 8 of 10
Harvest Rustic Table: Non-Powered Installation Packet
Note: If bow exists within aprons running lengthwise along table, correct with provided L-brackets.
1. Attach L-bracket to apron with (2) #10 Phillips head screws.
2. Push against apron in direction of bow; attach L-bracket to surface with (2) #12 wood screws.
External Stiffeners
1. Place rst stiffener along row of anti-bow brackets, with one end 7/8“ from the apron. Attach
stiffener to surface with (2) #10 x 7/8 Hex head screws into outer-most holes of stiffener.
2. Place second stiffener along inside wall of st stiffener, with end 7/8” from opposite apron than
the rst stiffener. Attach with (2) #10 x 7/8 Hex head screws into outer-most holes.
3. Finish installing external stiffeners with (16) #10 x 7/8 Hex head screws.
4. Repeat steps 1-3 for 2 remaining stiffeners on other half of worksurface.
Hardware:
x40
Anti-Bow Brackets continued...
#10 Phillips
screws
#12 Wood
screws
Install outer
stiffeners rst
Outermost screws
7/8” gap
from apron

Page 9 of 10 3430399500
Harvest Rustic Table: Non-Powered Installation Packet
x16
x4
x8
1. Install leveling glides into threaded insert on each leg.
2. Attach foot rest to legs with (8) 1/4-20 x 3/4” machine screws. Repeat for opposite end.
3. Insert (1) Double-Hole Dowel Nut into each side of foot rail. Rotate nut so the threaded hole
and slot are facing end of the rail.
4. Place foot rail between foot rests and install (2) 5/16 x 2” machine screws into the threaded
dowel holes of each end. Repeat for remaining foot rail.
Glide
Foot Rest & Foot Rail (standing height only)
Hardware:
Foot Rest
3/4” Machine Screws
2” Machine
Screws
Dowel
Nut
Build view Stand view
1. Once fully assembled, lift and rotate the table to the upright position.
2. Check legs to make sure that they are perpendicular to the oor.
3. Level table.
Flip Table Upright
*Important*
Table should be rolled by at least two installers. Table should be lifted while ipping due
to the overall weight. Failure to adequately support table may result in damage to legs.

3430399500Page 10 of 10
Harvest Rustic Table: Non-Powered Installation Packet
Exploded View
Final assembled table
