Allsteel Park Series User manual

Park
Installation Instructions
Allsteel Inc.
Muscatine, Iowa 52761-0071
www.allsteelofce.com
Index
Kit of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Planter Assembly, NAHP/NALP . . . . . . . . . . . . . . . . . . . .3
Worksurface Attachment
General , NARC, NAPWT, NA4828RB, NA4815RB . . . . . 4
Layered Coffee, NALC . . . . . . . . . . . . . . . . . . . . .4
Electrical Attachment . . . . . . . . . . . . . . . . . . . . . . . . . .5
Fastener Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Page 1 of 5

Illustration 1: Kit of Parts
Planter Trough NALPB NAHPB
NALC NAPWTB NARCB
NAPSRT NAPT
Installation Packet
Failure to install product as instructed, use of hardware other than that which is provided, or failure to comply
with instructions can result in product failure, personal injury, or property damage.
WARNING
Park
3430408800Pages 2 of 5

Step 1 - Place the Planter Trough inverted on a clean, dry surface and place the base on top of the Planter Trough.
Step 2 - Align the large oval holes on the top crossbars of the frame with the threaded attachment and secure with 4 A
screws. Stand unit upright and adjust levelers.
Detailed View of Large Oval Holes
and Threaded Attachment
WARNING:
PLANTER TROUGHS ARE NOT INTENDED FOR SOIL.
PLANTER TROUGHS ARE NOT WATER TIGHT.
PLANTER LINER SOLD SEPERATELY AND HIGHLY
SUGGESTED FOR USE WITH LIVE, POTTED PLANTS.
Planter with NAPSRT Planter with NAPT
Installation Packet
Create
Park
3430408800 Page 3 of 5
Illustration 2: Planter Assembly - NAHP/NALP
050-4554
A x 4
12

Step 1 - Place worksurface topside down on a clean, dry surface. Place base on top.
Step 2 - Align holes on attachment plates or tube with pilot holes on the underside of the worksurface. Use Bscrews to
attach base to worksurface. Stand unit upright and adjust levelers.
B x 12
Step 1 - Place round worksurface on top of frame. Align pilot holes in worksurface to the holes in the attachment plate
and use 4 B screws to attach base to worksurface.
Step 2 - PIace pill shaped worksurface on base. Align pilot holes in the worksurface to the attachement plates and use
8 Bscrews to attach base to worksurface. Adjust levelers.
*** All pilot holes in frame should have a fastener installed***
Installation PacketPark
3430408800Page 4 of 5
Illustration 6a: Worksurface Attachment - NARC, NA4828RB, NA4815RB, NAPWT
Illustration 6b: Worksurface Attachment - NALC

Step 1 - Determine desired locations for the slide mount on the underside of the worksurfaces. Reference images
below for suggested locations.
Step 2 - Install slide mount to the underside of the worksurface with given hardware and insert Minitap. Use Cable
Management Straps (C) to secure excess cord to frame.
B
50-2560
#10 x 7/8 Wood Screws (B)
050-4554
A
50-4554
#1/4-20 1/2 Lg Phl RH Screw (A)
*** All screws printed to 1:1: scale ***
Cable Management
Strap (C)
350-1691
C
Cable Management
Strap
Slide Mount
Installation Packet
Create
Park
3430408800 Page 5 of 5
Illustration 7: Electrical Attachment, NALC - Optional
Illustration 8: Fastener Chart
