aoyue 469 User manual

Instruction Manual
Thank you for purchasing the Aoyue 469
Soldering Station. Please read the manual
before using the unit.
Keep manual in accessible place for future
reference.
Soldering Station
469
AOYUE
®

2
TABLE OF CONTENTS
Product Description ......................................... 3
Package Inclusion............................................ 4
Package Content ............................................ 4-5
Product Assembly ........................................... 6-7
Safety Precautions ........................................... 8
Specifications .................................................. 9
Functions and Features.................................... 9
Operating Guidelines....................................... 10
Care and Maintenance ................................. 11
This manual is designed to familiarize and instruct
the operator with the proper operation and
maintenance of the equipment. The “Care and
Safety Precautions” section explains the hazards
of using any type of soldering or reworking
device. Please read carefully and observe the
guidelines in order to maximize usage and
minimize the risk of injury or accidents .

3
The Aoyue 469 is a high performance soldering
iron. It is equipped with a fast acting PTC ceramic
heater suitable for advance soldering needs. The
separate tip and heater design offers cost efficiency
and easy replacement of tips.
The portable and lightweight design of the
system saves precious desktop space and allows easy
packing for occasions where offsite soldering is
required.
 469 Main Station
 Spring Type Iron Holder
(with securing screw)
 469 Platform
 Sponge Holder with Cleaning Sponge
 Solder Spool Stand
 User Manual
PACKAGE INCLUSION
PRODUCT DESCRIPTION

4
Platform
Nuts and Bolts
Sponge
Tray
PACKAGE CONTENT
Sponge

5
469 Soldering
System
Solder Spool
Stand
Solder Iron
Holder
PACKAGE CONTENT

6
2
1
3
Screw in Solder
Iron Holder.
Snap in Spool
Stand
PRODUCT ASSEMBLY

7
4
5
Note: Solder
Wire not
included.
Place in Sponge Tray
PRODUCT ASSEMBLY

8
CAUTION: Improper usage can cause serious injury to personnel
and/or damage to equipment and work area. For your own
safety, please observe the following precautions.
SAFETY PRECAUTIONS
●Check each component after opening the package to make sure
everything is in good condition. If there are any suspected
damage, do not use the item and report the issue to your vendor.
●Turn OFF the main power switch and unplug the device from
power source when moving the device.
●Do not strike or subject the main unit (and all its components) to
physical shock. Use carefully to avoid damage to any part.
- Never drop or sharply jolt the unit.
- Contains delicate parts that may break if the unit is dropped.
●Make sure the equipment is always grounded. Always connect
power to a grounded receptacle.
●Temperature may reach as high as 480°C when switched ON.
- Do not use the device near flammable gases, paper and other
flammable materials.
- Do not touch heated parts, which can cause severe burns.
- Do not touch metallic parts near the tip.
●Disconnect the plug from the power source if the unit will not be
used for a long period.
- Turn off power during breaks, if possible.
●Soldering process produces smoke, use on well ventilated places.
●Do not alter the unit, specifically the internal circuitry, in any
manner. HIGH VOLTAGE present inside the unit. DO NOT
attempt to service equipment.

9
SPECIFICATIONS
MAIN STATION
Voltage Input : available in 110V / 220V
Station Dimensions: 51(w) x 59 (h) x 85 (d) mm
Weight: 235 grams
Power Consumption: 60W
Temperature Range: 300°C - 480°C
Heating Element PTC Ceramic heater
PTC ceramic voltage: available in 110V / 220V
FUNCTIONS and FEATURES
 PTC ceramic heater and removable tip design.
 High power heating element for fast heat recovery.
 Temperature control knob for easy adjustment.
 Portable and lightweight system.

10
OPERATING GUIDELINES
REMINDERS:
 Make sure the equipment is placed on a flat stable surface and all
the heat-generating components placed on their respective hold-
ers or stands.
 Ensure all function switches are OFF prior plugging to wall outlet.
 Ensure all terminal connections are properly secured.
A. INITIAL PROCEDURES
1. Follow Assembly Guide to put together station.
2. Plug the power cord into a grounded wall socket. The
station is protected against electrostatic discharge and
must be grounded for full efficiency.
3. Turn Power Switch ON.
4. The unit is now ready for use.
B. TEMPERATURE CONTROL
1. Turn the power ON. LED indicator will start blinking
indicating system is now turned “On”.
2. To Increase the temperature, turn the Temperature
control knob clock wise. To decrease Set temperature,
turn the Temperature control knob counter clockwise.
