SMOK-CHEK®V
A Fire/Life Safety Holder Product
Model 0101
Push Side Mounting
Independent Closing Means
*85° thru Maximum Degree of Swing
Single Point Hold Open
Not for Use on Doors that will be
Manually Closed on a Daily Basis
General Information:
Non Handed
Door Hanging Means:
• Standard 4”, 4-1/2”, or 5” Butt Hinges
• 3/4” Offset Pivot
• For other means, contact factory
2” Minimum head frame
For frame face sizes less than 2”, contact factory
Maximum reveal 3-1/2”
For reveals from 3-1/2 to 7”, use arm 550789
*For hold-open from 105° - 180°, use arm 550789
Door Closing Device by others
ISFM0101
Left Hand Shown
Screw
01844016
02344010-602
01030
06344808
02301420-602
02344010-602
02344012-602
Description
1/4-20 x 1 FLH Allen (1)
Pan HD 1/4-20 x 5/8 (4)
Washer (1)
FLHD 1/4-20 x 1/2 (1)
#14x1-1/4 PHPWS (2)
1/4-20x5/8 PHPMS (6)
1/4-20x3/4 PNHDSMS (2)
Holder Cover
550106-*(non-detectored)
Magnet
930105 120VAC
930106 24VAC/DC
Holder Assembly (includes magnet)
550100 120VAC
550101 24VAC/DC
www.rixson.com
Door Pivot Bracket
565118T689
Push Side Arm
550136K*
Reinforcing Plates
By Others
12 Ga. Min.
C
Reinforcing Plates
By Others
12 Ga. Min. 3-1/2 (89)
Reveal
Max.
4-1/16
(103)
D
For Frame Less Than
Shown On Chart
Consult Factory
C
1/2 (12.7)
5/8 (16)
D
2-1/2 (63.5)
2-5/8 (67)
1-1/2
(38)
Stop Dim.
1-1/4
(31.8)
C
LButt Hinge or Pivot
9-1/8
(232)
7/8
(22)
1/4-20 Machine Screw
(4 Places)
10-3/4
(273)
1-1/8
(80.6)
8-3/16
(208)
Optional Knock Out
“In Out” Wiring
1-1/4
(31.8)
10-1/4
(260)
12-1/2
(318)
7/8 (22)
Dia.
Hole
7/8
(22) 3/4
(19)
1-11/16
(43) B
Stop Dim
1/2 (12.7)
5/8 (16)
B
1-3/4 (44.5)
1-7/8 (47.7)
1-3/16
(30)
1-1/2
14-20 Machine Screw
or #14 Wood Screws
(2 Places)
Mounting Hole Locations
• Right hand shown
• Door hanging means: 4”, 4-1/2”, 5” Butts or 3/4” Offset Pivots
• All dimensions given in inches (mm)
Page 2
ISFM0101
Solid Line Represents Double Egress Frame
Dotted Line Represents Standard Double Rabbeted Frame
www.rixson.com
Push Side Mounting
Page 3
ISFM0101
1. Mounting Holder
A. Layout & prepare screw holes.
B. Remove appropriate knock out in Smok-Chek &
attach 3/8” (9.5) conduit fitting. (Fig. 1a)
C. Push conduit back into frame.
D. Attach holder with (6) 1/4-20 x 5/8 pan HD screws –
tighten securely.
E. Attach arm to holder with (1) 1/4-20 x 1 FHD allen
screw. (Fig. 1b)
CAUTION: SQUARE ON ARM MUST BE INSERTED AND TIGHTENED INTO HOLDER VERY
SECURELY BEFORE ARM IS ATTACHED TO SPINDLE OF CLOSER.
Power Supply
Magnet
Hot
Switch
Neutral
BEFORE BEGINNING WIRING, INSTALLER MUST BE GROUNDED!
3. Electrical Wiring
Field Wires should be 18ga OR as required by local code
A. Connect switch – in series – with HOT lead of
electromagnet.
Note:
120vAC draws .018 amp
24vAC/DC draws .091 amp
Fig. 1b
Fig 1a
www.rixson.com
Push Side Mounting
2. Mounting Door Pivot Bracket
A. Mount door bracket to door and fasten
with two 1/4-20x1/2” RDH or #14x1-1/4
Pan HD screws.
B. Slide bracket arm into holder arm.
C. Attach arm to bracket spindle with washer
and 1/4-28x1/2” FLH screws. (Fig. 2a)
D. Position arm as per suggested arm
settings listed in chart. (Fig. 2b)
E. Assemble holder and bracket arms
together with the 1/4-20x5/16” RDH
screws.
12 3481012 14 16 1
Fig 2a
Fig 2b
Arm Setting No. 18
Door Hanging
Means
4” Wide Butts
4-1/2” Wide Butts
5” Wide Butts
Swing Clear
3/4” Offset Pivot
Arm Settings
85°/135° 130°/180°
17 16
18 16
19 16
17 -
18 16
Rixson® and Smok-Chek® are registered trademarks of Yale Security Inc., an ASSA ABLOY Group company.
Copyright© 2003, 2009, Yale Security Inc., an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Yale Security Inc., is prohibited.
4. Making Adjustments to the Holder
A. Closer spring force should be as low as possible.
(Closer should arrive at lowest setting).
B. Turn OFF Power (using ON/OFF switch).
C. To set Hold Open:
1. Door should be in CLOSED position.
2. Raise or lower cam until the word “Push” is dis-
played from the UNDERSIDE of the unit (Fig 4a).
3. Open door to desired Hold Open position.
4. Raise or lower cam and ROTATE until pocket of
cam is in position next to Roller A shown in Fig 4b
5. Release cam to re-engage teeth.
6. Turn ON power (using ON/OFF switch).
7. OPEN DOOR. Door should stay in Hold Open
position–if not, repeat Steps 3 and 4.
8. Pull door OUT of Hold Open–door should close
freely.
9. OPEN DOOR. If releasing force needs to be
increased, turn adjusting nut IN. If lesser holding
force is desired, turn nut OUT.
10. Attach holder cover.
Trouble-Shooting Tips:
1. Turn ON power.
2. Can door swing far enough to engage hold open? Minimum opening is 85°.
3. Make sure closer is at lowest spring setting.
4. Put piece of metal against the magnet to make sure it is receiving current.
5. If not, double check wiring instructions.
6. If so, with door in closed position look up at holder mechanism. Word PUSH should be visible, if
not, adjust cam.
7. Turn adjusting nut.
8. Check arm indexing.
Page 4
ISFM0101
Fig 4a
Fig 4b
Hold Open
Adjust Nut
www.rixson.com
Push Side Mounting
