AXIOMTEK IPC974-519-FL User manual

IPC974-519-FL
Industrial and Fanless Computers
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate
information. Axiomtek Co., Ltd. assumes no responsibility for any infringements of
patents or any third party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the
accuracy, completeness or usefulness of any information in this document. Axiomtek
does not make any commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any
time without notice.
No part of this document may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.
Copyright 2020 Axiomtek Co., Ltd.
All Rights Reserved
May 2020, Version A3
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The IPC974-519-FL does not come equipped with an operating system. An
operating system must be loaded first before installing any software into the
computer.
2. Be sure to ground yourself to prevent static charge when installing the
internal components. Use a grounding wrist strap and place all electronic
components in any static-shielded devices. Most electronic components are
sensitive to static electrical charge.
3. Disconnect the power cord from the IPC974-519-FL before making any
installation. Be sure both the system and the external devices are turned
OFF. Sudden surge of power could ruin sensitive components. Make sure the
IPC974-519-FL is properly grounded.
4. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
5. Turn OFF the system power before cleaning. Clean the system using a cloth
only. Do not spray any liquid cleaner directly onto the screen.
6. Do not leave this equipment in an uncontrolled environment where the
storage temperature is below -20℃or above 80℃. It may damage the
equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance
is a must, only a trained technician is allowed to do so. Integrated circuits on
computer boards are sensitive to static electricity. To avoid damaging chips
from electrostatic discharge, observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted
portion of the system unit chassis for a few seconds. This will help to
discharge any static electricity on your body.
When handling boards and components, wear a grounding wrist strap,
available from most electronic component stores.

iv
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: IPX40
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with
air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
5. Type of protection against electric shock: Class I equipment
General Cleaning Tips
You may need the following precautions before you begin to clean the computer.
When you clean any single part or component for the computer, please read and
understand the details below fully.
When you need to clean the device, please rub it with a piece of dry cloth.
1. Be cautious of the tiny removable components when you use a vacuum cleaner
to absorb the dirt on the floor.
2. Turn the system off before you start to clean up the component or computer.
3. Never drop the components inside the computer or get circuit board damp or
wet.
4. Be cautious of all kinds of cleaning solvents or chemicals when you use them
for the sake of cleaning. Some individuals may be allergic to the ingredients.
5. Try not to put any food, drink or cigarette around the computer.

v
Cleaning Tools:
Although many companies have created products to help improve the process of
cleaning computers and peripherals, users can also use household items to clean
their computers and peripherals. Below is a listing of items available for cleaning
computers or computer peripherals.
Keep in mind that some components in your computer may only be cleaned using a
product designed for cleaning components of the same types. Please read the
instructions that come with a cleaning product to avoid misuse.
Cloth: A piece of cloth is the best tool to use when rubbing up a component.
Although paper towels or tissues can be used on most hardware as well, it is
recommended to use a piece of cloth.
Water or rubbing alcohol: You may moisten a piece of cloth a bit with some
water or rubbing alcohol and rub it on the computer. Unknown solvents may
be harmful to the plastics parts.
Vacuum cleaner: Vacuuming dust, dirt, hair, cigarette particles, and other
particles out of a computer can be one of the best methods of cleaning a
computer. Over time these items can restrict the airflow in a computer and
cause circuitry to corrode.
Cotton swabs: Cotton swabs moistened with rubbing alcohol or water are
excellent tools for wiping hard to reach areas in your keyboard, mouse, and
other locations.
Foam swabs: If possible, use lint free swabs such as foam swabs.
Note: It is strongly recommended that you should shut down the system before you
start to clean any single components.
Please follow the steps below:
1. Close all application programs;
2. Close operating software;
3. Turn off power switch;
4. Remove all device;
5. Pull out power cable.

vi
Scrap Computer Recycling
Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in
case computers require maintenance or repair; or for recycling in case computers are out of
order or no longer in use.
Trademark Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Pentium®are registered trademarks of Intel Corporation.
Windows 10, Windows 10 IoT Enterprise, Windows 7, are trademarks of Microsoft
Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Safety Precautions................................................................................................iii
Classification......................................................................................................... iv
General Cleaning Tips ..........................................................................................iv
Scrap Computer Recycling..................................................................................vi
CHAPTER 1 INTRODUCTION................................................................................1
1.1 General Description........................................................................... 1
1.2 System Specifications.......................................................................2
1.2.1 Main CPU Board...............................................................................................2
1.2.2 I/O System ........................................................................................................3
1.3 M/B Block Diagram & System Dimensions......................................7
1.4 Outlets ................................................................................................ 9
1.5 Packing List...................................................................................... 11
1.6 Jumper Settings............................................................................... 12
1.6.1 Restore BIOS Optimal Defaults (JP3) ..........................................................12
1.7 Connectors....................................................................................... 13
1.7.1 MINI CARD SLOT (CN4).................................................................................14
1.7.2 LAN+USB3.0 (CN8、CN9)..............................................................................15
1.7.3 VGA Connector (CN10)..................................................................................16
1.7.4 USB 2.0 Connector (CN11)...........................................................................17
1.7.5 Audio Connector (CN12) ...............................................................................17
1.7.6 DC-in Phoenix Power Connector (CN15).....................................................17
1.7.7 HDMI Connector (CN13)................................................................................18
1.7.8 SATA Power connector (SCN1、SCN2).......................................................18
1.7.9 SATA Connector (SATA1~SATA4)................................................................19
1.7.10 Power On/OFF Button(SW1).........................................................................19
1.7.11 AT/ATX Switch (SW3)....................................................................................19
1.7.12 Reset Button(SW2)........................................................................................20
1.7.13 Remote Power Switch Connector (PWRBT1) .............................................20
1.7.14 Flexible IO - COM I/O Card Connector (AX93511) ......................................20
1.7.15 Flexible IO –Isolated COM & DIO I/O Card (AX93512)...............................21
1.7.16 Flexible IO –Isolated COM x4 I/O Card (AX93516).....................................24
1.7.17 Flexible IO- USB3.0x2 & COMx2(RS232/422/485) & LAN1(AX93519)........25
1.7.18 Riser Card- PCIe x16 Gen3 & 3 PCIe x4 Gen 3(AX96410) ..........................28
1.7.19 Riser Card- PCIe x16 Gen3 & 1 PCIe x4 Gen 3 & 2 PCI(AX96411).............30
CHAPTER 2 HARDWARE INSTALLATION.......................................................33
2.1 Installing the Processor ..................................................................33
2.2 Installing the Memory Module......................................................... 35
2.3 Installing the Hard Disk Drive .........................................................37
2.4 Installing the Fan Module and PCI or PCIe Card ...........................38
2.4.1 Installing PCI or PCIe add-in card................................................................39
2.4.2 Installing RTX2080 w/FAN kit .......................................................................43
2.4.3 The length limitation of an add-in card.......................................................46

viii
2.5 Installing the WIFI Module............................................................... 48
2.6 Installing USB dongle kit ................................................................ 49
2.7 Installing foot pad............................................................................ 50
2.8 Wall mounting.................................................................................. 51
CHAPTER 3 AMI BIOS UTILITY...........................................................................53
3.1 Starting............................................................................................. 53
3.2 Navigation Keys............................................................................... 54
3.3 Main Menu........................................................................................55
3.4 Advanced Menu................................................................................ 56
3.5 Chipset Menu ...................................................................................71
3.6 Security Menu .................................................................................. 78
3.7 Boot Menu ........................................................................................79
3.8 Save & Exit Menu............................................................................. 80
APPENDIX A WATCHDOG TIMER......................................................................83
A.1 About Watchdog Timer....................................................................83
A.2 How to Use Watchdog Timer ..........................................................83
APPENDIX B HDD HOT-SWAPPABLE..............................................................89
Using HDD hot-swappable function...............................................................89
Removing Hot-Swappable storage................................................................. 90
APPENDIX C CONFIGURING SATA FOR RAID...............................................93

IPC974 Series User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed specifications of the IPC974-
519-FL. Chapter 1 includes the following sections:
General Description
System Specifications
Dimensions
I/O Outlets
Jumper Settings
Connectors
Package List
1.1 General Description
The IPC974-519-FL is a fanless system that supports the LGA1151 socket for Intel®
Xeon and 6th/7th generation CoreTM i7/i5/i3 processors. The IPC974-519-FL supports
Windows® 7 and Windows®10, with a rugged design that makes it suitable for the
most endurable operation.
The IPC974-519-FL supports two hard-drive bays, which allow customers to easily
add storage and maintain the system.
Embedded O.S. supported
The IPC974-519-FL not only supports Windows®7 and Windows®10, but also
supports embedded OS, such as Windows®7 embedded. For storage device, the
IPC974-519-FL supports four HDD drive bays

IPC974 Series User’s Manual
2
1.2 System Specifications
1.2.1 Main CPU Board
CPU
Socket LGA1151 for 6th /7th Generation Intel®CoreTM i7/i5/i3 and Xeon processors, up to
80W. CPU support is listed as below.
Processor
Core
Thread
Base frequency
TDP
i5-6400T
4
4
2.20 GHz
35 W
i5-6500TE
4
4
2.30 GHz
35 W
E3-1268LV5
4
8
2.40 GHz
35 W
G4400TE
2
2
2.40 GHz
35 W
i7-6700TE
4
8
2.40 GHz
35 W
G3930TE
2
2
2.70 GHz
35 W
i3-6100TE
2
4
2.70 GHz
35 W
i5-7500T
4
4
2.70 GHz
35 W
i7-6700T
4
8
2.80 GHz
35 W
i7-7700T
4
8
2.90 GHz
35 W
i3-7101TE
2
4
3.40 GHz
35 W
i5-6400
4
4
2.70 GHz
65 W
i5-6500
4
4
3.20 GHz
65 W
i5-7500
4
4
3.40 GHz
65 W
G4400
2
2
3.30 GHz
54 W
i7-6700
4
8
3.40 GHz
65 W
i7-7700
4
8
3.60 GHz
65 W
i3-6100
2
4
3.70 GHz
51 W
i3-7101E
2
4
3.90 GHz
54 W
E3-1275V6
4
8
3.80 GHz
73 W
E3-1225V5
4
4
3.30 GHz
80 W
E3-1275V5
4
8
3.60 GHz
80 W
System Chipset
Intel®C236 chipset
BIOS
AMI BIOS, with Smart View and Customer CMOS Backup.
System Memory
Two DDR4-2133/2400 un-buffered ECC SO-DIMM max. up to 32GB

IPC974 Series User’s Manual
Introduction
3
Features
Fanless operation
Compact & front IO design
Supports four expansion slots
DC to DC power supply; supports 24VDC (uMin=19V/uMax=30V)
TPM2.0
Supports system power on delay function
Supports Intel® RAID 0,1,5
1.2.2 I/O System
Standard I/O Interface -- Font
One ATX power on/off switch
One 4-pin terminal block
One ATX/AT Mode switch
One Reset switch
One 2-pin connector output for remote power on/off switch
DC to DC power supply, supports 24VDC (uMin=19V/uMax=30V) with phoenix
power plug
Four USB 3.0 ports
Two USB 2.0 ports
HDD access/power LED
Two G.E. LAN ports (i219LM and i211AT)
One Ground Terminal
Flexible IO
AX93511 4 x RS-232/422/485 module (default RS-232)
AX93512 2 x RS-232/422/485 w/ isolated 1.5KVDC protection and
8-in/8-out isolated 1.5KVDC DIO
AX93516 4 x RS232/422/485 w/isolated 2KVDC module
AX93519 2 x RS232/422/485 + 2 USB3.0 + 1 G.E. LAN(i211AT)
One VGA supports resolution up to 1920 x 1200 @60Hz
One HDMI 1.4b supports resolution up to 4096 x 2160 @24Hz
1 x Audio (Line-out)

IPC974 Series User’s Manual
4
Expansion Slot
1 x on board full-size PCI Express Mini Card slot with USB/PCIe interface w/SIM slot
AX96410: 1 PCIex16 + 3 PCIex4
AX96411: 1 PCIex16 + 1 PCIex4 + 2 PCI
Note: The maximum power rating for expansion slots at 60 ℃ cannot exceed
the following value:
The maximum loading of +3.3V+5V+12V<150W
The maximum loading of +3.3V+5V+12V<480W (w/AX98268)
Note: 12V maximum loading 10A(120W), the remaining 30W is shared by 3.3V
& 5V.
Note: The system power rating may thus be changed base on differing attached
device combinations.

IPC974 Series User’s Manual
Introduction
5
1.2.3 System Specification
Drive Capacity
1 x HDD drive bay (default, supports 2 x 2.5”HDD/SSD)
1 x HDD drive bay (optional, supports 2 x 2.5”HDD/SSD)
(height 7mm or 9.5mm)
Note: Since Gen. 2 SSD with JMicron controller has compatibility issue with
Intel PCH, it is strongly recommended to use Gen. 3 SSD on IPC974-519.
Power Input
24VDC (uMin=19V/uMax=30V) with phoenix power plug
Operation Temperature
Processor
Core
Thread
Base
frequency
TDP
Operating temperature
(Ambient with air flow
& W.T. HDD or W.T. SSD)
i5-6400T
4
4
2.20 GHz
35 W
-10℃-70℃
i5-6500TE
4
4
2.30 GHz
35 W
-10℃-70℃
E3-1268LV5
4
8
2.40 GHz
35 W
-10℃-70℃
G4400TE
2
2
2.40 GHz
35 W
-10℃-70℃
i7-6700TE
4
8
2.40 GHz
35 W
-10℃-70℃
G3930TE
2
2
2.70 GHz
35 W
-10℃-60℃
i3-6100TE
2
4
2.70 GHz
35 W
-10℃-60℃
i5-7500T
4
4
2.70 GHz
35 W
-10℃-60℃
i7-6700T
4
8
2.80 GHz
35 W
-10℃-60℃
i7-7700T
4
8
2.90 GHz
35 W
-10℃-60℃
i3-7101TE
2
4
3.40 GHz
35 W
-10℃-60℃
i5-6400
4
4
2.70 GHz
65 W
-10℃-60℃
i5-6500
4
4
3.20 GHz
65 W
-10℃-60℃
i5-7500
4
4
3.40 GHz
65 W
-10℃-60℃
G4400
2
2
3.30 GHz
54 W
-10℃-50℃
i7-6700
4
8
3.40 GHz
65 W
-10℃-50℃
i7-7700
4
8
3.60 GHz
65 W
-10℃-50℃
i3-6100
2
4
3.70 GHz
51 W
-10℃-50℃
i3-7101E
2
4
3.90 GHz
54 W
-10℃-50℃
E3-1275V6
4
8
3.80 GHz
73 W
-10℃-50℃
E3-1225V5
4
4
3.30 GHz
80 W
-10℃-50℃
E3-1275V5
4
8
3.60 GHz
80 W
-10℃-50℃

IPC974 Series User’s Manual
6
Storage Temperature
-20℃~ 80℃
Humidity
10% ~ 90% (Non-condensing)
Dimensions
188.14 mm (7.40”) (W) x 192 mm (7.54) (H) x 317 mm (12.46") (D)
Note: All specifications and images are subject to change without notice.
Note: The performance of the system could be adversely affected at an over spec
operating temperature or with an unrecommended processor.
Note: If the operating temperature is above 35°C, it is recommended to use a wide
temperature SSD on the device.
Note: If the operating temperature is above 35°C, it is recommended to use a wide
temperature Wi-Fi module on the device.

IPC974 Series User’s Manual
Introduction
7
1.3 M/B Block Diagram & System Dimensions
The following diagrams show you M/B block diagram, system dimensions and outlines of the
IPC974-519-FL.

IPC974 Series User’s Manual
8

IPC974 Series User’s Manual
Introduction
9
1.4 Outlets
The following figures show you outlets on the front and top panels of the IPC974-519-FL.

IPC974 Series User’s Manual
10
No.
Description
No.
Description
1
2 x Antenna opening
11
2-pin connector output for remote power
on/off switch
2
1 x HDD drive bay(default, support
2 x 2.5” HDD/SSD)
12
2 x USB 2.0
3
1 x HDD drive bay(optional,
support 2 x 2.5”HDD/SSD)
13
1 x 10/100/1000Mbps ethernet(i211-AT)
2 x USB3.0
4
HDD access/power LED
14
1 x 10/100/1000Mbps ethernet(i219LM)
2 x USB3.0
5
Power on/off switch
15
VGA
6
Extension Window
(1)Blank cover (default)
(2)1 x Wifi kit and/or (3) 1 x USB
dongle kit
(4)AX92902+AX93287: 1 x
10/100/1000 Mpbs Ethernet
module (Intel® i210-AT)
(5) AX92903: CANBus module
(6) AX92906: 1 x RS-232 module
16
HDMI
7
4-pin terminal block
17
Extension System I/O Module
(1) AX93511: 4 x RS-232/422/485 module
(default RS-232)
(2) AX93512: 2 x RS-232/422/485 with
isolated 1.5kVDC & 8-in/8-out with
isolated 1.5kVDC DIO module
(3) AX93516: 4 x RS-232/422/485 with
isolated 2kVDC module
(4) AX93519: 1 x 10/100/1000 Mbps (Intel®
i211-AT) Ethernet, 2 x RS-232/422/485,
and 2 x USB 3.0 module
(5)Blnak I/O cover
8
AT/ATX mode switch
18
Expansion Interface
(1) AX96410: 1 PCIe x16 + 3 PCIe x4
(2) AX96411: 1 PCIe x16 + 1 PCIe x4 + 2
PCI
9
Line out
19
1 x Terminal ground
10
Reset switch

IPC974 Series User’s Manual
Introduction
11
1.5 Packing List
The package bundled with your IPC974-519-FL should contain the following items:
IPC974-519-FL unit x 1
Screw pack x 1
Foot pad x 4
CPU grease x 1
Terminal block x 1
Remote switch cable x 1
Extension holder bracket kit x 1
If you cannot find this package or any items are missing, please contact Axiomtek distributors
immediately.

IPC974 Series User’s Manual
12
1.6 Jumper Settings
Properly configure jumper settings on the SBC87511/SBC87512 to meet your application
purpose. Below you can find a summary table of all jumpers and onboard default settings.
Note: How to setup Jumpers
Illustrations below show that a cap on a jumper is to “close”the jumper, whereas that off a
jumper is to “open”the jumper.
[Open] [Closed] [Pin1-2 Closed]
Jumper
Descriptions
Setting
JP3
Clear RTC : Normal
Short 1-2
1.6.1 Restore BIOS Optimal Defaults (JP3)
Put jumper clip to pin 2-3 for a few seconds then move it back to pin 1-2. Doing this procedure
can restore BIOS optimal defaults.
Function
Setting
Normal operation (Default)
1-2 close
Restore BIOS optimal defaults
2-3 close
