B. Braun Vista basic User manual

Vista™basic
Infusion Pump
Quick
Reference
Rx only
Vista™ and Working Together for Excellence in Safety
are a trademarks of B. Braun Medical Inc.
©2002, B. Braun Medical Inc. 950853-Rev B 06/02
Alarm Troubleshooting
Air In Line! • Check for air in air-in-line
detector.
• Check that tubing is properly
inserted in air-in-line detector.
• Remove air from line.
Battery • Plug pump into wall outlet.
Too Low!
Door Open! • Close door.
Dwnstream • Open clamps.
Occlusion! • Check for kinked tubing.
• Check IV site.
• Check occlusion pressure
setting.
Pump • Pump is stopped.
Stopped! • Either start infusion or press
to extend hold time
3 minutes.
Silence alarms by pressing .
Refer to Instructions for Use for complete
operating instructions.
B. Braun Medical Inc.
824 Twelfth Avenue
Bethlehem, PA 18018
1-800-227-2862
www.bbraunusa.com
Program Mode
1. Press OPTS until PROGRAM MODE is
displayed
2. Press ON .
3. Enter the rate for Step 1 and press OK .
4. Enter the volume for Step 1 and press OK .
5. Repeat Steps 3 and 4 until all steps are
complete and press OK .
6. Review the Total VTBD and press OK .
7. Press START .
Ramp Taper Mode
1. Press OPTS until RAMP TAPER MODE is
displayed
2. Press ON .
3. Enter the total bag volume to be delivered and
press OK .
4. Enter the Ramp Up time in hours and minutes
and press OK .
5. Enter the Taper Down time in hours and minutes
and press OK .
6. Enter the Total Time for the infusion in hours
and minutes and press OK .
7. Review the calculated Max Rate and
press OK .
8. Press START .

7 8 9 0
4 5 6 C
1 2 3
START
STOP
Important Keys
Setting the Pump
1. Press (On/Off).
2. Press button on top of door to open.
3. Insert tubing into pump.
• Push open tube pincher A
• Place tubing in tube pincher A
• Insert tubing along channel B
• Push tubing into Air In Line Detector C
4. Close Door.
Yes, No, OK, etc.
On/Off
(Power)
Alarm Silence
Start/Stop
Alarm Light
Infusing Light
Number
Keys
A
B
C
5. Is this a new therapy?
• Yes : clears current infusion data.
•No : returns pump to last
programmed infusion.
6. Prime set?
•Yes : follow prompts to prime tubing.
•No : begin programming infusion.
Continuous Mode
1. Enter the rate using the number keys.
2. Press VTBD .
3. Enter the bag volume using the number keys.
4. Press OK .
5. Press START .
Changing the Rate
1. While infusing,
enter the new rate
using the number
keys.
2. Press OK .
NOTE:
If the OK key is not pressed within 10 seconds
of the change, the infusion will continue at the
original rate.
Changing the VTBD
1. Stop infusion.
2. Press VTBD .
3. Press .
4. Enter the new
volume to be
delivered.
5. Press OK .
6. Press .
Piggyback Mode
1. Press OPTS until PIGGYBACK is displayed
2. Press ON .
3. Press END .
4. Press PIGY .
5. Enter Rate/VTBD or VTBD/Time as in
Continuous Mode.
6. Press START .
950853-Rev 06/02
