Blatchford Esprit User manual

Esprit
User Guide
ESP22L1S–ESP30R8S
ESP22L1SD–ESP30R8SD
User Guide
Brugervejledning
Brukerhåndbok
Käyttöopas
Användarhandbok
Руководство пользователя
用户指南
 
PK3
EN 2
DA 8
NO 14
FI 20
SV 26
RU 32
ZH 38
AR 44

2
EN
Contents
Contents.................................................................................................................................................................2
1 Description and Intended Purpose ....................................................................................................................3
2 Safety Information....................................................................................................................................................3
3 Construction ...............................................................................................................................................................4
4 Function........................................................................................................................................................................5
5 Maintenance ...............................................................................................................................................................5
6 Limitations on Use....................................................................................................................................................5
7 Technical Data ............................................................................................................................................................6
938446PK3/1-0121

3
Please keep these instructions.
The term device is used throughout this document to refer to Esprit.
Application
This device is to be used exclusively as part of a lower limb prosthesis.
Intended for a single user.
It is a moderate-energy-return foot. Independent heel and toe spring provides some axial
deection. The split toe provides good ground compliance.
Any changes in the performance or
function of the limb e.g. restricted
movement, non-smooth motion or
unusual noises should be immediately
reported to your service provider.
Always use a hand rail when descending
stairs and at any other time if available.
The device is not suitable for extreme
sports, running or cycle racing, ice and
snow sports, extreme slopes and steps.
Any such activities undertaken are done
so completely at the users’ own risk.
Recreational cycling is acceptable.
Assembly, maintenance and repair of
the device must only be carried out by
a suitably qualied clinician.
The user should contact their clinician if
their condition changes.
Ensure only suitably retrotted vehicles
are used when driving. All persons are
required to observe their respective
driving laws when operating motor
vehicles.
To minimise the risk of slipping and
tripping, appropriate footwear that
ts securely onto the footshell must be
used at all times.
This warning symbol highlights important safety information which must be
followed carefully.
1 Description and Intended Purpose
2 Safety Information
938446PK3/1-0121

4
Principal parts:
• Carrier Assembly with Pyramid (aluminum/St. Stl./titanium)
• Heel & Toe Springs (e-carbon)
• Spring attachment screws (titanium/St. Stl.)
• Glide Sock (UHM PE)
• Foot shell (PU)
Heel Spring Screws
Heel
Spring
Toe spring
Screw
Carrier Assembly
Toe Spring
Pyramid
Glide
Sock
Foot
Shell
3 Construction
938446PK3/1-0121

5
Maintenance must be carried out by competent personnel.
We recommend a regular visual check at least annually. Signs of wear that may aect function
should be reported to their service provider (e.g. signicant wear or excessive discoloration from
long term exposure to UV).
Any changes in performance of this device must be reported to the practitioner.
Changes in performance may include:
• reduced energy return
• unusual noises
• excessive or reduced movement
The practitioner must also be informed of any changes in body weight and/or activity level.
Cleaning
Use a damp cloth and mild soap to clean outside surfaces, do not use aggressive cleansers.
This device comprises an e-carbon toe and independent heel spring.
Heel and toe springs are attached to the carrier using titanium and stainless steel screws.
The foot is wrapped in a UHM PE sock which is in turn surrounded by a PU foot shell.
Intended life
A local risk assessment should be carried out based upon activity and usage.
Lifting loads
User weight and activity is governed by the stated limits.
Load carrying by the user should be based on a local risk assessment.
Environment
This device is waterproof to a maximum depth of 1 meter.
Thoroughly rinse this device with fresh water after
use in abrasive environments such as those that
may contain sand or grit, for example, to prevent
wear or damage to moving parts.
Thoroughly rinse with fresh water after use in salt
or chlorinated water.
Foot products must be adequately nished to prevent water ingress into the foot shell where
possible. If water enters the foot shell, the limb should be inverted and dried before further use.
Exclusively for use between -15˚C and 50 ˚C (5 ˚F to 122 ˚F).
4 Function
5 Maintenance
6 Limitations on Use
938446PK3/1-0121
