BLK BOX 21-0109-0K User manual

OWNERS MANUAL & QUICK START GUIDE
COMPACT RACK DNA60
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
PRODUCT SPECIFICATION
PRODUCT WEIGHT
MAX USER WEIGHT
MAX TRAINING WEIGHT
DIMENSIONS
SAFE WORKING ZONE
-000kg
000kg
000kg
mm x mm x mm
-
-
-
21-0109-0K
-mm x mm x mm
#MADEINBELFAST

WARNING
xx
Nm
SPIRIT LEVEL
10MM MASONRY
DRILL BIT
TOOLS REQUIRED
17MM SPANNER X2
13MM SPANNER
HAMMER
HAMMER DRILL VACUUM STEP LADDER
PARTS & ATTACHMENTS
No. Name SKU QTY
1 2.4 UPRIGHT DNA60
WITH FEET
21-0036-0A 4
2 1.2 BRANDING BOX CM
DNA60
21-0017-0A 1
3 1.2 BOX CM DNA60 21-0013-0A 2
4 0.7 BOX CM DNA60 21-0036-0A 2
5 0.7 BOX & BAR CM
DNA60
21-0011-0A 2
6 MULTIGRIPS DNA60 21-0151-0A 1
7 M10X80 SLEEVE
ANCHOR
16-0031 12
8 M10X90 BOLT 10-0008 46
9 M10 FLAT WASHER 10-0019 104
10 M10 NYLOCK NUT 10-0024 46
11 J-HOOKS PAIR 16-0001 1
1
2
3
4
11
7
8
10 9
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.
#MADEINBELFAST
6
5

ASSEMBLY
x
8
x
4
1
BOLT 1QTY BRANDING BOX (21-0017-0A] AND 1QTY 1.2 BOX (21-0013-0A) BETWEEN 2QTY
UPRIGHTS (21-0036-0A) WITH BOLTS ASSEMBLY AS SHOWN. ENSURE LOGOS ON
BRANDING BOX (21-0017-0A) IS FACING FORWARD, LOGOS ON UPRIGHTS ARE
FACING OUTWARD AND ALL BOLTS FACING INWARDS.
10.0008
10.0019 x2
10.0024
10.0008
10.0019 x2
10.0024
#MADEINBELFAST

x
4
x
4
x
8
x
1
2
x
6
2
BOLT 1QTY 1.2 BOX (21-0013-0A) BETWEEN 2QTY UPRIGHTS (21-0036-0A) AND CONNECT TO
EXISTING ASSEMBLY USING 2QTY 0.7 BOX & BAR (21-0036-0A) AND 2QTY 0.7 BOX (21-0011-0A) WITH
BOLT ASSEMBLY AS SHOWN. BOLT 1QTY MULTIGRIPS (21-0151-0A) TO 1QTY 1.2 BOX (21-0013-0A)
WITH BOLT ASSEMBLY AS SHOWN ENSURE LOGO ON UPRIGHTS ARE FACING OUTWARD AND BOLTS
ARE FACING INWARD.
10.0008
10.0019 x2
10.0024
10.0008
10.0019 x2
10.0024
10.0008
10.0019 x2
10.0024
10.0008
10.0019 x2
10.0024
#MADEINBELFAST
10.0008
10.0019 x2
10.0024

xx
Nm
x34
x
4
x
8
3
TIGHTEN ALL BOLT ASSEMBLIES WITHIN THE CIRCLE TO SPECIFIED TORQUE. ENSURE ALL
UPRIGHTS ARE PLUMB. DRILL AND SECURE THE MIDDLE HOLE ON EACH UPRIGHT AS
SHOWN IN GUIDE. REMOVE ALL BOTTOM CROSSMEMBERS, DRILL AND SECURE
REMAINING HOLES ON UPRIGHTS AS SHOWN IN GUIDE. REATTACH THE BOTTOM
CROSSMEMBERS.
#MADEINBELFAST
10.0031
10.0019
10.0031
10.0019
xx
Nm
DRILL
HOLE
90MM
VACUUM
HAMMER IN
BOLT
TIGHTEN
SLEEVE ANCHOR
BOLT FITTING
-DRILL 10MM HOLE
THROUGH FLOOR
COVERING, 90MM
DEEP USING PLATE
AS A GUIDE.
-VACUUM OUT THE
DUST.
-HAMMER SLEEVE
ANCHOR DOWN
INTO THE HOLE.
-TIGHTEN SLEEVE
ANCHOR TO
SPECIFIED TORQUE
USING 13MM
SPANNER.

1:1 SCALE FASTENERS
FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
M10x80 SLEEVE ANCHOR
10-0031
M10x90 BOLT
10-0008
NYLOCK NUT
10-0024
M10 FLAT WASHER
10-0019
