BLK BOX 21-0130-0E User manual

45kg
OWNERS MANUAL & QUICK START GUIDE
WALL MOUNTED COMPACT 1 BAY GOLIATH
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
PRODUCT SPECIFICATION
1200mm x 2408mm x 760mm
21-0130-0E
2700mm x 3272mm x 1960mm
#MADEINBELFAST
PRODUCT WEIGHT
MAX USER WEIGHT
MAX USER
MAX TRAINING WEIGHT
DIMENSIONS
SAFE WORKING ZONE
-125kg
300kg
-
-
-
-
1
-

WARNING
SPIRIT LEVEL
10MM MASONRY
DRILL BIT
TOOLS REQUIRED
17MM SPANNER X2
13MM SPANNER
HAMMER
HAMMER DRILL VACUUM STEP LADDER
PARTS & ATTACHMENTS
No. Name SKU QTY
1 2.4 UPRIGHT DNA60
WITH FEET
21-0036-0A 2
2 0.7 SINGLE BAR WM
DNA60
21-0032-0B 2
3 1.2 SINGLE BAR CM
DNA60
21-0015-0A 1
4 J-HOOKS PAIR 16-0001 1
5 M10X80 SLEEVE
ANCHOR
10-0031 6
6 M10X90 BOLT 10-0008 10
7 M10 NYLOCK NUT 10-0024 16
8 M10 FLAT WASHER 10-0019 10
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.
#MADEINBELFAST
1
2
3
4
5
6
87
xx
Nm

x
1
0
ASSEMBLY
1
BOLT 1QTY 1.2 SINGLE BAR CM (21-0015-0A) BETWEEN 2QTY UPRIGHTS (21-0036-0A)
AND 2QTY 0.7 SINGLE BAR WM (21-0032-0B) WITH BOLTS ASSEMBLY AS SHOWN.
LOGO ON UPRIGHTS ARE FACING OUTWARD AND ALL BOLTS FACING INWARDS.
#MADEINBELFAST
10.0008
10.0019 x2
10.0024

x
8
x
6
30
Nm
x10
DRILL HOLE VACUUM
90MM
2
TIGHTEN ALL BOLT ASSEMBLIES WITHIN THE CIRCLE TO THE SPECIFIED TORQUE . ENSURE
UPRIGHTS ARE PLUMB AND ALL SINGLE BAR ARE LEVEL. DRILL AND SECURE UPRIGHTS
AND 1.2 SINGLE BAR WM (21-0032-0B) AS SHOWN IN GUIDE.
#MADEINBELFAST
10.0031
10.0019
10.0031
10.0019
HAMMER IN
BOLT TIGHTEN
SLEEVE ANCHOR BOLT FITTING
-HAMMER SLEEVE ANCHOR INTO THE HOLE.
-TIGHTEN SLEEVE ANCHOR TO SPECIFIED TORQUE
USING 13MM SPANNER.
-DRILL 10MM HOLE, 90MM
DEEP USING PLATE AS
A GUIDE.
-VACUUM OUT THE DUST.
SLEEVE ANCHOR BOLT FITTING
30
Nm

#MADEINBELFAST
1:1 SCALE FASTENERS
FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
M10x80 SLEEVE ANCHOR
10-0031
M10x90 BOLT
10-0008
NYLOCK NUT
10-0024
M10 FLAT WASHER
10-0019
