Bradley Terrazzo WF2613 User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX [phone]
bradleycorp.com
Installation
WF2613
Terrazzo®54" Classic Corner Washfountain
with Infrared Control
215-1451 Rev. F; ECN 13-00-001
© 2013 Bradley
Page 1 of 22 3/5/2013
Table of Contents
Pre-Installation Information ........................2
Corner Washfountain Dimensions ...................3
Rough-In Specifications........................ 4–5
Installing the Drain...............................6
Assembling Pedestal .............................6
Anchoring Pedestal ..............................7
Installing Drain Spud in Bowl.......................7
Installing Supplies w/ Optional Soap Dispenser ......8–9
Valve Connections for Infrared ....................10
Electrical Connections for Infrared .................11
Adjust the Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning and Maintenance .......................13
Soap Valve Parts List and Maintenance ..........14–15
Sprayhead Parts List and Troubleshooting ...........16
Infrared Troubleshooting .........................17
Solenoid Valve Troubleshooting....................18
Stop, Strainer and Check Valve Parts List............19
Check Valve Troubleshooting......................19
Valve Assembly Parts ........................20–21
Thermostatic Mixing Valve Troubleshooting...........22

WF2613 Installation
23/5/2013 Bradley • 215-1451 Rev. F; ECN 13-00-001
Supplies Required by Installer
• (6) lag bolts, screws or other fasteners to anchor washfountain pedestal to floor.
• 1" hot and cold water supply lines and fittings
• Reducing fittings and 1/2" nominal copper tubing supply lines for types with supplies from above
• 2" drain lines and fittings
• Standard P-trap (special vented trap supplied for B and H type)
• Pipe sealant and plumber’s putty
• 1-1/2" vent pipe on types vented through washfountain column
• 110 VAC GFI power source for 110/24 VAC UL Class II transformer supplied
• OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit. This feature prevents accidental
water delivery during regular maintenance and service.
Supply lines for one or two washfountains should be 1"; for three washfountains 1-1/4"; for more than three washfountains
pipe size should increase proportionally. Vent pipe to be 1-1/2" on models vented through washfountain.
Pre-Installation Information
Terrazzo Material
Terrazzo is a mosaic-looking natural stone and concrete material polished to a high gloss and sealed with clear polyurethane
resin for long lasting beauty. Terrazzo is precast and composed of 85% stone and 15% binder with steel reinforcing rods cast into
the bowl.
Adaptive Infrared
The sprayhead is controlled by a solenoid valve, allowing the user to activate a flow of water. The Infrared sensor will take a few
minutes to adapt to its environment when the unit is powered up.
IMPORTANT!
Read this entire installation manual to ensure proper installation. When finished with the
installation, file this manual with the owner or maintenance department.
Separate parts from packaging and make sure all parts are accounted for before discarding
any packaging material. If any parts are missing, do not begin installation until you obtain
the missing parts.
Make sure that all water supply lines have been flushed and then completely turned off
before beginning installation. Debris in supply lines can cause valves to malfunction.
Product warranties may be found under “Product” on our web site
at www.bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
•
•
•
•

Installation WF2613
Bradley • 215-1451 Rev. F; ECN 13-00-001 3/5/2013 3
Corner Washfountain Dimensions
Length of Tie Pipe Required for Vent Through Washfountain Column
E
A
B
C
F
D
G
K
J
H
ADJUST TO TOWEL DISPENSER
MOUNTING HOLES
6" (152)
L
Approximate Dimensions in Inches
Material Size A B C D E F G H J K L
Terrazzo 54 19* 29-1/4* 39-1/8* 42-5/8* 36-1/4* 51-1/8* 59-1/2 26 28 37-1/4 10-1/4
Approximate Dimensions in Millimeters (mm)
Material Size A B C D E F G H J K L
Terrazzo 1372 483* 743* 994 1083 921 1299 1511 660 711 946 260
Type Pipe Length
54" Less Soap Dispenser 21-1/2" (546mm)
54" With Soap Dispenser 30" (762mm)
54" Less Soap Dispenser With Towel Dispenser 55-1/2" (1410mm)
54" With Soap Dispenser With Towel Dispenser 48" (1219mm)
54" With Cube Adapter 32" (813mm)
54" With Cube Adapter With Towel Dispenser 50" (1270mm)
54" With Cube Adapter And Soap Dispenser 40" (1016mm)
* Subtract 4" from dimensions for juvenile height.
* Subtract 102mm from dimensions for juvenile height.
Drain must be connected with 2" schedule 40 welded wrought iron pipe, minimum, to provide lower
support for this installation. Vent or support pipe must be of the same material in 1-1/2".

WF2613 Installation
43/5/2013 Bradley • 215-1451 Rev. F; ECN 13-00-001
Rough-In Specifications
Type A
Off-line vent with supplies from below
12-3/4"
(324)
12-3/4"
(324)
1" NPT
Supplies
Thru Wall
(Optional)
Supplies
Thru Wall Trap For Wall
Outlet Only
Trap For Wall
Outlet Only
Drain
Thru Wall
Drain
Thru Wall
Clearance Hole
Clearance Hole
Supplies and
Drain Thru Floor,
Trap Located
Below Floor
Drain Thru Floor
Trap Located
Below Floor
2" NPT Drain
Thru Wall (Stub
Out to Suit Trap
Dimension)
(Optional)
2" NPT Drain
Thru Wall (Stub
Out to Suit Trap
Dimension)
(Optional)
1" NPT Supplies Thru
Floor (Stub Up 2-1/2"
(64) Above Floor)
1" NPT Supplies From Above Must Reduce
to 1/2" Nominal Copper Tubing on These
Centers To Pass Thru Wasfountain
Cold
Right Wall
Right Wall
Left Wall
Left Wall
Left Wall
Left Wall
Hot
Tr a p
18-1/2"
(470)
7-1/4"
(184)
8-3/8"
(213)
18-1/2" (470) 2" NPT Drain Thru
Floor (Optional) Stub
Up 3" (76) Above FLoor
2" NPT Drain Thru
Floor (Optional) Stub
Up 3" (76) Above FLoor
10"
(254)
10"
(254)
10"
(254)
Tr a p
Floor
Floor
10"
(254)
4"
(102)
4"
(102)
A
A
B
8-3/8"
(213)
8-1/2"
(216)
7-1/4"
(184)
9-3/4"
(248)
54" (1372)
bowl
54" (1372)
bowl
Center of
Washfountain
Center of
Washfountain
Type O
Off-line vent with supplies from above
UPC and IPC restrict the vertical distance from the
fixture outlet to the trap weir to not more than 24".
Check state and local codes for variances.
Top View
Top View
Side
View
Side
View
Notes For All Models:
• All pipes and fittings not furnished by Bradley are shown in broken lines.
• Supply lines for one to two washfountains should be 1"; for three washfountains 1-1/4"; for more than three
washfountains, pipe sizes should be increased proportionately.
• Overhead supplies must be reduced to 1/2" copper tube to pass through support tube.
• Check valve inlets are 1/2" NPT.
• Dimensions shown in parentheses are millimeters.
Dim Right Wall Left Wall
Std. Ht. Juv. Ht. Std. Ht. Juv. Ht.
A11-1/4" to 13-1/4"
(286mm to 337mm)
9-1/4" to 10-1/4"
(235mm to 260mm)
6" to 11"
(152mm to 279mm)
6" to 8-1/2"
(152mm to 216mm)
B12" (305mm) 8-1/4" (210mm) 12" (305mm) 8-1/4" (210mm)
Use this range of heights
when hook-up is made with
a coupling and nipple (2"
drain through wall must
not interfere with diagonal
frame member on pedestal).
Cold
Hot
4-1/2"
(114)

Installation WF2613
Bradley • 215-1451 Rev. F; ECN 13-00-001 3/5/2013 5
Rough-In Specifications
Type B
Centrally rising vent with supplies from above
12-3/4"
(324)
1" NPT Supplies From Above
Must Reduce to 1/2" Nominal
Copper Tubing on These Centers
To Pass Thru Wasfountain
Right Wall
Right Wall Right Wall
Left Wall
Left Wall
Left Wall
10"
(254)
10"
(254)
10"
(254)
Vent
Vent
Floor
Floor
Drain Thru Floor
10"
(254)
A
8-1/2"
(216)
7-1/4"
(184)
9-3/4"
(248)
54" (1372)
bowl
54" (1372)
bowl
1-1/2" NPT Vent
to Ceiling
1-1/2"
NPT Vent
to Ceiling
Type O
Centrally rising vent with supplies from below
Top View
Top View
Side
View Side
View
Notes For All Models:
• All pipes and fittings not furnished by Bradley are shown in broken lines.
• Supply lines for one to two washfountains should be 1"; for three washfountains 1-1/4"; for more than three
washfountains, pipe sizes should be increased proportionately.
• Overhead supplies must be reduced to 1/2" copper tube to pass through support tube.
• Check valve inlets are 1/2" NPT.
• Dimensions shown in parentheses are millimeters.
• For Maximum rigidity of sprayheads/support tube assembly, use 1-1/2" NPT galvanized pipe for vent. Use of plastic or
copper for vent is not recommended.
Dim Right Wall Left Wall
Std. Ht. Juv. Ht. Std. Ht. Juv. Ht.
A11-1/4" to 13-1/4"
(286mm to 337mm)
9-1/4" to 10-1/4"
(235mm to 260mm)
6" to 11"
(152mm to 279mm)
6" to 8-1/2"
(152mm to 216mm)
Use this range of heights
when hook-up is made with
a coupling and nipple (2"
drain through wall must
not interfere with diagonal
frame member on pedestal).
Cold
Cold
Hot
Hot
2" NPT Drain
Stub Up 3" (76)
Above FLoor
1" NPT Supplies Thru
Floor (Optional)(Stub Up
2-1/2" (64) Above Floor)
2" NPT Drain Thru
Floor (Stub Up3"
(76) Above Floor)
12-3/4"
(324)
18-1/2" (470)
1" NPT
Supplies
Thru Wall
Supplies
Thru Wall
Drain
Thru Wall
Supplies
Thru Floor Supplies
Thru Floor
18-1/2"
(470)
7-1/4"
(184)
4-1/2"
(114)
8-3/8"
(213)
8-3/8"
(213)
1" NPT Supplies
Thru Wall (Optional)

WF2613 Installation
63/5/2013 Bradley • 215-1451 Rev. F; ECN 13-00-001
1Installing the Drain
ARough in supply and drain piping
as required for your installation.
AAssemble the legs and scuff base panels with the
5/16" carriage bolts and nuts provided
BAssemble the drain to the
dimension shown below
BAttach the pedestal frame members, the rear support
members and the rear legs with the 5/16" stove bolts
and nuts provided.
When an Infrared control is ordered, a plug-in
location for the 24 VAC transformer is required.
Compliance/conformity to local codes and
ordinances is the responsibility of the installer.
All piping shown in dotted lines
to be supplied by installer.
2Assembling the Pedestal
Drain Thru Floor
(Optional)
Wall Bracket
(140-146 LH - Left Hand)
(140-146 RH - Right Hand)
Rear Leg
(193-006 Std. Ht.)
(193-006A Juv. Ht. )
Lower Support
(194-041)
Upper Support (194-042)
Diagonal Support
(194-043 Std. Ht.)
(194-043A Std. Ht. )
5/16" Carriage Bolt
(160-060A)
Scuff Base End
(185-023 ALH - Left Hand)
(185-023 ARH - Right Hand)
Scuff Base
(185-015A)
Frame Member
(194-005)
Pedestal Leg
(193-002 Std. Ht.)
(193-002B Juv. Ht.)
12-3/4"
(324) 7-1/4"
(184)
9"
(229)
18-5/8" (473) Std.
14-5/8" (371) Juv.
7-1/4"
(184)
12-3/4"
(324)
Nut
(161-040)
5/16" Flat
Head Stove
Bolt (160-104)
Leg
Frame
Joint
Vented Trap
(111-024)
Type A and O Type B and H

Installation WF2613
Bradley • 215-1451 Rev. F; ECN 13-00-001 3/5/2013 7
WARNING! Use suitable lifting equipment to
position the bowl and pedestal
assembly. Handle wtih care!
Failure to do so could result in
serious personal injuries.
CAUTION! Bowl surface is very smooth.
Approximate weight of bowl is
73 pounds. Handle with Care!
3Anchoring Pedestal
APosition the pedestal assembly. Anchor
the pedestal assembly to the floor with
suitable anchors (supplied by installer).
BPlace the bowl on the pedestal using
suitable lifting equipment.
4Installing Drain Spud in Bowl
ALoosely attach the drain spud to the bowl
with the locknut and washer.
Seal between drain spud and drain hole with
plumber’s putty (supplied by installer).
For proper drainage, the bowl and the
pedestal must be level when they are
secured to the floor
Strainer
(S45-067)
Holes for Anchor
Bolts (Supplied
by Installer)
Spud
(112-015)
Washer
(142-068)
Drain Pre-Pack
(S45-273)
Bowl
Locknut
(161-021)
BTighten the spud and lock nut against bowl.
B Trap Option: Attach B trap to drain spud.
Tie Pipe Option: Attach tie pipe bracket to
drain spud.
CSecure the strainer to drain spud with screws
provided.
DConnect spud (or B Trap or Tie Pipe Bracket)
to drain.

WF2613 Installation
83/5/2013 Bradley • 215-1451 Rev. F; ECN 13-00-001
5a Installing Supplies with Optional Soap Dispenser for
A/O drain units
A
B
Install hemmed end (not sharp end) of
support tube (welded seam toward wall)
with gasket onto bowl.
Install restraining bracket on the support
tube above the backsplash. Use suitable
anchors to attach to wall.
C
Connect 1/2" supply tubing to sprayhead.
• Using a sharp knife, cut tubing squarely
and remove any burrs. DO NOT pinch
or crush end of tubing.
• Loosen nut on fitting. Moisten end of
tube and push into fitting until it is firmly
seated. Tighten nut to secure tube
to fitting (make sure nut is securely
tightened).
• If connector leaks, reseat tubing
according to above procedure.
If leaking persists, replace male
connector, or call your Bradley
representative for assistance.
D
E
F
G
Place sprayhead with 1/2" tubing onto
support tube. Run tubing down through
support tube.
Assemble the lower tie rod (the longer
threaded rod), upper tie bar (notched at
corners), lower tie bar, tie rod nut, and
coupling nut, then attach the 4-1/4" tie rod
to coupling nut. Make sure upper tie rod is
postioned as shown.
Place infrared module assembly on top of
sprayhead. Rotate until infrared module
locks in with tie bar. Drop two infrared
module wires down into the pedestal.
FOR UNITS WITH SOAP OPTION: Install
the spacer, soap dispenser and cover
using the coupling nut, third tie rod (8-5/8"
long) and second coupling nut. Secure with
acorn nut and socket head set screw.
FOR UNITS WITHOUT SOAP OPTION:
Secure infrared module cover and
dispenser cover with acorn nut and socket
head set screw.
Male 1/2"
Tube
Connector
269-626
Tubing
Dispenser
Cover
Upper Tie Bar
(159-009A)
Corner Restraining
Bracket (S70-061E)
(Fits Around Support Tube)
Type "O" Drain
(Supplies from Above)
Type "A" Drain
Acorn Nut (110-052A)
and Set Screw (160-093)
Sprayhead
Soap
Dispenser
Spacer
(113-155A)
IR Module Assembly
(S83-046)
Coupling Nut (110-051D)
Set Screw (160-208)
Sprayhead
(S05-054C)
Support Tube
(S57-005)
Support Tube
Gasket (125-011)
1/2" Supply
Tube
Valve
Assembly
Hot
Cold
Tie Rod Hex Nut (110-064)
Set Screw (160-208)
Lower Tie Bar (159-009)
Lower (Longest)
Tie Rod (176-008A)
Upper Tie Bar (159-009A)
(Notched at Corners)
4-1/4" Module Tie
Rod (176-118)
Soap
Dispenser
Lid
8-5/8" Soap Tie
Rod (176-010) Parts Shown
in Box are
for Unit
with Soap
Dispenser
Coupling Nut
(110-051D) Set
Screw (160-208)
Soap Dispenser
Gasket (124-066
Nut
For models with optional paper towel
dispensers, tie pipe assembly, or shroud,
see separate instruction sheets
Tubing

Installation WF2613
Bradley • 215-1451 Rev. F; ECN 13-00-001 3/5/2013 9
5b Installing Supplies with Optional Soap Dispenser for
B/H drain units
AInstall hemmed end (not sharp end)
of support tube (welded seam toward
intersection of walls) with gasket onto bowl.
B
Connect 1/2" supply tubing to sprayhead.
• Using a sharp knife, cut tubing squarely
and remove any burrs. DO NOT pinch
or crush end of tubing.
• Loosen nut on fitting. Moisten end of
tube and push into fitting until it is firmly
seated. Tighten nut to secure tube
to fitting (make sure nut is securely
tightened).
• If connector leaks, reseat tubing
according to above procedure.
If leaking persists, replace male
connector, or call your Bradley
representative for assistance.
C
E
G
D
F
Place sprayhead with 1/2" tubing onto support
tube. Run tubing down through support tube.
Insert the 1-1/2" vent pipe through the infrared
module, sprayhead, and support tube.
Connect vent pipe to vent through
ceiling with pipe union.
Place infrared module assembly on top of
sprayhead. Drop two infrared module wires
down into the pedestal.
FOR UNITS WITH SOAP OPTION: Place the
spacer, soap dispenser and cover in position
on top of IR module. Slide tie bar over 1-1/2"
vent pipe 1/2" below top of soap dispenser lid
and secure with the two cap screws included
with the tie bar. Slide the dispenser cover over
1-1/2" vent pipe and secure with the two cap
screws included with the tie bar.
FOR UNITS WITHOUT SOAP OPTION: Slide
tie bar over 1-1/2" vent pipe, 1/2" below top of
infrared module and secure with set screws.
Slide the dispenser cover over 1-1/2" vent pipe
and secure with the two cap screws included
with the tie bar.
Dispenser
Cover
Cap Screw
(160-108)
Supplies 1/2"
Nominal Copper
Tubing
Type "H" Drain
(Supplies from Below)
Type "B" Drain
Soap
Dispenser
Spacer
(113-155A)
Soap Dispenser
Gasket (124-066)
IR Module
Assembly
(S83-046)
Sprayhead
(S05-054C)
Support Tube
(S57-005)
Support Tube
Gasket (125-011)
Valve
Assembly
Hot Cold
Vented Trap
(111-024)
Upper Tie Bar Location
for Unit with Soap
(159-020)
Upper Tie Bar Location
for Unit without Soap
(159-020)
1-1/2" Vent Pipe
Soap
Dispenser Lid
Parts Shown
in Box are
for Unit
with Soap
Dispenser
For models with optional paper towel
dispensers, tie pipe assembly, or shroud,
see separate instruction sheets
Upper Tie Bar
(159-009A)
Corner Restraining
Bracket (S70-061E)
(Fits Around Support Tube)

WF2613 Installation
10 3/5/2013 Bradley • 215-1451 Rev. F; ECN 13-00-001
6Valve Connections for Infrared
A
Connect the stop-strainer-check valves,
mixing valve, volume control valve and
solenoid valve assembly to the supplies.
Use pipe sealant to seal threads.
B
C
D
For overhead supply lines, install 1/2"
nominal copper supply tubing by passing
the lines through the holes in the dispenser
cover and down through the support tube.
Using suitable fittings, install the
complete valve assembly to the supplies
at the approximate height indicated in
table to the right.
Connect the 1/2" supply tubing from the
sprayhead to the solenoid valve assembly.
Manual Mixing Valve (S01-038)
Optional Thermostatic
Mixing Valve (S01-525)
Distance to
Finished Floor
(Refer to Table
Above)
Supply
Tubing
Stop/Strainer/Check
Valve (S60-003)
Tailpiece
(129-007)
Washer
(124-001A)
Reducer
Nut (110-005)
Solenoid
Valve
Assembly
(S08-055)
Volume Control
Valve (S02-045)
Flush supply lines before making
connections.
Distance from 1/2" Supply to Finished Floor
Model Number Type A or O Type B or H
Standard Height 9" (229mm) 6-3/16" (157mm)
Juvenile Height 5-1/4" (133mm) 3-7/16" (87mm)
