Bradley S19-130BF User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
215-1263 Rev. F; ECN 17-05-039
© 2017 Bradley
Page 1 of 5 7/18/2017
S19-130BF
Plastic Showerhead
S19-130ABF
Plastic Showerhead with Stainless
Steel Shroud
Drench Shower Vertical Supply
Table of Contents
Pre-Installation Information .............................................................2
Supplies Required...........................................................................3
Assemble components....................................................................3
Connect water supply......................................................................3
Assembly of Components - S19-130BF..........................................4
Parts List .........................................................................................4
Assembly of Components - S19-130ABF .......................................5
Parts List .........................................................................................5

2
S19-130BF, S19-130ABF Installation
7/18/2017 Bradley • 215-1263 Rev. F; ECN 17-05-039
WARNING
Flush the water supply lines before beginning installation and after installation is complete. Test
the unit for leaks and adequate water flow. Main water supply to the eyewash should be “ON” at all
times. Provisions shall be made to prevent unauthorized shutoff.
CAUTION
Emergency equipment must be supplied with tepid water (60°F to 100°F/15.6°C to 37.8°C). Any
prolonged exposure to near freezing water affects the body's ability to maintain body temperature,
increasing the risk of hypothermia.
NOTICE
Before installing this product, ensure that there are adequate clearances around the product and
activation of the product does not interfere with other products or obstructions.
Avoid cleaners containing organic solvents, alcohols and hydrocarbons. Rinse with water after
cleaning.
IMPORTANT
The installation and location of all safety drench showers, eye and eye/face washes must comply
with the requirements of ANSI/ISEA Z358.1.
Read this installation manual completely to ensure proper installation, then file it with the owner or
maintenance department. Compliance and conformity to drain requirements and other local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any
packaging material. If any parts are missing, do not begin installation until you obtain the missing
parts.
The ANSI/ISEA Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley plumbed
emergency fixtures require a minimum of 30 PSI (0.21MPa) flowing pressure.
Self-closing spring-loaded valves are not UL classified to ANSI/ISEA Z358.1.
Weekly activation must be conducted on all plumbed emergency equipment to ensure a suitable
flushing fluid supply is present and any sediment build-up in the supply line is cleared. Emergency
equipment should be inspected monthly to address any maintenance issues ensuring the
equipment is in good operating condition and that there are no signs of wear.
Workers who may come in contact with potentially hazardous materials should be trained regarding
the placement and proper operation of emergency equipment per ANSI/ISEA Z358.1.
For questions regarding the operation or installation of this product, visit www.bradleycorp.com or
call 800-BRADLEY (272.3539).
Product warranties and parts information may also be found under ”Products” on our web site at
bradleycorp.com.

3
Installation S19-130BF, S19-130ABF
Bradley • 215-1263 Rev. F; ECN 17-05-039 7/18/2017
45"
(1142mm)
45"
(1142mm)
6-1/4"
(158mm)
9"
(229mm)
Ø 3-1/10"
(79mm)
8"
(201mm)
7'-0"
(2134mm)
to Floor
7-3/4"
(197mm)
9"
(229mm)
Ø 10-3/4"
(273mm)
9-3/8"
(238mm)
7'-0"
(2134mm)
to Floor
Supplies Required
• Teflon tape and pipe sealant
• Piping to 1" NPT water supply inlet
• Adequate supply pipe supports
• Minimum 4" (102 mm) drain to accommodate
30 gallons (115 liters) per minute discharge for
shower waste
• Sign-mounting hardware
Assemble components
1. Assemble components as shown on page 4
(S19-130BF or on page 5 (S19-130ABF.
2. Apply pipe sealant (supplied by installer) to all
male-threaded pipe joints.
3. Thread the jam nut onto the threaded end
of the pull rod. Thread the pull rod onto
the coupling and tighten the jam nut. The
triangular end of the pull rod must be in line
with the hook end (see page 4).
4. The bottom edge of the showerhead should be
7'-0" (2134 mm) from the floor.
Connect water supply
NOTICE! Do not rely on Bradley’s Drench Shower
to support supply piping.
1. Connect water supply piping to 1" NPT inlet
on unit (piping supplied by installer). Provide
adequate supports (supplied by installer)
for supply pipe using pipe hangers or other
means.
2. Mount the safety sign to the wall using sign-
mounting hardware supplied by installer.
S19-130BF
S19-130ABF
All dimensions assume standard thread
engagement. Variations in manufacturing allow
for +/- ¹⁄₈” (3mm) per threaded joint. To find
the tolerance of a dimension, add the number
of thread joints in between a dimension and
multiply it by ¹⁄₈” (3mm).

4
S19-130BF, S19-130ABF Installation
7/18/2017 Bradley • 215-1263 Rev. F; ECN 17-05-039
Assembly of Components - S19-130BF
P.O. Box 309, Menomonee Falls,WI 53051
R
TEST THIS UNIT EACH WEEK
Test-operate valve(s) each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich im Testbetrieb prüfen, bestätigt
durch Unterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1ST WÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnement des valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne va pas fait
un rapport immédiatement.
P.O. BOX 309, MENOMONEE FALLS, WI 53052-0309 USA
TEL: 1-800-BRADLEY FAX: [phone])
http://www.bradleycorp.com
114-050
54
ALIGN
HANDLE
PIECES
AS SHOWN
1.4
1.11
1.1
1
3
2
1.2
1.3
Parts List
1" NPT
Supply Inlet
NOTE: Use
teflon tape
only.
Item Part No. Qty. Description
1 S30-060 1 Stay-Open Ball Valve Assembly
1.1 S27-278 1 Ball Valve with Jam Nut
1.11 110-214 1 Jam Nut (only)
1.2 153-489 1 Adapter
1.3 124-048 1 Washer
1.4 128-202 1 Handle
Item Part No. Qty. Description
2 S90-365D 1 Pull Rod, 45"
2.1 161-026 1 Nut, 1/4"-20
3 S24-188 1 Plastic Showerhead Assembly
4 204-421 1 Emergency Inspection Tag
5 114-050 1 Safety Sign

5
Installation S19-130BF, S19-130ABF
Bradley • 215-1263 Rev. F; ECN 17-05-039 7/18/2017
Assembly of Components - S19-130ABF
Parts List
2
1
3
3.2
3.1
3.11
3.12
P.O. Box 309, Menomonee Falls,WI 53051
R
TEST THIS UNIT EACH WEEK
Test-operate valve(s) each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich im Testbetrieb prüfen, bestätigt
durch Unterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1ST WÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnement des valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne va pas fait
un rapport immédiatement.
P.O. BOX 309, MENOMONEE FALLS, WI 53052-0309 USA
TEL: 1-800-BRADLEY FAX: [phone])
http://www.bradleycorp.com
114-050
54
ALIGN
HANDLE
PIECES
AS SHOWN
1.4
1.11
1.1
1.2
1.3
1" NPT
Supply Inlet
NOTE: Use
teflon tape
only.
Item Part No. Qty. Description
1 S30-059 1 Stay-Open Ball Valve Assembly
1.1 S27-278 1 Ball Valve with Jam Nut
1.11 110-214 1 Jam Nut (only)
1.2 153-489 1 Adapter
1.3 124-048 1 Washer
1.4 128-202 1 Handle
2 S90-365D 1 Pull Rod, 45"
2.1 161-026 1 Nut, 1/4"-20
Item Part No. Qty. Description
3 S24-189 1 Stainless Steel Showerhead
Assy.
3.1 S24-193 1 Stainless Steel Shroud Kit
3.11 187-053 1 Showerhead Shell
3.12 154-147 1 Ring
3.2 S24-188 1 Plastic Showerhead Assembly
4 204-421 1 Emergency Tag
5 114-050 1 Safety Sign
