Bradley Express SS Series User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
SS-3N/AST/STD
SS-3N/AST-WH
Express®Lavatory
System - SS-Series
SS-3N/AST/STD/LSD-3
SS-3N/AST-WH/LSD-3
215-1494 Rev. G; ECN 17-08-026
© 2018 Bradley
Page 1 of 15 2/22/2018
Table of Contents
Pre-Installation Information ...............................2
Components ..........................................3
Supplies Required......................................4
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rough-Ins ............................................6
Install the Bowl ........................................7
Mount the Frame.......................................7
Connect the Supply - Hot and Cold Supply ..................8
Connect the Supply - Single Tempered Supply ...............8
Install the Drains .......................................9
Connect Supply and Tubing ..............................9
Push Button Assembly .................................10
Sprayhead Components ................................10
Adjust the Temperature .................................10
Cleaning and Maintenance for Terreon®. . . . . . . . . . . . . . . . . . . . 11
Cleaning and Maintenance for Stainless Steel ...............11
Brand Names ........................................11
Troubleshooting – Metering Air Valve ......................12
Thermostatic Mixing Valve Troubleshooting .................13
Stop Valve Troubleshooting ..............................14
Fill Soap Dispenser....................................15
Clean Soap Dispenser .................................15

SS-3N/AST/STD, SS-3N/AST/WH Installation
22/22/2018 Bradley • 215-1494 Rev. G; ECN 17-08-026
Special Note for Sprayhead/Bowl retrofit
to retrofit new SS-3N sprayhead onto existing SS-3 bowl
1½" (38mm)
Drill hole
Ø 1" (25mm) to
1½" (38mm).
Existing Hole
2¼" (57mm)
WARNING
Make sure that all water supply lines have been flushed and then completely turned off before beginning
installation. Debris in supply lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior to installation. Electrical
power MUST remain off until installation is complete. After installation is complete, turn on the water supply
first, then turn on the electrical power.
Installer's hardware must be appropriate for wall construction. Wall anchors must have a minimum pull-out
rating of 1,000 pounds.
NOTICE
Overtightening fasteners can damage the Terreon material. Use caution when tightening bowl and sprayhead
fasteners.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file this
manual with the owner or maintenance department. Compliance and conformity to local codes and ordinances
is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
Product warranties may be found under “Products” on our website at www.bradleycorp.com.

Installation SS-3N/AST/STD, SS-3N/AST/WH
Bradley • 215-1494 Rev. G; ECN 17-08-026 2/22/2018 3
Components Sprayhead Cover
(SS-3N-COVR-ONLY)
(Contact your local Bradley
Representative for part number.
Sprayhead Body
(33-3N-SPYD-ASSY)
Contact your local Bradley
Representative for part number.
Main Frame (S17-323)
Screw 10-24
(160-386)
Washer (142-002BJ)
Pedestal Panel
Coal (186-1454B)
Bowl
(33-3N-BOWL)
Contact your local Bradley
Representative for part number.
LockWasher (142-002BK)
Nut, 5/16-18 (161-036)
Scuff Base (S17-324) (Used with
Standard Height Frame Only)
Scuff Panel Fasteners (160-450)
Washers (142-002CA) (4) Places
Scuff Base Panel
Coal (185-033B)
Panel Fasteners (160-450)
Washers (142-002CA)
(8) Places
Bolt 5/16-18
(160-371)
#8-32 Screw
(160-319)
Strainer (P16-075)
Drain Plug (P16-072)
1/8" Rubber Washer (125-001DP)
Waste Shoe
(111-062)
Waste Tee
(111-063)
P-Trap (Polypropylene)
(269-1697)
Optional P-Trap
(Chrome-Plated Brass)
(S29-094)
Drain Assembly
Bowl Mounting
Hardware
1/4"-20x1/2"
Pan Head
Screw (qty 4)
(160-389)
1/4"-20
Washer
(qty 4)
(142-002DB)

SS-3N/AST/STD, SS-3N/AST/WH Installation
42/22/2018 Bradley • 215-1494 Rev. G; ECN 17-08-026
Supplies Required
• (8) 3/8" wall anchors, bolts and 1" min. O.D. washers to mount main frame and bowl to wall (minimum
pull-out rating of 1,000 lbs.)
• STD. HEIGHT ONLY: (2) 3/8" wall anchors, bolts and 1" min. O.D. washers to mount scuff base to wall
• 1/2" nominal copper tubing for hot and cold supplies and 1-1/2" NPT drain piping
• OPTIONAL: 240/208-volt or 277-volt electrical box for electric tankless water heater
SOAP
SOAP SOAP
SOAP
Top View
80" (2032)
Front View
Standard Frame
Front View
Wall-Hung Frame
8-5/8" (219)
30" (762)
8" (203)
51-1/4" (1302)
58" (1473)
64" (1626)
68-1/4" (1734)
8" (203)
68-1/4" (1734)
58" (1473)
64" (1626)
8" (203) Radius 10" (254) Radius
30" (762)
(mm)

Installation SS-3N/AST/STD, SS-3N/AST/WH
Bradley • 215-1494 Rev. G; ECN 17-08-026 2/22/2018 5
Dimensions - Side Views
TAS
TAS
Wall Hung Mounted
at Standard Height
Standard
Height
Wall Hung Mounted
at Juvenile Height
Ages: 6 through 12
Wall Hung Mounted
at TAS Height
Grades: 6 through 8 or 9
Wall Hung Mounted
at TAS Height
Grades: Pre-K through 5 or 6
21-1/8" (537)
38-1/2"
(978)
34"
(864)
30"
(762)
13-1/4"
(311)
11-1/2"
(292)
Scuff Base on
Standard Height
Only
3" (76)
8-5/8"
(219)
38-1/2"
(978)
34"
(864)
30"
(762)
8-5/8"
(219)
21-1/8" (537)
11-1/2"
(292)
13-1/4"
(311)
8-5/8"
(219)
21-1/8" (537)
11-1/2"
(292)
8-5/8"
(219)
21-1/8" (537)
11-1/2"
(292)
8-5/8"
(219)
21-1/8" (537)
11-1/2"
(292)
36-1/2"
(927)
32"
(813)
28"
(711)
11-1/4"
(286)
35-1/2"
(902)
31"
(787)
27"
(686)
10-1/4"
(260)
34-1/2"
(876) 30"
(762)
26"
(660)
9-1/4"
(235)
(mm)

SS-3N/AST/STD, SS-3N/AST/WH Installation
62/22/2018 Bradley • 215-1494 Rev. G; ECN 17-08-026
CODE DESCRIPTION QTY.
A 3/8" Wall Anchors with a minimum pull-out force of 1,000 lbs. for Bowl 2
B 3/8" Wall Anchors with a minimum pull-out force of 1,000 lbs. for Mainframe 6
C3/8" Wall Anchors for Base Frame, Standard Frame option only, minimum pull-out force not
required 2
D1 1/2" nominal copper tubing for Cold Supply, stub-out 2" from wall 1
D2 1/2" nominal copper tubing for Hot or Tempered Supply, stub-out 2" from wall 1
E 1-1/2" NPT Drain, stub-out 2" from wall 2
F
On the bowl back, measure the distance between the ¾" bowl mounting holes. Divide this
measurement in half. Measure and mark this dimension on the wall to the left and the right
of the centerline. Install two 3/8" wall anchors with a minimum pull-out rating of 1,000 lbs
(supplied by installer) at locations marked.
2
RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS FOR
CODES A–E, H, C and W FIXTURE STYLE
34" None Standard Height
34" None Wall-Hung
32" Subtract 2" TAS, Grades 6 through 8 or 9
31" Subtract 3" Juvenile Height
30" Subtract 4" TAS, Pre-K through Grades 5 or 6
1Rough-Ins
28-3/4"
(730)
32"
(813)
15"
(381)
4"
(102)
Floor
2-3/4"
(70)
24"
(610)
34"
(864)
Rim Height
See Chart
Below
38-1/2"
(978)
24-3/8"
(619)
BB
BB
CC
E
F
B
D2
A
5-5/8"
(143)
B
38-1/2"
(978)
24-3/8"
(619)
8"
(203)
D1
F
A
3-1/2"
(89)

Installation SS-3N/AST/STD, SS-3N/AST/WH
Bradley • 215-1494 Rev. G; ECN 17-08-026 2/22/2018 7
Anchoring the frame to a wall that is not flat may cause the
frame to bend, making it difficult to reinstall the access panels.
If necessary, use shims to compensate for wall distortion.
2Mount the Frame
AUsing a T20 torx key, remove the
fasteners securing the access panel to
the main frame, and remove the panel.
B
Once you have positioned the frame
such that it is level and flat against the
wall or shimmed, mount the frame to
the wall at six places using 3/8" bolts
and 1" min. O.D. washers.
When mounting the standard height frame,
mount the scuff base to the wall at the
same time using two additional 3/8" bolts
and washers.
Scuff Panel
Standard Height
Frame Only
Scuff Base Frame
Standard Height
Only
3Install the Bowl
The sprayhead body has slotted holes for adjusting the fit-up with
the bowl and wall. For clarity, the scuff base frame and drain are
not shown. Turn the tailpiece down to its proper position before
installing the bowl.
AAttach the bowl to the frame using
the ¼-20 x ½" pan-head screws and
washers. Do not tighten screws.
B
Secure the
bowl to the wall
anchors with
two 3/8" bolts
and washers. Do
not overtighten.
CTighten the pan-head
screws. Do not overtighten.

SS-3N/AST/STD, SS-3N/AST/WH Installation
82/22/2018 Bradley • 215-1494 Rev. G; ECN 17-08-026
45
45
45
The letter “H” on the Navigator
Mixing Valve indicates hot water
supply inlet.
45
4a Connect the Supply - Hot and Cold Supply
C
Connect one end of each hose to the
Navigator valve (one on the hot side,
one on the cold side).
Connect the other swivel end to the
stop valves.
A
Loosen but do not remove the
two mounting screws holding the
valve bracket to the frame.
Slide the valve bracket up and
lift it from the frame. BAttach the stops to the hot and cold
water wall stub-outs.
C
Connect one end of flexible hose
to the tempered line adapter.
Connect the other swivel end to
the stop valve.
4b Connect the Supply - Single Tempered Supply
A
Loosen but do not remove the
two mounting screws holding the
valve bracket to the frame.
Slide the valve bracket up and
lift it from the frame.
BAttach the stop to the tempered wall
stub-out.

Installation SS-3N/AST/STD, SS-3N/AST/WH
Bradley • 215-1494 Rev. G; ECN 17-08-026 2/22/2018 9
To Drain
Stub-Out
5Install the Drains
Red Supply
Tubing
Green Supply
Tubing
Black Supply
Tubing
6Connect Supply and Tubing
A
Loosen the compression nuts.
Push the sprayhead supply tubes firmly
into the tube connectors until they are
fully seated.
Tighten the compression nuts by hand.
B
Loosen the compression nuts.
Push the matching color 1/8" tubes
firmly into the tube connectors until
they are fully seated.
Tighten the compression nuts by hand.

SS-3N/AST/STD, SS-3N/AST/WH Installation
10 2/22/2018 Bradley • 215-1494 Rev. G; ECN 17-08-026
Sprayhead Components
Push Button Assembly
To access push button assembly: Remove the Phillips-head screws located in the bottom of the sprayhead body and lift the
Terreon cover/shelf off.
To reinstall sprayhead cover/shelf: Position the cover/shelf on the sprayhead body and secure it to the sprayhead body using
the screws provided.
H
C
This valve is NOT factory preset. Upon installation, the temperature of this
valve must be checked and adjusted to ensure delivery of a safe water
temperature. Water in excess of 110°F (43°C) may cause scalding.
¼" Tube Connector
(169-890)
Actuator Body ASM
(S39-802)
Spring (135-065)
U-Cup (125-099)
Piston (119-227A)
Duckbill (198-010)
Bracket, SSN Push
Button (140-956)
Nut, ½" - 14 NPSM
(110-115)
Push Button
(S08-324)
#10 Screw
(160-353)
Aerator (S05-180)
7Adjust the Temperature
ALoosen the cap screw about ¼"
(4–6 turns) and lift up the cover
(do not remove).
B
Using the cover, turn the
cartridge gently until desired
water temperature is reached. Do
not turn past stops as this may
damage the unit. Push the cover
down and tighten the screw.
CReinstall the valve bracket. Turn on the water supply to the Express and check for
leaks. Push the operating buttons of each station until all the air is purged from
the lines and water is flowing smoothly. Reinstall the access panel.
