Bradley s19314 series User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
215-1684 Rev. U; ECN 18-05-037
© 2018 Bradley
Page 1 of 59 10/19/2018
S19314 Series
Halo™ Combination Drench Shower
and Eyewash or Eye/Face Wash
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

2
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
Table of Contents
Table of Contents..........................................................................2
Pre-Installation Information ................................................................ 3-4
Halo Pre-Configured Models ................................................................5-7
Halo Configurator..........................................................................8
Dimensions ..............................................................................9
Installation Instructions .................................................................10–11
Service Parts — Bowl and Hub...........................................................12–13
Service Parts — Eyewash, Eye/Face Wash and Bowl Covers ...................................14–16
Service Parts — Base and Drain.............................................................17
Service Parts — Drench Shower..........................................................18–20
Service Parts — Optional Accessories ........................................................21
Avant l’installation ..................................................................... 22-23
Modèles préconfigurés Halo ..............................................................24-26
Configuration du produit ...................................................................27
Dimensions .............................................................................28
Instructions d'installation ................................................................29–31
Pièces de remplacement — Récepteur et moyeu.............................................32–33
Pièces de remplacement — Douche oculaire, Douche oculaire/faciale et couvercle anti-poussières .....34–35
Pièces de remplacement — Bride et drain .....................................................36
Pièces de remplacement — Douche d'urgence ..............................................37–39
Pièces de remplacement — Accessoires en option ..............................................40
Información previa a la instalación. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41-42
Modelos preconfigurados Halo ............................................................43-45
Configuración del producto .................................................................46
Dimensiones ............................................................................47
Instrucciones de instalación. .............................................................48–49
Piezas de repuesto — Receptor y buje.....................................................50–51
Piezas de repuesto — Lavaojos, lavaojos/rostro y cubierta contrapolvo ...........................52–54
Piezas de repuesto — Base y drenaje ........................................................55
Piezas de repuesto — Ducha de aspersión .................................................56–58
Piezas de repuesto — Accesorios opcionales ..................................................59
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

3
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
WARNING
Flush the water supply lines before beginning installation and after installation is complete. Test
the unit for leaks and adequate water flow. Main water supply to the eyewash should be “ON” at all
times. Provisions shall be made to prevent unauthorized shutoff.
CAUTION
Emergency equipment must be supplied with tepid water (60°F to 100°F/15.6°C to 37.8°C). Any
prolonged exposure to near freezing water affects the body's ability to maintain body temperature,
increasing the risk of hypothermia.
NOTICE
Before installing this product, ensure that there are adequate clearances around the product and
activation of the product does not interfere with other products or obstructions.
Avoid cleaners containing organic solvents, alcohols and hydrocarbons. Rinse with water after
cleaning.
IMPORTANT
The installation and location of all safety drench showers, eye and eye/face washes must comply
with the requirements of ANSI/ISEA Z358.1.
Read this installation manual completely to ensure proper installation, then file it with the owner or
maintenance department. Compliance and conformity to drain requirements and other local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any
packaging material. If any parts are missing, do not begin installation until you obtain the missing
parts.
The ANSI/ISEA Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley plumbed
emergency fixtures require a minimum of 30 PSI (0.21MPa) flowing pressure.
Self-closing spring-loaded valves are not UL classified to ANSI/ISEA Z358.1.
Weekly activation must be conducted on all plumbed emergency equipment to ensure a suitable
flushing fluid supply is present and any sediment build-up in the supply line is cleared. Emergency
equipment should be inspected monthly to address any maintenance issues ensuring the
equipment is in good operating condition and that there are no signs of wear.
Workers who may come in contact with potentially hazardous materials should be trained regarding
the placement and proper operation of emergency equipment per ANSI/ISEA Z358.1.
For questions regarding the operation or installation of this product, visit www.bradleycorp.com or
call 800-BRADLEY (272.3539).
Product warranties and parts information may also be found under ”Products” on our web site at
bradleycorp.com.
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

4
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
Supplies Required:
• (3)
3⁄8" floor anchors and bolts
• Teflon tape and pipe sealant
• 30 PSI (2.0 bar) min/90 PSI (6.1 bar) max flow pressure
• 125 PSI (8.6 bar) max static pressure
• Piping to 1¼" NPT (BSPP) water supply inlet (30–90 psi [2.0-6.1 bar])
• Piping to 1¼" NPT drain outlet on unit (if included with unit)
• Adequate supply pipe supports
• Provisions to dispose of shower waste water (minimum 30 gallons [115 liters]) should be made (minimum 4" [102mm] drain.
• OPTIONAL: sign-mounting hardware
Local codes may require the installation of a backflow prevention valve to complete proper installation. Compliance with
local codes is the responsibility of the installer. Valve must be tested annually to verify that it is functioning properly.
Backflow prevention valves are not included with the fixture and may be supplied by the contractor or purchased from
Bradley Corporation.
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

5
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
Halo Pre-Configured Models
Halo Model
Number Description UL certified to ANSI/ISEA
Eyewashes
 S19314EW Halo Eyewash, plastic showerhead & bowl X
S19314P Halo Eyewash, plastic showerhead & bowl w/ hose spray X
S19314SB Halo Eyewash, plastic showerhead, stainless steel bowl X
S19314LL Halo Eyewash, plastic showerhead, stainless steel bowl, hand/foot activated X
S19314F Halo Eyewash, plastic showerhead w/ stainless steel shroud & bowl X
S19314UU Halo Eyewash, plastic showerhead w/ stainless steel shroud & bowl, hand/foot operated eyewash X
Eyewashes with Dust Cover
S19314PDC Halo Eyewash, plastic showerhead & bowl w/ dust cover X
S19314DC Halo Eyewash, plastic showerhead, stainless steel bowl & hinged dust cover X
Eye-Face Washes
S19314FW Halo Eye/face wash, plastic showerhead & bowl X
S19314SBFW Halo Eye/face wash, plastic showerhead, stainless steel bowl X
S19314AC Halo Eye/face wash, plastic showerhead, stainless steel bowl, hand/foot operated eyewash X
S19314TT Halo Eye/face wash, plastic showerhead w/ stainless steel shroud & bowl X
S19314SPR Halo Eye/face wash, stainless steel showerhead & bowl, hand/foot operated eyewash X
S19314BFPB Halo Eye/face wash, barrier-free, plastic showerhead & bowl X
S19314BF Halo Eye/face wash, barrier-free, plastic showerhead, stainless steel bowl X
Eye-Face Washes with Dust Covers
S19314PDCFW Halo Eye/face wash, plastic showerhead & bowl w/ dust cover X
S19314DCFW Halo Eye/face wash, plastic showerhead, stainless steel bowl & hinged dust cover X
S19314DCBF Halo Eye/face wash, barrier-free, plastic showerhead, stainless steel bowl w/ dust cove X
Eye-Face Washes without Eyewash Bowl
S19314GG Halo Eye/face wash, plastic showerhead, no bowl X
All Stainless Steel Eye-Face Wash
S19314BFSS Halo stainless steel eye/face wash and showerhead, barrier free X
S19314FSS Halo stainless steel eye/face wash and showerhead X
S19314SC Halo stainless steel eye/face wash, bowl, cover and showerhead X
S19314SS Halo stainless steel eye/face wash and showerhead with foot activation X
S19314SS16 Halo 316 stainless steel eye/face wash and showerhead with foot activation X
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

6
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
Halo Pre-Configured Models
Halo Model Number Description
IAPMO Oceana
certified to
AS4775 & AS4020
Eyewashes
 S19314EWZ Halo Eyewash, plastic showerhead & bowl
 S19314EWZS Halo Eyewash, plastic showerhead & bowl, stainless steel piping X
 S19314SBZ Halo Eyewash, plastic showerhead, stainless steel bowl
 S19314SBZS Halo Eyewash, plastic showerhead, stainless steel bowl, stainless steel piping X
 S19314LLZ Halo Eyewash, plastic showerhead, stainless steel bowl, hand/foot activated
S19314LLZS
Halo Eyewash, plastic showerhead, stainless steel bowl, hand/foot activated, stainless steel piping X
 S19314FZ Halo Eyewash, plastic showerhead w/ stainless steel shroud & bowl
 S19314FZS Halo Eyewash, plastic showerhead w/ stainless steel shroud & bowl, stainless steel piping X
 S19314UUZ
Halo Eyewash, plastic showerhead w/ stainless steel shroud & bowl, hand/foot operated eyewash
 S19314UUZS Halo Eyewash, plastic showerhead w/ stainless steel shroud & bowl, hand/foot operated
eyewash, stainless steel piping
X
 S19314PZ Halo Eyewash, plastic showerhead & bowl w/hose spray
Eyewashes with Dust Cover
S19314PDCZ Halo Eyewash, plastic showerhead & bowl w/ dust cover
S19314PDCZS Halo Eyewash, plastic showerhead & bowl w/ dust cover, stainless steel piping X
S19314DCZ Halo Eyewash, plastic showerhead, stainless steel bowl & hinged dust cover
S19314DCZS
Halo Eyewash, plastic showerhead, stainless steel bowl & hinged dust cover, stainless steel piping X
Eye-Face Washes
S19314FWZ Halo Eye/face wash, plastic showerhead & bowl
S19314FWZS Halo Eye/face wash, plastic showerhead & bowl, stainless steel piping X
S19314SBFWZ Halo Eye/face wash, plastic showerhead, stainless steel bowl
S19314SBFWZS Halo Eye/face wash, plastic showerhead, stainless steel bowl, stainless steel piping X
S19314ACZ Halo Eye/face wash, plastic showerhead, stainless steel bowl, hand/foot operated eyewash
S19314ACZS Halo Eye/face wash, plastic showerhead, stainless steel bowl, hand/foot operated eyewash,
stainless steel piping
X
S19314TTZ Halo Eye/face wash, plastic showerhead w/ stainless steel shroud & bowl
S19314TTZS
Halo Eye/face wash, plastic showerhead w/ stainless steel shroud & bowl, stainless steel piping X
S19314SPRZ Halo Eye/face wash, stainless steel showerhead & bowl, hand/foot operated eyewash
S19314SPRZS Halo Eye/face wash, stainless steel showerhead & bowl, hand/foot operated eyewash,
stainless steel piping
X
S19314BFPBZ Halo Eye/face wash, barrier-free, plastic showerhead & bowl
S19314BFPBZS Halo Eye/face wash, barrier-free, plastic showerhead & bowl, stainless steel piping X
S19314BFZ Halo Eye/face wash, barrier-free, plastic showerhead, stainless steel bowl
S19314BFZS
Halo Eye/face wash, barrier-free, plastic showerhead, stainless steel bowl, stainless steel piping X
All models with AS4775, AS/NZS 4020 Certification include BSPP threading.
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

7
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
Halo Model Number Description
IAPMO Oceana
certified to
AS4775 & AS4020
Eye-Face Washes with Dust Cover
S19314PDCFWZ Halo Eye/face wash, plastic showerhead & bowl w/ hinged dust cover
S19314PDCFWZS Halo Eye/face wash, plastic showerhead & bowl w/ hinged dust cover, stainless steel piping X
S19314DCFWZ Halo Eye/face wash, plastic showerhead, stainless steel bowl & hinged dust cover
S19314DCFWZS Halo Eye/face wash, plastic showerhead, stainless steel bowl & hinged dust cover, stainless
steel piping
X
S19314DCBFZ Halo Eye/face wash, barrier-free, plastic showerhead, stainless steel bowl w/ hinged dust cover
S19314DCBFZS Halo Eye/face wash, barrier-free, plastic showerhead, stainless steel bowl w/ hinged dust
cover, stainless steel piping
X
Eye-Face Washes without Eyewash Bowl
S19314GGZ Halo Eye/face wash, plastic showerhead, no bowl
S19314GGZS
Halo Eye/face wash, plastic showerhead, no bowl, stainless steel piping X
All Stainless Steel Eye/Face Wash
S19314BFSSZ Halo stainless steel eye/face wash & showerhead, barrier free X
S19314FSSZ
Halo stainless steel eye/face wash & showerhead X
S19314SCZ
Halo stainless steel eye/face wash, bowl, cover & showerhead X
S19314SSZ
Halo stainless steel eye/face wash and showerhead with hand/foot activation X
S19314SS16Z
Halo 316 stainless steel eye/face wash and showerhead with hand/foot activation X
Halo Pre-Configured Models
All models with AS4775, AS/NZS 4020 Certification include BSPP threading.
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

8
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
Standard Selections (Must select one from each category)
Configuration
¨A
¨B
¨C
¨0
6" Drain Height, B arrier Free
24" Drain Height
24" Drain Height, B
arrier Free
6" Drain Height, Standard
Pipe Material
¨A
¨B
¨C
¨D
¨F
¨G
¨H
¨J
NPT, Yellow BradTect Galvanized Steel
NPT, All 304 Stainless Steel
NPT, All 316 Stainless Steel *
NPT, Chrome-Plated
BSPP, Yellow BradTect Galvanized Steel ‡
BSPP, All 304 Stainless Steel ‡
BSPP, All 316 Stainless Steel‡
BSPP, Chrome-Plated ‡
Ball Valve
¨1
¨2
¨3
Stay-Open Shower and Eyewash, Chrome-Plated Brass
Stay-Open Shower and Eyewash, 316 SS
Self-Closing Shower and Stay-Open Eyewash, Chrome-Plated Brass **
Showerhead
¨A
¨B
¨C
¨D
¨E
Plastic Showerhead
Plastic Showerhead with Plastic Shroud
Plastic Showerhead with Stainless Steel Shroud
304 SS High Performance Showerhead
316 SS High Performance Showerhead
Eyewash – Eye/Face Wash
¨A
¨B
¨D
¨E
¨F
¨G
¨H
¨J
Halo Eyewash
Halo Eye/Face Wash
Halo Eyewash, 304 SS Yoke
Halo Eye/Face Wash, 304 SS Yoke
304 SS Halo Eye/Face Wash, 304 SS Yoke†
Halo Eyewash, 316 SS Yoke
Halo Eye/Face Wash, 316 SS Yoke
316 SS Halo Eye/Face Wash, 316 SS Yoke†
* Not available with barrier-free configurations.
** Self-closing valves are not ANSI/ISEA Z358.1 compliant.
‡ Not available in the U.S.
† Must select stainless steel pipe and ball valve when stainless
steel eye/face wash is required.
Model No. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S19314
How to Specify Model and Configurations
for Bradley Halo Products: 3 1 4
3421 789
9
6. Bowl and Dust Cover
7. Activation
8. Drench Hose and Backflow Prevention
9. Freeze and Scald Protection
1. Configuration
2. Pipe Material
3. Ball Valve
4. Showerhead
5. Eyewash – Eye/Face Wash
1
S
5 6
Bowl and Dust Cover
¨A
¨B
¨D
¨E
¨F
¨G
¨H
¨J
¨0
Plastic Bowl, No Dust Cover
Plastic Bowl, Plastic Dust Cover
304 SS, No Dust Cover
304 SS, 304 SS Dust Cover
304 SS, Plastic Dust Cover
316 SS, No Dust Cover
316 SS, 316 SS Dust Cover
316 SS, Plastic Dust Cover
No Bowl or Dust Cover
Activation
¨A
¨B
¨C
¨D
¨E
300 SS Handle
316 SS Handle
300 SS Handle, 300 SS Foot Pedal
300 SS Handle, 316 SS Foot Pedal *
316 SS Handle with 316 SS Foot Pedal *
Drench Hose and Backflow Prevention
¨A
¨B
¨C
¨D
¨0
¨Z
Drench Hose Kit with Vacuum Breaker
Drench Hose Kit with N9 Backflow Preventer
Drench Hose Kit with 9D Backflow Preventer
Drench Hose Kit without Backflow Preventer
No Drench Hose and No Backflow Prevention
Drench Hose Ready
Freeze and Scald Protection
¨N
¨P
¨R
¨0
¨Z
Anti-Freeze Valve
Anti-Scald Valve
Anti-Freeze and Anti-Scald Valves
No Anti-Freeze Valve and No Anti-Scald Valve
Anti-Freeze and Anti-Scald Valve Ready
Halo Configurator
NPT = National Pipe Thread
BSPP = British Standard Pipe Parallel Threads
All selections made through the configurator are only
UL certified to ANSI/ISEA Z358.1
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

9
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
Plastic Ø 10" (254mm)
Stainless Steel Ø 10¾" (273mm)
S19314 shown with Plastic Bowl and Plastic Showerhead
Dust Cover
Eyewash Bowl
Plastic Showerhead with Plastic
or Stainless Steel Shroud
6"
(152mm)
13"
(330mm)
62¼"
(1581mm)
to bottom
of base
Ø 3.1"
(78.7mm)
941⁄8"
(2391mm)
to bottom
of base
Type 304 and 316 Stainless Steel
Showerheads
34¾"
(883mm)
to bottom
of base
2613⁄16"
(681mm)
677⁄8"
(1724mm)
to bottom
of base
923⁄16"
(2342mm)
to bottom
of base
47"
(1193mm)
to bottom
of base for
barrier free
option
1½"
(38mm)
Dimensions
All dimensions assume standard thread engagement. Variations in manufacturing allow for +/- 1⁄8"
(3mm) per threaded joint. To find the tolerance of a dimension, add the number of thread joints
across the length of the dimension and multiply it by 1⁄8" (3mm).
24½"
(622mm)
to Bottom
of Base
13¼"
(337mm)
Standard
drain
outlet
Optional
drain
outlet
Optional
barrier free
pull rod
18½"
(470mm)
861⁄8"
(2188mm)
to bottom
of base
Water Flow Rate
Showerhead 20–26 gpm
Eyewash 4–5¼ gpm
Eye/Face Wash 4–5¼ gpm
Body Wash 2–8 gpm
19¾"
(502mm)
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

10
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
1Assembly — Connect Base and Eyewash
Standard eyewash unit is shown. Other units are similar.
Connect components before securing the base to the floor. When connecting
components, use the rubber grip pad (provided) around pipes to prevent marring.
Apply pipe sealant (supplied by installer) to all male-threaded pipe joints, making
sure not to get any excess over the edge of the pipes.
1¼" NPT
drain outlet
For optional foot pedal
installation, the base
must be positioned
so that the hole in the
base is perpendicular
to the user.
20½"
(521mm)
pipe length
Halo unit with 24"
drain option
Halo unit with standard
drain option
12¾"
(324mm)
pipe length
1¼" NPT
drain outlet
BSPP-NPT
1-1/4" Adapter
if supplied
with provided
option
BSPP-NPT
1-1/4" Adapter
if supplied
with provided
option
³⁄₈" bolts and anchors
supplied by installer.
(3) Ø3⁄8" (10mm) holes on
Ø8" (203mm) bolt circle
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

11
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
1¼" NPT below supply inlet
2Assembly — Connect Drench Shower Components
Use teflon
tape only.
Alternate 1¼" NPT below
supply inlet
Standard eyewash unit is shown. Other units are similar.
Apply pipe sealant (supplied by installer) to all male-threaded pipe
joints, making sure not to get any excess over the edge of the pipes.
BSPP = British Standard Pipe Parallel Thread (not available in the
U.S.)
26" (660mm)
pipe length
If this tee is used as the
supply inlet, use the plug
on the top supply inlet
and use BSPP adapter
here if supplied with
provided option.
1" outlet
for shower
26" (660mm)
pipe length
Showerhead with
stainless steel
shroud option
Stainless
steel tee with
reducer
BSPP-NPT
1-1/4" Adapter
if supplied
with provided
option
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

12
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
1
4
3
5
Cross (Item #3) is for use with freeze/scald
valves and drench hose accessories only.
2b
4
2a
2b
15a
10a
10c
11a
12
17
14
13
16
17
15b
10b
11b
12
17
10c
Service Parts —Bowl and Hub
Hub with Plastic Bowl
Hub with Stainless Steel Bowl
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

13
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
Service Parts List —Bowl and Hub
1 111-092 1 Hub
1 111-093 1 Hub stainless steel
1 111-095 1 Hub stainless steel 316
1 111-094 1 Hub stainless steel polish
2a 113-006LQ 1 Pipe ½" x 3½"
2a 113-965 1 Pipe ½" x 3½" stainless steel
2a 113-1211 1 Pipe ½" x 3½" stainless steel 316
2a 113-596 1 Pipe ½" x 3½" chrome
2b 113-006LG 2 Pipe ½" x close
2b 113-867 2 Pipe ½" x close stainless steel
2b 113-1210 2 Pipe ½" x close stainless steel 316
2b 113-006aw 2 Pipe ½" x close chrome
3 169-1090 1 Cross ½"
3 169-1091 1 Cross ½" stainless steel
3 169-1098 1 Cross ½" stainless steel 316
3 169-1097 1 Cross ½" chrome
4 300-0393 2 Plug ½" chrome
4 153-230 2 Plug ½" stainless steel
4 153-460 2 Plug ½” stainless steel 316
5 S27-327 1 Ball valve ½" with nut
5 S27-328 1 Ball valve ½" ss 316 with nut
5 S27-329 1 Ball valve ½" frost proof with nut
5 S27-330 1 Ball valve ½" ss 316 frost proof with nut
5.1 110-215 1 Nut
5.1 110-248 1 Nut stainless steel 316
10a 113-1202 1 Pipe 1¼" x 11" thd. one end
10a 113-1203 1 Pipe 1¼" x 11" thd. one end stn. steel
10a 113-1138 1 Pipe 1¼" x 11" thd. one end chrome
10a 113-1139 1 Pipe 1¼" x 11" thd. one end stn. steel 316
10b 113-1204 1 Pipe 1¼" x 7" thd. one end
10b 113-1205 1 Pipe 1¼" x 7" thd. one end stainless steel
10b 113-1206 1 Pipe 1¼" x 7" thd. one end chrome
10b 113-1212 1 Pipe 1¼" x 7" thd. one end stn. steel 316
10c 169-724 1 Plug 1¼" painted galvanized
10c 269-251 1 Plug 1¼" chrome
10c 269-238 1 Plug 1¼" stainless steel
10c 269-1402 1 Plug 1¼" stainless steel 316
11a 110-239 1 Nut plastic, slip joint
11b 110-240 1 Nut, stainless steel slip joint
11b 110-242 1 Nut, stainless steel 316 slip joint
12 125-176 1 O-ring
13 111-099 1 Bowl mount aluminum
13 111-100 1 Bowl mount aluminum painted
13 111-101 1 Bowl mount stainless steel
13 111-102 1 Bowl mount stainless steel 316
14 124-082 1 Bowl gasket
15a 187-320 1 Bowl plastic
15b S90-393 1 Bowl stainless steel (includes Item 14)
15b S90-394 1 Bowl stn. steel 316 (includes Item 14)
16 160-467 4 Screw
17 110-115a as req’d. Nut ½" NPSM chrome brass
17 110-238 as req’d. Nut ½" NPSM stainless steel
17 110-241 as req’d. Nut ½" NPSM stainless steel 316
Item Part No. Qty Description Item Part No. Qty Description
S90-395 Plastic Prepack includes items 10a, 11a, 12, 15a
15a
10a
11a
12
300 Series SS Prepack S90-391 includes items 10b, 11b, 12, 13, 14, 15b
316 Series SS Prepack S90-392 includes items 10b, 11b, 12, 13, 14, 15b
14
13
15b
10b
11b
12
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

14
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
Service Parts —Eyewash
Service Parts —Eye/Face Wash
20
25
26
27 28
23
22
21a
22
Prepack S65-339 includes items 26, 27, 28
Prepack S88-068 includes items 25, 26, 27, 28
Prepack S88-069 includes items 25, 26, 27, 28 (300 series ss)
Prepack S88-070 includes items 25, 26, 27, 28 (316 ss)
25
26
27 28
20
25
26
27 28
21b
22
22
24a
24b
Eyewash Cover Prepack
S45-2675 includes items
22 and 23
23
22
22
Eye/Face Wash Cover Prepack
S45-2676 includes items 22,
24a and 24b
22
22
24a
24b
21b 21f 21j
or or
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

15
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
Service Parts —Plastic Bowl Cover
Service Parts —Stainless Steel Bowl Cover
40
44
45
36
41
35b
39
39 42
43
5.1
39
40 42
43
44
45
36
41
35a
39
39 42
43
5.1
Handle Prepacks include items 39, 40, 41, 44, 45, 5, 5.1
Prepack S08-390 (for units with brass ball valve)
Prepack S08-391 (for units with stainless steel ball valve)
Prepack S08-392 (for units with brass frost-proof ball valve)
Prepack S08-393 (for units with stainless steel frost-proof ball valve)
Prepack S08-394 (for units with 316 stainless steel ball valve and handle)
Prepack S08-395 (for units with 316 stainless steel frost-proof ball valve
and handle)
39 40
41
44
45
5.1
5
Plastic Bowl Cover Prepack S90-390
includes items 35a, 36, 39, 42, 43
39 42
43
36
35a
Stainless Steel Bowl Cover Prepack
S90-388 includes items 35b, 36, 39,
42, 43
Stainless Steel (316) Bowl Cover
Prepack S90-389 includes items 35b,
36, 39, 42, 43
39 42
43
36
35b
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

16
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
Service Parts List —Eyewash, Eye/Face Wash and Bowl Covers
Item Part No. Qty Description
20
20
20
20
171-001
171-002
171-003
171-004
1
1
1
1
Body
Body stainless steel
Body stainless steel 316
Body polished
21a
22
23
S05-190
in service kit
in service kit
1
2
2
Sprayhead ass’y. eyewash
(includes)
Pivot pin
Flip cover eyewash
21b
22
24a
24b
S05-192
in service kit
in service kit
in service kit
1
2
1
1
Sprayhead ass’y. eye/face wash
(includes)
Pivot pin
Flip cover right
Flip cover left
21f
22
24a
24b
S05-204
in service kit
in service kit
in service kit
1
2
1
1
Sprayhead stainless steel 304
ass'y. eye/face (includes)
Pivot pin
Flip cover right
Flip cover left
21j
22
24a
24b
S05-205
in service kit
in service kit
in service kit
1
2
1
1
Sprayhead stainless steel 316
ass'y. eye/face (includes)
Pivot pin
Flip cover right
Flip cover left
25
25
25
25
115-158
115-159
115-164
115-165
1
1
1
1
Cap
Cap stainless steel
Cap stainless steel 316
Cap polished
Item Part No. Qty Description
26 125-157 2 O-ring
27 125-175 1 Flow control
28 S65-340 1 Screen (incl. 3 per pack)
35a
35b
35b
in service kit
in service kit
in service kit
1
1
1
Bowl cover plastic
Bowl cover stainless steel
Bowl cover stainless steel 316
36 114-097 1 Bowl cover decal
39
39
160-389
160-469
as req'd.
as req'd.
Screw ¼-20 x ½" stn. steel
Screw ¼-20 x ½" stn. steel 316
40
40
S08-385
S08-388
1
1
Handle ss (incl. items 41, 44,
45, 5.1)
Handle ss 316 (incl. items 41,
44, 45, 5.1)
41 114-096 1 Decal
42 142-002AV as req'd. Bowl cover washer
43
43
161-060
161-062
as req'd.
as req'd.
Nut stainless steel
Nut stainless steel 316
44 153-372R 1 Adapter ball valve
44
153-
372R316
1Adapter ball valve stainless steel
316
45 142-002DA 1 Lockwasher
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

17
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
Foot Pedal kits
S45-572 (standard foot pedal kit)
S45-1314SS (stainless steel foot pedal kit)
S45-1314SS16 (316 stainless steel foot pedal kit)
Base and Drain Kits for 24"Drains include
items 1, 4, 301b, 302b, 303
S29-098 (standard)
S29-099 (stainless steel)
S29-100 (316 stainless steel)
S29-101 (chrome)
Service Parts and Parts List —Base and Drain
14
301a
303
304
302a
302b
305a
305b
301b
1111-092 1 Hub
1 111-093 1 Hub stainless steel
1 111-095 1 Hub stainless steel 316
1 111-094 1 Hub stainless steel polish
4 300-0393 2 Plug ½" chrome
4 153-230 2 Plug ½" stainless steel
4 153-460 2 Plug ½" stainless steel 316
301a 113-1197 1 Pipe 1¼" x 20½"
301a 113-1198 1 Pipe 1¼" x 20½" chrome
301a 113-541 1 Pipe 1¼" x 20½" stainless steel
301a 113-1213 1 Pipe 1¼" x 20½" stainless steel 316
301b 113-1217 1 Pipe 1¼" x 12¾"
301b 113-1218 1 Pipe 1¼" x 12¾" chrome
301b 113-1219 1 Pipe 1¼" x 12¾" stainless steel
301b 113-1220 1 Pipe 1¼" x 12¾" stainless steel 316
302a 169-727 1 Tee 1¼" painted galvanized
302a 269-237 1 Tee 1¼" stainless steel
302a 269-1398 1 Tee 1¼" stainless steel 316
302a 269-253 1 Tee 1¼" chrome
302b 169-853 1 Coupling 1¼" galvanized
302b 269-257 1 Coupling 1¼" chrome
302b 269-1048 1 Coupling 1¼" stainless steel
302b 269-2016 1 Coupling 1¼" stainless steel 316
303 113-006NA 1 Pipe 1¼" x close painted galvanized
303 113-865 1 Pipe 1¼" x close stainless steel
303 113-1223 1 Pipe 1¼" x close stainless steel 316
304 S06-189 1 Plug chrome solid
305a 131-059 1 Base painted
305a 131-062 1 Base stainless steel
305a 131-079 1 Base stainless steel 316
305b 131-044 1 Base chrome
321 169-1117 1 BSPP-NPT 1-1/4" 303SS
321 169-1118 1 BSPP-NPT 1-1/4" 316SS
326 169-724 1 Plug 1¼" painted galvanized
326 269-251 1 Plug 1¼" chrome
326 269-238 1 Plug 1¼" stainless steel
326 269-1402 1 Plug 1¼" stainless steel 316
Item Part No. Qty. Description Item Part No. Qty. Description
14
303
302b
301b
326
321
Supplied
with BSPP
Thread
options only
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

18
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
P.O.Box 309, Menomonee Falls,WI 53051
R
TESTTHIS UNIT EACH WEEK
Test-operate valve(s)each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich imTestbetrieb prüfen, bestätigt
durch Unterschrift.Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1STWÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnementdes valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne vapas fait
un rapport immédiatement.
P.O.BOX 309, MENOMONEE FALLS,WI 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-052
Service Parts —Drench Shower
360a
362
362
331
330
343
341
360b
360a
360a
361a
361b
342
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

19
Installation S19314
Bradley • 215-1684 Rev. U; ECN 18-05-037 10/19/2018
Brass Valve Prepacks include items 350a, 351, 353,
354a
S30-059 (for standard brass valve)
S30-103 (for frost-proof brass valve)
Service Parts —Drench Shower
352
351a
351b
353
344a
325
329
326
328
302
327
340
325
344b
350a
350c
350b.2
354c
354b
355a
350b.1
354a
350a.1
350b
350a.1
302
Self-Closing Valve Prepacks
S19-0011 (for standard brass valve)
S30-107 (for frost-proof brass valve)
includes items 350c, 351, 353, 354a, 355a
351
353
350c
355a
354a
350a.1
Stainless Steel Valve Prepacks include items
350b, 354b, 355b
S30-061 (for stainless steel valve)
S30-081 (for 316 stainless steel valve)
S30-104 (for frost-proof stainless steel valve)
350b.2
354b
355b.1
350b
351b
352
350a
354c
350a.1
321
BSPP Adapter -
Supplied with BSPP
Thread options only
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115

20
S19314 Installation
10/19/2018 Bradley • 215-1684 Rev. U; ECN 18-05-037
Parts List —Showerhead and Shower Valves
302 169-727 1 Tee 1¼" painted galvanized
302 169-727B 1 Tee 1¼" painted galvanized BSP
302 269-237 2 Tee 1¼" stainless steel
302 269-1398 2 Tee 1¼" stainless steel 316
302 269-253 1 Tee 1¼" chrome
321 169-1117 2 BSPP-NPT 1-1/4" 303SS
321 169-1118 2 BSPP-NPT 1-1/4" 316SS
325 113-1199 2 Pipe 1¼" x 26"
325 113-1195 2 Pipe 1¼" x 26" stainless steel 316
325 113-1200 2 Pipe 1¼" x 26" stainless steel
325 113-1201 2 Pipe 1¼" x 26" chrome
326 169-724 1 Plug 1¼" painted galvanized
326 269-251 1 Plug 1¼" chrome
326 269-238 1 Plug 1¼" stainless steel
326 269-1402 1 Plug 1¼" stainless steel 316
327 169-722 1 Tee 1¼" x 1" x 1¼"
327 269-249 1 Tee 1¼" x 1" x 1¼" chrome
328 269-1400 1 Reducer 1¼" x 1" stainless steel 316
328 269-236 1 Reducer 1¼" x 1" stainless steel
329 113-006LN 1 Pipe 1" x close painted galvanized
329 113-1214 1 Pipe 1" x close stainless steel 316
329 113-006NL 1 Pipe 1" x close stainless steel
329 113-625 1 Pipe 1" x close chrome
330 113-006MT 1 Pipe 1" x 21" painted galvanized
330 113-1215 1 Pipe 1" x 21" stainless steel 316
330 113-864 1 Pipe 1" x 21" stainless steel
330 113-1216 1 Pipe 1" x 21" chrome
331 169-847 1 Elbow 1" painted galvanized
331 169-1073 1 Elbow 1" chrome
331 169-1074 1 Elbow 1" stainless steel
331 169-1075 1 Elbow 1" stainless steel 316
340 269-915 1 Rubber Grip Pad
341 204-421 1 Emergency Inspection Tag
342 114-052 1 Safety Sign
342 114-052E 1 Safety Sign (not available in the U.S.)
343 151-001 2 Curtain Hook for Safety Sign
344a 128-156A 1 Pull Rod
344b S90-365D 1 Pull Rod ADA
344a 128-157 1 Pull Rod stainless steel 316
350a S27-278 1 Ball valve 1"
350a S27-301 1 Ball valve 1" frost proof
350a.1 110-214 1 Nut
350b S27-276 1 Ball valve 1" stainless steel
350b S27-325 1 Ball valve 1” stainless steel frost proof
350b.1 142-002BC 1 Lockwasher
350b.2 161-079 1 Nut
350c S27-286 1 Ball valve 1" self-closing
351a 140-720 1 Bracket stop ball
351b 153-489 1 Adapter
352 124-048 1 Washer flat
353 S19-001 1 Spring
354a 128-129 1 Handle
354b 128-142 1 Handle stainless steel
354b 128-155 1 Handle stainless steel 316
354c 128-201 1 Handle
355a 142-002DC 1 Lockwasher
3⁄8"
360a S24-188 1 Drench shower assembly
360b S24-191 1 Drench shower stainless steel
360b S24-201 1 Drench shower stainless steel 316
361a 187-053 1 Shroud stainless steel
361b 154-058 1 Shroud plastic
362 154-147 1 Shroud ring
Item Part No. Qty Description Item Part No. Qty Description
BSP = British Standard Pipe Thread (not available in the U.S.)
WWW.RESTROOMDIRECT.COM 704 • 937 • 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115
