Bradley HN-200 User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
800 BRADLEY (800 272 3539) [phone]
bradleycorp.com
Installation
215-741 Rev. C; ECN 15-03-004
© 2015 Bradley
Page 1 of 6 4/29/2015
HN-200 Recess-Mounted
Shower
California Title 24
Table of Contents
Pre-Installation Information ..........................3
Rough-Ins .......................................4
Installation .......................................5
Cleaning and Maintenance ..........................6
Valve Right/Seat Right Shown

2
HN-200 Recess-Mounted Shower Installation
4/29/2015 Bradley • 215-741 Rev. C; ECN 15-03-004
WARNING
This shower system may not protect the user from scalding when there is a failure of other temperature-
controlling devices elsewhere in the plumbing system.
Hardware supplied by installer must be appropriate for wall construction. Wall anchors used must have a
minimum pull-out rating of 300 lbs.
NOTICE
Excessive heat to the Equa-flo™ system will damage the internal parts of the valve.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file
this manual with the owner or maintenance department. Compliance and conformity to local codes and
ordinances is the responsibility of the installer. Product warranties may be found under “Products” on our
Web site at bradleycorp.com.
Plumbing contractor shall be responsible for installing shower control pane at the correct height to meet
accessibility requirements.
This manual covers all of the HN-200 variations and options available, including shower seat and curtain
installation. Simply omit the steps which do not apply to the unit you are installing.
Make sure all parts are accounted for before discarding any packaging material. If any parts are missing, do
not attempt to install your Bradley HN-200 shower until obtaining the missing parts.
Valve Right/Seat Right version is shown throughout this manual. Valve Left/Seat Left is opposite.

3
Installation HN-200 Recess-Mounted Shower
Bradley • 215-741 Rev. C; ECN 15-03-004 4/29/2015
Pre-Installation Information
Material
Control Panel Material: The shower control panel is constructed of 14-gauge type 304 stainless steel.
Valve and Component Material: All exposed parts (except seat cover) are stainless steel or polished chrome-plated
brass. Valve bodies are brass casting.
Supplies Required
• Wall anchors to mount HN-200 shower panel on wall (supplied by installer)
• 1/2" IPS hot (or 1/2" IPS tempered) and cold water supply
• (6) wall anchors for 1/4"-20 x 1-1/4" screws to mount grab bar on wall of shower stall
The HN-200 shower is furnished assembled for job site installation. Particular care must be taken by the
contractor for proper height placement of the shower. Always check local codes for compliance.
Dimensions
60" (1524mm)
Min Clear Face
of Finish to Face
of Finish
30"
(762mm)
Min
36"
(914 mm)
15"
(381 mm)
Level and Clear Area
Optional 9562
Shower Seat
Optional L-Shaped
Grab Bar
4"
(102 mm)

4
HN-200 Recess-Mounted Shower Installation
4/29/2015 Bradley • 215-741 Rev. C; ECN 15-03-004
Rough-in (as viewed from front)
1
ARough-in 1/2" IPS hot and cold water supply
piping for Equa-Flo valve at dimensions
shown (piping supplied by installer)
Flush supply lines before making connections.
Install the supply inlets no lower than 48"
(1219mm) and no higher than 60" (1524mm).
When facing the wall, the supply pipe to the left of
the centerline is HOT.
23"
(584mm)
1/2" NPT
Supplies
13-1/4"
(336mm)
4"
(102mm)
2"
(613mm)
C
LValve
19"
(483mm)
48" to 60"
(1219 to
1524mm)
AFF
40"
(1016mm)
40-1/2"
(1029mm)
4"
(102 mm)
37"
(940mm)
33"
(838mm)
Top of
Grab Bar 18"
(457mm)
Top of Seat
33"
(838mm)
Top of
Grab Bar
18"
(457mm)
Top of Seat

5
Installation HN-200 Recess-Mounted Shower
Bradley • 215-741 Rev. C; ECN 15-03-004 4/29/2015
Install Shower and Grab Bar
2
APosition the face place on the wall. Mark the
wall and install (18) wall anchors suitable for
use with 14"-20 machine screws.
CAttach the face plate to the wall with the
(18) 1/4"020 x 3/4" button head Allen key
screws provided.
D
Position the "L" of the grab bar to fit the
back wall of the shower stall. Using the
flange as a template, mark the wall and
install the (6) wall anchors (supplied by
installer) for the 1/4"-20 x 1-1/4" flat head
Allen key screws.
It is the installer's responsibility to use the
correct anchors for the particular job's wall
construction.
1/4"-20 x 3/4" Allen Key Screw
Concealed
Mounting
Cover
Grab Bar
BConnect stainless steel hoses to the 1/2" IPS
for the hot and cold water supply.
ESecure the grab bat to the (6) wall anchors
using the (6) 1/4"-20 x 1-1/4" flat head Allen
key screws provided.
Install Curtain Rod
3
AMeasure and cut the stainless steel curtain
rod to fit the shower stall opening.
BUsing (2) #10-13 x 2" Phillips oval screws,
mount one shower rod flange 80" (2023mm)
from the floor as close to the opening of the
shower stall as possible.
CInsert one end of the shower rod into the
flange. Slide the other shower rod flange
onto the shower rod.
D
Position the shower rod and flange on the
opposite side of the shower stall opening
at the same dimensions as the other flange.
Secure the flange to the wall with
(2) #10-13 x 2" Phillip head screws provided.
EInstall ten hooks onto the curtain rod and
hang the curtain on the rod.
60"
(1524mm)
Shower
Rod
Flange 80"
(2032mm)
to floor

6
HN-200 Recess-Mounted Shower Installation
4/29/2015 Bradley • 215-741 Rev. C; ECN 15-03-004
Cleaning and maintenance instructions for stainless steel
Material Description: Stainless steel is extremely durable, and maintenance is simple and inexpensive. Proper care,
particularly under corrosive conditions, is essential. Always start with the simplest solution and work your way toward
the more complicated.
Routine cleaning: Daily or as often as needed use a solution of warm water and soap, detergent, or ammonia.
Apply the cleaning solution per the manufacturer’s instructions and always use a soft cloth or sponge to avoid
damaging the finish.
Stubborn Stains: To remove stains from stainless steel use a stainless steel cleaner and polish such as Ball®
stainless steel cleaner or a soft abrasive. Always follow the manufacturer’s instructions and apply in the same
direction as the polish lines.
CAUTION! Never use ordinary steel wool or steel brushes on stainless steel. Always use stainless steel
wool or stainless steel brushes.
Special Situations for Material
Fingerprints and Smears: To remove fingerprints or smears use a high quality stainless steel cleaner and polish in
accordance with the manufacturer’s instructions. Many of these products leave a protective coating that helps prevent
future smears and fingerprints.
Grease and Oil : To remove grease and oil use a quality commercial detergent or caustic cleaner. Apply in
accordance to the manufacturer’s instructions and in the direction of the polish lines.
Precautions: Avoid prolonged contact with chlorides (bleaches, salts), bromides (sanitizing agents), thiocyanates
(pesticides, photography chemicals, and some foods), and iodides on stainless steel equipment, especially if acid
conditions exist.
CAUTION! Do not permit salty solutions to evaporate and dry on stainless steel.
The appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the
actual source of the rust in some iron or steel particles which may be touching, but not actually a part of the stainless
steel structure.
NOTE: Strongly acidic or caustic cleaners may attack the steel, causing a reddish film to appear. The use of these
cleaners should be avoided.
Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, nor does the omission of any brand name cleaner imply its inadequacy. Many products named are
regional in distribution, and can be found in local supermarkets, department and hardware stores, or through your
cleaning service. It is emphasized that all products should be used in strict accordance with package instructions.
Shower Curtain Repair Parts
Part No Qty Description
151-001 10 Curtain hooks
113-313A 1 Curtain Rod
150-157 2 Shower Rod Flange
269-373 4 #10-13 x 2" Phillips Head Screw
170-006 1 Shower Curtain
