Bradley LUCENT Series User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
AD3-LUCENT_Install Rev. B
© 2023 Bradley
Page 1 of 23 11/8/2023
Euro Style Restroom Partitions
Glass – LUCENT Series
Read the instructions in this manual before
beginning installation. Save these instructions
and refer to them for inspection, maintenance,
and troubleshooting information.
For questions regarding the operation, installation or maintenance of this product, visit bradleycorp.com
or call 800.BRADLEY (800.272.3539).
Product warranties and parts information may also be found under “Resources” on our website at bradleycorp.com.
Table of Contents
Safety Information ...........................2
Supplies Required ...........................2
Measuring & Marking Drill Holes ................3
Marking Drill Holes for Floor Pivots..............3
Installing the Floor Pivots .....................4
Attaching the Retaining Brackets ...............5
Installing & Securing the Dividing Panel ..........6
Installing the Dividing Panel ...................7
Mounting the Headrail ........................8
Assembling Panels to Pilasters Using L-Brackets ..9
Installing the Doors .........................10
Hydraulic Hinge Guide.......................10
Aligning the System.........................11
Final Assembly.............................12
Mounting the Door Latch.....................13
Latch Selection Guide .......................13
Mounting Hooks & Bumpers ..................20
Assembling the Self-Closing, Hydraulic Hinge
Assembly .................................20
Fraction-Decimal Conversion Chart ............23

2
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
Safety Information
Warning
Before beginning installation, make sure that the wall and floor backing are adequate to support the secure mounting of the
toilet compartment units.
Partitions are extremely heavy and may require more than one person to position and install.
Failure to comply with these instructions may result in personal injury and/or property damage and will void the partition
warranty.
Caution
Personal protective equipment (PPE) is required during the installation and maintenance of this product.
Notice
Make sure all floors and walls are clean and smooth. Remove loose impediments, such as protruding nails and other debris
which could affect installation.
Carefully remove components from skid, do not drag.
Important
Review your partition layout drawings and verify the number of stalls and components before beginning installation.
Read this installation manual completely to ensure proper installation, then file it with the owner or maintenance department.
This installation manual provides instruction for the assembly of normal partition configurations and standard components.
Non-standard configurations or components including but not limited to curved or angled walls, notched walls, partial walls,
oversized panels, or modified hardware may not be covered in this manual. Compliance and conformity to local codes and
ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding packaging material. If any parts are
missing, do not begin installation until you obtain the missing parts.
Supplies Required
• Chalk line and pencil
• 4D laser level
• Power drill or screw gun with drill bit extension
• Cordless screwdriver
• Power rivet gun
• Metric tape measure (recommend a wood folding metric ruler)
• Standard hand tools
• Metric drill bits as needed
• Torque wrench and Torx bit 30 with bore
• Metric Allen wrench set
• Countersunk rosette key or small snap ring wrench
• HB45 construction adhesive or equal
• Step ladder
• Fast drying epoxy
• Clamps

3
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
When installing the partition components, consult the
applicable Bradley Partition submittal drawing specific to
this job for compartment layout dimensions.
Refer to the drawing for the measurements for exact
drilling points for the holes in the floor.
Refer to the drawing for the measurements for exact
drilling points for the holes in the floor and dividing panel
supports.
Optional - Use Bradley provided (on loan) drilling guide to
aid in drilling holes in floor.
1Measuring & Marking Drill Holes
2Marking Drill Holes for Floor Pivots
Using the hinge oor pivot as a template, trace the
drilling hole locations onto the center line of the front
panel on the oor.
Trace the drilling holes for the oor pivot and the
dividing panel support onto the dividing panel
centerline on the oor.
A
B
On the traced centerlines, use a wet drill with an
18mm core bit to drill 30mm into the oor.
C
From the accompanying production drawing note
the centerline dimensions and the dimension line
of the front wall. Transfer these measurements to
the oor. In some cases, a oor drill guide will be
provided.
A
Account for gaps, pilaster width, and door width.
Exact dimensions of floor drillings is crucial.
Centerline of lower hinge assembly hole in floor is
83mm from edge of door on the hinge side.
Panel support floor anchor is 113mm center line
recessed in from centerline front pilaster. Confirm
before drilling hole.

4
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
3Installing the Floor Pivots
Verify all dust and water has been removed from the
drilled holes. Insert fast-drying, epoxy-based adhesive
into the holes.
A
Place the oor pivot into the glue until the large collar
plate is pressed rmly against the oor. Verify the oor
pivot is vertically straight.
C
Wear gloves and use Acetone to quickly and carefully
remove any excess glue before the glue cures.
D
After the lower portion of the oor pivot/support is
set and the glue has hardened, you can assemble the
upper components to the oor units. For lower door
hinge units, thread the male threaded post into the
lower unit, assemble the ball bearing washer next,
metal washer next, and nally the thick brass bushing
onto the oor unit, in that order. Thread the post out
by one full turn so door hinge does not rub against
base.
For the regular support units, thread the male
threaded post into the lower unit, followed by the
large silver bushing.
E
It is normal for some excess glue to seep out from
under the plate.
Optional-thread Bradley provided (on loan) target level
to aid installing lower floor support perfectly level.
Verify the setscrew is accessible to allow for height
adjustment.
Depending on the room and floor temperature, the
glue may cure quickly. If glue dries before the excess
can be removed, you may carefully chip away the
excess glue using a chisel.
It is normal for some excess glue to seep out from
under the plate.
Unthread upper collar from the oor support.
B

5
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
4Attaching the Retaining Brackets
Mark the centerline hole locations on existing back and
side walls for the retaining brackets that support the
dividing panels. Use a 4D laser level and begin with the
lowest bracket. These dimensions are appropriate for
standard height panels.
• Lower bracket 67mm from the oor.
• Middle bracket 1050mm from oor
• Upper bracket 1900mm from oor
A
Be aware of your surroundings and avoid electrical wires
and pipes.
Drill the marked hole locations on existing back and
side walls using an 8 mm drill bit, and then secure the
retaining brackets in place using 8 mm x 51 mm wall
anchors and 5.5 mm x 60 mm countersunk screws.
Use a level to make sure the brackets are vertical.
Place the angled bracket into the lower retaining
bracket as shown. The angled bracket will support the
dividing panel and prevent it from slipping.
C
B

6
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
5Installing & Securing the Dividing Panel
Assemble the lower part of the support bracket into
the two holes found along the lower part of the front
of the dividing panel. This lower support bracket has a
large round opening that goes over the oor support,
with four set screws for nal adjustment. Loosen all
four set screws on the lower hinge assembly so the
inner points are completely out of the way of the oor
pivot.
Assemble the base to the glass by inserting the larger
female threaded posts covered with grey plastic
brushing into the holes in the glass. Face the screw
heads away from the front for aesthetic purposes.
Thread the smaller portion of the bracket with the (2)
M6 x 25mm screws through the plate into the female
threads. Tighten to the glass.
A
B
Repeat steps (ref above) for the upper supports.
Upper supports are similar to the lower supports
with the exception that the top has a small female
threaded opening.
C
Verify the gray nylon heads are fully inserted into the
partition glass.

7
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
Carefully slide the wooden block away from the
dividing panel until the support leg can be set onto
the oor pivot.
Set the dividing panel onto the support.
E
F
6Installing the Dividing Panel
Insert the rear of the dividing panel into the retaining
brackets mounted on the wall, and then place a
50mm wood block and shins under the front of the
panel for support.
Use a 4D laser level to align the panel perpendicular
to the wall.
Makes sure panel is ush and level.
Tighten the retaining brackets down onto the panel to
secure it in place.
A
B
C
D
NOTICE! This is a vise-type bracket. No not overtighten!

8
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
7Mounting the Headrail
Mark the centerline for the dividing panel onto the headrail.
Drill a hole on top of the headrail and countersink this hole in
the center of the headrail width using a 8.5mm drill bit.
A
Place the headrail onto the upper dividing wall holder and
secure using M8x25mm screws (screw threads have already
been prepared).
B
Adjust the headrail horizontally and secure the wall connector
to the wall using 6mmx30wall anchors and 5mmx38mm
countersunk screws.
C
Cover the round flange with square finish cover, secure with
glue to keep in place.
D
No cutting of the headrail should be necessary. The headrail
should already by cut to the correct length. Check for specific
location labels. Use the dividing panels as a guide.
Slide square finished cover over headrail, then assemble round
threaded adjusting flange on end of headrail.
Center of the headrail equals the centerline of the front wall
plus 113mm.

9
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
8Assembling Panels to Pilasters Using L-Brackets
Place the black nylon sides of the L-brackets against
the glass holes on the dividing panel. Do this on both
sides of the glass.
Secure the L-brackets together using M6x16mm
flathead screws and flat nuts.
Verify the panels and pilasters are level and flush.
Attach the pilasters to the end panels using the
L-brackets, countersunk 4 pin rosettes (facing the
outside of the stall), and M6x16mm screws.
A
B
D
C
Verify there is an approximate gap of 3mm between
the pilaster and panel.
Place L-brackets at the top, middle, and bottom of
the panel.

10
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
9Installing the Doors
Adjust floor clearance and level the door. Tighten the
set screw on back of the reach over bracket, into
back of head rail to secure upper assembly, using a
3mm Allen wrench.
C
This will prevent the doors from falling out of adjustment.
Assemble upper and lower hinge assembly to door
similar to instructions on page 6. The upper hinge
assembly will have a hinge post protruding through
the top of the hinge bracket. Face screws inward for
aesthetic purposes.
A
Select the proper upper hinge assembly from the guide
shown on next page.
Hydraulic Hinge Guide for Self Closing Doors
BRO0540108
BRO0540108
BRO0540107
BRO0540107
Front
Front Front
Front
Headrail
Headrail
Headrail
Headrail
Door
Door
Door
Door
With the head rail in place, lower door in lower floor
pivot. This floor pivot should be complete with the
base, ball bearing disk, washer, and brass grommet.
Secure upper hinge assembly by carefully lowering
the upper reach over bracket over the head rail and
capture the upper hinge pin in the hole of the reach
over bracket. Make sure plastic grommet is in place
around pin.
B

11
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
10 Aligning the System
Adjust the door by unscrewing the setscrew and
moving the reach-over bracket back and forth along
the headrail.
Adjust the vertical clearance of the door by adjusting
the set screw using a 2mm Allan wrench that is in the
collar against the floor. Thread the post up or down,
then fully tighten the set screw. The post should be
at least one full rotation above base to prevent door
from scraping the base.
To adjust the placement of the lower hinge assembly
(front/back/left/right) adjust the four set screws using
a 3mm Allan wrench. Fully tighten against the large
inner brass grommet.
Adjust the clearance between the door and pilaster by
moving the middle pilaster within the long holes of the
dividing panel angles.
Make any fine tune height adjustments using the
lower hinge floor pivot. Loosen the setscrew, lift the
door slightly, and then twist the upper part of the
bearing up or down.
When the desired door height is obtained, re-tighten
the lower hinge floor pivot setscrew.
A
B
C
D
E

12
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
11 Final Assembly
Verify that the final adjustments to the system have
been made, and then fasten all screw connections.
Torque fasteners to 120NM.
Use a 4mm drill bit to drill through the existing
hole in the reach-over bracket into the headrail.
Secure the reach-over bracket and headrail using a
4mmx14mm rivet.
Use HB45 adhesive to glue the oval cover plates onto
the dividing panel angle brackets and the locking
device onto the middle pilaster.
Use HB-45 adhesive to glue the full length no-site
strips to the latch side and hinge side (if needed) of
the door.
A
B
C
D
For outswing doors: Glue a full size no-site strip to
the inside edge of the pilaster.
For inswing doors: Glue the pre-cut shorter no-site
strip on the lower portion of the inside edge of the
door, and up against the bottom of the large latch
mechanism. Glue the longer pre-cut no-site strip
the same way on the upper portion of the inside
edge of the door, against the top of the large latch
mechanism.
E

13
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
Locate the proper Lucent Latch kit. Refer to the image
below for the proper latch kit number.
Door
Door
Door
Door
Headrail
Headrail
Headrail
BRO0540511
BRO0540512
BRO0540510
BRO0540513
Front
Front
Front
Front
Latch Selection Guide
12 Mounting the Door Latch

14
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
Insert the small set screw into occupancy indicator. This set screw port should be straddling the line between a white and red
field of the occupancy disk. Make sure the set screw is flush with the outside wall of the indicator disk, and that the tip does not
protrude into the core of the disk. Use a 3mm Allen wrench.
A
Insert the occupancy indicator into the back of the
knob with the set screw positioned in line with one of
the angled holes. Use the hole that allows the white
portion of the occupancy disk to show through the
holes in the front of the knob.
B

15
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
Place the thin white disk and the thick grey spacer
disk on the back of the knob assembly, and place on
the outside of door, with the three holes in the knob
facing down. White should be showing through the
holes in the knob.
C

16
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
Attach the latch mechanism to the door.
For Inswing Doors
1. Locate the large latch mechanism. Notice the
black padded material to be placed against the
glass.
2. Place the retaining flange on the front of the
latch mechanism, and place this assembly on
the other side of the door, on the glass, over the
latch opening.
3. Level the large mechanism, and thread the large
screws into the back of the flange, through the
large latch mechanism, through the door, and
into the back of the knob on the other side of
the door.
4. Tighten the screws using a T-25 torx wrench.
For Outswing Doors
1. Locate the large latch mechanism. Notice the
blackpadded material to be placed against the
glass.
2. Place the thin white disk on the retaining flange
and place flange on the inside of door over
opening.
3. Place the knob with the three holes facing down
against the large mechanism. Place on the
outside of door with thick plastic spacer in the
door.
4. Level the large mechanism, and thread the large
screws through the back of the flange, through
the door, through the large mechanism, and into
the back of the knob.
5. Tighten the screws using a T-25 torx wrench.
D

17
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
Locate the groove in the paddle handle brass stem. Align that
groove downward, and insert the paddle handle at a 45 deg.
angle away from the latch side edge of the door. Make sure
the grey plastic “top hat” bushing is in place at base of stem
as shown. Assemble the paddle handle into the inside opening
in the door. This should be inside the stall. Push all the way in.
E

18
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
While keeping pressure against the paddle handle
tight against the mechanism, tighten the set screw in
the indicator disk through the angled hole found at
the bottom of the knob using a 3mm Allen wrench.
This is to fix the paddle handle to the latch assembly.
In the unlock position, white should show through the
knob.
F
Test by rotating the paddle handle back and forth
towards the edge of the door and back. This should
move the locking latch in and out of the large
mechanism, and white should appear in the knob
while unlocked, and red while locked.
G

19
Installation Euro Style Restroom Partitions, Glass — LUCENT Series
Bradley • AD3-LUCENT_Install Rev. B 11/8/2023
The strike is to be glued to the pilaster
using the HB-45 glue or equivalent.
Perform the following only after all
adjustments are completed. This should be
the last step of the door latch assembly.
To align properly, open the door and move
the handle to the locked position. Slide
the strike over the latch, leaving a small
even space between the mechanism and
the strike. Make sure the strike is in line
with the mechanism. Carefully apply glue
to the back side of the strike and slowly
close the door, making sure the glue on
the strike makes good contact with the
pilaster. Carefully hold in this position for
a couple minutes, making sure the strike
does not move. Unlock the door, swing the
door away, and carefully clamp the strike in
place for full curing of the glue. Make sure
the strike does not move.
H
IMPORTANT: A 4mm L-wrench can be used as an
emergency egress tool to unlock the latch from the
outside of the stall.

20
Euro Style Restroom Partitions, Glass — LUCENT Series Installation
11/8/2023 Bradley • AD3-LUCENT_Install Rev. B
13 Mounting Hooks & Bumpers
14 Assembling the Self-Closing, Hydraulic Hinge Assembly
Measure and then mark the location for the hook on
the inside of the door
Attach the hook to the door (inside) using HB45
construction adhesive.
Attach the door bumper to the inside pilaster using
HB45 construction adhesive.
Use a strip of adhesive tape to hold the door bumper
in place until the adhesive dries.
A
Place the gear into the self-closing mechanism by
aligning it into the notch.
A
B
C
D
The self-closing hinge assembly is available for left-hand
and right-hand closing doors. Verify the correct unit is being
used for the correct swing configuration.
Refer to "Hydraulic Hinge Guide for Self Closing Doors" on page 10.
