BROSA Caledonia Rattan 2 Drawer Console Table User manual

Caledonia Rattan
2 Drawer Console Table
A S S E M B LY GU I D E
V1

FOR YOUR SAFETY
Lift, don’t drag. This protects
your floor and product.
Avoid loose screws. Tighten
fixtures every few months.
Assembly requires 2 people.
It's always easier with a
friend.
Contact our support online
or call 1300 027 672.
Check the assembly guide
for required components.
?
Assembling this product on
a soft surface protects its
finish.

Components
Before you get started, check you have all of the pieces below.
If anything’s missing, we’ll sort it out right away. Simply visit:
www.brosa.com.au/pages/product-return-and-parts-request
Hardware
A x 12
(M6 x 40)
B x 12
(Ø8 x Ø25)
D x 4
(M6 x 20)
E x 4
(Ø8 x Ø25)
C x 12
(Ø8 x Ø16)
F x 1
(M4)
Body x 1
①
Leg Frame x 2
②
Shelf x 1
③

Step 1 Fit the tongues of the shelf ③into the slots of
the leg frames ②. Make sure the stickers match
as per the diagram below.
②
③
②

Step 2 Fit a spring washer C to a long bolt A followed by
a flat washer B. Insert the long bolt into a hole on
the leg frame to fix the shelf. Screw the bolt with
your hand. Leave the bolt loosely attached.
Repeat this for the remaining holes on the leg
frames.
A x 6
B x 6
C x 6
C
A
B

Step 3 Fit a golden washer E to a golden bolt D. Insert
the golden bolt into a hole on the bracket. Screw
the bolt with your hand. Leave the bolt loosely
attached. Repeat this for the remaining brackets.
D x 4
E x 4
D
E

Step 4 Align the structure formed in Step 3 with the
holes on the bottom of the body ①. Make sure
the stickers match as per the diagram below.
Fit a spring washer C to a long bolt A followed by
a flat washer B. Insert the bolt into a hole on the
leg frame. Screw the bolt with your hand and
leave it loosely attached. Repeat this for all holes
on the leg frames.
①
A x 6
B x 6
C x 6
C
A
B

Step 5 Once the structure is built up, tighten all bolts
with the Allen key F.
F x 1
F
F

Step 6 Place the completed piece of furniture the right
way up in its desired location.
Adjust the foot stoppers to make all legs sit firmly
on the ground.

Step 7 Enjoy your new Caledonia Rattan 2 Drawer
Console Table!
