BROSA Voss Dining Table User manual

ASSEMBLY GUIDE
Voss Dining Table
v1.0

Components
Hardware
A x 8
Spec: M8 x 16
B x 6
Spec: M8 x 35
C x 8
Spec: M5 x 20
D x 8
Spec: M8
E x 8
Spec: M8
F x 4
Spec: Ø20 x 20
Upon unpacking your table from it’s delivery box, you should have the
separate pieces shown below. Folow the steps on the pages to assemble your
new dining table.
Rafter x 1
What you need
Table top x 1Leg x 2

Step 1
B x 6
C x 8
F x 4
F
B
Step 1.2
Step 1.1
Step 1.3
1.1 Align a leg (1) to rafter (2) so that its bolt slots are
facing corresponding slots in rafter (2). Fit a bolt (B)
from the outer side of the rafter and turn it with the
allen key until it is tightened and secured. Repeat for
the other legs (1).
1.2 Fit a screw (C) from the inner side of the rafter (2)
and turn it with the screwdriver until it is tightened
and secured. Repeat for the other legs (1).
1.3 Insert trim caps (F) in bottom of each leg.

Step 2
Step 3
A x 8
D x 8
E x 8
D
E
A
Place table upright on a level surface. Enjoy your
new dining table!
Align table top (3) above the construction formed in
Step 1. Fit a spring washer (E) and a at washer (D)
to a bolt (A). On the underside of the table, tighten
the bolt (A) with the allen key into corresponding
hole until it is secure. Repeat for all other holes.
