BROSA Field Entertainment Unit User manual

ASSEMBLY GUIDE
Field Entertainment Unit
v1.0

Components
A x 12
(Bolt)
B x 1
(Allen key)
Hardware
What you need
Left Leg x 1
Right Leg x 1
Body x 1
Glass Shelf x 1
Before you get started, check you have all of the pieces below. If anything’s
missing, please visit www.brosa.com.au/pages/product-return-and-parts-request
and we’ll sort it out right away.
C x 8
(Shelf Support)
D x 4
(Glass Shelf
Support)
5
4
1
2
3

Step 1 Align the legs (4, 5) to the underside of the body (1)
so that the holes are overlaping. Secure them with
bolts (A) using an allen key (B). With a help of the
partner lift the storage and place on it’s legs on a
level surface.
A x 12
B x 1
5
B
A
4
1

Step 2
C x 8
Step 2.1
Step 2.1
Step 2.2
Step 2.3
Step 2.3
1.1 Insert a pair of shelf supports (C) into the side
holes in the compartment and another pair in facing
holes on the same level.
1.2 Tilt the shelf (3) so it ts into the opening. Insert
the shelf .
1.3 Lower the shelf until it rests securely on all four
supports.
С
С
С
С
3
1
3
Step 2.2

Step 3.1
Step 3.2
Step 3.3
Step 3
D x 4
1.1 Insert a pair of glass shelf supports (D) into the
side holes in the compartment and another pair in
facing holes on the same level.
1.2 Insert the glass shelf (3) so it ts into the
opening.
1.3 Lower the shelf until it rests securely on all four
supports.
D
D
3

Step 4 hinges if needed.

Step 5 Enjoy your new storage!
