Burg Intro.Code User manual

www.burg.de
Intro.Code
Operating Manual

Intro.Code | 06-2023 Rev. 04 | English | 2
The electronic code lock Intro.Code is the entry into a new
dimension of digital security for steel and wooden furniture.
With its simple operation by numerical code, the lock makes
everyday life easier and impresses with its high-quality materials.
Especially the solid metal knob convinces with its noble matt
chrome surface. The lock adapts to any installation situation,
thanks to common mounting holes and replaceable cam.
Important: Please observe all warnings and read through
the entire operating instructions before you begin with
the configuration.
Indroduction
Intro.Code
Introduction 2
General 2
Technical data 3
Scope of delivery 3
Optional accessories 3
Default settings 3
Features 3
Product dimensions 3
Functional description 4
Configuration 4 - 5
Operation 5
Emergency power supply 6
Battery replacement 6
Reset to default settings 6
Declaration of Conformity and FCC Compliance 6
Disposal and battery note 6
Content
D
E
F
I
H
+-
G
12
34
A
C
B
ALED Bnumber key
Cconfirmation key Dreset hole
Estator Fbattery compartment
Gbattery Hmicro USB port
Iclosure hole
The latest version of this guide is available at:
www.burg.de
General
Scan here for instruction video:

Intro.Code | 06-2023 Rev. 04 | English | 3
Dimension Ø 43,3 mm
Battery VARTA1CR2450 (1x)
Locking cycles13,000
Working temperature -20° C to 55° C
rel. humidity: 10% - 85%
Mode Multi-user mode,
Private mode
Material Housing: Zamak
Front cap: plastic
Cam: steel
Mounting dimension 16 mm x 19 mm
Lock attachment M19 nut (1x)
Locking direction Left (90°), door hinge: DIN right
Right (90°), door hinge: DIN left
Cam type B
Max. door thickness 18 mm
Code length 4 to 15 digits
User code (default) 1234
Master code (default) 4321
No. of master codes max. 1
No. of user codes max. 1
Data Sheet
Technical Data
Front view Back view
Product Dimensions
Scope of Delivery
ergonomic handling and high-quality design
external battery change
easy to retrofit, e.g. for replacement of mechanical cam locks
latch adjustable in 45° steps
emergency power supply via micro USB port
Features
1x locking system
1x cam fixing screw2M4 x 8 mm
1x washer 12 mm (DIN 9021 M4)
1x M19 nut
cam type B
for single packaging:
1x length 53 mm, without crank (1-36 RIH-501 G)
1x length 40 mm, crank 3 mm (1-36 RIH-514 K)
1x length 40 mm, cranking 6 mm (1-36 RIH-515 K)
for industry packaging: order related
Optional Accessories
opening and reset pin
anti-twist protection (W-MSZ-01)
23,3 mm25,6 mm
4,5 mm
19 mm
43,3 mm
38 mm
16 mm
Side view
Top view
Mode Multi-user mode3
Fake code function Off
Default Settings
3 Applies from versions EIRR-007 to EIRR-010. Private Mode applies to earlier versions.
1 The lock is approved for VARTA brand batteries. The use of other batteries
may result in a reduced number of possible locking cycles.
2 The use of a screw with a different length may cause damage to the lock.

Intro.Code | 06-2023 Rev. 04 | English | 4
1Change the Mode
a) Multi-user mode (default)
1. Enter master code and press . A longer beep and
the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Press again. Enter the numbers 4and 4.
4. Confirm with . A longer beep confirms the successful
process.
Note: Changing the mode does not reset the lock
to the default setting.
b) Private Mode
1. Enter master code and press . A longer beep and
the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Press again. Enter the numbers 4and 3.
4. Confirm with . A longer beep confirms the successful
process.
Note: Changing the mode does not reset the lock
to the default setting.
2Set the Master Code and User Code
a) Master code
1. Enter current master code and press . A longer beep
and the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Enter new master code and confirm with . A longer
beep and the green LED confirm the successful process.
Note: User code and master code must not be the same.
Only one master code can be stored. During the storage
process, the old master code is overwritten.
Mode: Fixed Assigned Authorization (private mode)
In this mode, a user code is preset with which the lock can
be operated. The lock unlocks when the stored user code is
entered. A code that has not been saved is rejected by the lock.
This mode is suitable for user groups where the user rights are
not to change permanently, e.g. for an office cabinet.
Mode: Multi-User Authorization (multi-user mode)
In this mode, user codes are only valid for a single locking ope-
ration. The lock locks when a user code is entered and unlocks
when the same code is entered. When unlocking, this code is
deleted from the lock so that a new user code can be used. The
lock remains in the open state until a new user code is used for
locking. This mode is suitable for changing user groups whe-
re the locker is only used temporarily or once, e.g. in a sports
facility.
Master code
The master code authorizes the programming of the lock. In
addition, the master code can unlock the lock independently
of the set mode (emergency opening). In multi-user mode,
the code used for locking is deleted after the master code is
entered.
Note: We recommend programming a private master code befo-
re putting the lock into operation.
LED Locking Indication
If the lock is in the locked state, the green LED flashes briefly
every three seconds.
Battery Warning
If the battery voltage falls below a certain level, the LED lights
up briefly when the code is entered. If the voltage falls into the
critical range, the lock can no longer be operated.
Block Mode
If an incorrect code is entered four times in succession, the lock
locks for 60 seconds. During this time, the lock rejects any code
entry.
Fake Code Function
To prevent the user code from being read when it is entered,
the fake code function can be activated. In this case, a non-va-
lid code (fake code) is entered before or after the correct code is
entered. This code may have a maximum of 15 digits.
Functional Description Configuration

Intro.Code | 06-2023 Rev. 04 | English | 5
b) Lock
The lock locks automatically within 4 seconds. The red LED
flashes briefly. To close, turn the knob back to the starting
position until it engages.
2Mutli User Mode
a) Lock
1. Close the door and turn the knob back to its original
position.
2. Press . The green LED starts flashing.
3. Enter user code and press . A longer beep and
the red LED confirm the successful process.
b) Unlock
1. Enter user code and press . A longer beep and
the green LED confirm the successful process.
2. Turn the knop to the open position within 3 seconds.
Note: The lock signals an incorrect code entry with three
consecutive beeps.
3Unlock via Master Code
1. Enter master code and press . A longer beep and
the green LED confirm the successful process.
Multi-user mode: the active user code is deleted.
Private mode: the active user code is reset to factory
setting ( 1-2-3-4).
Note: The lock signals an incorrect master code entry
with three consecutive beeps.
Operation
b) User Code (Private Mode)
1. Enter current user code and press . A longer beep
and the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Enter new user code and confirm with . A longer beep
and the green LED confirm the successful process.
Note: User code and master code must not be the same.
Only one master code can be stored. During the storage
process, the old master code is overwritten.
c) Reset User Code
To reset the user code, the master code is entered.
When the master code is entered, the lock unlocks.
Multi-user mode: the active user code is deleted.
Private mode: the active user code is reset to factory
setting ( 1-2-3-4).
3Activate / Deactivate Fake Code Function
1. Enter master code and press . A longer beep and
the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Press again.
To activate, enter the numbers 4and 2.
To deactivate, enter the numbers 4and 1.
4. Confirm with . A longer beep confirms the successful
process.
1Private Mode
a) Unlock
1. Enter user code and press . A longer beep and
the green LED confirm the successful process.
2. Turn the knop to the open position within 3 seconds.
Note: The lock signals an incorrect code entry with three
consecutive beeps.

Intro.Code | 06-2023 Rev. 04 | English | 6
Disposal and Battery Note
Image rights: cover, wood texture, Maksym Chornii / 123rf
Battery Replacement
2. Remove the battery compartment and replace the battery
according to the symbols ( + / - ) (Fig. p. 2).
Note: The surface of the battery must be free of residues and
fingerprints, otherwise malfunctions may occur. If the surface
is dirty, it must be cleaned with a dry cloth.
1. Press the reset pin into the closure hole on the side of the
lock. Turn the housing slightly to the left and pull it forward.
Reset to Default Settings
To reset the lock, press the reset pin briefly into the reset hole on
the back. All stored data will be deleted from the lock.
Important: The reset hole can only be operated in the
disassembled state.
EU Directive 2012/19/EU regulates the proper take-back, treat-
ment and recycling of used electronic equipment.
Every consumer is required by law to dispose of batteries,
accumulators or electrical and electronic equipment („waste
equipment“) powered by batteries or accumulators separate-
ly from household waste, as they contain harmful substances
and valuable resources. Disposal can be done at a collection or
take-back point approved for this purpose, e.g. a local recycling
center. Waste equipment, batteries or rechargeable batteries are
accepted there free of charge and recycled in an environmentally
friendly and resource-saving manner.
Waste equipment, used batteries or rechargeable batteries can
also be returned to us. The return must be sufficiently stamped to
the address below.
The following symbol on the waste electrical equipment, batte-
ries or accumulators indicates that they must not be disposed of
with household waste:
Caution when using batteries!
The battery may explode or release flammable gases if it is mis-
handled, destroyed, or the wrong type of battery is used. Do not
recharge the battery, disassemble it, expose it to extremely high
temperatures or throw it into a fire.
On batteries containing harmful substances, you will find indica-
tions in the form of abbreviations for the ingredients cadmium
(Cd), mercury (Hg) and lead (Pb) in each case.
BURG Lüling GmbH & Co. KG
Volmarsteiner Str. 52
58089 Hagen (Germany)
[phone]
[e-mail]
www.burg.de
If the battery voltage is insufficient, the locking system can be
connected to an external power supply (e.g. power supply unit,
notebook or power bank) via the micro-USB connection using
a micro-USB cable. The locking system can then be operated
normally.
Note: We recommend to replace the batteries at the first battery
warning.
Emergency Power Supply
3. Replace the battery compartment, slide the housing back
onto the lock and turn until it clicks into place.
Note: The lock is approved for VARTA brand batteries. The
use of other batteries may result in a reduced number of
possible locking cycles.
Declaration of Conformity and FCC Compliance
Scan here for Declaration of Conformity and FCC Compliance:
