Intro.Code
Operating Manual

Intro.Code | 12-2022 Rev. 03 | English | 2
The Intro.Code is the electronic combination code lock for con-
venient and secure locking of cabinets and valuables compart-
ments.
It can be conveniently used in both wooden and steel furniture.
Thanks to its simple operation, the lock makes everyday life ea-
sier and shines with its high-quality design and ergonomic hand-
ling. Thanks to the easy retrofitting and the flexibly adjustable
bolt, the lock easily adapts to any installation situation.
Important: Please observe all warnings and read through
the entire operating instructions before you begin with
the configuration.
Introduction
The latest version of this guide is available at:
www.burg.de
General
Intro.Code
Introduction 2
General 2
Technical data 3
Scope of delivery 3
Optional accessories 3
Default settings 3
Features 3
Product dimensions 3
Functional description 4
Configuration 4 - 5
Operation 5
Emergency power supply 6
Battery replacement 6
Reset to default settings 6
Disposal and battery note 6
Content
D
E
F
I
H
+-
G
12
34
A
C
B
ALED Bnumber key
Cconfirmation key Dreset hole
Estator Fbattery compartment
Gbattery Hmicro USB port
Iclosure hole
Scan the QR code to get to the instruction video:

Intro.Code | 12-2022 Rev. 03 | English | 3
Dimension Ø 43,3 mm
Battery VARTA1CR2450 (1x)
Locking cycles13,000
Working temperature -20° C to 55° C
rel. humidity: 10% - 85%
Mode Multi User Mode,
Private Mode
Material Housing: Zamak
Front cap: plastic
Cam: steel
Mounting dimension 16 mm x 19 mm
Lock attachment M19 nut (1x)
Locking direction Left (90°), door hinge: DIN right
Cam type B
Max. door thickness 18 mm
Code length 4 to 15 digits
User code (default) 1234
Master Code (default) 4321
No. of Master Codes max. 1
No. of user codes max. 1
Factsheet
Technical Data
Front view Back view
Product Dimensions
Scope of Delivery
ergonomic handling and high-quality design
external battery change
easy to retrofit, e.g. for replacement of mechanical cam locks
latch adjustable in 45° steps
emergency power supply via micro USB port
Features
1x locking system
1x cam fixing screw2M4 x 8 mm
1x washer 12 mm (DIN 9021 M4)
1x M19 nut
cam type B
for single packaging:
1x length 53 mm, without crank (1-36 RIH-501 G)
1x length 40 mm, crank 3 mm (1-36 RIH-514 K)
1x length 40 mm, cranking 6 mm (1-36 RIH-515 K)
for industry packaging: order related
Optional Accessories
opening and reset pin
anti-twist protection (W-MSZ-01)
23,3 mm25,6 mm
4,5 mm
19 mm
43,3 mm
38 mm
16 mm
Side view
Top view
1 The lock is approved for VARTA brand batteries. The use of other batteries
may result in a reduced number of possible locking cycles.
2 The use of a screw with a different length may cause damage to the lock.
Mode Private Mode
Fake code function Off
Default Settings

Intro.Code | 12-2022 Rev. 03 | English | 4
b) Private Mode (default)
1. Enter Master Code and press . A longer beep and
the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Press again. Enter the numbers 4and 3.
4. Confirm with . A longer beep confirms the successful
process.
Note: Changing the mode does not reset the lock
to the default setting.
2Set the Master Code and Code
a) Master Code (Private Mode / Multi User Mode)
1. Enter current Master Code and press . A longer beep
and the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Enter new Master Code and confirm with . A longer
beep and the green LED confirm the successful process.
b) User Code (Private Mode)
1. Enter current user code and press . A longer beep
and the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Enter new user code and confirm with . A longer
beep and the green LED confirm the successful process.
Note: User code and Master Code must not be the same.
Only one user code / Master Code can be stored. During
the storage process, the old user code or Master Code is
overwritten.
c) Reset User Code (Private Mode / Multi User Mode)
To reset the user code, enter the Master Code. Entering the
Master Code also unlocks the lock.
Multi User Mode
The active user code is deleted.
Private Mode
The active user code is reset to the default setting (1234).
Mode: Fixed Assigned Authorization (Private Mode)
In this mode, a user code is pre-set with which the lock can
be operated. This mode is suitable for user groups where user
rights do not have to change permanently, e.g. in an office
cabinet. The lock is unlocked by entering a stored user code. A
non-stored code is rejected by the lock. To unlock, the stored
user code is entered. To lock, the knob is turned back (counter-
clockwise) until the cam engages.
Mode: Multi User Authorization (Multi User Mode)
This mode is suitable for changing user groups who only use the
compartment temporarily or once, e.g. in a sports facility. User
codes are valid for a single locking process and are deleted by
the lock when the compartment is reopened so that a new user
code can be used. The locking bolt remains open until a new
user code locks the lock again. To lock, the hook key is pressed
and a code of choice is entered. The entry is confirmed with the
hook key. The green LED starts flashing. The lock is opened by
entering the same code.
LED Locking Indication
When the lock is locked, the green LED flashes briefly every
three seconds.
Battery Warning
If the battery voltage falls below a certain level, the LED lights
up briefly when the PIN is entered. If the voltage falls into the
critical range, the lock can no longer be operated.
Block Mode
If the code is entered incorrectly four times in succession, the
lock blocks for 60 seconds. During this time, the lock rejects any
code entry.
Fake Code Function
To prevent the code from being copied, a fake code is entered
before or after the code entry (maximum 15 digits). This func-
tion can be set as an option.
Functional Description
Configuration
1Change the Mode
a) Multi User Mode
1. Enter Master Code and press . A longer beep and
the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Press again. Enter the numbers 4and 4.
4. Confirm with . A longer beep confirm the successful
process.

Intro.Code | 12-2022 Rev. 03 | English | 5
3Unlock via Master Code
1. Enter Master Code and press . A longer beep and
the green LED confirm the successful process.
Note: The lock signals an incorrect Master Code entry with
three consecutive beeps. Unlocking by Master Code resets
the code to the factory setting (1234) in Private Mode. In
Multi User Mode, the code used for locking is deleted.
1Private Mode
a) Unlock
1. Enter user code and press . A longer beep and
the green LED confirm the successful process.
2. Turn the knob to the right (clockwise)
within 3 seconds.
Note: The lock signals an incorrect code entry with three
consecutive beeps.
b) Lock
The lock locks automatically within 4 seconds. The red LED
flashes briefly. To close, turn the knob to the left (counter-
clockwise).
2Mutli User Mode
a) Lock
1. Press . The green LED starts flashing.
2. Enter user code and confirm with . A beep and
the red LED confirm the successful process.
3. To lock, turn the knob to the left (counterclockwise).
b) Unlock
1. Enter user code and press . A longer beep and
the green LED confirm the successful process.
2. Turn the knob to the right (clockwise)
within 3 seconds.
Note: The lock signals an incorrect code entry with three
consecutive beeps.
3Activate / Deactivate Fake-Code Function
1. Enter Master Code and press . A longer beep and
the green LED confirm the successful process.
2. Directly press and hold the button for 2 seconds.
The green LED starts flashing.
3. Press again.
To activate enter numbers 4and 2.
To deactivate enter numbers 4and 1.
4. Confirm with . A longer beep confirm the successful
process.
Operation

Intro.Code | 12-2022 Rev. 03 | English | 6
Entsorgungs- und Batteriehinweis
Image rights: cover, wooden structure, Maksym Chornii / 123rf
Battery Replacement
It is recommended to change the battery as soon as the lock
indicates a low battery level.
Note: The lock is approved for VARTA brand batteries. The use
of other batteries may result in a reduced number of possible
locking cycles.
2. Remove the battery compartment as shown in the illustration
and replace the battery. Insert the new battery according to
the symbols ( + / - ) (see page 2).
Note: The surface of the battery must be free of residues and
fingerprints, otherwise malfunctions may occur. If the surface
is dirty, it must be cleaned with a dry cloth.
1. Press the reset pin into the closure hole on the side of the
lock as shown in the illustration. Turn the housing slightly to
the left and pull it forward.
3. Carefully push the housing back onto the lock and turn it
slightly until it snaps into place.
Reset to Default Settings
To reset the lock, press the reset pin briefly into the reset hole on
the back. All stored data will be deleted from the lock.
Important: The reset hole can only be operated in the
disassembled state.
Emergency Power Supply
If the batteries do not have enough voltage, an external power
supply can be connected via the micro USB port.
For this, the touchpad has to be connected to a power supply,
notebook or power bank via micro USB cable. The lock can then
be operated again.
Note: We recommend to replace the batteries immediately.
EU Directive 2012/19/EU regulates the proper take-back, treat-
ment and recycling of used electronic equipment.
Every consumer is required by law to dispose of batteries,
accumulators or electrical and electronic equipment („waste
equipment“) powered by batteries or accumulators separate-
ly from household waste, as they contain harmful substances
and valuable resources. Disposal can be done at a collection or
take-back point approved for this purpose, e.g. a local recycling
center. Waste equipment, batteries or rechargeable batteries are
accepted there free of charge and recycled in an environmentally
friendly and resource-saving manner.
Waste equipment, used batteries or rechargeable batteries can
also be returned to us. The return must be sufficiently stamped to
the address below.
The following symbol on the waste electrical equipment, batte-
ries or accumulators indicates that they must not be disposed of
with household waste:
Caution when using batteries!
The battery may explode or release flammable gases if it is mis-
handled, destroyed, or the wrong type of battery is used. Do not
recharge the battery, disassemble it, expose it to extremely high
temperatures or throw it into a fire.
On batteries containing harmful substances, you will find indica-
tions in the form of abbreviations for the ingredients cadmium
(Cd), mercury (Hg) and lead (Pb) in each case.
BURG F.W. Lüling KG
Volmarsteiner Str. 52
58089 Hagen (Germany)
[phone]
[e-mail]
www.burg.de
