Circontrol Wallbox eNext Series User manual

Installation Manual
Wallbox
eNext Series

Wallbox eNext Series Installation Manual

Wallbox eNext Series
Installation Manual
COPYRIGHT INFORMATION
This document is copyrighted, 2019 by Circontrol, S.A. All rights are reserved.
Circontrol, S.A. reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual can be reproduced, copied, translated or transmitted in
any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate
and reliable. However, the original manufacturer assumes no responsibility
for its use, or for any infringements upon the rights of third parties at hat may
result from its use.
All other product names or trademarks are properties of their respective
owners.

Wallbox eNext Series Installation Manual

01
1 — So, hello!
2 — Before
installation
3 — Overview
4 — Dimensions
5 — Installation
6 — Technical Data
7 — Need Help?
Here’s your guide
to install eNext.
02
04
08
10
12
24
26

02
Wallbox eNext Series Installation Manual
1

03
This manual provides commissioning information about Wallbox eNext,
which has been designed and tested to allow electric vehicle charging,
specified in IEC 61851.
This document has different sections such as step-by-step installation
procedure and technical data.
ELECTRICAL RISK
Necessary precautions shall be taken to prevent any electrical
risk while the operations are carried out within the unit.
Unit must be disconnected from any power source during
commissioning.
ATTENTION!
Indicates that damage to property can occur if appropriate
precautions are not taken.
So, hello!
THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT
SAFETY INFORMATION IN THIS DOCUMENT
• Complies with IEC 61851, Electric vehicle conductive
charging system (IEC 61851-1:2017).
• Complies with IEC 62196, Plugs, socket-outlets, vehicle
couplers and vehicle inlets (IEC 62196-1 and IEC 62196-2).
• Standards: 2014/35/UE, LVD;2014/30/UE, EMC.

04
Wallbox eNext Series Installation Manual
• Avoid contact with energized
electrical circuits.
• Disconnect the power source before
servicing or repairing electrical
equipment. The only way to be sure.
• Use only tools and equipment with
non-conducting handles when
working on electrical devices.
Easier to check.
• Never use metallic pencils or
rulers, or wear rings or metal
watchbands when working with
electrical equipment. This rule is
very easy to forget, especially when
you are showing some electrical
part pointing with metallic pencil.
• Enclose all electric contacts and
conductors so that no one can
accidentally come into contact.
• When it is necessary to handle
equipment that is plugged in, be
sure hands are dry and, when
possible, wear nonconductive
gloves, protective clothes and
shoes with insulated soles.
• If it is safe to do so, work with only
one hand, keeping the other hand
at your side or in your pocket, away
from all conductive material. This
precaution reduces the likelihood
of accidents that result in current
passing through the chest cavity.
• Never handle electrical equipment
when hands, feet, or body are wet
or perspiring, or when standing on
a wet floor.
IMPORTANT ELECTRICAL SAFETY INSTRUCTIONS
Read carefully all the instructions before starting in
order to ensure properly handling of electrical parts.
2
A safe work environment is not enough to control all potential electrical hazards. It is
recommended to be very cautious and work safely. So, the safety rules shown below
could help to control risks of injury or death from workplace hazards.

05
• Charge Point must not be installed
in areas where potential risk of
explosions are.
• Do not install the Charge Point
where falling objects may damage
the equipment.
• The surface where the Charge
Point is placed must withstand the
mechanical forces.
• This unit is no shall be used for
anything other purpose than
electric vehicle charging modes as
are expected in IEC 61851.
• Do not modify this unit. If
modified, Circontrol will reject all
responsibility and the warranty will
be void.
• Comply strictly with electrical
safety regulations according to your
country.
• Do not use any adapter, except those
approved by the EV manufacturer.
• Do not perform any repair o
manipulation of the unit while it is
energized.
• Only trained and qualified personnel
should be able to access to low-
voltage electrical parts inside the
unit.
• Check the installation annually by
qualified technician.
• Remove from service any item
which have a fault that could be
dangerous for users (broken plugs,
caps that don’t close...).
• Use only Circontrol supplied spare
parts.
• Do not use this product if the
enclosure or the EV connector is
broken, cracked, open, or shows
any other indication of damage.
IMPORTANT CHARGE POINT SAFETY INSTRUCTIONS
Read carefully all the instructions before starting in order
to ensure properly installation of the Charge Point.
Before installation
Refer to chapter "6 - TECHNICAL DATA" for more information about environmental
installation conditions.
The Charge Point is designed for installation in indoor and outdoor areas. For each of
the different conditions of installation, the unit must be installed safely and assuring the
adequate protections.

06
Wallbox eNext Series Installation Manual
ELECTRICAL WIRING CONSIDERATIONS
Take into consideration this section before starting
wiring connections of the Charge Point.
1 — ELECTRICAL PROTECTIONS
Charge Point may not include elements of electrical protection.
If this equipment has internal electrical protections, are installed in each socket-
outlet for the protection of the user against an electrical failure, according to the
international standard IEC 61851-1:2017.
In order to guarantee the total protection of the users and the installation (power
supply line included) in front of any electrical hazard, install a main circuit breaker
(MCB) and a residual current device (RCD) upstream of the Charge Point is mandatory.
These electrical protections and the rest of the installation have to be aligned with
the local and national rules. The selectivity of the protections has to be guaranteed
at all times.
2 — POWER SUPPLY LINE DIMENSIONING
The dimensioning of the input power supply line of the Charge Point must be checked
by a qualified electrician. Note that several factors such as cable length between
distribution board and Charge Point, maximum output current of the Charge Point
may influence the criteria of cable selection.
In such cases, increasing the cable cross-section is required to adapt the temperature
resistance of the power supply line.
3 — MAXIMUM OUTPUT CURRENT
Please refer to chapter "6 - TECHNICAL DATA" to consult the default factory settings
from maximum output current of the Charge Point.
If the power supply is lower than maximum output current, it is necessary to adjust the
nominal current. To perform this adjustment, please refer to the INSTRUCTION MANUAL.
This value may vary depending on the model.

07

08
Wallbox eNext Series Installation Manual
3
What’s included:
Charge Point Installation
Manual
2.5 mm
Allen wrench Identification
label

09
Overview
1 — Beacon lights
2 — Cable glands
3 — Plugs*
4 — Wall support holes
5 — Closing box holes
(*) Plugs may vary depending on the model
1
2
3
52
4
4
4
5

10
Wallbox eNext Series Installation Manual
4
Dimensions in mm
39
335 315
200
335

11
*This measurement may vary
Dimensions
168
52,5 105
230
52,562,5
34 34
62,5
20*
39,5
255
20,5

12
Wallbox eNext Series Installation Manual
5
Material:
Tap drill 6/8M
Tools:
• Allen wrench of 2,5 mm is included in the installation kit.
• Screws, sealing washers and plastic anchors are not included.
• The fastening system of the Charge Point has been designed to be
installed on a wall.
»This system has been tested on a concrete wall, to be securely
fixed in such conditions is recommended to use:
3 x Inox A2 wall screws: DIN 7982 Ø4,8x3
3 x plastic anchors: 6x40 or 8x40
»If the wall surface has different properties, the screws and plastic
anchors must be defined by a qualified installer.
Screw driver DrillerRatchet*
2.5mm Allen
(*) Ratchet tool can be used to open/close the Charge Point if required by the conditions of
installation.

13
Installation
ARequirements
• Please comply with your country regulations.
• The Charge Point shall be installed on a wall or on Circontrol accessories.
• When installing the unit, some space shall be reserved for usability, maintenance
and safety reasons. The picture below shows the recommended minimum
distances:
Dimensions in mm
300
1100
300
300
If the recommendations are not followed as described,
Circontrol will reject all responsibility and the warranty
will be void.

14
Wallbox eNext Series Installation Manual
BOpening
Open the Wallbox using an Allen wrench.
2.5mm Allen wrench
Use the ratchet tool to open / close
in conditions that hinder access

15
CPositioning
Drill the wall.
Drill bit M 6/8
Dimensions in mm
1100
255
230
115

16
Wallbox eNext Series Installation Manual
DFixing
Place the unit on the previous pierced points and fix it with screws.
