INSTALLATION INSTRUCTIONS
C-TR-A-FP LED Flat Panel
E.LITE
LED LIGHTING BY CREE
A "or,o*,
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety
precautions should always be followed including the
following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before
installation.
DANGER - Risque de choc - Couper l'alimentation
avant l'installation.
2. Caution - Risk of Fire.
Attention - Risque D'incendie
3. This luminaire must be installed in accordance with the
nec or your local electrical code. lf you are not familiar
with these codes and requirements, consult a qualified
electrician.
Ce produit doit ete instail4 conformdment A nec ou votre
code 4lectrique local. Si vous n'€tes pas familier avec ces
codes et ces exigences, veuillez contacter un 6lectricien
qualifi6.
4. Suitable for damp locations.
Convient aux emplacements humides.
5. Min 90"C supply conductors.
Les fils d'alimentation 90"C min.
6. lnherentlyprotected.
Protection inherente.
7. Type lC. Vapor barrier must be suitable lor 90"C.
Type lC. Le pare-vapeur doit convenir pour 90"C.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE
INSTALLATION
1. Locate desired fixture location in ceiling grid.
2. Remove existing ceiling panel at chosen location. Remove
adjacent ceiling panel to allow for wiring access from above.
3. Place fixture into T-bar ceiling grid. Bend clips on top of fixture up
and rotate out to engage with T-bar support grid. See Figure 1.
Secure fixture to grid in compliance with state and local codes.
4, Remove screw on driver wiring chamber and remove cover. Set
screw and cover aside to be reinstalled later.
5. Remove appropriate 1/2" knockout(s) to allow lor entry of supply
wiring into wiring chamber.
6. Make wiring connections per the Fixture Wiring seclion.
NOTE:
. Terminal blocks in driver wiring chamber will accommodate
14-20 AWG solid or stranded leads.
. For dimming connections (if used) use Class 1 wiring
methods only.
7. Reattach cover of wiring chamber with screw that was removed in
Step 4 above.
8. Replace adjacent ceiling panel removed in Step 2.
FIXTURE WIRING
Fixture is equipped with universal volt driver 12O-277V
(ie. 120V, 208V, 240V or 277Y)
PHASE TO NEUTRAL WIRING 1201277V
1. Connect supply ground to fixture ground (green) lead.
2. Connect supply common to fixture neutral (white) lead.
3. Connect supply Vin to fixture hot (black) lead.
Tuck all wires carefully into wiring chamber ensuring that no
wires are pinched.
PHASE TO PHASE WIRING 2O8I24OV
'l . Connect supply ground to fixture ground (green) lead.
2. Connect supply L1 (Hot) to fixture neutral (white) lead.
3. Connect supply L2 (Hot) to fixture hot (black) lead.
Tuck all wires carefully into wiring chamber ensuring that no
wires are pinched.
DIMMING
1. Grey and violet leads are for 0-'l0V dimming systems.
Cap off if not used.
2x21x4
FIGURE 1
