Degelman PRO-TILL 41 User manual

AConnect Hydraulics WHEELS
ROLLERS
TRANSPORT
WINGS
JACK
3
5
4
2
1
5
4
1
3
2
FLOAT
(if available)
CONSTANT
PRESSURE
3
5
3
42222 4
1 111
* Refer to operators manual for complete safety and operation info.
Maintenance
(Check Machine Daily)
143412 v1.0
QUICK-START GUIDE*
for PRO-TILL 41/45
* Refer to operators manual for complete safety and operation info.
T
O
B
E
E
L
I
G
I
B
L
E
F
O
R
Y
O
U
M
U
S
T
R
E
G
I
S
T
E
R
WARRANTY
REMEMBER! You must complete Product
Registration to be eligible for Warranty.
GPS Reference
(Set overlap to 6”per side)
(with 20" discs) 2" Depth
Pro-Till 41 491” (12.47m)
Pro-Till 45 532” (13.51m)
(with 20” discs) MAX Depth
Pro-Till 41 493” (12.52m)
Pro-Till 45 534” (13.56m)
(Consider setting the GPS to include
a 6”implement oset to the right)
• Hydraulic Connections/Hoses
• Working points & pins
• Hubs, Spindles, & Tire Pressure:
- Center: 58 PSI (400 kPa)
- End Wheels: 58 PSI (400 kPa)
• Check for missing, worn or
damaged parts.
*Refer to operators manual for
complete safety and operation info.
IMPORTANT: The Wing Cylinder Circuit includes a Down Pressure
Valve. Operator must engage wing circuit hydraulics constantly
in the extended direction to ensure constant down pressure.

BPut in Field Position
i)
ii)
iii)
1”
3
4
4
FMAX Transport Speed: 40 km/h (25 MPH)
ELower Wheels for Headland Turns.
1
PRO-TILL 41/45
Scraper Position Overview (Rubber Rollers)
Set Gap
distance at
1/4” to 3/8”
from roller surface.
Storage Position
Maintenance
Position
Engaged Position
Remove the 4 bolts to rotate into
or out of “Storage position”,
then re-install.
Loosen the 4 bolts to rotate up into
“Maintenance
Position”
& secure.
Loosen the 4
bolts to rotate
downward.
Set the scraper
clearance
(1/4” to 3/8”).
Properly tighten.
DTest. Check. Adjust. 10-12 MPH
100m100m
(Ideal Operating Speed)
CSet Cutting Depth
(Start with 12 stops
per cylinder, test
depth & adjust)
(IMPORTANT: Add depth
stops starting from rod end)
IMPORTANT: Re-phase and cycle oil in the Depth Control
Cylinders before use. This is especially important
after long periods of storage.
1 2
3
iv)
v)
3
3 3
3
IMPORTANT: Operator must read and understand the
tractor manual in order to place the required hydraulic
circuits into oat position or constant pressure position.
4
IMPORTANT: The Pro-Till
model shown may dier,
but the general procedure
remains the same.
(*Pro-Till 40 shown)
Rear Disc Depth Adjustment
(2 Outer Roller Frame Cylinders)
Front Disc Depth Adjustment
(2 End Wheel Cylinders)
1 2
Typically
Set to 2”
