Dragino LG01v2 User manual

LG01v2 -- LoRa Gateway User Manual
last modified by Kilight Cao
on 2023/06/20 10:40

Table of Contents
1. Introduction .......................................................................................................................................................................... 4
1.1 What is LG01v2 ............................................................................................................................................................. 4
5.2.5 Plot data chart in LG01v2 .................................................................................................................................... 28
6. How users can access LG01v2 using serial USB ....................................................................................................... 30
7. OTA System Update ....................................................................................................................................................... 33
8. FAQ .................................................................................................................................................................................... 33
8.1How does LG01v2 communicate with Lora shield (LoRa.h) .................................................................................. 33
8.2 How does LG01v2 communicate with Heltec LoRa Node ..................................................................................... 36
8.3 How does LG01v2 communicate with LoRaWAN node ........................................................................................ 39
9. Trouble Shooting .............................................................................................................................................................. 43
9.1 Fallback IP does not work, how can users check ................................................................................................. 43
10. Supports .......................................................................................................................................................................... 44
12. Order Info ........................................................................................................................................................................ 45
13. Manufacturer Info ........................................................................................................................................................... 45
14. FCC Warning .................................................................................................................................................................. 45



Table of Contents：
•1. Introduction
•1.1 What is LG01v2
•1.2 Specifications
•1.3 Features
•1.4 Block Diagram
•1.5LED Indicators
•1.6 Button Intruction
•2. Quick Start
•2.1 Access and Configure LG01-v2
•2.1.1 Find IP address of LG01-v2
•Method 1: Connect via Ethernet with DHCP IP from the router
•Method 2: Connect via LG01v2 Fallback IP
•Method 3: Connect via WiFi with DHCP IP from the router
•2.1.2 Access Configure Web UI

•3. Web Configure Pages
•3.1 Home
•3.2 Network Settings
•3.2.1 Network --> WiFi
•3.4.2 Network --> System Status
•3.5 System
•3.5.1 System --> System Overview
•3.5.2System --> Backup/Restore
•3.5.3 System --> System General
•3.5.4 System --> Remoteit
•3.5.5 System --> Package Management
•4. Build in Server
•4.1 Application Server -- Node-Red
•5. How to configure the Lora Gateway
•5.1 Configure and Debug LoRa wireless of LG01v2
•5.2 Example: LG01v2
•5.2.1 Introduce for the example:
•5.2.2 Set Up LA66 Shield + UNO
•Set up LA66 Module
•Set up Arduino UNO
•1. Open Arduino IDE
•2. Open project
•3.Open the Serial Monitor to check the LA66 Shield data
•5.2.3 Set Up LG01v2
•5.2.4 Test result
•5.2.5 Plot data chart in LG01v2
•6. How users can access LG01v2 using serial USB
•7. OTA System Update
•8. FAQ
•8.1How does LG01v2 communicate with Lora shield (LoRa.h)
•8.2 How does LG01v2 communicate with Heltec LoRa Node
•8.3 How does LG01v2 communicate with LoRaWAN node
•9. Trouble Shooting
•9.1 Fallback IP does not work, how can users check
•10. Supports
•11. Reference
•12. Order Info
•13. Manufacturer Info
•14. FCC Warning
1. Introduction
1.1 What is LG01v2
The LG01v2 is anopen-source single channel LoRa Gateway. It lets you bridge LoRa wireless network to an
IP network via WiFi , Ethernet or Cellular Network (via Optional 4G module). The LoRa wireless allows users to
send data and reach extremely long ranges at low data rates.
LG01v2 is specially design for peer to peer LoRaprotocol instead of LoRaWAN protocol. The LG01v2 use
single channel LoRa module to minimize the deployment cost for a private p2p LoRa wireless network.
LG01v2 uses Open Source Linux system. User can modify the Linux part and develop customize software base on
it. It has 1.2Ghz Quad-Core CPU , 4GB eMMC storage and 512MB RAM for most application.
LG01v2 supports remote management. System Integrator can easy to remote monitor the gateway and
maintain it.

1.2 Specifications
Hardware System:
• CPU: Quad-core Cortex-A7 1.2Ghz
• RAM: 512MB
• eMMC: 4GB
Interface:
• 10M/100M RJ45 Ports x 1
• WiFi 802.11 b/g/n
Operating Condition:
• Work Temperature: -20 ~ 65°C
• Storage Temperature: -20 ~ 65°C
• Power Input: 5V, 2A, DC
1.3 Features
• Open Source Debian system
• Managed by Web GUI, SSH via WAN or WiFi
• Remote Management
• Auto-provisioning for batch deployment and management
• LoRa Gateway
• Built-in Node-Redlocal Application server
1.4 Block Diagram
1.5LED Indicators
LG01-V2 has totally four LEDs, They are:
# Power LED: This RED LED will be solid if the device is properly powered
# ETH LED: This RGB LED will blink GREEN when the ETH port is connecting
# SYS LED: This RGB LED will show different colors in different states:
# SOLID GREEN: The device is alive with a LoRaWAN server connection.
# BLINKING GREEN: a) Device has internet connection but no LoRaWAN Connection. or b) Device
is in booting stage, in this stage, it will BLINKING GREEN for several seconds and then with BLINKING GREEN
together
#SOLID RED: Device doesn't have an Internet connection.
# WIFI LED:This LED shows the WIFI interface connection status.
1.6 Button Intruction
LG01-V2 has a black toggle button, which is:
#Long press 4-5s :the gateway will reload the Network andInitialize wifi configuration
LED status: ETH LED will BLINKIND BULE Until the reload is finished.
# Long press more than 10s:the gateway will restore the factory settings.

LED status: ETH LED will SOLID BULE Until the restore is finished.
2. Quick Start
The LG01-V2 supports network access via Ethernet or Wi-Fi connection andruns without a network.
In most cases, the first thing you need to do is make the LG01-v2 accessible to the network.
2.1 Access and Configure LG01-v2
2.1.1 Find IP address of LG01-v2
Method 1: Connect via Ethernet with DHCP IP from the router
Connect the LG01-V2 Ethernet port to your router and LG01-V2 can obtain an IP address from your router. In the
router's management portal, you should be able to find what IP address the router has assigned to the LG01-V2.
You can also use this IP to connect.
Method 2: Connect via LG01v2 Fallback IP
Steps to connect via fallback IP:
1. Connect the PC's Ethernet port to LG01v2's WAN port

2. Configure PC's Ethernet port has IP: 172.31.255.253 and Netmask: 255.255.255.252
Settings --> Network & Internet --> Ethernet --> Change advanced sharing options -->Double-
click"Ethernet" --> Internet Protocol Version 4 (TCP/IPv4)
As in the below photo:
Configure computer Ethernet port steps video:fallback ip.mp4
If you still can't access the LG01v2 fallback ip, follow this connection to debug :Trouble Shooting
3. In the PC, use IP address 172.31.255.254 to access the LG01v2 via Web or Console.

Method 3: Connect via WiFi with DHCP IP from the router
Fill in the WiFi information by checking the box and clicking Save&Apply

Wi-Ficonfiguration successful
2.1.2 Access Configure Web UI
Web Interface
Open a browser on the PC and type the LG01v2 ip address (depends on your connect method)
http://IP_ADDRESS or http://172.31.255.254(Fallback IP)

You will see the login interface of LG01v2 as shown below.
The account details for Web Login are:
User Name: root
Password: dragino
3. Web Configure Pages
3.1 Home
Shows the system running status:

3.2 Network Settings
3.2.1 Network --> WiFi
3.4.2 Network --> System Status

3.5 System
3.5.1 System --> System Overview
Shows the system info:

3.5.2System --> Backup/Restore

3.5.3 System --> System General
In the System-> System General interface, Users can customize the configuration System Password and set
Timezone.
In addition, Users can customize the FallBack IP address.
3.5.4 System --> Remoteit
In the System-> Remoteit interface, users can configure the gateway to be accessed remotely via Remote.it.
the users can refer to this link to configure them:Monitor & Remote Access Gateway

3.5.5 System --> Package Management
In the System --> Package Management interface,Users can check the current version of Core Packages.

4. Build in Server
The default factory version of LG01-V2 is installed with the built-in Applicant server: Node-Red
Note:
Path: System --> Built-in Server
Troubleshooting：
1. URL does not jump properly
For the Node-Red, you can use the local IP address and the port is 1880 to access it.
4.1 Application Server -- Node-Red
You can access the gateway'sbuilt-in AS server ofNode-Redvia the URL(http://<hostname>:1880or http://
<local-IPV4-address>) in your browser.
Such ashttp://dragino-54ff12:1880 or http://<Local-IPV4-Address>

5. How to configure the Lora Gateway
5.1 Configure and Debug LoRa wireless of LG01v2
First, the user needs to access the Linux console of LG01v2 via ssh
IP address: IP address of LG01v2
Port: 22
User Name:root
Password: dragino(default)

Users can access the Lora configuration page by running the following command, then select the option ''serial
port setup":
root@dragino-2406ef:~# minicom -s
And then, change the setting:
Serial Device:/dev/ttyUSB0
Bps/Par/Bits:9600 8N1
Note: Enter the corresponding letter to change the configuration, like A,B,C

EnterAT+CFGin the interface to get the configuration,
AT+FRE=868.100,868.100 --->TX and RXfrequency
AT+GROUPMOD=0,0 ---> TX and RX group
AT+BW=0,0 ---> TX and RX Bandwidth
AT+SF=12,12 ---> TX and RX Spreading Factor
AT+POWER=14 ---> TXPower Range
AT+CRC=1,1 ---> TX and RX CRC Type
AT+HEADER=0,0 ---> TX and RX Header Type
AT+CR=1,1 ---> TX and RX Coding Rate
AT+IQ=0,0 ---> TX and RX InvertIQ
AT+PREAMBLE=8,8 ---> TX and RX Preamble Length
AT+SYNCWORD=0 ---> Syncword(0: private，1: public)
AT+RXMOD=65535,0 ---> Rx Timeout and Reply mode
AT+RXDAFORM=1
5.2 Example: LG01v2
5.2.1 Introduce for the example:
